CHRONIC MYELOGENOUS LEUKEMIA The Story Never Ends…

1
CHRONIC MYELOGENOUS LEUKEMIAThe Story Never
Ends
2
Clinical Presentation of CML

• Asymptomatic in 50 of cases
• Common Symptoms Common Signs
• Fatigue Palpable splenomegaly
• Weight loss/anorexia
• Abdominal fullness
• Common Laboratory Findings
• Abnormal differential
• Anemia
• Leukocytosis
• Basophilia
• Thrombocytosis

3
CML Peripheral Blood Smear
Normal
Chronic phase CML
4
Clinical Course Phases of CML
Advanced phases
Chronic phase Median duration 56 years
Accelerated phase Median duration69 months
Blast crisis Median survival36 months
5
Ph Chromosome
6
the Ph Chromosome
1
2
3
4
5
6
7
8
10
11
9
12
13
14
15
16
17
18
19
20
21
22
x
Y
7
(No Transcript)
8
Bcr-Abl Signal Transduction Pathways
Adapted from Kantarjian H et al. Hematology.
200090-109.
9
Evaluation of Response to Rx. in CML Patients
MOLECULAR
CYTOGENETIC
HEMATOLOGICAL
10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
DETECTION OF MINIMAL RESIDUAL DISEASE IN LEUKEMIA

14
METHODOLOGIES FOR DETECTING MRD

• Conventional cytogenetics
• FISH
• Nucleic acid amplification techniques
• Qualitative RT-PCR
• Quantitative RT-PCR

15
DO YOU PREFER QUALITY TO QUANTITY???
Mathematics is the science of pure quantity but
what about medicine?
16
METHODS TO DETECT MRD IN LEUKEMIA
17
In the present mangament of leukemias I prefer
quantity to quality
It is the real time for real-time PCR
18
Changes in Cytogenetic and Molecular Findings in
a Patient Responding to Rx.
19
Historical Rx. for CML

• Palliative
• Arsenic trioxide 1865
• Spleen irradiation - 1903
• Busulfan -1953
• Hydroxyurea -1966
• Interferon alfa ARA -C -mid - 1980s
• Curative
• BMT - alloBMT - 1970s

20
(No Transcript)
21
NOVEL THERAPEUTIC OPTIONS IN HEMATOLOGIC
MALIGNANCIES
22
DRUGS DONT JUST POP OFF THE SHELVES
!!!Specificity in drug development
23
Bcr-Abl Signal Transduction Pathways
Adapted from Kantarjian H et al. Hematology.
200090-109.
24
IMATINIB
25
(No Transcript)
26
(No Transcript)
27
Drug Gives Hope to Sufferers of Rare Leukemia
Time 28.5.01

• A new drug for treating a form of leukemia is

• achieving extraordinary results, restoring
  normal life to patients who believed they had no
  hope
• The patients are feeling well and have almost
  normal blood counts
• STI 571 is an extremely important drug.
• Its effectiveness would inspire more research
  into drugs that will work as well, using the same
  approach in other cancers

28
Toxicity minimal

• Nausea
• Arthralgias
• Myalgias
• Hematological toxicities
• Fluid retention - edema

• Abnormal liver function tests
• Diarrhea
• Vomiting
• Fatigue
• Rash

29
IRIS Study Design Imatinib Versus IFN-? Ara-C
1106 patients enrolled from June 2000 to January
2001
Imatinib


S
R




IFN
Ara-C


S screeningR randomisation



30
Imatinib is Superior to IFN-? Ara-c in Every
Parameter
IRIS Study Summary of the 12-Month Data
Response
CHR complete hematological response MCR
major cytogenetic response PD progressive
disease AP accelerated phase BC blast
crisis.
31
Early BCR-ABL Transcript Decline Predicts For
Cytogenetic Response in CML Patients Treated with
Imatinib

• The degree of tumor load reduction as measured by
  cytogenetic response is an important prognostic
  factor for CML patients on therapy
• Because of the high rate of CCyR observed with
  imatinib, the appropriate measure for response is
  molecular remission using RT-PCR

32
Correlation Between Cytogenetic Response
(Chromosomal) and Molecular Response )RQ-PCR(

• Major cytogenetic response (MCyR) 1 log
  reduction
• Complete cytogenetic response (CCyR) 2 log
  reduction
• Major molecular response (MMR) gt 3 log reduction
• Good correlation between measurements of BCR-ABL
  transcripts in the marrow and PB
• Nevertheless, cytogenetic analysis should be
  repeated at regular intervals because Ph-negative
  clonal evolution has been observed (MDS?)

33
Monitoring patients on imatinib
34
Operational Definition of Failure Suboptimal
Response for Patients Treated with IM 400 mg
Daily

• Failure - patient should be moved to other
  treatments whenever available
• Suboptimal response - patient may still have a
  substantial benefit from continuing IM treatment,
  but the long term outcome is not likely to be
  optimal, so that the patient becomes eligible for
  other treatments
• Warnings - patient should be monitored very
  carefully and may become eligible for other
  treatments

35
THE IRIS STUDY The Australian Group

• Proposed that a 3-log reduction be defined as a
  major molecular response
• It defined a group with remarkable stability of
  response
• It represented a further 1 log reduction below
  the level of CCyR

lt 0.1
36
IRIS Study 7 year follow-up Imatinib arm

• Estimated overall survival _at_ 7 years 86 (94
  considering only CML related deaths)
• Estimated EFS _at_ 7 years 81
• Estimated rate without AP/BC _at_ 7 years 93
• MMR and the depth of molecular response increase
  over time
• No unique, previously unreported adverse event
  attributed to imatinib observed over the past 2
  years
• Imatinib 400 mg daily confirmed as the standard
  of care for the initial therapy of chronic phase
  CML

37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
Imatinib plasma levels

• In the IRIS trial, patients with low day-29
  imatinib trough concentrations were less likely
  to achieve a CCyR and MMR
• Plasma level monitoring is not currently part of
  routine management
• Measuring plasma concentrations may be useful in
  the case of resistance or unusually severe side
  effects

42
Mechanisms of IM Resistance

• Oral biovailability
• Plasma-protein binding
• Changes in intracellular availability of imatinib
• Increased expression of BCR-ABL
• Clonal evolution
• Mutations in the ABL-kinase domain
• Quiescent stem cells

43
(No Transcript)
44
(No Transcript)
45
ABL KINASE DOMAIN MUTATIONS

• The kinase domain of the BCR-ABL oncoprotein is
  identical to the kinase domain of the normal abl
  protein
• It can be divided into 4 parts
• ATP (phosphate) binding pocket P loop
• interveneing secquence
• Catalytic domain
• Activating loop
• Imatinib occupies mainly the P loop

46
(No Transcript)
47
(No Transcript)
48
Resistance workup

• A thorough history to ascertain the patients
  adherence to the prescribed drug regimen
• Measurement of imatinib plasma concentrations
• Once a rise of BCR-ABL transcripts has been
  confirmed and compliance ascertained
• physical exam
• CBC
• bone marrow morphology
• karyotyping
• screening for BCR-ABL kinase domain mutations

49
Approaches to Prevent or Overcome Imatinib
Resistance

• Increase imatinib dose to 600 -800 mg
• Combine imatinib with other drugs of known anti
  CML activity
• To use new BCR-ABL inhibitors or others
• BMT

50
Novel Agents in CML TherapyTyrosine Kinase
Inhibitors and Beyond

• The emergence of resistance to imatinib has
  become a significant problem
• The most common cause of imatinib resistance is
  the selection of leukemic clones with point
  mutations in the Abl kinase domain that prevent
  the appropriate binding of imatinib

51
Novel Agents in CML TherapyTyrosine Kinase
Inhibitors and Beyond

• Single agent therapy with imatinib may not be the
  best long-term option in CML for a proportion of
  patients
• A multitude of novel agents have been developed
• ATP competitive Bcr-Abl tyrosine kinase
  inhibitors
• non-ATPcompetitive Bcr-Abl tyrosine kinase
  inhibitors
• inhibitors acting on targets found in signaling
  pathways downstream of Bcr-Abl
• targets without established links with Bcr-Abl

52
Bcr-Abl Signal Transduction Pathways
Adapted from Kantarjian H et al. Hematology.
200090-109.
53
IMATINIB
54
Second Generation ATP-Competitive Bcr-Abl
Inhibitors

• Nilotinib
• Dasatinib
• Bosutinib
• INNO-406

55
(No Transcript)
56
(No Transcript)
57
Adverse Effects

• Hematologic
• Gastrointestinal
• Pleural / Pericardial Effusion
• Edema
• Rash
• Flushing
• Headaches

58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
Adverse Effects

• Hematologic
• Gastrointestinal
• Increase in LFT
• Increase in lipase
• Dry skin
• Rash
• Alopecia

62
(No Transcript)
63

• Dasatinib and nilotinib represent the first of
  the newer generation TKIs which are effective and
  safe
• Subclones with novel Bcr-Abl mutants might
  develop in response to these new small-molecule
  inhibitors
• Therefore, alternative therapeutic approaches are
  required
• These may involve the combination of Bcr-Abl TKIs
  with inhibitors of non-Bcr-Abl targets or targets
  downstream of Bcr-Abl to achieve a synergistic
  effect

64
Non-ATP TKI Kinase inhibitors

• ONO12380
• Aurora kinase inhibitor
• MK-0457 (VX-680)
• Pha-739358
• SGX393
• XL228
• AP24534
• AP23846

65
T315I Kinase Inhibitors

• ON012380
• MK-0457, formerly known as VX-680, an Aurora
  kinase inhibitor
• Another Aurora kinase inhibitor, PHA-739358
• SGX393 is an azaindole

66
(No Transcript)
67

• Allosteric Inhibitors
• Heat Shock Protein 90 Inhibitors
• Arsenic Trioxide
• Homoharringtonine
• Histone Deacetylase Inhibitors
• Proteasome Inhibitors
• Cyclin-Dependent Kinase Inhibitors
• DNA-Methyltransferase Inhibitors
• Targeting Pathways Downstream of Bcr-Abl
• Farnesyl Transferase Inhibitors
• Tipifarnib
• Lonafarnib

68
Homoharringtonine (HHT)

• HHT is a natural alkaloid derived from certain
  trees and has been in use in China for many years
  for the treatment of AML and CML
• In the pre-imatinib era it was the most
  efficient treatment for interferon-a failures
• HHT inhibits protein synthesis and induces
  apoptosis by bcr/abl independent pathways and
  thus is active in imatinib resistant CML
  including patients with the T315I mutation
• Currently HHT and interferon-a are the only
  available drugs active against cells with the
  T315I mutation

69
Omacetaxine (OMA)

• OMA is the semisynthetic derivative of HHT and is
  more available and less expensive
• It is also active against the T315I mutant and
  is currently being tested in Phase II trials in
  TKI-resistant patients with or without the T315I
  mutant
• OMA is given subcutaneously
• Toxicity is mild and manageable and is mainly
  myelosuppression

70
The European LeukemiaNet Recommendations for
the Management of CML Revisited The Updated 2009
Version

• M. Baccarani, J. Cortes, F. Pane, D.
  Niederwieser,
• G. Saglio, J. Apperley, F. Cervantes, M.
  Deininger, A. Gratwohl, F. Guilhot, A. Hochhaus,
  M. Horowitz,T. Hughes, H. Kantarjian, R. Larson,
  J. Radich, B. Simonsson, R.T. Silver,
• J. Goldman, and R. Hehlmann

71
Present Goal of Therapy in CML

• An aim for 100 survival
• An aim for normal quality of life

72
The European LeukemiaNet (ELN) decided

• To review recent results of therapy
• To review standard monitoring procedures
• To review definitions of responses
• To update published recommendations

73
Aim

• Optimize management of CML
• Standardize management of CML

74
Methods

• Relevant papers that appeared after the
  publication of the original ELN recommendations
• Four panel meetings were held between December
  2007 and December 2008
• Treatment recommendations were limited to the 3
  registered TKIs alloHSCT

75
(No Transcript)
76
Summary and Update of Imatinib Clinical Results

• The advantage of imatinib 400 mg daily compared
  with IFN- and LD-ARA-C was confirmed
• With a follow-up of 7 years imatinib was
  discontinued for
• Adverse events 5
• Lack of efficacy 15
• Other reasons 20

77
Summary and Update of Imatinib Clinical Results

• 75 of patients with CCgRs have maintained the
  response so far
• The 6-year EFS -83
• The 6-year PFS -93
• The 6-year OS 88
• From 4th year - all the curves showed a tendency
  to plateau

78
Imatinib Dose Issues

• The French SPIRIT Study
• Borderline superiority of imatinib 600 mg
  compared with 400 mg _at_ 12 months
• CCgR rate- 65vs. 57
• MMolR rate - 52 vs. 40
• Novartis-sponsored study
• Significant superiority for 800 mg over 400 mg
  regarding MMolR rate
• _at_ 3 months - 12 vs. 3
• _at_ 6 months - 34 vs. 17
• _at_ 9 months - 45 vs. 33
• BUT not _at_ 12 months - 46 vs. 40

79
Imatinib Dose Issues

• An ELN study of high risk patients according to
  Sokal
• Did not show a significant superiority of
  imatinib 800 mg compared with 400 mg
• CCgR _at_ 12 months - 64 vs. 58
• MMolR _at_12 months - 40 vs. 33,

80
Combination With Other Agents

• Imatinib is being tested in combination with IFN-
  and AraC
• The French SPIRIT Study
• 636 pts. with early chronic phase
• imatinib 400 mg
• imatinib 600 mg
• Imatinib 400 mg with pegylated IFN-2a
• Imatinib 400 mg with LD-AraC
• Best response in the arm with imatinib plus IFN
• However, 46 of patients discontinued IFN- during
  the 1st year

81
Resistance and BCR-ABL1 Kinase Domain Mutations

• Advanced stage -resistance frequently associated
  with point mutations
• Chronic phase - resistance associated with point
  mutations in lt50 of pts.
• The poorer outcome of patients with P-loop
  mutations remains controversial
• T315I mutation is a marker of failure for all the
  available TKIs
• Methods to identify mutations
• DHPLC
• direct sequencing

82
(No Transcript)
83
Treatment Discontinuation and Interruption

• 6/12 patients who were in CMolR for more than 2
  years did not experience relapse _at_ 9 - 24 months
• They had been pretreated with IFN
• The 6/12 patients who experienced relapse had
  been treated with imatinib only
• Two subsequent report did not show association
  with IFN pre-treatment

84
Prognostic FACTORS
85
Imatinib First Line - Baseline Prognostic Factors

• The prognostic classifications of Sokal / Hasford
  is valid for imatinib treatment
• In the IRIS study differences were significant
  according to Sokal regarding
• 12 months CCgR rates MmolR rates
• 6-year OS, PFS EFS rates
• Once a CCgR was achieved, outcome was not
  affected by pretreatment risk score

86
Imatinib First Line - Baseline Prognostic Factors

• Del 9q- not confirmed as prognostic factor
• Variant translocations were not significant
• Other CCA/Ph predict shorter PFS OS

87
Imatinib First Line, Response-Related Prognostic
Factors

• _at_ 3 mos. - failure to achieve a CHR
• The probability of achieving a CCgR is small
• The 5-year OS PFS significantly shorter
• _at_ 3 mos.- completely Ph
• low probability of achieving a CCgR later on
• _at_ 6 mos. - 95 Ph
• low chance of subsequent CCgR MMolR

88
Imatinib First Line, Response-Related Prognostic
Factors

• _at_ 12 mos. - CCgR better than PCgR PCgR better
  than less than PCgR
• _at_ 18 mos. MMolR predicts for better 6-yr. EFS
• Loss of CHR/CCgR predicts shorter PFS OS
• Loss of MMolR - prognostic value controversial
• Increase in transcript level - closer monitoring

89
Imatinib First Line, Response-Related Prognostic
Factors

• The detection of a kinase domain mutation
• The prognostic value of CCA/Ph- is not clear
• An evolution towards AML or MDS lt10, mainly
  those with -7

90
Dasatinib Nilotinib, Baseline Response
Related Prognostic Factors

• In imatinib-intolerant patients
• No data predicting the response to dasatinib
  nilotinib at baseline
• In imatinib-resistant patients
• Reduced probability of response to dasatinib
  nilotinib
• Responses to dasatinib nilotinib should be
  rapid
• Detection of a new mutation during treatment with
  dasatinib nilotinib is important

91

• Cytogenetics
• should be performed by chromosome banding
  analysis of marrow cell metaphases until CCgR has
  been achieved
• Interphase FISH
• Cannot be used to assess CR
• Can substitute for chromosome banding analysis to
  monitor the completeness of a CCgR

92
Response Definitions

• Optimal response
• No indication to change therapy
• Survival close to 100 _at_ 6-7 years
• Suboptimal response
• The patient may still have a substantial
  long-term benefit from continuing a specific
  treatment
• The chances of an optimal outcome are reduced
• Failure
• A favorable outcome is unlikely
• The patient should receive a different treatment
• Warning
• Characteristics of the disease may adversely
  affect the response to that therapy
• Requires close monitoring

93

• A new definition of optimal response
• An earlier definition of
• suboptimal response - cytogenetic resistance _at_ 3
  mos.
• failure - hematologic resistance _at_ 3 mos.
• failure - Cytogenetic resistance _at_ 6 mos.
• del9q - no longer a warning
• CCA/Ph
• at diagnosis - warning factor
• during treatment -a marker of treatment failure
• The significance of increase in transcript level
  2 -10

94

• Hydroxyurea may be used only for a short period
• IFN- is still an option in case of pregnancy
• The standard dose of imatinib in CML-CP is 400 mg
  daily

95
(No Transcript)
96
Provisional but warranted
97
(No Transcript)
98
SUMMARY
99
CML Historical Context Until 2000

• Fatal disorder with poor prognosis
• Median survival 3-5 years
• Allogeneic SCT curative in 40 to 70 of patients
• Associated with mortality and toxicity
• IFN alfa cytarabine CCyR of 20 to 30
• Median survival 6-7 years
• Also associated with adverse events
• Other options hydroxyurea, busulfan

Faderl S, et al. N Engl J Med. 1999131207-219.
100
CML Clinical Perspective Since 2000

• Indolent disorder with excellent prognosis
• Estimated 5-year survival 90
• Median survival excellent, potentially
  multi-decade
• Functional cure
• Frontline treatment imatinib mesylate
• Second-line, postimatinib failure allogeneic SCT
• Evolving role of novel TKIs dasatinib, nilotinib

Druker BJ, et al. N Engl J Med.
20013441031-1037.
101
Overview of Historical vs Modern Perspective
Faderl S, et al. N Engl J Med. 1999131207-219.D
ruker BJ, et al. N Engl J Med. 20013441031-1037.
102
Survival in Early Chronic-Phase CML
1.0
0.8
90
0.6
Proportion Surviving
0.4
0.2
0.0
0
3
6
9
12
15
Years From Referral
University of Texas M.D. Anderson Cancer Center
Database 1965-2005
103
Historic Development of CML Therapy
104
Historical Aspects of CML From Bennet to
Druker 160 Years of Attempts to Treat Cure
CML

• 1st description Hughes Bennet - lucocythaemia
  Edinburgh, 1845
• 2nd description Robert Virchow -
  leukämieBerlin, 1858
• Origin in BM Neumann, 1869
• Minot 166 cases of CML , 1924
• Whitby Britton comprehensive description of
  the clinical picture, 1935
• Bernard The term for blastic crisis,
  metamorphosis, 1959
• Nowell Hungerford description of the
  Philadelphia chromosome, 1960
• Janet Rowley describes the translocation
  t(922), 1973
• Bartram-Characterization of the BCR-ABL fusion
  gene, 1983
• BCR-ABL transfected BM cells induced leukemia in
  mice, 1990
• Druker - Gene targeted Rx , 1998

105
IMATINIB STILL THE BEST TREATMENT FOR CML

• Dont Change Winning Horses !

106
Final Decision, even more in the Imatinib
era Patient-physician shared decision
107
CML"This is not the end, it is not even the
beginning of the end. But it is, perhaps, the end
of the beginning." London, November 10,
1942
