Overview of Cluster Hardware and Software

1
Overview of Cluster Hardware and Software

• Class 2

2
TDG Cluster
3
Hardware Configuration

• 1 master node 64 compute nodes Gigabit
  Interconnection
• Master Node
• Dell PE2650, P4-Xeon 2.8GHz x 2
• 4GB RAM, 36GB x 2 U160 SCSI (mirror)
• Gigabit Ethernet ports x 2
• SCSI Storage
• Dell PV220S
• 73GB x 10 (RAID5)

4
Hardware Configuration

• Compute Nodes
• Dell PE2650, P4-Xeon 2.8GHz x 2
• 2GB RAM, 36GB U160 SCSI HD
• Gigabit Ethernet ports x 2
• Gigabit Ethernet Switch
• Extreme BlackDiamond 6816
• 256Gb Backplane
• 72 Gigabit ports (8 ports card x 9)

5
Software List

• Operating System
• ROCKS 3.1.0 from http//www.rocksclusters.org
• MPI and PVM libraries
• LAM/MPI 7.0.4
• MPICH 1.2.5.2
• mpiJava 1.2
• PVM 3.4.3-6beolin
• Compilers
• GCC 3.2.3
• PGI C/C/f77/f90/hpf version 5.1
• J2SDK 1.4.2

6
Software List

• Applications
• Amber 7
• Gamess
• Gaussian 03
• Gromacs 3.2
• MATLAB 6.5 with MPITB
• NAMD 2.5
• Q-Chem 2.1
• R 1.8.1
• VMD 1.8.2
• WebMO 4.1

7
Software List

• MATH and Other Libraries
• ATLAS 3.6.0
• ScaLAPACK 1.7
• SPRNG 2.0a
• HPJava 1.0
• Editors
• Vi
• Pico
• Emacs
• joe
• Queuing system
• Torque/PBS
• Maui scheduler

8
Cluster O.S. ROCKS 3.1.0

• Developed by NPACI and SDSC
• Based on RedHat Entreprise Linux 3.0
• Allow setup of 64 nodes in 1 hour
• Useful command for users to monitor jobs in all
  nodes. E.g.
• cluster-fork date
• cluster-ps morris
• cluster-kill morris
• Web based management and monitoring
• http//tdgrocks.sci.hkbu.edu.hk

9
Ganglia
10
Hostnames

• Master node
• External tdgrocks.sci.hkbu.edu.hk
• Internal frontend-0
• Compute nodes
• comp-pvfs-0-1, , comp-pvfs-0-64
• Alias
• comp-pvfs-0-1.local, , comp-pvfs-0-64.local
• cp0-1, cp0-2, , cp0-64

11
Network Design
12
Kickstart Graph

• http//tdgrocks.sci.hkbu.edu.hk/homepage/dot-graph
  .php

13
Login Master Node

• Login is allowed remotely in all HKBU networked
  PCs by SSH or vncviewer
• SSH Login (Terminal)
• Using your favourite SSH client software, namely
  putty, SSHsecureshell on windows and openssh on
  Linux/UNIX
• e.g. on all SCI workstations (spc01 spc30),
  type
• ssh tdgrocks.sci.hkbu.edu.hk

14
Login Master Node

• VNC Login (GUI)
• Download vncviewer from http//www.uk.research.att
  .com/vnc/
• E.g. in spc01 spc30.sci.hkbu.edu.hk,
• vncviewer vnc.sci.hkbu.edu.hk51
• E.g. in windows, run vncviewer and upon asking
  the server address, type
• vnc.sci.hkbu.edu.hk51

15
Username and Password

• The unified password authentication has been
  implemented
• Same as that of your NetWare account
• Password authentication using NDS-AS
• Setup similar to the UNIX servers in ITSC

16
SSH Key Generation

• To make use of multiple nodes in the PC cluster,
  users are restricted to use ssh.
• Key generation is done once automatically during
  first login
• You may input a passphrase to protect the key
  pair
• The key pair is stored in your HOME/.ssh/
• Use the following script to regenerate the SSH
  key
• /u1/local/share/makeKey

17
User Policies

• Users are allowed to remote login from other
  networked PCs in HKBU.
• All users must use their own user account to
  login.
• The master node (frontend) is used only for
  login, simple editing of program source code,
  preparing the job dispatching script and
  dispatching of jobs to compute node. No
  foreground or background can be run on it.
• Dispatching of jobs must be done via the OpenPBS
  system.

18
Torque/PBS system

• Provide a fair and efficient job dispatching and
  queuing system to the cluster
• PBS script shall be written for running job
• Either sequential or parallel jobs can be handled
  by PBS
• Jobs error and output are stored in different
  filenames according to job IDs.

19
PBS Script Example (Sequential)

• !/bin/bash
• PBS -l nodes1
• PBS -N prime
• PBS -q default
• the above is the PBS directive used in batch
  queue
• echo Running on host hostname
• /u1/local/share/example/pbs/prime 216091

• PBS scripts are shell script with directives
  preceding with PBS
• The above example request only 1 node and deliver
  the job named prime in default queue.

20
Delivering Sequential Job

• Prepare and compile executable
• cp /u1/local/share/example/pbs/prime.c ./
• cc o prime prime.c -lm
• Prepare and edit PBS script as previous
• cp /u1/local/share/examples/pbs/prime.bat ./
• Submit the job
• qsub prime.bat

21
PBS Script Example (Parallel)

• !/bin/sh
• PBS -N cpi
• PBS -r n
• PBS -e cpi.err
• PBS -o cpi.log
• PBS -l nodes5ppn2
• PBS -l walltime010000
• This job's working directory
• echo Working directory is PBS_O_WORKDIR
• cd PBS_O_WORKDIR
• echo Running on host hostname
• echo This jobs runs on the following processors
• echo cat PBS_NODEFILE
• Define number of processors
• NPROCSwc -l lt PBS_NODEFILE
• echo This job has allocated NPROCS nodes
• Run the parallel MPI executable cpi
• /u1/local/mpich-1.2.5/bin/mpirun -v -machinefile
  PBS_NODEFILE -np NPROCS /u1/local/share/example/
  pbs/cpi

22
Delivering Parallel Job

• Copy the PBS script examples
• cp /u1/local/share/example/pbs/runcpi ./
• Submit the PBS job
• qsub runcpi
• Note the error and output files named
• cpi.e???
• cpi.o???

23
MPI Libraries
24
MPICH

• MPICH is an open-source, portable implementation
  of the Message-Passing Interface Standard. It
  contains a complete implementation of version 1.2
  of the MPI Standard and also significant parts of
  MPI-2, particularly in the area of parallel I/O.
• URL http//www-unix.mcs.anl.gov/mpi/
• MPICH 1.2.5.2 with gcc
• /u1/local/mpich-1.2.5/bin
• MPICH 1.2.5.2 with pgi
• /u1/local/mpich-pgi/bin

25
LAM/MPI

• LAM/MPI is a high-performance, freely available,
  open source implementation of the MPI standard.
• LAM/MPI supports all of the MPI-1 Standard and
  much of the MPI-2 standard.
• LAM/MPI is not only a library that implements the
  mandated MPI API, but also the LAM run-time
  environment a user-level, daemon-based run-time
  environment that provides many of the services
  required by MPI programs.
• URL http//www.lam-mpi.org/
• LAM 6.5.9
• /usr/bin
• LAM 7.0.4
• /u1/local/lam-7.0.4/bin

26
mpiJava

• mpiJava provides an object-oriented Java
  interface to the Message Passing Interface (MPI)
  standard, for use on parallel or distributed
  computing platforms.
• It also includes a comprehensive test suite for
  the Java interface.
• It includes some simple examples and demos.
• URL http//www.hpjava.org/mpiJava.html
• mpiJava 1.2
• /u1/local/mpiJava/

27
Applications
28
AMBER 7

• Assisted Model Building with Energy Refinement
• Includes
• a set of molecular mechanical force fields for
  the simulation of biomolecules (which are in the
  public domain, and are used in a variety of
  simulation programs)
• and a package of molecular simulation programs
  which includes source code and demos.
• URL http//amber.scripps.edu
• AMBER 7
• /u1/local/amber7

29
Gamess

• The General Atomic and Molecular Electronic
  Structure System (GAMESS)
• It is a general ab initio quantum chemistry
  package.
• Calculates molecular properties, transition
  states, models solvent effects, orbitals, etc.
• URL http//www.msg.ameslab.gov/GAMESS/GAMESS.html

• Gamess
• /u1/local/gamess

30
Gaussian 03

• Calculate the basic laws of quantum mechanics
• Predicts the energies, molecular structures, and
  vibrational frequencies of molecular systems
  along with numerous molecular properties.
• It can be used to study molecules and reactions
  under a wide range of conditions, including both
  stable species and compounds which are difficult
  or impossible to observe experimentally such as
  short-lived intermediates and transition
  structures.
• URL http//www.gaussian.com/
• Gaussian 03
• /u1/local/g03

31
Gaussian 03 GaussView
32
Gromacs 3.2

• GROMACS is a versatile package to perform
  molecular dynamics, i.e. simulate the Newtonian
  equations of motion for systems with hundreds to
  millions of particles.
• URL http//www.gromacs.org
• Gromacs 3.2
• /u1/local/gromacs

33
MATLAB 6.5 with MPITB

• Call MPI library routines from within the MATLAB
  interpreter.
• Processes can be spawned and arranged in
  topologies, MATLAB variables can be
  sent/received.
• Commands for remote execution may be passed as
  strings to the desired MATLAB "computing
  instance", and the result may be sent back to the
  MATLAB "host instance".
• URL http//atc.ugr.es/javier-bin/mpitb_eng
• MATLAB 6.5 with MPITB
• /u1/local/matlab/toolbox/mpitb

34
NAMD 2.5

• Reads X-PLOR, CHARMM, AMBER, and GROMACS input
  files.
• Generates structure and coordinate files.
• Efficient conjugate gradient minimization.
• Fixed atoms and harmonic restraints.
• Thermal equilibration via periodic rescaling,
  reinitialization, or Langevin dynamics
• Simulation of the temperature, pressure, etc.
• URL http//www.ks.uiuc.edu/Research/namd/
• NAMD 2.5
• /u1/local/namd2

35
Q-Chem 2.1

• Supports Ground State Self-Consistent Field
  Methods, Wave Function Based Treatments of
  Electron Correlation, Excited State Methods,
  Properties Analysis and Basis Sets.
• URL http//www.q-chem.com/
• Q-Chem 2.1
• /u1/local/qchem

36
R 1.8.1

• Provides a wide variety of statistical (linear
  and nonlinear modeling, classical statistical
  tests, time-series analysis, classification,
  clustering, ...) and graphical techniques, and is
  highly extensible.
• Produces well-designed publication-quality plots.
• URL http//cran.r-project.org/
• R 1.8.1
• /u1/local/R

37
R 1.8.1
38
VMD 1.8.2

• Supports various kind of Molecular
  Representations, Coloring Styles, Transparency
  and Materials, Display and rendering features
• Supports various kind of plugins
• Supports Interactive Molecular Dynamics
  Simulation
• URL http//www.ks.uiuc.edu/Research/vmd/
• VMD 1.8.2
• /u1/local/vmd-1.8.2

39
VMD 1.8.2
40
MATH and Other Libraries
41
ATLAS 3.6.0

• The ATLAS (Automatically Tuned Linear Algebra
  Software) project is an ongoing research effort
  focusing on applying empirical techniques in
  order to provide portable performance. At
  present, it provides C and Fortran77 interfaces
  to a portably efficient BLAS implementation, as
  well as a few routines from LAPACK.
• URL http//sourceforge.net/projects/math-atlas/
• ATLAS 3.6.0
• /u1/local/ATLAS

42
ScaLAPACK 1.7

• ScaLAPACK libraries are distributed memory
  versions (PBLAS) of the Level 1, 2 and 3 BLAS,
  and a set of Basic Linear Algebra Communication
  Subprograms (BLACS) for communication tasks that
  arise frequently in parallel linear algebra
  computations. In the ScaLAPACK routines, all
  interprocessor communication occurs within the
  PBLAS and the BLACS. One of the design goals of
  ScaLAPACK was to have the ScaLAPACK routines
  resemble their LAPACK equivalents as much as
  possible.
• URL http//www.netlib.org/scalapack/scalapack_hom
  e.html
• ScaLAPACK 1.7
• /u1/local/SCALAPACK

43
SPRNG 2.0a

• The Scalable Parallel Random Number Generators
  Library (SPRNG)
• SPRNG is a set of libraries for scalable and
  portable pseudorandom number generation, and has
  been developed keeping in mind the requirements
  of users involved in parallel Monte Carlo
  simulations.
• The generators implemented in SPRNG are (i) two
  versions of Linear Congruential with Prime Addend
  and (ii) modified Additive Lagged Fibonacci (iii)
  Multiplicative Lagged Fibonacci (iv) Combined
  Multiple Recursive Generator (v) Prime Modulus
  Linear Congruential Generator.
• URL http//sprng.cs.fsu.edu/
• SPRNG 2.0a for MPICH
• /u1/local/sprng2.0
• SPRNG 2.0a for LAM/MPI
• /u1/local/sprng2.0-lam

44
HPJava 1.0

• HPJava is an environment for scientific and
  parallel programming using Java. It is based on
  an extended version of the Java language. One
  feature that HPJava adds to Java is a
  multi-dimensional array, or multiarray, with
  properties similar to the arrays of Fortran.
• URL http//www.hpjava.org
• HPJava 1.0
• /u1/local/hpjdk

45
Homework 1

• Copy the files in /u1/local/share/example/pbs
• cp /u1/local/share/example/pbs/cpi.c .
• cp /u1/local/share/example/pbs/Makefile .
• cp /u1/local/share/example/runcpi .
• Type make to create cpi executable
• Modify runcpi to run cpi executable in this
  directory
• Run runcpi in PBS with 1,2,4,6,8,10,12,16,24
  nodes (CPUs) and plot the time graph
• Hints qsub l nodes12 runcpi for requesting 12
  nodes
• From the graph, find the best no. of processors
  to run this program
• Due day Jan 13, 2005 e-mail to
  morris_at_hkbu.edu.hk

46
END
