FISCHER PORTER REBUILD

1
FISCHER PORTER REBUILD
HPD THE NEXT GENERATION
2
SUTRON MANUAL
SOLAR PANEL MOUNT
BATTERY
PRECIP RECORDER
SD CARD
SOLAR PANEL
TOOLS MISC.
LOAD CELL
3
BASEPLATE (BOTTOM)
SHIPPING SCREW
DASHPOT/ LOADCELL MOUNTING
4
LOAD CELL MOUNTED
FRONT OF BASE
5
LOOSEN SET SCREWS TO INSERT SCREWS FOR LOAD CELL
SCREW
6
ALLEN HEAD SCREWS
7
FRONT VIEW OF LOAD CELL
8
SIDE VIEW OF LOAD CELL
9
LOAD CELL PLUNGER MOUNTED
10
PLUNGER
LOADCELL
11
PLUNGER CENTERED
12
ADJUSTING SCREWS (4)
13
PRECIP RECORDER MOUNTED
GROUND ATTACHED
BATTERY CABLE
14
PRECIP RECORDER MOUNTING SCREWS
15
ENSURE CLEARANCE
16
ATTACH LOADCELL CABLE
17
CHECK BATTERY VOLTAGE - 12.5V
18
INSIDE PRECIP RECORDER
BATTERY CABLE
NOT USED
SOLAR PANEL CABLE
19
CHECK VOLTAGE FOR BATTERY
BATTERY CABLE
20
SOLAR PANEL CONNECTIONS
CHECK VOLTAGE
WIRE TO SOLAR PANEL
21
(No Transcript)
22
COMPUTER CONNECTION
GROUND
LOAD CELL
SOLAR PANEL
BATTERY
23
SOLAR PANEL MOUNT
24
(No Transcript)
25
(No Transcript)
26
SD CARD ACCESS
27
COMPUTER ACCESS
28
DOWNLOAD TO SD CARD
INSERT CARD
29
PRESS SET TO SELECT LAST OF DAYS
30
DEFAULT 60 DAYS PRESS SET
31
DOWNLOAD COMPLETE REMOVE CARD
32
CALIBRATION CHECK 1) REMOVE HOOD 2) PLACE BAR ON
BUCKET
3) LET READING STABILZE READ 4) PLACE 5 INCH
WEIGHT, LET READING STABILZE 5) DIFFERENCE
IN READINGS SHOULD BE 5.0 (/- 0.2)
