RADIATION DOSE CONSIDERATIONS IN CT IMAGING

1
RADIATION DOSE CONSIDERATIONS IN CT IMAGING

• Jeffrey T. Seabourn, M.D.
• Gem State Radiology

2
Disclosures
3
Disclosures
4
Radiation Dose Considerations in CT
ImagingLearning Objectives

• Learn the reasons for heightened concern about
  radiation exposure from CT
• Learn basic concepts of radiobiology, CT
  radiation measurement, and range of exposures for
  various exams
• Understand the consensus opinions on the risks of
  radiation
• Learn about strategies Radiologists employ to
  minimize radiation exposure from CT

5
Radiation Dose Considerations in CT
ImagingLearning Objectives

• Learn the reasons for heightened concern about
  radiation exposure from CT
• Learn basic concepts of radiobiology, CT
  radiation measurement, and range of exposures for
  various exams
• Understand the consensus opinions on the risks of
  radiation
• Learn about strategies Radiologists employ to
  minimize radiation exposure from CT

6
Radiation fear Why Now?

• Rapid rise in population radiation exposure from
  medical imaging
• NEJM article 11/07 by Brenner Hall
• Lay press activity USA Today, Time, Washington
  Post, NY Times
• X-rays classified as carcinogens by WHO, CDC, and
  NIEHS

7
Radiation exposure from CT

• 60 million CTs/yr in 2006 c/w 3 million in
  1980.
• Estimated at between 69-72 million in 2007.
• 4-7 million CTs performed annually on Peds
• Increasing by 10 per year
• 33 under age 10
• 10 times more sensitive to radiation
• Rate has doubled in last 5 years
• CT has become the largest source of medical
  radiation dose

8
(No Transcript)
9
Radiation Fear
10
Radiation Fear Recent developments

• Radiation over-exposures reported at Cedars-Sinai
  Medical Center involving brain CT perfusion scans
• Prompts FDA investigation 10/09
• Initially reveals 206 cases of over-exposure (8x
  expected level) over an 18 month period.
• FDA finds additional cases in LA area and in
  Alabama
• Class action lawsuit filed

11
Radiation Fear Recent developments

• FDA launches initiative to rein in medical
  radiation 2/9/10
• Congressional sub-committee hearings on radiation
  safety 2/26/10
• FDA hearings on radiation safety 3/30/10

12
Radiation Fear Recent Publications

• Exposure to Low-Dose Ionizing Radiation from
  Medical Imaging Procedures. NEJM, August 27,
  2009 Number 9 Volume 361849-857 Reza Fazel,
  M.D., et. al.
• Collected CT data from 5 Healthcare markets from
  2005-2007
• Categorized effective radiation doses into 4
  categories
• Low (lt3mSv)
• Moderate (gt3-20mSv) 19.4 of enrollees
• High (gt20-50mSv) 1.9 of enrollees
• Very high (gt50mSv) .19 of enrollees
• Conclusions Imaging procedures are an important
  source of exposure to ionizing radiation and can
  result in high cumulative effective doses

13
Radiation Fear Recent Publications

• Projected Cancer Risks From Computed Tomographic
  Scans Performed in the United States in 2007.
  Amy Berrington de González, Dphil et. al.
• Arch Intern Med. 2009169(22)2071-2077.
• Sponsored by NIH and NCI
• Estimated 29,000 new cancers from CTs performed
  in 2007
• Estimates based on BEIR VII risk modeling

14
Radiation Fear Recent Publications

• Radiation Dose Associated With Common Computed
  Tomography Examinations and the Associated
  Lifetime Attributable Risk of Cancer. Arch Intern
  Med. 2009169(22)2078-2086. Rebecca
  Smith-Bindman, MD et. al.
• Radiation doses from common CT exams were higher
  and far more variable than previous estimates.
• Up to a 13-fold variation between highest and
  lowest dose for each study type
• Attempted to measure LAR of cancer based on age,
  sex and CT dose estimates.

15
Radiation Dose Considerations in CT
ImagingLearning Objectives

• Learn the reasons for heightened concern about
  radiation exposure from CT
• Learn basic concepts of radiobiology, CT
  radiation measurement, and range of exposures for
  various exams
• Understand the consensus opinions on the risks of
  radiation
• Learn about strategies Radiologists employ to
  minimize radiation exposure from CT

16
Radiation Bio-effects

• Direct interaction
• Cellular macromolecules (proteins or DNA) are hit
  by ionizing radiation
• Cell death
• DNA mutation
• Indirect interaction
• Radiation interacts with cellular water
• Hydrolysis of H20 resulting in a OH- free radical
• Formation of unstable H2O2 stable organic
  peroxide lack of essential enzyme cell
  death
• Anti-oxidants block recombination into H2O2
  preventing stable organic H2O2 compounds from
  occurring

17
Radiation terms and definitions

• Radiation exposure (R) ionization of air by
  photons (x-rays).
• Absorbed dose (Gy) energy absorbed due to
  ionizing radiation.
• Equivalent dose (Sv) takes into account the
  type of radiation involved (gamma vs. x-rays)
• Effective dose (Sv) accounts for tissue
  radiosensitivity in determining equivalent whole
  body dose.

18
Organ Radio-sensitivity
19
Biological Effects of Ionizing Radiation

• Stochastic Effects
• Deterministic Effects

20
Stochastic Effects

• Exposure to low-dose radiation
• Severity is independent of dose
• No safe threshold dose
• Probability of a biological effect increases with
  dose
• May take a lifetime to manifest (or more)
• Results in carcinogenesis and genetic effects

21
Deterministic Effects

• Result from high radiation doses
• Generally not an issue in diagnostic imaging
• Severity is dose dependent
• Higher dose increased severity
• There is a threshold
• Examples hair loss, cataracts, skin changes,
  sterility, nausea, CNS damage, death

22
Deterministic effect Band alopecia CTA Brain
perfusion
23
CT RADIATION MEASUREMENTS CDTI AND DLP

• CTDI CT dose index (mGy)
• DLP Dose length product (mGy-cm)

24
CT RADIATION MEASURMENTS CTDI

• CTDI (mGy)
• CTDI100
• CTDIW Weighted avg. of center (1/3) and
  peripheral (2/3) contributions of dose.
• CTDIVOL CTDIW/pitch
• For the same tube current and voltage,
• Decrease in diameter will increase effective
  dose
• Smaller pitch will increase CTDI

25
CT RADIATION MEASUREMENTS DLP

• DLP (mGy-cm)
• CTDIVOL x scan length
• Represents the integrated dose across the scan
  length.
• Can be multiplied by a conversion factor to yield
  an effective dose estimate

26
CT RADIATION MEASUREMENTS

• CTDIVOL and DLP are displayed on newer CT
  scanners.
• Useful for comparing CT protocols between
  scanners.
• Do NOT represent effective dose measurements
  (mSv).
• Represent calculations from phantom measurements.
• Can be used to estimate effective dose using
  conversion factors.

27
ESTIMATING EFFECTIVE DOSE FROM CT

• Effective dose estimates can be calculated using
  anatomic region specific conversion factors and
  multiplying them by the DLP.
• Effective dose (mSv) DLP k(E/DLP)
• Representative adult values for k(E/DLP) are
• Head/Neck .0031
• Head .0021
• Neck .0059
• Chest .014
• A/P .015
• Trunk .015

28
Comparison of Adult and Pediatric k-values
29
ESTIMATING EFFECTIVE DOSE EXAMPLE ADULT HEAD CT

• Head CT
• CTDIVOL 118.4 mGy
• DLP 1183 mGy-cm
• Effective dose estimate DLP x 0.0021
• 2.5 mSv

30
(No Transcript)
31
Radiation Dose Considerations in CT
ImagingLearning Objectives

• Learn the reasons for heightened concern about
  radiation exposure from CT
• Learn basic concepts of radiobiology, CT
  radiation measurement, and range of exposures for
  various exams
• Understand the consensus opinions on the risks of
  radiation
• Learn about strategies Radiologists employ to
  minimize radiation exposure from CT

32
Risks of Ionizing Radiation from Diagnostic
imaging

• No published studies have directly attributed
  cancer to CT scanning
• Relationship between radiation exposure and
  cancer risk at low radiation doses is less clear
• Proving this definitively and accurately would
  require hundreds of thousands to millions of
  subjects
• Therefore, assumptions must be made based on
  other forms of ionizing radiation exposure
• Most widely used source Atomic bomb survivors
• Additional sources of risk estimates come from
  expert panel reviews
• BEIR reports
• ICRP
• UN Subcommittee on Atomic Radiation

33
Atomic Bomb Survivor Data

• Largest longitudinal study to date
• 35,000 survivors exposed to doses lt 150mSv
• Followed for cancer incidence over 55 years
• Direct, statistically significant evidence for
  risk in the dose range from 5-150 mSv
• Instantaneous WB exposure to x-rays, particulate
  radiation, neutrons
• Pierce, DA and Preston, DL. Radiation-related
  cancer risks at low doses among atomic bomb
  survivors. Radiation Research, 200, 154(2) p.
  178-86.

34
Radiation Exposure

• Background 3 mSv/ year at sea level
• Transcontinental Flight 1mSv/hour
• Chest X-Ray 0.02 mSv
• MDCT Abdomen and Pelvis 10 mSv
• Hiroshima Survivors showing excess cancer deaths
  2 to 20 mSv

35
Radiation Dose Comparisons
36
Adults age 45 or older

• Very low risk of excess cancer for one scan
• High prevalence of cancer in patients over 45
• May not live long enough to express mutation
• Usually past reproductive age

37
But for a 10 year old

• Long lifespan in which to manifest mutation
• Immature, rapidly developing body systems, more
  radiosensitive
• May pass mutations to progeny

38
Compare the Risk
39
Compare the Risk
Estimated radiation-induced cancer risk is 3-5
times greater in children than in adults
40
(No Transcript)
41
Radiation Risk in Context

• Baseline risk of cancer 20-25 (1 in 4-5)
• Late middle aged adult getting average CT has
  lifetime risk of cancer increased from 20 to
  20.01

42
Comparable non-radiation risks

• Assume 10 mSv CT scan
• Smoking 140 cigarettes in lifetime (lung CA)
• Spending 7 months in NYC (air pollution- lung CA)
• Driving 4,000 miles in a car (accident)
• Flying 250,000 miles in a jet (accident)

43
Risks of Ionizing Radiation from Diagnostic
ImagingBottom Line

• No direct cause-effect relationship established
  between low-dose radiation and cancer
• Although the risk is small, it is also cumulative
• Statistically significant increase in cancer
  risks above 50mSv
• The benefits of an indicated CT far outweigh the
  risks

44
Radiation Dose Considerations in CT
ImagingLearning Objectives

• Learn the reasons for heightened concern about
  radiation exposure from CT
• Learn basic concepts of radiobiology, CT
  radiation measurement, and range of exposures for
  various exams
• Understand the consensus opinions on the risks of
  radiation
• Learn about strategies Radiologists employ to
  minimize radiation exposure from CT

45
Radiation exposure from CT

• Collective dose to population is rising
• High radiation dose per exam
• Increasing number of indications
• Increasing availability
• Easier to perform
• Faster

46
Two Pillars of CT Dose Reduction
47
Appropriate Utilization

• Causes of over-utilization
• Defensive medicine practices
• Estimated that up to 30 of imaging is
  unneccessary
• Physician self-referral
• Imaging the worried well
• Inappropriate recommendations for CT imaging by
  Radiologists
• ACR appropriateness criteria
• Whole Body CT screening

48
(No Transcript)
49
(No Transcript)
50
Appropriate Utilization

• Strategies to reduce radiation exposure from CT
  exams
• CT vs. other imaging tests
• Avoid repetitive studies
• Tailor the exam to the patient
• Tailor the exam to the application
• Reduce dose as much as possible
• Limit the scan range

51
Appropriate Utilization

• CT should be avoided when an US or MRI is of
  comparable diagnostic utility
• Body MR Liver, Pancreatic, and Renal imaging
• US vs. CT for appendicitis in children
• ACR appropriateness criteria
• US 8/9 RRL none
• CT 7/9 RRL high

52
Appropriate Utilization

• CT should be avoided when prior diagnostic
  radiation exposure is excessive
• Repeat visits to ED
• Chest pain CTPA
• Abdominal pain A/P CT

53
Optimization of CT protocols

• CT technique should be tailored to the patient
  and his/her body habitus
• Use of pediatric specific imaging protocols
  (Image Gently campaign)
• Reduction of peak KvP relative organ dose
  reductions range from 30-55
• Use of AEC programs
• Patients with a larger body habitus will receive
  a larger dose, but still have issues with image
  noise

54
Optimization of CT protocols

• CT technique should be monitored and controlled
  to ensure that the dose is as low as reasonably
  achievable (ALARA principle)
• Peak KvP optimization BMI or weight-based
  protocols
• Tube current adjustment (mAs) AEC software
• Adjust pitch in pitch, decrease in dose
• Develop and use a chart or table of tube-current
  settings based on patient weight or diameter and
  anatomical region of interest.
• Reduce the number of multi-phasic scans with
  contrast
• Limit the scan range

55
(No Transcript)
56
Sure Exposure Dose Reduction System
After the operator sets plan on scanogram, the
scanner will calculate the absorption of patient
body, and decide appropriate scan technique
. During scanning, the scanner modulates mA with
every gantry rotation. (right)
As a result, detector output is maintained.
Therefore, the image noise of each slice is also
maintained, providing the same Image Quality at a
lower patient dose. (left)
57
Future efforts at CT dose reduction

• Hardware improvements from vendors
• Shift away from slice wars with a renewed
  emphasis on dose reduction strategies
• Volume scanning- Aquilion One
• Dual energy- Siemens Definition Flash
• More efficient detectors- GEMS
• Software Iterative reconstruction techniques
• ASIR- GEMS
• IRIS- Siemens

58
Technological Advancements in CT Dose Reduction
ASIR
59
Future efforts at CT dose reduction Dose
Awareness

• Requirements to list CTDIvol and DLP with the
  patients image data
• Pilot program to integrate patient dose profile
  at order entry level
• Would require the ordering provider to break the
  glass if patient has exceeded agreed upon
  cumulative dose thresholds

60
Future efforts at CT dose reduction Dose
Awareness

• Dose Index Registry (DIR)
• Part of National Radiology data Registry (NRDR)
• Will collect and provide feedback on dose
  estimate information from various modalities
• Allows fine tuning of protocols and increases
  awareness

61
Future efforts at CT dose reduction Legislative
and Regulatory reform

• Congressional oversight and legislation to reduce
  medical radiation errors
• Intelligently attempt to modify the currently
  fragmented oversight, accreditation, licensing
  and QA requirements for medical use of radiation
• Rep. Waxman astonished that no federal agency
  has authority over medical radiation safety
  issues
• FDA regulations

62
(No Transcript)
63
What can patients do?

• Keep accurate health records to document exposure
  to ionizing radiation
• Google Health
• EMR patient portals
• Seek out facilities that are committed to
  radiation safety
• ACR accredited facilities
• Independent audit of CT utilization
• Protocols
• Tech training
• Image quality

64
What can patients do?

• Ask questions
• Why do I need this exam?
• How will having this exam improve my
  healthcare?
• Do you have an ownership interest in the CT
  scanner?
• Be an advocate for your children
• Is CT the best test for this indication?
• Will the exam be adjusted based on the size of my
  child?

65
What Providers can do

• Become dose aware
• Education
• Lectures
• Websites
• www.acr.org
• www.radiologyinfo.org
• www.imagegently.org
• Appropriate utilization
• ACR appropriateness criteria with RRLs
• Utilize Radiologists as a resource

66
Physician Education

• Useful websites
• www.acr.org
• Radiation safety
• ACR appropriateness criteria
• www.radiologyinfo.org
• Jointly sponsored by ACR/RSNA
• Information for patients
• www.imagegently.org
• Image gently campaign
• Sponsored by the alliance for Radiation Safety in
  Pediatric Imaging

67
What GSR does

• Standardization of CT protocols across facilities
• Reduce dose for or eliminate multi-phasic exams
• Individually protocol every CT exam that gets
  ordered
• Change to a different modality
• Limit or modify the scan range
• Review outside CTs to determine whether a follow
  up CT is indicated

68
What GSR does

• ACR accreditation
• All IMI sites
• Medicaire requirement 1/2012
• Implementation of dose reduction strategies
• Requires detailed knowledge of CT technology
• Ongoing efforts at tech education and training

69
Conclusions

• Advancements in CT imaging have revolutionized
  the practice of medicine
• Increasing utilization has led to an increase in
  population exposure, of particular concern for
  children.
• Radiologists have role as principal gatekeepers
• ALARA principal
• Educate and counsel regarding risks
