RHIZANOVA™

1
RHIZANOVA

• Tree Transplant
• Tree Injectable
• Pt Injectable
• Flower and Palm Rx

2
Benefits of Mycorrhizae

• Root absorptive area increased
• greater area for nutrient uptake
• increased water absorption
• Fungi solubilize and mobilize nutrients
• phosphorous uptake enhanced
• otherwise, insoluble forms often unavailable to
  plant
• Improved fitness
• essential for nutritionally and/or moisture
  deficient areas
• healthy plant more able to grow, reproduce,
  resist or tolerate diseases, drought stress, etc.
• non-mycorrhizal plants usually dont survive

3
Benefits of Mycorrhizae contd

• Mantles formed by EM provide physical barriers to
  pathogens
• Excreted metabolites improve soil structure
• by-product of solubilization of minerals

4
Mycorrhizae increase root absorptive area
5
Benefits of Mycorrhizae
6
Types of Mycorrhizae

• Ectomycorrhizae (Ecto)
• fungi grow between root cortical cells produce a
  sheath (mantle) covering the root surface
• on trees and shrubs
• all conifers, also oak, hickory, chestnut, birch,
  beech, basswood, pecan, Eucalyptus
• some fungi produce mushrooms, puffballs
• Pisolithus tinctorius (PT)

7
Thelephoroid ectomycorrhizae on Douglas-fir
Yellowish fungal mantle covers roots
Ecto species
8
Bisected puffball of Pisolithus tinctorius
9
Types of Mycorrhizae contd

• Endomycorrhizae (sometimes called vesicular-
  arbuscular mycorrhizae(VAM)
• fungi grow within root cortical cells produce
  arbuscules within cells, often vesicles
• not all produce vesicles, but all produce
  arbuscules
• on deciduous trees and shrubs and herbaceous
  plants
• maple, sycamore, elm, etc. also flowers,
  grasses, etc.
• No above ground fungal structures
• Glomus spp.

10
Simplified anatomy of an arbuscular mycorrhiza.
M. Brundrett, L. Melville, and L. Peterson (1994)
"Practical Methods in MycorrhizaResearch"
(Mycologue Publications).
11
Vescicles of Glomus intraradices
hyphae
root
Endo species
12
Scutellospora erythropa extraradical hyphae
hyphae
Endo species
spores
13
Glomus mosseae arbuscule in leek root cortex cell
14
Mycorrhizal preferences

• Endomycorrhizae
• herbaceous plant species
• non-woody agricultural crops, turf, ornamentals
• Ectomycorrhizae
• Trees (particularly conifers), woody shrubs
• Both
• Trees and woody shrubs (particularly broad leaf)

15
Mycorrhizal preferences

• Endomycorrhizae
• Acacia, Ash, Bay, Boxelder, Buckeye, Cedar,
  Chokeberry, Cherry, Cottonwood, Crabapple,
  Cypress, Dogwood, Elm, Ginkgo, Gum, Hackberry,
  Hawthorn, Holly, Horsechestnut, Juniper,Locust,
  Magnolia, Mesquite, Mimosa, Mulberry, Palm,
  Persimmon, Poplar, Redbud, Redwood, Russian
  Olive, Serviceberry, Sumac, Sycamore, Tupelo,
  Walnut, Yew
• Ectomycorrhizae
• Alder, Arborvitae, Aspen, Basswood, Beech, Birch,
  Chestnut, Fir, Hemlock, Hickory, Larch, Linden,
  Oak, Pecan, Pine, Spruce
• Both
• Eucalyptus, Willow, Poplar

16
Distribution of Mycorrhizal Fungi

• Naturally present in most native soils
• most plants and trees, have co-evolved with
  mycorrhizal fungi
• associations are the rule, not the exception
• Absent or poorly distributed in artificial or
  disturbed soils
• plants can fail if mycorrhizae do not establish

17
Distribution of Mycorrizal Fungi contd

• All soils not the same
• inoculum potential varies
• may not be sufficient to allow successful plant
  establishment
• species distribution varies
• those present may be ineffective on non-native
  species

18
Mycorrhizal Inoculants

• Ecto fungi long used by forest industry
• pine seedling establishment
• Commercial Endo inoculants relatively new
• most plants are mycorrhizal
• non-coniferous plants primarily support Endo
• benefits extended to greater range of plants
• association essential for success

19
Inoculation strategies

• Transplants
• non-native introductions
• areas with significant soil disturbance
• scraped, top soil removed
• nutritionally poor, drought prone areas
• Plants growing poorly due to environmental
  stresses
• soil compaction

20
Influence of fungicides on mycorrhizal fungi

• Normal usage rates and application methods
  (spray) normally has no effect on mycorrhizal
  fungi
• metabolized by soil microbes
• Drenches/Soil Injection could have detrimental
  effects
• Systemics mostly transported upwards in plant and
  not to roots.
• General rule avoid use of fungicides 2 - 3 weeks
  before and after inoculation
• toxic Carbamates (Maneb, Zineb), PCNB,
  Chlorothalonil (Daconil, Bravo), Triazoles
  (Bayleton), Benomyl (Benlate)
• non-toxic Signature, Captan, Carbendazim,
  Metalaxyl (Ridomil, Subdue)

21
Advantages of Rhizanova

• Emphasis on quality and quantity of inoculum
• Becker-Underwood an ISO 9001 registered company
• The only certified inoculum in the industry
• Species selected for effectiveness for the
  broadest range of plants
• No unnecessary amendments
• some amendments can be detrimental
• phosphorous fertilizers at high rates

22
Mycorrhizal colonization of Ponderosa pine roots
by Becker-Underwood Tree Transplant and Tree Root
Dip inoculants in tests conducted by Mycorrhizal
Applications, Grants Pass, OR in 1998.
23
RHIZANOVA Tree Transplant

• Packaging 3 oz. Foil Pack 130 Packs/pail or
• 25 lb. bulk pail w/scoop
• Contains Endo Ecto Superabsorbent
  Polymer Humic Acid
• Rates 3 oz. per 1 foot diameter root ball
• Benefits Double the Endo spore count vs. the
  competition 25 higher Ecto spore count vs. the
  competition Same price

24
RHIZANOVA Tree Injectable

• Packaging 6 oz. WSP 16 WSPs/case
• Contains Endo Ecto Humic Acid Surfactant
• Rates 6 oz. WSP per 100 gallons Inject 1/2 gal.
  on 2.5 ft. grid pattern within drip line
• Benefits 7.5 more spores for the same price as
  the competition

25
RHIZANOVA Pt Injectable

• Packaging 6 oz. WSP 16 WSPs/case
• Contains Ecto Humic Acid Surfactants
• Rates 6 oz. WSP per 100 gallons Inject 1/2 gal.
  on 2.5 ft. grid pattern within drip line
• Benefits Equal the spore count for 15 less than
  the price of the competition

26
RHIZANOVA Flower and Palm Rx

• Packaging 4 x 6 lb. pail or 30 lb. pail
• Contains Endo Superabsorbent Polymer Humic
  Acid Organic Fertilizer
• Rates Flowers - ½ oz. per foot of row
  or 3 lbs. per 100 sq. ft.
• Palms - 3 oz. Per 3 ft. of gray wood
• or per 5 gallon container
• Benefits Increased color and blooms

27
Thank You!!!!!We appreciate your business!
