Title: Technology Integration: RSerPool & Server Load-balancing


1
Technology Integration RSerPool Server
Load-balancing
  • Curt Kersey, Cisco Systems
  • Aron Silverton, Motorola Labs

2
Contents
  • Motivation
  • Background
  • Server Load-balancing
  • Server Feedback
  • RSerPool
  • Unified approach
  • Description
  • Sample Flows
  • Work Items

3
Assumptions / Terminology
  • All load-balancing examples will use TCP/IP as
    the transport protocol. This could easily be any
    other protocol (e.g., SCTP).
  • SLB Server Load-Balancer.
  • Virtual Server Virtual instance of application
    running on SLB device.
  • Real Server physical machine with application
    instances.

4
Motivation
  • Highly redundant SLB.
  • More accurate server pooling.

5
Server Load-balancing
6
What does a SLB do?
  • Gets user to needed resource
  • Server must be available
  • Users session must not be broken
  • If user must get to same resource over and over,
    the SLB device must ensure that happens (ie,
    session persistence)
  • In order to do work, SLB must
  • Know servers IP/port, availability
  • Understand details of some protocols (e.g., FTP,
    SIP, etc)
  • Network Address Translation, NAT
  • Packets are re-written as they pass through SLB
    device.

7
Why to Load-balance?
  • Scale applications / services
  • Ease of administration / maintenance
  • Easily and transparently remove physical servers
    from rotation in order to perform any type of
    maintenance on that server.
  • Resource sharing
  • Can run multiple instances of an application /
    service on a server could be running on a
    different port for each instance can
    load-balance to different port based on data
    analyzed.

8
Load-Balancing Algorithms
  • Most predominant
  • least connections server with fewest number of
    flows gets the new flow request.
  • weighted least connections associate a weight /
    strength for each server and distribute load
    across server farm based on the weights of all
    servers in the farm.
  • round robin round robin thru the servers in
    server farm.
  • weighted round robin give each server weight
    number of flows in a row weight is set just
    like it is in weighted least flows.
  • There are other algorithms that look at or try to
    predict server load in determining the load of
    the real server.

9
How SLB Devices Make Decisions
  • The SLB device can make its load-balancing
    decisions based on several factors.
  • Some of these factors can be obtained from the
    packet headers (i.e., IP address, port numbers,
    etc.).
  • Other factors are obtained by looking at the data
    beyond the network headers. Examples
  • HTTP Cookies
  • HTTP URLs
  • SSL Client certificate
  • The decisions can be based strictly on flow
    counts or they can be based on knowledge of
    application.
  • For some protocols, like FTP, you have to have
    knowledge of protocol to correctly load-balance
    (i.e., control and data connection must go to
    same physical server).

10
When a New Flow Arrives
  • Determine if virtual server exists.
  • If so, make sure virtual server has available
    resources.
  • If so, then determine level of service needed by
    that client to that virtual server.
  • If virtual machine is configured with particular
    type of protocol support of session persistence,
    then do that work.
  • Pick a real server for that client.
  • The determination of real server is based on flow
    counts and information about the flow.
  • In order to do this, the SLB may need to proxy
    the flow to get all necessary information for
    determining the real server this will be based
    on the services configured for that virtual
    server.
  • If not, the packet is bridged to the correct
    interface based on Layer 2.

11
SLB Architectures
  • Traditional
  • SLB device sits between the Clients and the
    Servers being load-balanced.
  • Distributed
  • SLB device sits off to the side, and only
    receives the packets it needs to based on flow
    setup and tear down.

12
SLB Traditional View with NAT
Server1
Server2
SLB
Client
Server3
13
SLB Traditional View without NAT
Server1
Server2
SLB
Client
Server3
14
Load-Balance Layer 3 / 4
  • Looking at the destination IP address and port to
    make a load-balancing decision.
  • In order to do that, you can determine a real
    server based on the first packet that arrives.

15
Layer 3 / 4 Sample Flow
Server1
Server2
SLB
Client
2 SLB makes decision on Server
Server3
Rest of flow continues through HTTP GET and
Server response.
16
Load-Balance Layer 5
  • The SLB device must terminate the TCP flow for an
    amount of time BEFORE the SLB decision can be
    made.
  • For example, the cookie value must be sent by the
    client, which is after the TCP handshake before
    determining the real server.

17
Layer 5 Sample Flow
Server1
Server2
SLB
Client
Server3
2 SLB device determines it must proxy flow
before decision can be made.
Rest of flow continues with Server
response. Note the flow can be unproxied at this
point for efficiency.
18
SLB Distributed Architecture
FE
Server
FE
Server
Client
Server
FE
FE Forwarding Engines, which are responsible
for forwarding packets. They ask the SLB
device where to send the flow.
SLB
19
Distributed Architecture Sample Flow
Server1
FE
Client
Server2
2 FE asks where to send flow.
Server3
SLB
Server4
Subsequent packets flow directly from Client to
Server2 thru the FE. The FE must notify the SLB
device when the flow ends.
20
Server Feedback
21
Determining Health of Real Servers
  • In order to determine health of real servers, SLB
    can
  • Actively monitor flows to that real server.
  • Initiate probes to the real server.
  • Get feedback from real server or third party box.

22
Server Feedback
  • Need information from real server while it is a
    part of a server farm.
  • Why?
  • Dynamic load-balancing based on ability of real
    server.
  • Dynamic provisioning of applications.

23
Server Feedback Use of Information
  • Availability of real server is reported as a
    weight that is use by SLB algorithms (e.g.,
    weighted round robin, weighted least
    connections).
  • As weight value changes over time, the load
    distribution changes with it.

24
How to Get Weights
  • Statically configured on SLB device never
    change.
  • Start with statically configured value on SLB
    device for initial start-up, then get weight
    from
  • Real server
  • Third party box / Collection Point
  • It is assumed that if a third party box is being
    used, it would be used for all the real servers
    in a server farm.

25
Direct Host Feedback
  • Description Have agents running on host to
    gather data points. That data is then sent to
    SLB device just for that physical server.
  • Note agent could report for different
    applications on that real server.
  • Agent could be based on available memory, general
    resources available, proprietary information, etc.

26
Direct Host Feedback
  • Pros
  • Have some way to dynamically change physical
    servers capability for SLB flows.
  • Cons
  • SLB device must attempt to normalize data for all
    real servers in a server farm. If have
    heterogeneous servers, it is difficult to do.
  • Difficult for real server to identify itself in
    SLB terms for case of L3 vs. L4 vs. L5, etc SLB
    scenarios.

27
Third Party Feedback Network
Server1
Server2
SLB
Client
Server3
Collection Point
28
Host to Third Party Feedback
  • Description Real servers report data to a
    collection point. The collection point
    system can normalize the data as needed, then it
    can report for all physical servers to the SLB
    device.
  • Pros
  • Have a device that can analyze and normalize the
    data from multiple servers. The SLB device can
    then just do SLB functionality.
  • Cons
  • Requires more communication to determine dynamic
    weight could delay the overall dynamic affect
    if it takes too long.

29
RSerPool
30
RSerPool Architecture
ASAP
PE
ASAP
PE
PU
PE
31
RSerPool Overview
  • RSerPool protocols sit between the user
    application and the IP transport protocol
    (session layer).
  • The application communication is now defined over
    a pair of logical session layer endpoints that
    are dynamically mapped to transport layer
    addresses.
  • When a failure occurs at the network or transport
    layer, the session can survive because the
    logical session endpoints can be mapped to
    alternative transport addresses.
  • The endpoint to transport mapping is managed by
    distributed servers providing resiliency.

32
RSerPool / SLB Unified Approach(A Work in
Progress)
33
Unified View Overview
  • Preserve the RSerPool architecture
  • Any extensions or modifications are backwards
    compatible with current RSerPool.
  • SLB extensions at ENRP Server and PE are optional
    based on pool policy chosen / implemented.
  • Utilize SLB distributed architecture
  • Introduce FE when using SLB pool policies.
  • Add SLB technology to the ENRP Server
  • SLB-specific versions of pool policies.
  • SLB-ltpool_policygt example SLB-WRR takes into
    account additional host feedback such as number
    of flows on each PE.
  • Add server feedback
  • Enable delivery of host feedback from PEs to home
    ENRP Server.
  • Enable delivery of host feedback to FE from ENRP
    Server.

34
Unified Component Description
  • ASAP
  • Between PE and ENRP Server is extended to include
    additional host feedback such as current number
    of flows on PE.
  • Encapsulation of host feedback protocol in pool
    element parameter.
  • Information will be replicated among peer ENRP
    Servers.
  • Subscription service and/or polling between ENRP
    Server and PU allows delivery of host feedback
    (membership, weights, flows, etc).
  • Subscription is between PU and current ENRP
    Server (not replicated).
  • PU must be re-register subscription upon
    selection of new ENRP Server.
  • Subscription and polling service previously
    discussed in design team as an addition to core
    ASAP functionality.
  • Make decision on flow destination based on
    SLB-specific pool policy (i.e., load-balancing
    algorithm).

35
Unified Component Description
  • FE
  • RSerPool enabled application (PU)
  • Uses RSerPool API for sending flows to PE.
  • ASAP control plane for PE selection.
  • Bearer plane uses flow-specific protocol (e.g.,
    HTTP, SIP, etc) and corresponding transport
    (e.g., TCP, SCTP).
  • Must know which pools support which applications
    (SLB-types).
  • Add parameter to SLB-enabled PEs?
  • Choose pool handle based on incoming client
    requests and supported SLB-types (SLB-L4,
    SLB-HTTP, SLB-SIP, etc).
  • If no other SLB-type matches, the SLB-L4 will be
    used.
  • NAT, reverse NAT.
  • Proxy service.

36
Unified Component Description
  • FE (continued)
  • Configuration
  • Server Pools
  • Static configuration of pool handles pool names
    are resolved upon initialization.
  • Static configuration of pool handles and PE
    detail, including initial/default weights.
  • Automagic configuration?
  • Protocol Table
  • Maps supported SLB-types to pool handles by
    looking for best match in incoming packet, e.g.,
  • SLB-L4 (must implement).
  • SLB-HTTP.
  • SLB-SIP.

37
Unified Component Description
  • PE
  • SLB-enabled PEs must support dynamic host
    feedback.

38
Unified Layer 3/4 Example
PE1
2 Correlate request to SLB-type then choose
pool handle. Then do a send to that pool handle.
PU / FE
Client
PE2
ASAP Pool handle resolution subscription/polling
.
PE3
ASAP with host feedback
ENRP Server
ENRP Server
39
Server Feedback How to Implement with RSerPool
40
Unified PE Communication
  • PEs will send their weights to ENRP server via
    ASAP protocol.
  • Server agent on host provides weight to PE
    application.
  • There are some protocols that exist for reporting
    this information. The current list
  • Server/Application State Protocol, SASP
  • Joint IBM / Cisco Protocol.
  • IETF draft is currently available.
  • Dynamic Feedback Protocol, DFP
  • Cisco developed Protocol.
  • IETF draft is in progress.

41
Design Team Work Items
42
How to Implement To Do List
  • Details, Details, Details .....
  • Reconcile design with pool policy draft
  • Determine what information needs to be passed.
  • Determine what algorithms need to be added where.
  • Define SLB-ltpool policiesgt.
  • Determine best method for implementation of host
    feedback.
  • Complete Layer 5 example with session persistence
    mechanism at FE.

43
How to Implement To Do List
  • Polling / Subscriptions.
  • Complete DFP IETF draft, so it can be considered.
  • Everything else.
Write a Comment
User Comments (0)
About PowerShow.com
