Adeel Husain PGY 3

1
Open Fractures

• Adeel Husain PGY 3
• Loma Linda University
• Dept of Orthopaedic Surgery

2
Definition

• Break in the skin and underlying soft tissue
  leading directly into or communicating with the
  fracture and its hematoma

3
History

• Last century, high mortality with open fractures
  of long bones
• Early amputation in order to prevent death
• WWI, mortality of open femur fractures gt 70
• 1939 Trueta closed treatment of war fractures
• Included open wound treatment and then enclosure
  of the extremity in a cast
• Greatest danger of infection lay in muscle, not
  bone

4
History

• 1943 PCN on the battlefield quickly reduced rate
  of wound sepsis
• Delayed closure of wounds
• Hampton closure btwn 4th and 7th day
• Larger defects continued to be left open to heal
  by secondary intention

5
History

• Advances shifted the focus
• Preservation of life and limb ? preservation of
  function and prevention of complications
• However, amputation rates still exceed 50 in the
  most severe open tibial fractures assoc with
  vascular injury

6
Epidemiology

• 3 of all limb fractures
• 21.3 per 100,000 per year

7
Open fracture classification

• Allows comparison of results
• Provides guidelines on prognosis and treatment
• Fracture healing, infection and amputation rate
  correlate with the degree of soft tissue injury
• Gustilo upgraded to Gustilo and Anderson
• AO open fracture classification
• Host classification of open fractures

8
Gustilo and Anderson Classification

• Model is tibia, however applied to all types of
  open fractures
• Emphasis on wound size
• Crush injury assoc with small wounds
• Sharp injury assoc with large wounds
• Better to emphasize
• Degree of soft tissue injury
• Degree of contamination

9
Type 1 Open Fractures

• Inside-out injury
• Clean wound
• Minimal soft tissue damage
• No significant periosteal stripping

10
Type 2 Open Fractures

• Moderate soft tissue damage
• Outside-in
• Higher energy
• Some necrotic muscle
• Some periosteal stripping

11
Type 3a Open Fractures

• High energy
• Outside-in
• Extensive muscle devitalization
• Bone coverage with existing soft tissue

12
Type 3b Open Fractures

• High energy
• Outside in
• Extensive muscle devitalization
• Requires a flap for bone coverage and soft tissue
  closure
• Periosteal stripping

13
Type 3c Open Fractures

• High energy
• Increased risk of amputation and infection
• Any grade 3 with
• major vascular injury requiring repair

14
Why use this classification?

• Grades of soft tissue injury correlates with
  infection and fracture healing

15
Gustilo and AndersonBowen and Widmaier

• 2005 Host classification predicts infection after
  open fracture
• Gustilo and Anderson classification and the
  number of comorbidities predict infection risk
• 174 patients with open fractures of long bones
• Sorted into three classes based on 14
  immunocompromising factors
• Agegt80, current nicotine use, DM, malignancy,
  pulmonary insufficiency, systemic
  immunodeficiency, etc

16
What they found

• Patients with any compromising risk factor has
  increased risk of infection
• May benefit from additional therapies that
  decrease the risk of infection.

17
Gustilo Classification a simple and useful
tool, but is it accurate?

• 1994 Brumback et al.
• 125 randomized open fractures
• 245 surgeons of various levels of training
• 12 cases of open tibia fractures, videos used
• Interobserver agreement poor
• Range 42-94 for each fracture
• Ortho attendings - 59 agreement
• Ortho Trauma Fellowship trained attendings - 66
  agreement

18
So.

• Fracture type should not be classified in the ER
• Most reliably done in the OR at the completion of
  primary wound care and debridement

19
Microbiology

• Most acute infections are caused by pathogens
  acquired in the hospital
• 1976 Gustilo and Anderson
• most infections in their study of 326 open fxs
  developed secondarily
• When left open for gt2wks, wounds were prone to
  nocosomial contaminants such as Pseudomonas and
  other GN bacteria
• Currently most open fracture infections are
  caused by GNR and GP staph

20
Nocosomial infection?!!!!
Cover the wounds quickly

• Only 18 of infections were caused by the same
  organism initially isolated in the perioperative
  cultures
• Carsenti-Etesse et al. 1999
• 92 of open fracture infections were caused by
  bacteria acquired while the patient was in the
  hospital

21
Common bacteria encountered with open fractures
22
What systemic antibiotic?
(Gustilo, et al JBJS 72A 1990)
23
Antibiotic comparisons

• No difference btwn clindamycin and cefazolin
• Patzakis et al.
• For type 12, cipro cefamandolegentamicin
• For type 3, cipro worse (31 vs 7.7 infection)
• Cipro and other fluoroquinolones inhibit
  osteoblast activity and fracture healing

24
When and for how long?

• Start abx as soon as possible
• Less than 3 hours ? 4.7 infection rate
• Greater than 3 hours ? 7.4
• No difference btwn 1 and 5 days of post op abx
  treatment
• Mass Gen recommended treatment
• Cefazolin Q 8 until 24 hours after wound closed
• Gentamicin or levofloxacin added for type 3

25
Local antibiotic therapy

• High abx conc within the wound and low systemic
  conc
• Reduces risk of systemic side effect
• Vancomycin or aminoglycosides
• Heat stable
• Available in powder form
• Active against suspected pathogens

26
Antibiotics - locally

• Prevents secondary contamination by nocosomial
  pathogens
• Useful adjunct to systemic abx
• Potential for abx impregnated bone graft, bone
  graft substitute, and abx coated IMN

27
Antibiotic Beads

• Cons
• Requires removal
• Limited to heat stable antibiotics
• Increased drainage from wound

• Pros
• Very high levels of antibiotics locally
• Dead space management

28
Goals of treatment

• 1. preserve life
• 2. preserve limb
• 3. preserve function
• Also.
• Prevent infection
• Fracture stabilization
• Soft tissue coverage

29
Stages of care for open fractures
30
Initial assessment management

• ABCs
• Assess entire patient
• Careful PE, neurovasc
• Abx and tetanus
• Local irrigation 1-2 liters
• Sterile compressive dressings
• Realign fracture and splint
• Do not culture wound in the ED
• 8 of bugs grown caused deep infection
• cultures were of no value and not to be done
• Recheck pulse, motor and sensation

31
Can I take pictures with my phone and send it to
my senior?

• Documents characteristics accurately
• Prevents multiple examinations
• Decreases contamination
• Communication via digital photography was more
  useful than verbal communication
• 1.3-megapixel camera is comparable with higher
  resolution cameras when viewing color images on
  computer desktop

32
Primary surgery

• Objectives of initial surgical management
• Preservation of life and limb
• Wound debridement
• Definitive injury assessment
• Fracture stabilization

Stages of open fracture management in the OR
33
Surgical emergency!

• 1898 Friedrich guinea pigs
• Take to the OR within 6-8 hours
• 1973 Robson
• bacteria multiply in contaminated wounds
• 105 organisms/gram of tissue is the infection
  threshold
• Reached at 5.17 hours
• 1995 Kindsfater et al
• 47 G2/3 fxs at 4.8 months out.
• Less than 5 hrs ? 7 infection
• Greater than 5 hrs ? 38 infection
• However G3 fxs were treated later

34
Or not?.... Calling the 6 hour rule into
question
No significant difference before or after 6
hours!!!

• 1993 Bednar and Parikh. No significant
  difference
• 3.4 vs 9 82 open femoral/tibial fxs
• 2004 Ashford et al. No significant difference
• 11 vs 17 pts from the austrailian outback
• 2004 Spencer et al.... No significant difference

• 10.1 vs 10.9 142 open long bone fxs from UK
• 2003 Pollack and the LEAP investigators. No
  correlation
• 315 open long bone fxs
• 2005 Skaggs et al.No significant difference

• children with all types of open fractures 554
  open fractures

35
Do we even need to do operative debridement?
Do we even need to debride low grade open
fractures?

• Orcutt et al... No significant difference, BUT
• 50 type 1 2 open fractures
• less infection in nonoperative group (3 vs 6)
• Less delayed union in nonop group (10 vs 16)
• Yang et al.0 infections
• 91 type 1 open fractures treated without ID

36
However, after review of all literature..
Operative debridement is the standard of care!!!!

• Okike et al. states.
• Thorough operative debridement is the standard
  of care for all open fractures.
• Even if the benefits of formal ID were
  insignificant for low grade fractures, operative
  debridement is still required for proper wound
  classification.
• Open fractures graded on the basis of
  superficial characteristics are often
  misclassified.
• Huge risk not to explore and debride!

37
URGENTLY debride, not EMERGENTLY

• Time to OR is probably less important than
• Adequacy of debridement
• Time to soft tissue coverage
• Timing depends on.
• Is patient stable?
• Is the OR prepared?
• Is appropriate assistance available?
• Ortho trained scrub techs, assistant surgeons,
  xray techs, and other OR staff
• 2005 Skaggs et al
• If after 10pm, keep until the morning! Or at
  least within 24 hours.
• Unless.
• neurovasc compromise
• horrible soft tissue contamination
• compartment syndrome

Within 24 hours
Within 6 hours
38
ID in the OR

• Trauma scrub
• Soap and saline to remove gross debris
• Zone of injury
• Skin wound is the window through which the true
  wound communicates with the exterior
• Extend the traumatic wound
• Excise margins
• Resect muscle and skin to healthy tissue
• color, consistency, capacity to bleed and
  contractility
• Bone ends are exposed and debrided
• Irrigate
• Serial debridements?
• If needed, 2nd or 3rd debridement after 24-48
  hours should be planned

39
The Irrigation

• Amount
• No good data, copious is better
• Animal studies show improved removal of
  particulate matter and bacteria but effect
  plateaus
• Irrigation bags typically contain 3 L of fluid
• Anglen recommends
• 3L (one bag) for type 1
• 6L (two bags) for type 2
• 9L (three bags) for type 3

40
How to deliver the irrigation?(what animal
studies show)

• Bulb Syringe vs Pulsatile Lavage
• Pulsatile lavage
• Detrimental for early bone healing
• this is no longer present at 2 wks
• More soft tissue destruction
• More effective in removing particulate matter and
  bacteria
• High or low pressure?
• Higher pressure
• Better bone cleaning
• Worse soft tissue cleaning
• Slows bone healing

41
Antibiotics in the irrigation?
No proven benefit!

• Antibiotics (bacitracin and/or neomycin)
• Mixed results, controversial
• Costly
• bacitracin alone around 500/washout
• ?? Causing resistance
• Wound healing problems?
• Few reported cases of anaphylaxis
• Anglen No proven value in the care of open
  fracture woundssome risk, albeit small.

42
Soaps in the irrigation?

• Surfactants (i.e. Soaps)
• Less bacteria adhesion
• Emulsify and remove debris
• No significant difference in infection or bone
  healing compared to bacitracin solution, but more
  wound healing problems in bacitracin group

43
Level 4 evidence based recommendations

• 1st washout, highly contaminated
• ? Soap solution
• Repeat washout of clean wounds
• ? Saline
• Infected wounds
• ? Soap, then antibiotic

44
Wound closure after contaminated fracture
Dubunked!

• Timing and technique is controversial
• OPEN WOUND should be left OPEN!
• Prevents anaerobic conditions in wound
  Clostridium
• Facilitates drainage
• Allows repeat debridement

45
To close or not to close?

• Recently, renewed interest in primary closure
• Collinge, OTA 2004
• Moola, OTA 2005
• Russell, OTA 2005
• DeLong, J Trauma 2004/
• Bosse, JAAOS 2002
• Improved abx management
• Better stabilization
• Less morbidity
• Shorter hospital stay, lower cost
• NO increase in wound infection
• These wounds are at higher risk of clostridia
  perfringens if they do get infected.

• 1999 Delong et al 119 open fxs
• No significant difference
• delayed/nonunion and infection rates btwn
  immediate and delayed closure
• Immediate closure is a viable option

46
Contraindications to primary closure

• Inadequate debridement
• Gross contamination
• Farm related or freshwater immersion injuries
• Delay in treatment gt12 hours
• Delay in giving abx
• Compromised host or tissue viability

47
When to cover the wound?

• ASAP after wound adequately debrided
• Only 18 of infections are caused by the same
  organism isolated in initial perioperative
  culture
• Suggests hospital acquired etiology of infection
• Fix and Flap
• For Type IIIB IIIC open tibia fractures
• Early if not immediate flap coverage

48
Dressings

• Temporary closures rubber bands
• Wet to dry dressings
• Semi-permeable membranes
• Antibiotic bead pouch
• VAC

49
VAC

• Vacuum assisted wound closure
• Recommended for temporary management
• Mechanically induced negative pressure in a
  closed system
• Removes fluid from extravascular space
• Reduced edema
• Improves microcirculation
• Enhances proliferation of reparative granulation
  tissue
• Open cell polyurethane foam dressing ensures an
  even distribution of negative pressure

50
Types of fracture stabilization

• Splint
• Good option if operative fixation not required
• Internal fixation
• Wound is clean and soft tissue coverage available
• External fixation
• Dirty wounds or extensive soft tissue injury

51
Fracture stabilization

• Gustilo type 1 injury can be treated the same way
  as a comparable closed fracture
• Most cases involve surgical fixation
• Outcome is similar to closed counterparts

52
Fracture stabilization

• Gustilo type 23 usually displaced and unstable
• dictate surgical fixation
• Restore length, alignment, rotation and provide
  stability
• ideal environment for soft tissue healing and
  reduces wound infection
• reduces dead space and hematoma volume
• Inflammatory response dampened
• Exudates and edema is reduced
• Tissue revascularization is encouraged

53
When to use plates?

• Open diaphyseal fractures of arm forearm
• Open diaphyseal fractures lower extremity
• NOT recommended
• Open tibial shaft plating assoc high infection
  rate
• Open periarticular fractures
• Treatment of choice in both upper and lower
  extremities

54
When to use IM nails?

• Treatment of choice for most diaphyseal fractures
  of the lower extremity
• Inserted without disrupting the already injured
  soft tissue envelope
• Preserves the remaining extra osseous blood
  supply to cortical bone
• Malunion is uncommon

55
To ream or not to ream?

• Does reaming cause additional damage to the
  endosteal blood supply?
• Solid IM nails without reaming has a lower risk
  of infection that tubular nails with a large dead
  space
• However reamed IM nails are biomechanically
  stronger and can reliably maintain fracture
  reduction if statically locked
• 2000 Finkemeier et al.
• reamed vs unreamed interlocked nails of open
  tibias
• NO statistical difference in outcome and risk of
  complication

56
When to use external fixation?

• Diaphyseal fractures not amenable to IM nails
• Ring fixators for periarticular fractures
• Temporary joint spanning ex fix is popular for
  knee, ankle, elbow and wrist
• If temporary, plan for conversion to IM nail
  within 3 weeks

57
Ex-fix Weigh the pros and cons!

• Historically was definitive treatment
• Now, more commonly as temporary fixation
• Can be applied almost always and everywhere
• Severe soft tissue damage and contamination

• Advantages
• Easy and quick
• Relatively stable fixation
• No further damage done
• Avoids hardware in the open wound

• Disadvantages
• Pin track infections
• Malalignment
• Delayed union
• Poor patient compliance

58
Skin cover and soft tissue reconstruction

• Do these early!
• 1994 Osterman et al.
• Retrospective 1085 fractures, 115 G2 and 239 G3
• All treated with appropriate IV Abx and ID
• No infection if wounds closed at 7.6 days
• Yes infection if wounds closed at 17.9 days

Infection risk increases if wound open gt 7 days
59
Reconstructive ladder options for wound coverage
Type 1 open fx
Type 2/3A open fx
Type 3B open fx
60
Flap coverage for type 3b
61
Type 3c, a bad injury!

• Devastating damage to bone and soft tissue
• Major arterial injuries that require repair
• Poor functional outcome
• Consensus btwn ortho, vascular and plastics
• Salvage is technically possible in most cases
• However it is not always the correct choice esp
  type 3c tibia fractures

62
We can do both, salvage amputate.

• Vascular surgery can revascularize with bypass
  graft
• Generally before fracture stabilization
• Plastics can provide soft tissue coverage
• However, in the tibia, the severity to soft
  tissue envelope and bone may result in infected
  nonunion
• If salvage. long course of repeated surgical
  procedures
• Painful and psychologically distressing
• Functional outcome may be poor and no better than
  amputation

63
How to decide, salvage or amputate?

• Important factors in decision making
• General condition of the patient (shock)
• Warm ischemia time (gt6hours)
• Age (gt30 years)
• Cut to crush ratio (blunt injuries has a large
  zone of crush)

64
Gunshot injuries

• Energy dissipated at impact damage severity
• High velocity rifles and close range shotguns
• Worst, high energy of impact
• Huge secondary cavitation
• Secondary effects of shattered bone fragments
• Bullets lodged in joints should be removed
• avoid lead arthropathy and systemic lead poisoning

65
Low velocity GSW lt2000 ft/sec

• Low velocity handguns
• Less severe, not treated like open fractures
• Cavitation is not significant
• Secondary missile effects are minimal
• Bone fragments rarely stripped of soft tissue
  attachments and blood supply
• Soft tissue injuries not severe and skin wounds
  are small

66
Low velocity GSW open fractures
Treat open fractures from low velocity GSW as
closed fractures without Abx

• Geisslar et al.
• If neurovascular status normal, do local
  debridement
• NO formal ID needed
• IV Abx
• Approach fx fixation as if closed

• Dickey et al.
• No abx vs IV Ancef x 3d
• 67 low velocity GSW fxs
• Not requiring operative fixation
• No difference in infection rates

Dickey et al, J Ortho Trauma, 36-10,1989
67
Pitfalls and complications

• Infection ? delayed union, nonunion, malunion and
  loss of function
• Plan ahead to avoid delayed union and nonunion
• Predict nonunion in severe injuries with bone
  loss
• Bone grafting usually delayed 6 weeks when soft
  tissues have soundly healed
• Autogenous bone grafting is usual strategy
• Fibular transfer, free composite graft or
  distraction osteogenesis for complex defects
• Recombinant human BMP in open tibia fracture
  reduces risk of delayed union

68
Advances

• BMPs
• 40 decreased infection rate with BMP in type 3
  open tibia fractures
• Antibiotic Laden Bone Graft
• Tobramycin-impregnated calcium sulfate pellets
  with demineralized bone matrix
• Animal study successful in preventing infection

69
Summary
A good evidence (level 1 studies) B fair
evidence (level 2/3 studies) C poor quality
evidence (level 4/5 studies) I insufficient or
conflicting evidence
Okike K, Bhattacharyya T Trends in the
management of open fractures. A critical
analysis. J Bone Joint Surg. 2006
Dec88(12)2739-48.
70
Thank you
