Osseous Tissue and Bone Structure

1
Chapter 6

• Osseous Tissue and Bone Structure

2
Bones and Cartilages of the Human Body

• Hyaline
• Most abundant skeletal cartilage articular,
  costal, respiratory, nasal
• Elastic
• External ear, epiglottis
• Fibrocartilage
• IVD, knee menisci

3
Functions of the skeletal system

• 1. Support - framework for the body
• 2. Protection - skull, vertebrae, ribcage
• 3. Leverage - bones are levers, joints are
  fulcrums
• 4. Mineral storage (calcium)
• 5. Lipid Storage (yellow marrow)
• 6. Blood cell formation - hematopoiesis

4
Classification of Bones

• Axial skeleton bones of the skull, vertebral
  column, and rib cage
• Appendicular skeleton bones of the upper and
  lower limbs, shoulder, and hip

5
Classification of Bones By Shape

• Long bones
• longer than they are wide (e.g., humerus)

6
Classification of Bones By Shape

• Short bones
• Cube-shaped bones of the wrist and ankle

7
Classification of Bones By Shape

• Flat bones
• thin, flattened, and a bit curved (e.g., sternum,
  and most skull bones)

8
Classification of Bones By Shape

• Irregular bones
• bones with complicated shapes (e.g., vertebrae
  and hip bones)
• Sesamoid- form w/in a tendon
• Wormian- form in sutures

9
Classification of Bones By Shape
10
Structure of a typical long bone

• 1. Diaphysis- shaft of the bone
• Diathrough physisgrowth
• Contains medullary cavity (yellow in adults)
• 2. Epiphysis- epiabove physisgrowth
• Epiphyseal line- where diaphysis joins epiphysis
• Located at the metaphysis
• Articular cartilage- thin layer of hyaline cart
  to reduce friction cushion joint

11
Bone Membranes

• Periosteum double-layered membrane
• Outer fibrous layer is dense regular connective
  tissue
• Inner osteogenic layer is composed of osteoblasts
  and osteoclasts
• Richly supplied with nerve fibers, blood, and
  lymphatic vessels, which enter the bone via
  nutrient foramina
• Secured to underlying bone by Sharpeys fibers
• Endosteum delicate membrane covering internal
  surfaces of bone
• Active in bone repair

12
Structure of other bones

• No shaft or epiphysis
• Contain bone marrow but no cavity
• Thin plates of periosteum covered compact bone
  b/t endosteum covered spongy bone w/in
• Internal layer of spongy bone diploe

13
Types of bone

• 1. Compact- has osteon
• 2. Spongy- no osteons
• Lattice of plates called trabeculae (contain
  lacuna)
• w/in the trabeculae are marrow
• B.V.s from periosteum penetrate into spongy bone
  osteocytes are nourished directly from blood in
  marrow cavity

14
Bone cell types ( 2 of bone mass)

• 1. osteoprogenitor cells (osteogenic)
• Derived from mesenchyme have ability to
  differentiate into osteoblasts assist in
  fracture repair
• Found in the osteogenic layer of
  periosteum/endosteum, through Volkmanns canals
• 2. osteoblasts
• No mitotic potential found in osteogenic layer
  of peri/endosteum
• Secrete the organic components some of the
  mineral salts involved in bone formation (called
  osteoid) mature into osteocytes
• 3. osteocytes-cannot divide but maintain cellular
  activity
• Principle cells of bone tissue maintain bone
  matrix repair damaged bone
• 4. osteoclasts-found on inner peri/endosteum
• Derived from circulating monocytes and function
  to resorb bone

15
Bone (Osseous) Tissue

• Figure 63 Types of Bone Cells.

16
Intercellular substance

• 1. Matrix Proteins- organic matrix (primarily
  collagen, some glycoproteins)
• Somewhat flexible
• Approx. 35 of content
• Osteoblasts, osteocytes, osteoclasts
• 2. Mineral salts (hydroxyapatites)- primarily
  calcium phosphate, Ca3(PO4)2
• Approx 65 of content
• Extremely strong, responsible for bone hardness
  and its resistance to compression

17
Microscopic Structure of Compact Bone

• Osteon, or Haversian system the structural unit
  of compact bone
• Lamella weight-bearing, column-like matrix
  tubes composed mainly of collagen
• Haversian, or central canal central channel
  containing blood vessels and nerves
• Volkmanns (perforating) canals channels lying
  at right angles to the central canal, connecting
  blood and nerve supply of the periosteum to that
  of the Haversian canal
• Lacunae small cavities in bone that contain
  osteocytes
• Canaliculi hairlike canals that connect lacunae
  to each other and the central canal

18
Microscopic Structure of Compact Bone
19
Compact and Spongy Bone

• Figure 64a The Histology of Compact Bone.

20
Spongy Bone

• Does not have osteons
• The matrix forms an open network of trabeculae
• Trabeculae have no blood vessels
• The space between trabeculae is filled with red
  bone marrow
• which has blood vessels
• forms red blood cells and supplies nutrients to
  osteocytes
• In some bones, spongy bone holds yellow bone
  marrow which stores fat

21
Bone formation (osteogenesis)

• Osteogenesis occurs throughout life but in
  different ways
• 1. embryo responsible for laying down of bony
  skeleton (ossification well started by 8th week)
• 2. bone growth continues until early adulthood
• 3. remodeling repair continues for life
• Ossification - The process of replacing other
  tissues with bone (endochondral and
  intramembranous)
• Calcification - The process of depositing calcium
  salts
• Occurs during bone ossification and in other
  tissues

22
2 types of ossification

• 1. Intramembranous (dermal ossification)
• Formation of most of the flat bones of the skull
  and the clavicles from a fibrous membrane
• Fibrous connective tissue membranes are formed by
  mesenchymal cells
• 2. Endochondral
• Formation of bone in hyaline cartilage
• Both lead to the same type of bone
• Both begin with migration of mesenchymal cells
  from c.t. to areas of bone formation
• No blood supply? chondroblasts
• Blood supply?osteoblasts

23
Intramembranous Ossification Step 1

• Mesenchymal cells aggregate
• differentiate into osteoblasts
• begin ossification at the ossification center
• develop projections called spicules

24
Intramembranous Ossification Step 2

• Blood vessels grow into the area
• to supply the osteoblasts
• Spicules connect
• trapping blood vessels inside bone

25
Intramembranous Ossification Step 3

• Spongy bone develops and is remodeled into
• osteons of compact bone
• periosteum
• or marrow cavities

26
Endochondral Ossification

• Begins in the second month of development
• Uses hyaline cartilage bones as models for bone
  construction
• Requires breakdown of hyaline cartilage prior to
  ossification

27
Endochondral Ossification Step 1

• Chondrocytes in the center of hyaline cartilage
• enlarge
• form struts and calcify
• die, leaving cavities in cartilage

28
Endochondral Ossification Step 2

• Blood vessels grow around the edges of the
  cartilage
• Cells in the perichondrium change to osteoblasts

• producing a layer of superficial bone around the
  shaft which will continue to grow and become
  compact bone (appositional growth)

29
Endochondral Ossification Step 3

• Blood vessels enter the cartilage
• bringing fibroblasts that become osteoblasts
• spongy bone develops at the primary ossification
  center

30
Endochondral Ossification Step 4

• Remodeling creates a marrow cavity
• bone replaces cartilage at the metaphyses

31
Endochondral Ossification Step 5

• Capillaries and osteoblasts enter the epiphyses
• creating secondary ossification centers

32
Endochondral Ossification Step 6

• Epiphyses fill with spongy bone
• cartilage within the joint cavity is articulation
  cartilage
• cartilage at the metaphysis is epiphyseal
  cartilage

33
Epiphyseal Lines

• When long bone stops growing, after puberty
• Epiphyseal cartilage disappears
• At young adulthood cartilage division slows and
  the plate becomes smaller until it is reduced to
  a fine line epiphyseal line
• Females? age 18 Males?age 21

34
Blood Supply of Mature Bones

• 3 sets of blood vessels develop
• Nutrient artery and vein
• a single pair of large blood vessels enters the
  diaphysis through the nutrient foramen
• Metaphyseal vessels
• supply the epiphyseal cartilage where bone growth
  occurs
• Periosteal vessels provide
• blood to superficial osteons
• secondary ossification centers

35
Mature Bones

• As long bone matures
• osteoclasts enlarge marrow cavity
• osteons form around blood vessels in compact bone
• Effects of Exercise on Bone
• Mineral recycling allows bones to adapt to stress
• Heavily stressed bones become thicker and
  stronger
• Bone Degeneration
• Bone degenerates quickly
• Up to 1/3 of bone mass can be lost in a few weeks
  of inactivity

36
Bone Formation and Growth

• Figure 69 Heterotopic Bone Formation.

37
Effects of Hormones and Nutrition on Bone

• 1. Growth hormone
• Single most important stimulus to the epiphyseal
  plate (dwarfism/gigantism)
• 2. Thyroid hormone
• Moderates growth hormone to insure proper
  proportions of growth
• 3. Sex hormones (estrogens androgens)
• A great rush at puberty growth spurt
• Lead to a breakdown of cartilage that leads to a
  closure of plates steroids!
• 4. Calcitriol
• Made in kidneys synthesis requires
  cholecalciferol
• Helps absorb calcium phosphorus from GI tract

38
Additional dietary regulators

• Need adequate calcium, phophorus, magnesium,
  flouride, iron, manganese
• Calcium is necessary for
• Transmission of nerve impulses
• Muscle contraction
• Blood coagulation
• Secretion by glands and nerve cells
• Cell division
• Vitamin D absorption of calcium from GI
• Vitamin C formation of collagen
• Vitamin A stimulates osteoblast activity
• Vitamins K and B12 - help synthesize bone proteins

39
Chemical Composition of Bone
40
Control of Remodeling

• Two control loops regulate bone remodeling
• Hormonal mechanism maintains calcium homeostasis
  in the blood
• Mechanical and gravitational forces acting on the
  skeleton

41
Hormonal (-) feedback mechanism

• 1. PTH (parathyroid hormone)
• Released in response to dropping blood levels of
  calcium
• Stimulates osteoclastsraise blood Ca levels
• Increases absorption from digestive tract
• Causes reabsorption from kidneys
• 2. Calcitonin (secreted by thyroid)
• Causes Ca salts to be deposited in boneinhibits
  osteoclast activity increases calcium excretion
  at kidneys
• Mechanism is designed to maintain blood Ca at
  9-11 mg/100ml
• Ca is vital for nerve conduction muscle
  contraction
• BIG problems w/ breakdown in homeostasis

42
Calcium Homeostasis

• Figure 616a Factors That Alter the Concentration
  of Calcium Ions in Body Fluids.

43
Hormones for Bone Growth and Maintenance
44
Response to Mechanical Stress

• Wolffs Law bone remodels in response to stress
  placed upon it
• A deforming bone produces a minute electrical
  current. (-) on side of compression () on side
  of tension(-) seems to stimulate osteoblasts
  the calcification of bone

45
Bone Fractures (Breaks)

• Bone fractures are classified by
• The position of the bone ends after fracture
• The completeness of the break
• The orientation of the bone to the long axis
• Whether or not the bones ends penetrate the skin

46
Types of Bone Fractures

• Nondisplaced bone ends retain their normal
  position
• Displaced bone ends are out of normal alignment
• Complete bone is broken all the way through
• Incomplete bone is not broken all the way
  through
• Linear the fracture is parallel to the long
  axis of the bone
• Transverse the fracture is perpendicular to the
  long axis of the bone
• Compound (open) bone ends penetrate the skin
• Simple (closed) bone ends do not penetrate the
  skin
• Comminuted bone fragments into three or more
  pieces common in the elderly
• Spiral ragged break when bone is excessively
  twisted common sports injury
• Depressed broken bone portion pressed inward
  typical skull fracture
• Compression bone is crushed common in porous
  bones
• Epiphyseal epiphysis separates from diaphysis
  along epiphyseal line occurs where cartilage
  cells are dying
• Greenstick incomplete fracture where one side
  of the bone breaks and the other side bends
  common in children

47
The Major Types of Fractures
48
The Major Types of Fractures
49
Fracture Repair Step 1

• Bleeding
• produces a clot (fracture hematoma)
• establishes a fibrous network
• Bone cells in the area die

50
Fracture Repair Step 2

• Cells of the endosteum and periosteum
• Divide and migrate into fracture zone
• Calluses stabilize the break
• external callus of cartilage and bone surrounds
  break
• internal callus develops in marrow cavity

51
Fracture Repair Step 3

• Osteoblasts
• replace central cartilage of external callus
• with spongy bone

52
Fracture Repair Step 4

• Osteoblasts and osteocytes remodel the fracture
  for up to a year
• reducing bone calluses

53
Osteoporosis

• Bone reabsorptiongtbone production
• Osteopenia begins between ages 30 and 40
• Women lose 8 of bone mass per decade, men 3
• Decrease in bone mass?increase fracture risk
• Decreased levels of estrogen primarily
• Most important cause of fracture in womengt50
• 35 of bone mass may be gone by age 70
• Vertebrae femur neck are most affected

• Risk Factors
• Body build short women have less bone mass
• Weight thinner at greater risk
• Smoking decreases estrogen levels
• Lack of dietary calcium
• Exercise decrease rate of absorption
• Drugs alcohol, cortisone, tetracycline
• Premature menopause

54
Osteopenia

• Figure 619 The Effects of Osteoporosis on Spongy
  Bone.

55
Homeostatic Imbalances

• Osteomalacia
• Bones are inadequately mineralized causing
  softened, weakened bones
• Main symptom is pain when weight is put on the
  affected bone
• Caused by insufficient calcium in the diet, or by
  vitamin D deficiency
• Rickets
• Bones of children are inadequately mineralized
  causing softened, weakened bones
• Bowed legs and deformities of the pelvis, skull,
  and rib cage are common
• Caused by insufficient calcium in the diet, or by
  vitamin D deficiency

56
Developmental Aspects of Bones

• The embryonic skeleton ossifies in a predictable
  timetable that allows fetal age to be easily
  determined from sonograms
• At birth, most long bones are well ossified
  (except for their epiphyses)
• By age 25, nearly all bones are completely
  ossified
• In old age, bone resorption predominates
• A single gene that codes for vitamin D docking
  determines both the tendency to accumulate bone
  mass early in life, and the risk for osteoporosis
  later in life

57
Fetal Primary Ossification Centers at 12 weeks
of age
