Title: Demo: Exploiting the UCSC Genome Browser


1
Demo Exploiting the UCSC Genome Browser
  • Stefanie Butland
  • UBC Bioinformatics Centre
  • butland_at_bioinformatics.ubc.ca

2
UCSC Genome Gateway Structure
Custom tracks
Genome browser
Table browser
Your sequence
BLAT
Family browser
Downloadable files http//genome.ucsc.edu/download
s.html
3
http//genome.ucsc.edu/cgi-bin/hgGateway
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
Configure Tracks
8
Spliced ESTs
9
Genome Gateway Help/Users Guide
10
Worked Examples
  • Genome Browser
  • Glutaminyl-tRNA Synthetase (QARS) gene structure
    and sequence (see Demo 3.4 notes for guide)
  • BLAT of Factor VIII primers (see Demo 3.4 notes
    for guide )
  • Table Browser
  • Locations of simple repeats in QARS
  • Table Browser and Custom Tracks
  • Known genes on chromosome 4 that contain
    trinucleotide repeats

11
Table BrowserTabular output of simple repeats
in QARS
12
(No Transcript)
13
(No Transcript)
14
Tabular output of simple repeats in QARS
15
Custom Tracks generated by the Table Browser
  • Research Question Which known genes in the first
    25 Mb of chromosome 4 contain trinucleotide
    repeats?
  • An answer to this question can be found in the
    intersection of the Known Genes table with the
    Simple Repeats table (limited to repeat period
    3) in the region chr41-25,000,000

16
  • Go to the Table Browser and choose the Human
    assembly from July 2003

17
  • Choose Browser Tracks - Known Genes, and click
    Describe table for info on Known Genes content

18
  • for Position, enter chr41-25000000 and click
    Advanced query
  • under Select Output Format for knownGene, choose
    Custom Track and scroll down the page

19
  • under (Optional) Intersect Results with Another
    Table, choose Browser Tracks Simple Repeats,
    and click Intersect Results

20
  • under (Optional) Filter simpleRepeat Records by
    Field Values, select period is 3 and click
    Custom Track...

21
  • click Get Custom Track File to view the text
    output, then go back and click Get Custom Track
    to view this graphically in the Genome Browser

22
  • click Get Custom Track File to view the text
    output, then go back and click Get Custom Track
    to view this graphically in the Genome Browser

23
  • Find a way to zoom in on one of the genes with a
    repeat and turn the Simple Repeats track on in
    pack mode to view these

24
  • Research Question
  • Which known genes in the first 25 Mb of
    chromosome 4 contain trinucleotide repeats?
  • Related questions
  • How many genes is this?
  • Conduct the query in reverse - how many
    trinucleotide repeats are in known genes in the
    first 25 Mb of chromosome 4.
  • Can you explain the difference between the
    results of these queries?

25
Data Downloads http//genome.ucsc.edu/downloads.ht
ml
26
Example simpleRepeats table
27
Other Examples
  • For other examples to work through, see
  • Creating custom annotation tracks section of
    the Users Guide http//genome.ucsc.edu/goldenPath
    /help/hgTracksHelp.html
  • Table Browser paper, Karolchik et al (2004) NAR
    32D493-D496
