Pediatric Airway Management

1
Pediatric AirwayManagement

• SNOHOMISH COUNTY EMS

2
OBJECTIVES

• Anatomy
• Physiology
• Equipment
• Establish respiratory distress present
• Technique
• Post intubation management
• Pitfalls and Pearls
• Difficult airway

3
ANATOMY

• Unique lt2 years old
• Approaches normal adult airway by 8 years old
• Glottic opening high and anterior
• C1, transitions to C3/4, then C5/6 by adulthood
• More soft tissue, less tone

4
Consider copying fig 20-2 p 270 here
5
ANATOMY

• Large tongue in relation to oral cavity
• Large tonsils and adenoids that can bleed (no
  blind nasotracheal intubations)
• Angle of epiglottis to laryngeal opening more
  acute

6
ANATOMY

• Large occiput/cranium flexes the neck
• Avoid further neck flexion
• Use sniffing position
• Neck flexed, head extended

7
(No Transcript)
8
ANATOMY

• Small cricothyroid membrane
• lt3-4 years old almost nonexistant
• gt8 similar to adults
• No surgical cricothyroidotomy lt8
• Cricoid ring most narrow part of airway (below
  vocal cords)

9
PHYSIOLOGY

• Smaller floppy upper airway more likely to
  obstruct and more susceptible to swelling
• Resistance is inversely proportional to radius
• R ? 1/r4th power
• Small decrease in airway sizelarge increase in
  airway resistance

10
PHYSIOLOGY

• Crying increases the work of breathing 32 times
• Basal O2 requirement 2x that of adults
• FRC (functional residual capacity) 40 of adults
• Only half the alveoli of adults
• Overall, less reserve and faster desaturations

11
EQUIPMENT

• Length based systems
• Decrease errors
• Eliminate remembering and completing mathematical
  equations
• Organize equipment

12
BROSELOW SYSTEM
13
(No Transcript)
14
EQUIPMENT

• Self inflating bags smallest 450ml
• Pop off valves that may have to be closed
• Newborn equipment different than peds (0 blades,
  lt50mm oral airways, 250ml BVM, 3-0 tubes)

15
RESPIRATORY DISTRESS

• Rapid 30 second assessment
• T one
• I nteractive
• C onsolablity
• L ook/track
• S peech/cry

16
RESPIRATORY DISTRESS

• Altered mental status
• Nasal flaring
• Head bobbing
• Accessory muscle use
• Grunting

17
(No Transcript)
18
(No Transcript)
19
RESPIRATORY DISTRESS

• You must undress the patient
• Retractions
• Substernal
• Intercostal
• Supraclavicular
• Suprasternal

20
RESPIRATORY DISTRESS

• Infants are nose breathers
• Secretions can impeded air flow
• Bulb syringe nasal suction may alleviate this

21
RESPIRATORY FAILURE

• Impending respiratory arrest
• All of the above signs diminish
• Respiratory rate diminishes
• Mental status diminishes
• Child becomes quiet
• Mottling may develop

22
TECHNIQUEMEDICATIONS

• Succinylcholine
• Dose higher at 1.5mg/kg
• Etomidate
• 0.3mg/kg
• Fentanyl
• 1-3mcg/kg consider for age gt10 and head injury

23
TECHNIQUEMEDICATIONS

• Vecuronium
• 0.1mg/kg
• Rocuronium
• 1mg/kg

24
TECHNIQUE MEDICATIONS

• Atropine
• Routine use not recommended
• Should be available and prepared in case it is
  needed (more common in children lt1)
• 0.02mg/kg

25
TECHNIQUE HEAD POSITION

• Sniffing position
• Slight anterior displacement of neck (pulling
  chin up)
• Small infants may require elevation of shoulders
  with a towel to counteract a large occiput
  flexing head
• Older children may require a towel under the head
• Goal is to align ear canal anterior to shoulders
• Head tilt chin lift or Jaw thrust (trauma
  patients)

26
Picture Fig 21-1 page 284
27
TECHNIQUE OXYGEN SUPPLEMTATION

• Oxygen may be delivered by
• Blow by
• Nasal cannula
• Face mask
• Forcing the child to struggle with nasal cannula
  oxygen increase oxygen demand
• Blow by may suffice

28
TECHNIQUE BVM

• BVM alone may suffice for short transports
• Pediatric airway obstruction usually amenable to
  BVM
• The extra thoracic trachea is collapsible in
  children, so with increased negative pressure
  from inspiration during obstruction, obstruction
  may become worse and BVM may help

29
TECHNIQUE BVM

• Dont compress submental tissue
• Hold angle of mandible
• Use C-Clamp technique (solo)
• Use 2 providers when possible
• Dont put pressure on eyes (causes vagal
  response)

30
(No Transcript)
31
TECHNIQUE BVM

• Normal tidal volume 8-10ml/kg
• Watch for adequate chest rise
• Squeeze-Release-Release to allow for exhalation
• Only use enough force to see chest rise
• 8-10 BPM code, 12-20 alive (monitor end tidal CO2)

32
TECHNIQUE BVM

• Avoid gastric insufflation
• Avoid excessive peak inspiratory pressure
• Ventilate slowly and watch for chest rise
• Slight cricoid pressure (excessive will compress
  trachea in peds)

33
TECHNIQUE BLADES

• Follow Broselow guide
• Miller straight blade better until about age 5
• Lifts disproportionately large epiglottis out of
  way

34
TECHNIQUE CRICOID PRESSURE

• Insufficient evidence to routinely recommend
  cricoid pressure during intubation (as opposed to
  BVM)

35
TECHNIQUE LAYNGEAL MANIPULATION

• Use as needed
• Frequently
• B ackward
• U pward
• R ightward
• P ressure

36
TECHNIQUE TUBES

• Use Broselow guide
• Be prepared with tubes 0.5mm larger and smaller
• Narrowest part of airway is below cords
• If tight, use smaller tube
• If large air leak, use larger tube or same size
  tube with cuff
• Small air leak, no worries if adequate chest
  rise, O2 sat, end tidal CO2

37
TECHNIQUE TUBES

• Cuffed tubes
• Are OK
• Cuff pressure needs to be monitored (20-25cm
  water)
• Dont have to be inflated
• In general, go a size smaller if using cuffed
  tube for size lt6.0
• Too large a tube/too high cuff pressure)laryngeal
  tracheal stenosis which can develop rapidly

38
(No Transcript)
39
TECHNIQUE TUBES

• Tube insertion depth
• Follow Broselow
• 3x size of tube (4.0 ETT12cm insertion length at
  teeth)
• Secure tube, immobilize neck, as short trachea
  predisposes to moving tube too far in with neck
  flexion, and out with neck extension

40
TECHNIQUE CONFIRM PLACEMENT

• Tube fogging
• B/L breath sounds
• Silent epigastrum
• End Tidal CO2
• Pulse ox

41
TECHNIQUE END TIDAL CO2

• Peds detectors up to 15kg (adult detectors have
  too much dead space in circuit)
• Adult detectors over 15kg (peds detectors will
  cause too much resistance

42
TECHNIQUE END TIDAL CO2

• In cardiac arrest
• If lt10-15mmHg, focus on improving CPR and avoid
  over ventilation
• An abrupt and sustained increase may signal
  return of spontaneous circulation
• In non arrest
• Titrate to clinical condition (35-45 unless head
  injury/impending herniation 25-30)

43
POST INTUBATION MANAGEMENT

• Adequate sedation
• Benzodiazepines
• Diazepam 0.2mg/kg (max 10mg/dose)
• Lorazepam 0.05mg/kg (max 2mg/dose)
• Midazolam 0.1mg/kg (max 2mg/dose)
• Opiates
• Fentanyl 1-3mcg/kg (max 50mcg/dose)
• Morphine 0.05-0.2mg/kg (max 5mg/dose)
• Paralytics as needed
• Rocuronium 1mg/kg
• Vecuronium 0.1mg/kg

44
POST INTUBATION MANAGEMENT

• Problems
• D isplacement of tube (confirm placement)
• O obstruction of tube (pass suction catheter)
• P neumothorax
• E quipment failure (unhook from vent, check O2)

45
PITFALLS AND PEARLS

• Performance anxiety
• Equipment stocking and testing
• Troubleshooting
• Periodic training and practice

46
DIFFICULT AIRWAY

• Infectious disease causes
• Noninfectious causes including trauma
• Congenital abnormalities

47
DIFFICULT AIRWAY INFECTIOUS DISEASE

• Epiglottitis
• Croup
• Retropharyngeal abscess
• Bacterial Tracheitis
• Ludwigs angina

48
DIFFICULT AIRWAY INFECTIOUS DISEASE

• Small changes in airway diameter have a large
  impact on airway resistance
• Crying increases work of breathing 32 times
• Dont over treat

49
EPIGLOTTITIS

• If stable, leave patient with parent in position
  of comfort
• 2 person bag valve mask ventilation can be
  sufficient
• If needed, intubation can be attempted with a
  smaller than predicted tube
• Push on chest to try to see bubbles coming from
  airway if visualization obstructed
• One of the few indications for needle
  cricothyrotomy if all else fails

50
(No Transcript)
51
(No Transcript)
52
CROUP

• Subglottic narrowing
• Tube may fit through cords, but then get snug
• Use smaller than expected tube
• BVM can work, but requires 2 people and possible
  high pressure

53
(No Transcript)
54
DIFFICULT AIRWAY NONINFECTIOUS DISEASE

• Foreign body
• Burns
• Anaphylaxis
• Caustic ingestion
• Trauma

55
FOREIGN BODY

• Conscious
• Consider doing nothing if patient stable
• Back blows less than age 1 year
• Heimlich (age greater than 1)
• Unconscious
• BVM may work
• Direct laryngoscopy
• Removal of object
• Push it down and move the tube back to normal
  position
• Needle cricothyrotomy will only work if
  obstruction is above the cricothyrotomy level
  (you should see it but cant remove it)

56
(No Transcript)
57
(No Transcript)
58
BURNS, ANAPHYLAXIS, CAUSTIC INGESTIONS, TRAUMA

• If condition is decompensating and/or not
  responding to treatment, consider early
  intervention
• Should consider medications first in anaphylaxis

59
CONGENITAL ABNORMALITITES

• Dont try unless you have to
• May be more reasonable to support until
  respiratory failure/arrest has occurred
• Treat for causes of respiratory distress

60
CONGENITAL ABNORMALITITES MICROGNATHIA

• Small mandible reduces the space to which the
  tongue and soft tissue can be displaced out of
  your way

61
(No Transcript)
62
DIFFICULT AIRWAY ADJUNCTS

• LMA
• Needle cricothyrotomy
• Combitube/King LT

63
DIFFICULT AIRWAY LMA

• Can be used in all ages
• In small infants more complications
• Causes obstruction with relatively large
  epiglottis
• Easy to lose adequate seal with movement
• Air leaks
• Recommend inserting upside down and rotating it
  as advanced back
• Not for foreign bodies, caustics, burns

64
(No Transcript)
65
NEEDLE CRICOTHYROTOMY

• For use when you cant intubate or ventilate
• For use in children lt8-10 years old
• Not helpful for croup or distal foreign bodies

66
NEEDLE CRICOTHYROTOMY

• Extend head, towel under shoulders
• Identify landmarks
• Insert catheter (14g) over the needle at a 30
  degree angle directed toward feet
• Aspirate air
• Slide catheter off needle and remove needle
• Attach 3mm ETT adapter and begin BV

67
NEEDLE CRICOTHYROTOMY

• Will require excessive force due to small
  catheter diameter
• Pop off valve should be disabled
• Does not protect airway
• Does not allow for adequate ventilation, only
  oxygenation

68
(No Transcript)
69
NEEDLE CRICOTHYROTOMY

• Complications
• Inappropriate needle placement
• Inadequate ventilation (hypercarbia and acidosis)
• Obstruction of small catheter
• Subcutaneous emphysema

70
NEEDLE CRICOTHYROTOMY

• TTV
• For use gt5 years
• Supraglottic patency required to allow for
  exhalation (air stacking)
• Barotrauma
• Start with 20 PSI and adjust to chest rise
• Requires no more than of 1 second inspiration,
  then 3 seconds to exhale
• Nasal/oral airway should be placed as well

71
(No Transcript)
72
COMBITUBE/KING LT

• Double/single lumen tube designed to be place in
  esophagus
• Must be 4ft tall for small Combitube
• May not protect against aspiration
• Not for caustic ingestion or significant
  esophageal pathology

73
(No Transcript)
74
(No Transcript)
