SPINAL STENOSIS

1
SPINAL STENOSIS

• Jung U. Yoo, M.D.
• Professor and Chairman
• Department of Orthopedics and Rehabiliatation
• Oregon Health and Science University

2
STABILITY

• ORDINARY ACTIVITIES MAY GENERATE OVER 1000LB OF
  FORCE

3
MOTION
4
NEUROPROTECTION

• SPINAL CORD
• NERVE ROOTS

5
PATHOPHYSIOLOGY

• Three-joint Complex
• a large tripod with the disc as the front support
  and two facet joints as the back supports
• Any alteration in one of these joints can lead to
  damage to the others

6
STENOSIS
7
STENOSIS
8
FORAMINAL STENOSIS

• Compresses the exiting nerve root

9
CANAL SHAPE

• Round
• Triangular
• Trefoiled (15)
• Trefoiled asymmetric

10
DEGENERATION STENOSIS
11
PREVALENCE

• Most common indication for spinal surgery in
  patients over 60 y.o.
• 400,000 Americans are estimated to have spinal
  stenosis

12
STENOSIS

• Narrowing of the spinal canal or neuroforamina
• causing a symptomatic compression of the neural
  element.

13
SYMPTOMS

• Neurogenic claudication
• Radicular pain
• Weakness
• Sensory abnormalities
• Back pain

14
PHYSICAL FINDINGS

• Physical Finding Literature Review
• Limited lumbar extension 66-100
• Muscle weakness 18-52
• Sensory deficit 32-58
• Katz JN, et al Diagnosis of lumbar spinal
  stenosis. Rheum. Dis. Clin. North Am. 20471-483,
  1994

15
NEUROGENIC CLAUDICATION

• Cardinal symptom of lumbar stenosis
• Progressive pain and/or paresthesia in the back,
  buttock, thigh and calves brought on by walking
  or standing, and relieved by sitting or lying
  down with hip flexion

16
POSTURE
17
AMBULATION
18
DIFFERENTIAL DIAGNOSIS

• Vascular claudication
• Osteoarthritis of hip or knee
• Lumbar disc protrusion
• Intraspinal tumor
• Unrecognized neurologic disease
• Peripheral neuropathy

19
FORAMINAL STENOSIS

• Root symptoms
• Unilateral
• No claudication
• Acute or chronic

20
LATERAL RECESS STENOSIS

• Claudication
• Radicular pain
• Weakness is rare
• Acute or chronic

21
CENTRAL STENOSIS

• Varied presentation
• Classically with neurogenic claudication
• Some may only have back pain
• Rarely painless progressive weakness

22
DIAGNOSTIC TESTS
23
X-RAY

• Screening exam
• Stenosis cannot be diagnosed

24
X-RAY

• Instability such as scoliosis or listhesis

25
CT SCAN

• Difficult to diagnose stenosis
• Replaced by MRI
• May be useful for those who cannot have an MRI

26
CT SCAN

• Excellent bony detail

27
MRI

• Non-invasive
• Soft tissue visualization
• Gold standard

28
MRI

• Sagittal images
• Visualization of foramen

29
MYELOGRAPHY

• Excellent for intra-canal pathology
• Poor for foraminal pathology
• Replaced by MRI

30
MYELOGRAPHY

• Invasive
• 1 spinal headache
• Recurrent stenosis
• Inability to obtain MRI

31
MYELOGRAPHY
32
CT-MYELOGRAPHY

• Excellent visualization of spinal canal

33
CT-MYELOGRAPHY

• Excellent for recurrent stenosis
• Invaluable in surgical planning

34
MRI

• Expensive
• Patient cooperation
• Claustrophobia
• Open MRI

35
EMG-NCS

• Differentiation between neuropathy and
  radiculopathy
• Acute active denervation vs. chronic denervation

36
TREATMENT
37
NONOPERATIVE RX

• Rest
• Analgesic
• Oral steroid
• Physical therapy
• Bracing
• Spinal injection

38
REST

• Short term activity modification for acute pain
• Long term activity modification is not recommended

39
ANALGESIC

• NSAIDS
• Tylenol
• Narcotics
• Neurontin

40
Oral Steroid

• Effective for acute pain
• Short duration therapy
• ? Chronic or repeat tapering dose

41
PHYSICAL THERAPY

• Avoid extension exercises acutely
• William Flexion Exercises
• Water aerobics
• Strengthening of weak muscle groups

42
SPINAL INJECTIONS

• Epidural steroid
• Transforaminal root block
• Facet joint injection

43
EPIDURAL STEROID

• Commonly prescribed
• 50 short-term efficacy
• Not as selective
• May not require fluroscope

44
TRANSFORAMINAL ROOT BLOCK

• Highly selective
• Diagnostic as well as therapeutic
• Delivers medicine to the floor of spinal canal

45
FACET INJECTION

• Facet for back pain
• Not for radicular pain
• May act as epidural in 40 of cases

46
SPINAL INJECTION

• Most effective for acute pain
• May not be indicated in cases of acute
  denervation or progressive motor loss

47
OPERATIVE TREATMENT

• Decompression of neural element
• Stabilization of unstable segment

48
LAMINECTOMY
49
DECOMPRESSION OF LATERAL RECESS

• Undercutting the ventral aspect of the facet
  joints and the associated ligamentum flavum.
• Medial facetectomy if necessary
• The traversing nerve root underneath the facet
  joint must be visualized

50
FUSION

• Sagittal instability
• Scoliosis
• Iatrogenic pars defect
• Greater than 50 facet joint resection

51
INSTRUMENTATION
52
Thank you
