1
Feeding Value of Distillers GrainsDan LoyIowa
State University
2
Outline

• Ethanol Products-Processes
• Challenges and Opportunities with Distillers
  grains for Livestock
• Phosphorous Nutrition in Cattle
• P Calculator

3
Iowa Ethanol Production (Millions of Gallons
Source Iowa Corn Promotion Board
4
63
Source Bob Wisner
Source Bob Wisner
Capacity 129 of 2006 crop
Iowa corn processing ethanol plants, current
planned, 10/26/06
5
Figure 2.
8/30/06
Source Bob Wisner
6
5.5 Bil. Bu for ethanol
With 6.5 bil. Bu. 51.8 Mil. T
7
Can we feed it all?
8
Corn 3.80 /bu or 136/ton DDGS 125/ton
Baumel and Wisner
9
Co-Products of Wet Milling

• Corn Gluten Feed
• Corn Gluten Meal
• Corn Germ Meal
• Corn Oil
• Steep Water
• Corn Bran
• Distillers Solubles

Photos Corn Refiners Ass.
10
Co-Products of Dry Milling

• Distillers Grains
• Distillers Solubles
• Distillers Grains w/solubles wet, modified or dry

11
Modified Dry Distillers
12
Distillers feeds

• Distillers dried grains
• Well researched, global commodity
• Distillers wet grains and solubles
• Local resource for value added agriculture and
  community economic development
• Both are excellent feeds

13
Characteristics of Distillers Coproducts

• High fiber (rapidly digested)
• High energy (100 of corn for wet products )
• High protein (30 on DM basis)
• Minerals (High P, S) (Low Ca)

14
(No Transcript)
15
Wet Milling Products Chart
Corn Starch Germ Gluten Bran Lite Steep
Water SEM CCO Heavy Steep Water
Starch Sweetener Dextrose Corn Gluten
Feed Ethanol Fermentation Etoh
Distillers Solubles Other Fermentations
16
WET CORN GLUTEN FEED
High fiber (rapidly digested) High energy
(95-100 of corn) High protein (21) Minerals
(High P, K, Mg, S) (Low Ca)
17
Nutrient Profile
.
18
Nutrient Profile
.
19
(No Transcript)
20
New processing methods Fractionation

• Corn kernal is fractioned
• Endosperm-gtFermented-gtEthanol High protein
  Distillers and solubles
• Bran mixed with solubles-gt Bran Cake
• Germ

21
New processing methods Fractionation

• High Protein DG 40
• Germ Product
• Bran Product 12 Protein, High Fiber similar
  in energy to corn

22
Deoiled distillersComposition of VeraSun Feed
ProductsOil removed after the fermentation
Corn ME 3.72 kcal/g
23
(No Transcript)
24
Benefits and Challenges (Swine and Poultry)

• Benefits
• Potentially low cost feed ingredient
• Improves gut health (pigs)
• Phosphorous availability is improved
• Challenges
• Fiber limits performance
• Amino acid profile (low in lysine)
• Pork fat quality
• Inclusion
• Poultry (10-15), finishing swine (20), breeding
  swine can use higher levels

25
Benefits and Challenges (Dairy Rations)

• Benefits
• Excellent source of protein, energy and
  phosporous
• Fiber well utilized
• Challenges
• Fat content limits inclusion levels
• Amino acid balance may be an issue with the high
  producing dairy cow
• Inclusion
• Limited to less than 20 of diet (lactating dairy
  cow)

26
Benefits and Challenges (Cow-calf operations)

• Benefits
• Excellent source of protein, energy and P
• Compliments low quality forages and crop residues
• Stretches pasture and forage supply
• Challenges
• Needed in small quantities often under extensive
  conditions (delivery systems)
• Long term storage of wet feeds
• May need to adjust mineral programs and other
  supplements

27
Feeding of DDGS Cycles as Well.
Calving
Late Preg.
Weaning
28
McNay FarmBagging Modified Distillers Grain and
Solubles
Approx. 1.25 tons/foot of bag
29
McNay FarmBagging 80 Wet DGS 20 Ground Hay
Approx. 1.1 tons/foot of bag
30
Substitution of DDG for Grass

• 1 Pound DDG reduced grass consumption .5 to 1.5
  pounds (dry matter).
• 4-5 pounds DDG should reduce grass DMI by 2-7
  pounds.

31
Benefits (Feedlots)

• Quality Protein source
• Energy equals or exceeds corn grain
• Low starch improves management
• Works well with less grain processing
• High moisture feeds superior
• Cheap (potentially)

32
Effect of level of feeding on energy value of
Distillers grains
Feeding Value (of Corn) 0 50 100 150
Based Research at Midwest Universities Almost 1
decrease in energy value fore each 1 increase in
inclusion level (Nebraska analysis)
0 10 20 30 40 50 Distillers Grains
33
Challenges (Feedlot)

• Fat content limits usage to 40-50 of ration dry
  matter
• Sulfur content may limit usage to even lower
  levels depending on source
• High moisture feeds have short shelf life
• Phosphorous will be in excess of requirements

34
Feeding Levels Can be Limited by Sulfur
35
Phosphorus Excretion Steers fed control,
distillers soluble or wet DG

• Feeding distillers co-products
• Did not change P metabolism
• Increased P excretion
• Feeding DGS is a manure management issue

36
Use of DGS in Feedlot Diets
37
Land Area Required for Manure DisposalCorn -
Nitrogen Balance
Assumptions Manure added based on crop removal
corn yield 150 bu/acre 50 of manure N lost as
ammonia 1000-head feedlot occupied 304 days/year
Trenkle (2006)
38
Land Area Required Corn ProductionManure
Disposal - P
Trenkle (2006)
39
Thank You
Questions? www.iowabeefcenter.org dloy_at_iastate.ed
u (515) 294-BEEF
