Title: DNA Sequencing


1
DNA Sequencing
  • Basic Techniques
  • Project Design
  • Process Improvements

2
Project Size/Type
  • 500 bases
  • 2500 bases
  • 10 kbp
  • 150 kbp
  • 3 Mbp
  • simple
  • repeats
  • BIG
  • 1 locus EST,STS
  • whole cDNA/EST
  • gene, virus
  • BAC, big virus
  • bacterial genome
  • YAC-size
  • HUMAN, etc.

3
DNA Sequencing Methods
  • Chain termination/Dideoxy/Sanger
  • fluorescence paradigm, ABI, HOOD
  • Sequencing by hybridization
  • chips Affymetrix (Lander, et al)
  • other formats
  • Hyseq (Church, et al)
  • Lark

4
Dideoxy/Chain Terminator/Sanger
  • Template
  • Primer
  • Extension Chemistry
  • polymerase
  • termination
  • labeling
  • Separation
  • Detection

5
Chain Terminator Basics
TGCA
Extend
dN ddN 100 1
Ladder n, n1...
6
Electrophoresis
7
Template Preparation
  • ssDNA vectors
  • M13
  • pUC
  • PCR
  • dsDNA (/- PCR)

8
Primers
  • Universal primers
  • cheap, reliable, easy, fast, parallel
  • BULK sequencing
  • Custom primers
  • expensive, slow, one-at-a-time
  • ADAPTABLE

Primer Label
Dye Terminator
9
Extension Chemistry
100 termination Accurate Even signal
  • Polymerase
  • Sequenase
  • Thermostable (Cycle Sequencing)
  • Terminators
  • Dye labels (Big Dye)
  • spectrally different, high fluorescence
  • (mass labels??)
  • ddA,C,G,T with primer labels

10
Separation
  • Gel Electrophoresis
  • Capillary Electrophoresis
  • suited to automation
  • rapid (2 hrs vs 12 hrs)
  • re-usable
  • simple temperature control
  • 96 well format

migration 1/log N
11
Paradigm Instrument
  • Applied Biosystems
  • ABI3700 (early 1999)
  • 1500 samples/day!
  • http//www2.perkin-elmer.com/ga/3700/features.html
  • ABI377 (gel) and ABI310 (capillary)

12
Alternate Instruments
  • Molecular Dynamics, Beckman Coulter
  • ALF, LiCor
  • infrared detection

Not Complete List
13
Sample Output
14
Trace Editing
  • EditView
  • Mac
  • Chromas
  • WinNT
  • Consed
  • UNIX

15
Project Goals
  • de novo sequence
  • Chain terminators
  • repetitive sequencing
  • Sequencing by hybridization
  • Chip technology, eg

16
Sequencing Strategies
  • Random Sequence
  • Brute Force
  • Ordered
  • Divide and Conquer

Sequencing Assembly Finishing Annotation
Mix to Suit
17
Random Method
  • Shear DNA (nebulize)
  • finish ends, ligate into vector
  • Produce template
  • Sequence to target coverage
  • read length (500 typical)
  • accuracy (99 good)

Assemble Contigs
18
Random
19
Poisson Statistics
Lread length Nreads Ggenome size
P0e-L(N)/G
20
Poisson-2
Gap LengthP0G
21
Poisson-3
Gap NumberP0N (assume N500 bases)
22
4 Mbp Genome
  • 10x Coverage
  • 80,000 reads at 500 bases/read
  • 4 gaps
  • 400 bases in gaps

55 instrument days on ABI3700
23
3000 Mbp GenomeHUMAN
50000 instrument days on ABI3700
24
Automation
QT
25
Costs
  • Raw cost 0.01/base
  • Semi-finished 0.10 per base
  • finished 0.30 per base
  • High-quality Genome Project
  • 0.50/base

26
Ordered Methods
Primer Walking
Nested Deletion
27
Limitations
  • Slow, Expensive
  • Expertise Needed
  • especially nested deletion
  • Repeat Problems
  • especially primer walking

28
Finishing
  • GOALS
  • gt95 coverage on BOTH strands
  • every base covered 3X
  • resolve ambiguities
  • Finish when random no longer productive (3-10 X
    range)

29
Finish-How
  • Identify gaps, ambiguities
  • Extend from end of contigs
  • specific primers
  • subclones, etc.
  • Resolve ambiguities
  • consensus or resequence
  • specific primers, different chemistry

30
Assembly Methods
  • Strip out vector
  • Mask known repeats
  • Trim off unreliable data
  • Find Matches (500 x 500 x many!!)
  • how long (and what ktuple)
  • how perfect (reliability index)
  • where to look? (ends only vs entire)

31
Assembly Programs
  • PHRAP FAMILY
  • phrap, kangaroo, phrapo,
  • GAP4, TIGRAssembler,...
  • GCG
  • gelstart, gelenter, gelmerge, gelassemble,
    geldisassemble
  • thinly veiled vi editor
  • SeqWeb.

32
Assembly ImprovementsRepeat Problems
  • Multiple fragment sizes in 1 project
  • Use length/distance info

33
Project Management
  • Editing and Assembly
  • RepeatMasker
  • Phred/Phrap
  • Consed
  • Databases
  • ACeDB
  • A C. elegans database
  • Oracle

34
Annotation
  • ORFs
  • GRAIL, PowerBLAST
  • Repeats
  • Other Regions

Submit to Genbank ...HTGS (level1,2,3) ...nr
35
Sequencing by Hybridization
Hybridize labeled query DNA
CHIP OLIGOS (20-mers)
...gaactAatact... ...gaactCatact... ...gaactGatact
... ...gaactTatact...
site 1
...gaactaAtact... ...gaactaCtact... ...gaactaGtact
... ...gaactaTtact...
site 2
GAACTATGTACT
36
Modern Sequencing Challenges
  • Heterozygous DNAs
  • germline differences
  • somatic variation
  • Massive sequencing
  • population studies
  • genome scans
  • Minimal sample preparation
  • Doctors Office

Chips, Quantitative Seq Automation Miniaturization
37
Physical MappingGenome Characterization
  • Genome fragmentation and cloning
  • vectors, etc.
  • Physical map assembly
  • hybridization
  • fingerprinting
