Title: IQAC at DHVI


1
Welcome
  • IQAC at DHVI

2
CD4 Immunophenotyping for HIV Monitoring
  • Flow Cytometry

3
Introduction
  • Absolute CD4 T-lymphocyte counts are used to
    evaluate the immune status of patients with the
    human immunodeficiency virus (HIV).
  • CD4 antigen is the receptor for HIV. The
    absolute number of CD4 T lymphocytes is closely
    associated with HIV progression.

4
Flow Cytometry
  • Laser based high speed electronic cell analyzer
  • Fluorescent conjugated monoclonal antibodies
  • Analyze surface (and cytoplasmic) cellular
    antigens.
  • Flow rates 500 700 cells /second

5
Flow Cytometry
  • What Can a Flow Cytometer Tell Us About a Cell?
  • Its relative size (Forward Scatter- FSC)
  • Its relative granularity or internal complexity
    (Side Scatter-SSC)
  • Its relative fluorescence intensity (FL1,FL2,FL3,
    and FL4)

6
Light Scatter Properties
7
Blood Cells
8
Flow Light Scatter Pattern
9
Fluorescence
10
Fluorescence Emission
11
Fluorescence Intensity
12
2-parameter Dot Plot
13
Flow Cytometry System
  • Fluidics
  • To introduce and focus cells for analysis.
  • Optics
  • To generate and collect light signals.
  • Electronics
  • To convert optical signals to digital electronic
    signals for computer analysis.

14
Fluidics
15
Flow Cell
Injector Tip
Sheath fluid
Fluorescence
signals
Focused laser
beam
Purdue University Cytometry Laboratories
16
Sample Flow
17
Optics
  • Excitation optics
  • Laser(s)
  • Lenses to shape and focus the laser beam
  • Collection optics
  • A collection lens to collect light emitted from
    the particle-laser beam interaction
  • A system of optical mirrors and filters to route
    specified wavelengths of the collected light to
    designated optical detectors.

18
Forward Angle Light Scatter
Purdue University Cytometry Laboratories
19
90 Degree Light Scatter
Purdue University Cytometry Laboratories
20
Fluorescence Detectors
Laser
Purdue University Cytometry Laboratories
21
Optical Filters
22
Optics Scheme
23
Flow Layout
Example Channel Layout for Laser-based Flow
Cytometry
PMT
4
PMT
Dichroic
3
Filters
Flow cell
PMT
2
Bandpass
Filters
PMT
1
Laser
original from Purdue University Cytometry
Laboratories modified by R.F. Murphy
24
Fluidics and Optics Review
  • Created an illumination region with the
    excitation optics
  • Passed the cells precisely through the
    illumination region using hydrodynamic focusing
  • Routed the generated light signals to the
    specific detectors by collection optics

25
Electronics
  • Converts optical signals to proportional
    electronic signals (voltage pulses)
  • Analyzes voltage pulse height, area, or width
  • Interfaces with the computer for data transfer

26
SIGNAL AND PATTERN GENERATION
VOLTAGE
27
FLUORESCENCE INTENSITY PATTERN FROM A CELL
POPULATION
LASER
Number of events
PMT 1
Relative Fluorescence Intensity
28
DETECTION OF THREE FLUORESCENCE INTENSITY
PATTERNS FROM CELL SURFACE
LASER
Number of events
PMT 1
Relative Fluorescence Intensity
29
FLUORESCENT SIGNAL PATTERN COLLECTION
LASER
Number of events
PMT 1
Relative Fluorescence Intensity
30
SINGLE COLOR HISTOGRAMS
31
Dot Plot
32
Uncompensated vs. Compensated
FL2
FL1
33
Emissions Spectra
34
Fluorescence Overlap
35
Fluorescence Compensation
36
FITC Compensation
37
Compensation Examples
38
FUNDAMENTAL ASPECT OF COLOR COMPENSATION HOW TO
REMOVE GREEN (G) FROM ORANGE (O)
A spectral image generated by fluoro-chromes G
and O
Spectral energy from fluorochrome G is
subtracted from O
39
THREE PART DIFFERENTIAL ANALYSIS OF WHOLE BLOOD
BECTON DICKINSON
40
BIVARIATE QUADRANTS FOR T-CELL SUBSET MARKERS
Mandy et al., 2001
41
COMPONENTS OF BIVARIATE QUADRANT DISPLAY DUAL
T-CELL MARKERS ACD4 and BCD3
42
BIVARIATE QUADRANT HISTOGRAM FOR CD3 AND CD4
POSITIVE CELLS
43
TWO COLOR PATTERN
color CD3-CD4- black CD3CD4- blue CD3-CD4 cyan
CD3CD4 green
FL2-CD4
FL1-CD3
44
THREE COLOR PATTERN
CD4
CD4
CD3
CD8
CD8
CD3
45
FOUR COLOR PATTERN
CD4
CD8
CD56
CD3
CD3
CD3
CD8
CD4
CD4
CD56
CD56
CD8
46
FOUR COLOR DUAL LASER IMMUNOPHENOTYPING
Antibodies labeled with fluorescein Antibodies
labeled with phycoerythrin (PE) Antibodies
labeled with PE/CY5 or PerCP Antibodies labeled
with APC, CY5 or CY7
47
CD45 BASED HETEROGENEOUS GATING FOR T-CELL
SUBSETS
CD45-Gating Protocol
HC, NIH CDC GUIDELINES
Bergeron et al. 2002
48
Topics of Discussion
  • Testing Platforms
  • Single
  • Dual
  • Instrumentation
  • Reagents

49
Testing Platforms
  • Single platform instrument
  • Single platform testing can be performed on flow
    cytometer using calibration beads.
  • Cost per test is relatively higher.
  • Dual platform testing relies on a Hematology
    Analyzer.
  • Hematology cost per test is relatively
    inexpensive.
  • Comparison of both platforms.

50
Instrumentation
  • Flow Cytometers
  • Beckman Coulter
  • FC500, MCL-XL, Elite, Profile, Point Care
  • Becton Dickinson
  • Canto, FACSCalibur, FACSCan, FACSort, FACSCount
  • Guava Technologies Inc.
  • Personal Cell Analyzer System (PCA)
  • Partec - CyFlow
  • Accuri Cytometers
  • Hematology Analyzers
  • Coulter, Sysmex, Cell Dyn
  • Pipetters

51
Flow Cytometry Software
  • Beckman Coulter EPICS System II and Expo 32
  • Becton Dickinson Simultest, Multitest, and Cell
    Quest (Pro) for BD FACS
  • Becton Dickinson FACSCount
  • Guava PCA System
  • Partec FloMax
  • Accuri CFlow Plus
  • TreeStar, Inc. FlowJo
  • Verity Software House - WinList

52
Reagents
  • There are many manufacturers of monoclonal
    antibodies. Select IVD reagents to ensure
    quality and reliability.
  • Cytometer manufacturers are a good source for
    flow reagents.

53
Multi-color Antibody Panels
  • 2-color panels (Leucogate CD45/CD14, CD3/4,
    CD3/8, CD3/19, CD3/1656)
  • 3-color panels (CD3/4/8 CD3/4/45, CD3/8/45,
    CD3/19/45, CD3/1656/45)
  • 4-color panels (CD3/4/8/45, CD3/19/1656/45)

54
Instrument Maintenance
  • Daily start-up and shut down
  • Daily calibration
  • Monthly and periodic maintenance
  • Troubleshooting

55
BD FACSCount Procedures
  • Instrument Start Up
  • Preparing and Running Controls
  • Preparing and Running Samples
  • Instrument Cleaning and Maintenance
  • Troubleshooting

56
BD FACSCount Sample Prep Procedure
  • Material
  • Whole blood sample collected in anticoagulant.
  • BD FACSCount Reagents
  • BD FACSCount Control Beads
  • BD FACSCount Fixative
  • BD Reverse Pipetter
  • Procedure
  • Aliquot 50ul whole blood sample to FACSCount
    Reagent tubes
  • Incubate for 1 hour at RT
  • Add 50 ul of fixative
  • Run sample on instrument

57
BD FACSCalibur Procedures
  • Instrument Start up
  • FACSComp Calibration
  • Daily Controls
  • Patient Samples
  • Instrument Cleaning and Maintenance
  • Troubleshooting

58
BD MultiTest Reagent Staining Procedure (Lyse No
Wash)
  • Materials
  • Whole blood collected in anticoagulant.
  • MultiTest Reagent Panel
  • BD FACSLyse Solution
  • BD Falcon 12 x 75mm test tubes
  • Procedure
  • Add 50ul of blood sample to 10ul of antibody
    reagent.
  • Incubate for 15 minutes at RT
  • Add 450ul of a working dilution of BD FACSLyse
    solution.
  • Incubate for 15 minutes at RT
  • Acquire samples on flow cytometer

59
Beckman Coulter Epics / FC500 Procedures
  • Instrument Start up
  • FlowCheck FlowSet Calibrations
  • Fluorescence Compensation
  • Daily Controls
  • Patient Samples
  • Instrument Cleaning and Maintenance
  • Troubleshooting

60
Beckman Coulter Cyto-Stat Reagent Staining
Procedure (Lyse No Wash)
  • Materials
  • Whole Blood collected in anticoagulant.
  • Coulter Cyto-Stat Reagent Panel
  • Coulter T-Q Prep
  • 12 x 75mm test tubes
  • Procedure
  • Add 100ul of blood sample to 10ul of antibody
    reagent.
  • Incubate for 15 minutes at RT
  • Place tubes in T-Q Prep and start sample
    processing run.
  • Acquire samples on flow cytometer.

61
Quality Control and Quality Assurance
  • Controls
  • Reagents
  • Instruments
  • Proficiency Testing
  • Training and Competency
  • External Quality Assessment
  • UKNEQAS samples

62
Patient Reporting and Data Management
  • Patient Confidentiality
  • Reference Ranges
  • Data List Mode Files
  • Data Storage Devices

63
Acknowledgements
  • Beckman Coulter
  • Reagents Training Material
  • Becton Dickinson
  • Reagents Training Material
  • Health Canada, Francis Mandy, PhD
  • Training Material (PPT slides)
  • Purdue U. Cytometry Laboratories
  • Training Material (PPT slides)
  • Roswell Park Cancer Institute Laboratory of Flow
    Cytometry, Carleton C. Stewart, Ph.D
  • Training Material (PPT slides)

64
Conclusion
  • Thank you for your participation.
