UAB VPN Service

1
UAB VPN Service

• David Wolford, Communications Network Specialist

2
UAB Virtual Private Network

• User Services has provided VPN for many years
• First service was called PopTop and used PPTP
• Second and current service uses a Cisco 3060 VPN
  concentrator and uses IPSEC
• We currently average 50 IPSEC concurrent users

3
System Information

• Current appliance is a Cisco 3060 which has been
  in service for approximately eight years.
• We are preparing two Cisco ASA 5550 security
  appliances to replace our 3060 in the near
  future.
• The Cisco ASA 5550s will provide load sharing
  redundancy and will allow us to use the Cisco SSL
  client.

4
Reasons to Upgrade Service

• Cisco 3060 was originally purchased for wireless
  users. It was pressed into service with the
  blocking of Microsoft ports and is now
  end-of-life by Cisco.
• Implementation of border firewall and plans of
  tighter border security will increase the need.
• Cisco is favoring SSL for newer OS platforms like
  Windows 64-bit.

5
ASA5550
6
VPN Client Options

• Cisco IPSEC client
• IPSEC not available for 64 Bit Windows
• SSL Client

7
Client Downloadhttps//vpndpo.dpo.uab.edu
8
SSL VPN Client
9
Cisco IPSEC Client
10
Departmental VPN Groups

• Offers IP addresses from a defined pool of
  addresses for firewall traversal and resource
  access
• DCNS can add or remove users from groups
• Works with SSL and IPSEC VPN

11
Network Diagram
12
Split Tunneling
13
On the Horizon

• Integration with campus NAC
• Two factor authentication
