Voice Translation Rules

1
Voice Translation Rules

• Digit manipulation using translation rules and
• voice translation rules in Cisco IOS

2
Presentation Goal

• The Goal of this presentation is to provide the
  team with fundamental understanding of digit
  manipulation using Translation rules and Voice
  Translation rules.

3
Learning objectives

• At the end of the presentation you should be able
  to
• Identify the difference between a translation
  rule and a voice translation rule.
• Implement, test and troubleshoot the different
  methods of digit manipulation outlined in the
  presentation.

4
Vocabulary

• Automatic Number Identification (ANI) This is
  the Calling Number.
• Dialed Number Identification Service (DNIS)
  This is the Called Number.
• Translation Rule A basic method of digit
  manipulation based on a matched string.
• Voice Translation Rule A more advanced method
  of digit manipulation using regular expressions.

5
Why we need digit manipulation

• Digit manipulation is used to help manage our
  number plans.
• Different PSTN providers may provide different
  quantities of digits to different sites. This
  could lead to overlaps in DN ranges between
  sites. So we use the various methods of digit
  manipulation to standardize them.
• In this presentation we will only cover IOS
  (Voice) translation rules.

6
IOS Translation Rules

• How we use translation rules
• We use them to expand 5 digit extensions to the
  full 10 digit extension that is on the phone.
• We only use them in SRST and H.323 dial peers.
• We can only have a max of 10 rules configured for
  1 translation rule.

7
IOS Translation Rules cont.

• A translation rule consists of 3 parts
• The translation rule itself
• Translation-rule 1
• The rules that make up the translation rule
• Rule 0 7. 904987
• Where the translation rule is applied
• Voice-port 3/023
• Translate called 1

8
IOS Translation Rules cont.

• The rule below takes an inbound 5 digit called
  number and expands it to a full 10 digits
• Configuration
• Translation-rule 1
• Rule 0 7. 904987
• Rule 1 4. 904464
• Voice-port 3/023
• Translate called 1
• Verification
• FLJVFB401R1test translation-rule 1 77486
• The replaced number 9049877486

9
IOS Translation Rules cont.

• Implementing translation rules on our network
• translation-rule 1 - defines the translation
  rule
• Rule 0 3 561393 - individual rules that are
  specified for translation-rule 1
• Rule 1 15 1002015
• Rule 9 2 561362
• config removed
• call-manager-fallback -SRST configuration where
  the translation rule is applied
• config removed
• transfer-pattern 3....
• transfer-pattern 561393....
• transfer-pattern 100201....
• transfer-pattern 9T
• transfer-pattern 561362....
• transfer-pattern 2....
• translate called 1 - applies the
  translation-rule 1 to the callED number and
  expands it according to the translation rule
• config removed

10
Voice Translation Rules

• Voice Translation Rules are used in the same
  manner as Translation Rules but they allow for a
  more granular manner of digit manipulation for
  the following reasons
• They use regular expressions.
• They allow up to 15 rules to be specified per
  voice translation rule.
• Configured in 4 parts similar to translation
  rules.

11
Voice Translation Rules cont.

• Using voice translation rules requires an
  understanding of regular expressions.

12
Voice Translation Rules cont.

• The 4 parts of a voice translation rule are
• The voice translation rule.
• The rules that make up the voice translation
  rule.
• The profile that defines where the rule
  manipulates the digits.
• Lastly where the profile is applied.

13
Voice Translation Rules cont.

• A basic voice translation rule.
• This will match any 4 digit string that starts
  with a 2 and then replace it with 9120212012
• Voice translation-rule 1 -Defining the Voice
  Translation Rule
• rule 1 /2/ /912012012/ -The rule that
  dictates the matches and what to do
• Voice-translation-profile OutgoingCalled -Defining
  the voice translation profile that will be
  applied
• translate called 1 -Which voice translation
  rule to match on and where to apply
• Dial-peer voice 100 pots
• destination-pattern 2
• port 3/023
• translation profile outgoing OutgoingCalled -Whic
  h profile to apply and whether to apply to
  incoming or outgoing

14
Voice Translation Rules cont.

• Using voice translation rules requires an
  understanding of regular expressions.
• (they use this crazy table)

15
Voice Translation Rules cont.

• Regular expressions can be complex and confusing.
  Some things to keep in mind are
• Begin and end any match or replacement string
  with /
• rule 1 /1234/ /5678/
• The match string can be made up of an explicitly
  defined string or wildcards, the replacement
  string cannot contain any wildcards.
• Use the to match from the beginning of a
  string.
• rule 3 /7./ /9048675309/
• Use the to match from the end of a string.
• rule 2 /4.\(4.\)/ /90446\1/
• The (\) escapes the next character in the
  string.
• /3\(\)/ /345\1/

16
Voice Translation Rules cont.

• If you want to match a wild card and not change
  them create a set.
• rule 4 /3\(\) /4\1/
• Any digits that are in the match string but are
  not explicitly matched by the match string are
  carried over to the match string unchanged.
• The following slide has examples of some regular
  expressions used in voice translation rules.

17
Voice Translation Rules cont.

• Voice translation-rule 1
• Rule 1 // /8776754345/ - matches a null string
  and replaces it with 8776754345
• Rule 2 /987\(.\)/ /464\1/ - matches 987
  something and prepends the set (.) with with 464
• Rule 3 /\(770\)\(.\)/ /678\2/ - matches 770
  then prepends 678 to the second set (.)
• Rule 4 /\(\)464\(.\)/ /\1987\2/ - changes the
  middle of the number from 464 to 987
• Rule 5 /\(.\)7399/ /\15309/ - matches on the
  beginning of a number and replaces the end

18
Voice Translation Rules cont.

• How we use Voice Translation rules on our
  network.
• Voice translation-rule 1
• Rule 1/105110./ /9089872345/ - matches the
  nonDID range and replaces it with the BTN
• Rule 2 /\904\)1.1\(.\)/ /\1987\2/ - matches on
  the NPA of the site and the first pseudo
  number range
• Rule 3 /../ /9089872345/ - matches on the
  intercom line if it tries to make an offnet call
  during SRST
• These are applied as outgoing to the voice
  translation-profile then that profile is
  associated to the SRST config.

19
Voice Translation Rules cont.

• How do we verify the Translation Rules and Voice
  Translation Rules?
• To test a translation rule from the IOS CLI
• test translation-rule 1 77486 - the 1 specifies
  which translation rule to test against 77486 is
  the the number used to test the rule
• The replaced number 9049877486
• To test a voice translation rule from the IOS CLI
• test voice translation-rule 3 4642946 - the 3
  specifies which translation rule to test against
  4642946 is Matched with rule 2 the number
  used to test the rule
• Original number 4642946 Translated
  number 9044642946
• Original number type none Translated number
  type none
• Original number plan none Translated number
  plan none

20
Summary

• (Voice) translation rules can be used in the IOS
  to manipulate the digits in a call.
• Voice translation rules use regular expressions
  to match digits.

21
For your reading pleasure

• Regular-expression tutorial.
• http//www.regular-expressions.info/
• Voice Translation Rules.
• http//www.cisco.com/en/US/tech/tk652/tk90/technol
  ogies_tech_note09186a0080325e8e.shtml
• Using IOS Translation Rules - Creating Scalable
  Dial Plans for VoIP Networks.
• http//www.ciscosystems.com/en/US/tech/tk652/tk90/
  technologies_configuration_example09186a0080094681
  .shtml
