Programmable Routers

1
Programmable Routers

• Jae Woo Lee

2
Fundamental router design
Router
Routing protocols
RIB
Control plane
FIB
Packet forwarding
Forwarding plane (aka data plane)
3
Software router
routed, OSPFd, GNU Zebra, Quagga, XORP
User-level daemons
OS kernel Network devices
Linux, BSD, Click, NetFPGA, IXP
4
Extensible software control plane XORP

• Compete with Cisco Juniper, and be extensible!
• All standard protocols
• Event-driven, not scanner-based
• Multi-process architecture
• Modern software engineering
• Main contributions
• Staged design for BGP, RIB
• Scriptable inter-process communication mechanism
• Dynamically extensible CLI and management
  software
• Extensible policy framework

Handley, M., Kohler, E., Ghosh, A., Hodson, O.,
and Radoslavov, P Designing extensible IP router
software, NSDI 2005

5
Conventional router implementation
Slide borrowed from http//www.xorp.org/papers.htm
l
6
BGP
BGP
Slide borrowed from http//www.xorp.org/papers.htm
l
7
BGP Staged Architecture
Slide borrowed from http//www.xorp.org/papers.htm
l
8
Messages
add_route
delete_route
Filter Bank
Peer In
lookup_route
Slide borrowed from http//www.xorp.org/papers.htm
l
9
BGP
RIB Routing Information Base
Slide borrowed from http//www.xorp.org/papers.htm
l
10
RIB Structure
Routing protocols can register interest in
tracking changes to specific routes.
Slide borrowed from http//www.xorp.org/papers.htm
l
11
BGP
XRLs Interprocess communication
Slide borrowed from http//www.xorp.org/papers.htm
l
12
XRL XORP Resource Locator

• URL-like unified structure for inter-process
  communication
• Example
• finder//bgp/bgp/1.0/set_bgp_as?asu321777

• Finder resolves to a concrete method instance,
  instantiates transport, and performs access
  control.
• xtcp//192.1.2.38765/bgp/1.0/set_bgp_as?asu32
  1777

Slide borrowed from http//www.xorp.org/papers.htm
l
13
Commercializing XORP Vyatta

• Standard x86 hardware
• Flexible deployment
• Standard server hardware platforms
• Blades
• Virtualization
• Open-source software

Why Vyatta is Better than Cisco,
http//www.vyatta.com/downloads/whitepapers/Vyatt
a_Better_than_Cisco.pdf Will an open source
router replace your Cisco router? http//articles.
techrepublic.com.com/5100-10878_11-6163569.html
14
Software forwarding plane OS kernels
Control plane

• Interface between control and forwarding planes
• Linux (old)
• /proc, sysctl, ioctl
• Linux (new)
• Netlink socket
• BSD
• Routing socket

User-level routing daemons
/proc ioctl() netlink routing socket
Linux kernel
Forwarding plane

• J. Salim, H. Khosravi, A. Kleen, A. Kuznetsov,
  Linux Netlink as an IP Services Protocol, RFC
  3549, July 2003
• Bolla, R. and Bruschi, R., Linux Software Router
  Data Plane Optimization and Performance
  Evaluation, Journal of Networks (JNW) 2, 3 (June
  2007)
• Qing Li, Kip Macy, Optimizing the BSD Routing
  System for Parallel Processing, PRESTO 2009


15
Modular software forwarding planeClick modular
router
Control plane

• Elements
• Small building blocks, performing simple
  operations
• Instances of C classes
• Packets traverse a directed graph of elements
• FromDevice(eth0)-gtCheckIPHeader(14)
• -gtIPPrint-gtDiscard

User-level routing daemons
Linux kernel
Click
Forwarding plane

• Kohler, E., Morris, R., Chen, B., Jannotti, J.,
  Kaashoek, M. F., The click modular router, ACM
  Trans. Comput. Syst. 18, 3 (Aug. 2000)
• Andrea Bianco, Robert Birke, Davide Bolognesi,
  Jorge M. Finochietto, Giulio Galante, Marco
  Mellia, Click vs. Linux Two Efficient
  Open-Source IP Network Stacks for Software
  Routers, HPSR 2005

16
Elements
PATS Research Group
17-10-2020
16
17
Push and pull

• Push connection
• Source pushes packets downstream
• Triggered by event, such as packet arrival
• Denoted by filled square or triangle

• Pull connection
• Destination pulls packets from upstream
• Packet transmission or scheduling
• Denoted by empty square or triangle

• Agnostic connection
• Becomes push or pull depending on peer
• Denoted by double outline

PATS Research Group
17-10-2020
17
18
Push and pull violations
PATS Research Group
17-10-2020
18
19
Implicit queue v. explicit queue

• Implicit queue
• Used by STREAM, Scout, etc.
• Hard to control

• Explicit queue
• Led to push and pull, Clicks main idea
• Contributes to high performance

20
IP router configuration
PATS Research Group
17-10-2020
20
21
Click performance, circa 2000
MLFFR with 64-byte packet 333k, 284k, 84k for
Click, Linux w/ polling driver, Plain Linux
22
Improving software router performanceexploiting
parallelism

• Can you build a Tbps router out of PCs running
  Click?
• Not quite, but you can get close
• RouteBricks high-end software router
• Parallelism across servers and cores
• High-end servers NUMA, multi-queue NICs
• RB4 prototype
• 4 servers in full mesh acting as 4-port
  (10Gbps/port) router
• 4 ? 8.75 35Gbps
• Linearly scalable by adding servers (in theory)

• Dobrescu, M., Egi, N., Argyraki, K., Chun, B.,
  Fall, K., Iannaccone, G., Knies, A., Manesh, M.,
  and Ratnasamy, S. RouteBricks exploiting
  parallelism to scale software routers, SOSP 2009
• Bolla, R. and Bruschi, R., PC-based software
  routers high performance and application service
  support, PRESTO 2008

23
Improving software router performancespecialized
hardware
NetFPGA
Network processor

• Jad Naous, Glen Gibb, Sara Bolouki, Nick McKeown,
  NetFPGA Reusable Router Architecture for
  Experimental Research, PRESTO 2008
• Spalink, T., Karlin, S., Peterson, L., and
  Gottlieb, Y., Building a robust software-based
  router using network processors, SOSP 2001
• J. Turner, P. Crowley, J. Dehart, A. Freestone,
  B. Heller, F. Kuhms, S. Kumar, J. Lockwood, J.
  Lu, M.Wilson, C. Wiseman, D. Zar, Supercharging
  PlanetLab A High Performance,
  Multi-Application, Overlay Network Platform,
  SIGCOMM 2007
• Tilman Wolf, Challenges and applications for
  network-processor-based programmable routers,
  IEEE Sarnoff Symposium, Princeton, NJ, Mar. 2006

24
Commercial hardware routerJuniper
Control plane
Routing Engine (RE)
Switch Control Board (SCB)

• RE
• x86 PC running JUNOS
• PFE
• ASIC hardware and microcode
• MS-PIC
• MIPS64-based XLR network processor
• Each runs separate JUNOS
• JUNOS
• FreeBSD-based OS for all Juniper routers

Packet Forwarding Engine (PFE)
Multi-Services Module (MS-PIC)
Multi-Services Module (MS-PIC)
Forwarding plane
25
Extending commercial routerJUNOS SDK

• RE SDK
• Servers and management daemons running on RE
• Services SDK
• Data path apps running on MS-PIC
• Packet processing with zero-copy API at line rate
• 32 (virtual) CPUs
• 8 cores ? 4 hardware threads
• Data threads bound to dedicated CPUs to eliminate
  context switch

• James Kelly, Wladimir Araujo, Kallol Banerjee,
  Rapid Service Creation using the JUNOS SDK,
  PRESTO 2009

26
Standardizing backplaneIETF ForCES WG
-------------------------------------------------

OSPF RIP BGP RSVP LDP . . .

---------------------------------------------
---- ForCES Interface
-------------------------------------------
------
ForCES data control
packets messages (e.g.,
routing packets) v v
-------------------------------------------------
ForCES Interface
-----------------------------------------------
--
LPM FwdMeter Shaper NAT Classi-. .
. fier
-------------------------------------------
------ FE resources
-----------------------------------------
-------- Examples of CE and FE
functions.

• Forwarding and Control Element Separation
  (ForCES)
• Protocols for (multiple) control elements (CE)
  and forwarding elements (FE)
• Separation can be switch fabric or LAN
• Interoperability between router components
• Would Cisco Juniper care?

• J. Salim, H. Khosravi, A. Kleen, A. Kuznetsov,
  Linux Netlink as an IP Services Protocol, RFC
  3549, July 2003
• H. Khosravi, Ed., T. Anderson, Ed., Requirements
  for Separation of IP Control and Forwarding, RFC
  3654, November 2003
• L. Yang, R. Dantu, T. Anderson, R. Gopal,
  Forwarding and Control Element Separation
  (ForCES) Framework, RFC 3746, April 2004
• Ran Giladi, Niv Yemini, A programmable, generic
  forwarding element (GFE) approach for dynamic
  network functionality, PRESTO 2009

27
Control plane detached OpenFlow

• Physical separation of control and forwarding
• Forwarding plane in L2
• Flow table instead of FIB
• More general than IP
• Switch exposes flow table though simple OpenFlow
  protocol
• Keep it simple
• Vendor can keep platform closed
• Use outboard device for packet processing

OpenFlow Controller
OpenFlow Protocol
SSL
Flow table
OpenFlow-enabled Layer-2 Switch
Matches subsets of packet header fields
Switch Port
MAC src
MAC dst
Eth type
VLAN ID
IP Src
IP Dst
IP Prot
TCP sport
TCP dport

• McKeown, N., Anderson, T., Balakrishnan, H.,
  Parulkar, G., Peterson, L., Rexford, J., Shenker,
  S., and Turner, J., OpenFlow enabling innovation
  in campus networks, SIGGCOMM Comput. Commun. Rev.
  38, 2 (Mar. 2008)

28
Slicing network virtualization

• NIC virtualization
• Solaris Crossbow
• Router virtualization
• Cisco Juniper logical routers
• Virtual Routers on the Move (VROOM)

Virtual router
Virtual router
Virtual router

• Tripathi, S., Droux, N., Srinivasan, T., and
  Belgaied, K., Crossbow from hardware virtualized
  NICs to virtualized networks, VISA 2009
• Eric Keller, Evan Green, Virtualizing the Data
  Plane through Source Code Merging, PRESTO 2008
• Yi Wang, Eric Keller, Brian Biskeborn, Jacobus
  van der Merwe, Jennifer Rexford, Virtual routers
  on the move Live router migration as a
  network-management primitive, SIGCOMM 2008

29
Extreme programmabilityActive networks
Discrete approach code installed out-of-band
Integrated approach packet carries code (capsule)

• Heated debate in the 90s
• Far-reaching vision, still relevant today

• Calvert, K., Reflections on network architecture
  an active networking perspective, SIGCOMM Comput.
  Commun. Rev. 36, 2 (Apr. 2006)
• David L. Tennenhouse, Jonathan M. Smith, W. David
  Sincoskie, David J. Wetherall, and Gary J.
  Minden, A Survey of Active Network Research, IEEE
  Communications Magazine, Vol. 35, No. 1, January
  1997
• David L. Tennenhouse, David J. Wetherall, Towards
  an active network architecture, SIGCOMM Comput.
  Commun. Rev. 26, 2 (Apr. 1996)

30
Hosting tomorrows in-network services NetServ

• Reviving active network vision
• Signaling-based code installation
• Latest isolation and virtualization technology
• Ubiquitous common API, from cable modem to Cisco
  router

• Suman Srinivasan, Jae Woo Lee, Eric Liu, Mike
  Kester, Henning Schulzrinne, Volker Hilt, Srini
  Seetharaman, Ashiq Khan, NetServ Dynamically
  Deploying In-network Services, ReArch 2009

31
NetServ - prototype

• Prototype
• Java OSGi on top of Click
• Click Modular router platform
• OSGi dynamic loading and unloading of modules

• Measurement
• Bare Linux vs. Plain Click
• Penalty for kernel-user transition
• Plain Click vs. NetServ
• Java overhead
• 2) is small compared to 1)

32
