CIVIL AIR PATROL

1
CIVIL AIR PATROL United States Air Force
Auxiliary Maxwell Air Force Base, Alabama
2
DisclaimerThis presentation is for the
exclusive use of the Civil Air Patrol and is not
to be used for sale or profit.
3
AIRCRAFT SYSTEMS AND AIRPORTS

• Aerospace Dimensions

MODULE 2
By Patrick B. Smith, Washington Wing, CAP
4
Chapter 1 - Airplane Systems

• Upon completion of this chapter, the cadet should
  know
• Explain how a reciprocating engine operates
• Identify parts of the airplane engine when viewed
  externally
• Describe how a jet engine operates
• Identify basic cockpit-mounted power-plant
  controls.
• Identify basic flight instruments

5
Important Terms - Speaking the Language of
Airplane Systems

• power-plant - a term which applies to the
  airplanes engine and its accessories
• reciprocating - a type of engine that processes
  air and fuel by a back and forth movement of its
  internal parts
• cycle - a recurring series of event. The
  airplane engine has four cycles intake,
  compression, power and exhaust
• combustion - the chemical process of burning
• combustion chamber - an enclosed container in
  which fuel and air are burned for the production
  of energy
• stroke - the movement of the piston, within the
  combustion chamber, to its limits

6
Important Terms - Speaking the Language of
Airplane Systems

• compression - the act of making a given volume of
  gas smaller
• stoichiometric - a ration of fuel to air in
  which, upon combustion, all the fuel is burned
• rich mixture - a mixture of gasoline an air in
  which there is more gasoline and less air than
  needed for normal combustion
• lean mixture - a mixture of gasoline and air in
  which there is less fuel and more air
• fuel - a chemical substance which is used as a
  source of energy
• meter/metering - the process of allowing a
  precise amount of fuel to pass

7
(No Transcript)
8
THE AIRPLANES ENGINE

• Every internal combustion engine must have
  certain basic parts in order to change heat into
  mechanical energy. These are the cylinder,
  intake valve, exhaust valve, piston and
  connecting rod.

9
Modern Aircraft Powerplant Operation
10
Modern Aircraft Powerplant Operation

• Cylinder Arrangements

11
Converting Chemical Energy to Mechanical Energy
12
Comparing the Reciprocating, Jet and Rocket
Engines
13
Comparing the Reciprocating, Jet and Rocket
Engines
14
Comparing the Reciprocating, Jet and Rocket
Engines
15
The Chemistry of Power
An airplane engine is a heat engine. IT
converts heat energy into mechanical energy and
its the mechanical energy that turns a propeller.
16
The Gravity System Common General Aviation
Aircraft
17
(No Transcript)
18
The Pitot-Static System
19
(No Transcript)
20
Pratt Whitney F100-PW-229
21
Airplane Instrumentation
22
The Cessna 182s Flight Deck
23
The Larger the Aircraft, the Flight Instruments
Remain Basically the Same Like in this B-36J
24
The Flight Engineers Station on the B-36J. The
Invention of the Jet Engine eliminated over 200
Individual Instruments.
25
Douglas DC-8s Front Office
The Boeing 747s
26
The instruments may not change, but their form
sure has. The mechanical dials and gauges are
replaced with computer screens and digital
displays. Take a look at the Next Generation
Glass Cockpit on the Boeing 777.
27
Chapter 2 - Airports

• Upon completion of this chapter, the cadet should
  know
• Explain the basic layout of a general aviation
  airport
• Identify taxiway and runway signs and markings
• Explain the role of the Federal Aviation
  Administration in controlling air traffic
• Identify the different phases of the flight
  profile
• List the phonetic alphabet

28
Important Terms - The Language of Airports

• ATC - air traffic control
• beacon - a tower-mounted, large rotating light
  at an airport
• controlled airport - an airport with an operating
  control tower
• control tower - a structure that houses air
  traffic controllers
• course - the intended path of flight, measured in
  angular degrees from true or m magnetic north
• FAA - Federal Aviation Administration
• FSS - Flight Service Station

29
Important Terms - The Language of Airports

• heading - the direction that an airplane points,
  with respect to true or magnetic north,
  including any wind displacement
• noise abatement - a policy set forth by a
  governing body that controls the noise impact
  upon a community surrounding an airport
• ramp - the airports parking lot
• runway - a dedicated pathway for taking off and
  landing airplanes
• runway heading - a magnetic number that
  corresponds with the runway
• segmented circle - a set of indicators, usually
  surrounding an airports wind sock, that provide
  traffic pattern information to a pilot in the air

30
The Airport Environment

31
(No Transcript)
32
THE FLIGHT PROFILE
33
RUNWAY MARKINGS
34
RUNWAY MARKINGS
35
(No Transcript)
36
AIRPORT LIGHTING
37
WIND DIRECTION INDICATORS
38
RADIO COMMUNICATIONS AT AIRPORTS

• ALFA
• BRAVO
• CHARLIE
• DELTA
• ECHO
• FOXTROT
• GOLF
• HOTEL
• INDIA

• JULIET
• KILO
• LIMA
• MIKE
• NOVEMBER
• OSCAR
• PAPA
• QUEBEC
• ROMEO

• SIERRA
• TANGO
• UNIFORM
• VICTOR
• WHISKEY
• XRAY
• YANKEE
• ZULU

39
Chapter 3 - Airport to Airport - Aeronautical
Charts

• Upon completion of this chapter, the cadet should
  know
• Describe the basic layout of a sectional chart
• Explain the sectional chart legend
• Identify latitude and longitude lines
• Identify features such as railroads, pipelines,
  obstructions and highways
• Identify all of the information given about an
  airport

40
Important Terms - The Language of Charts

• cartography - the art and science of creating
  charts and maps
• chart - a projection, usually on paper, showing a
  body of land and other features such as water.
  The chart gives information, usually in the form
  of symbols, graphs or illustrations
• fix- the intersection of two lines of position
• latitude - a system of lines that run parallel to
  the equator, also know as parallels
• line of position (LOP) - the concept that an
  airplane is located somewhere along a given line
• longitude - a system of lines, know as meridians,
  between the north and south poles
• map - a representation of the surface of the
  Earth (or of the sky/space above
• nautical mile - a unit of length that is
  approximately 3076 feet

41
Important Terms - The Language of Charts

• projection - a method of transferring a portion
  of the Earths surface onto a flat chart. The
  most widely used in aeronautical charts is the
  Lambert Conformal Conic
• relief - a term used to describe elevations. A
  relief is depicted by color tints, contour lines
  and shading
• sectional - a chart specifically designed for
  aviation use and Visual Flight Rules. The scale
  is 1500,000 or approximately 8 statute miles to
  one inch
• scale - the size of an item, ore area, on a
  chart, compared to it in actuality
• statute mile - a unit of length that is 5,280
  feet
• tick - a small, or abbreviated mark on a line
• WAC - World Aeronautical Chart. Covers a larger
  area than the sectional chart. The scale is
  11,000,000 or 16 statute miles per one inch

42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
A SYSTEM OF GLOBAL ORGANIZATION
46
Sectional Aeronautical Charts
47
Sectional Aeronautical Charts
48
The Legend and Its Symbols
49
MAY YOU ALMOST ALWAYS NEVER FLY HORIZONTAL!
Are there any questions?
