Implementing ISA Server Publishing

1
Implementing ISA ServerPublishing
2
Introduction

• What Are Web Publishing Rules?
• ISA Server uses Web publishing rules to make Web
  sites on protected networks available to users on
  other networks, such as the Internet.
• A Web publishing rule is a firewall rule that
  specifies how ISA Server will route incoming
  requests to internal Web servers

3

• Web publishing rules provide
• Access to Web servers running HTTP protocol
• HTTP application-layer filtering
• Path mapping
• User authentication
• Content caching
• Support for publishing multiple Web sites using a
  single IP address
• Link translation

4
What Are Server Publishing Rules

• Web publishing and secure Web publishing rules
  can grant access only to Web servers using HTTP
  or HTTPS.
• To grant access to internal resources using any
  other protocol, you must configure server
  publishing rules
• Server publishing rules provide
• Access to multiple protocols
• Application-layer filtering for specified
  protocols
• Support for encryption
• IP address logging for the client computer

5
Considerations for Configuring DNS for Web and
Server Publishing
6
Configuring Web Publishing Rules

• Components of a Web Publishing Rule
  Configuration
• Web publishing rules map incoming HTTP or HTTPS
  requests to the appropriate Web servers located
  on a network protected by ISA Server.
• Web publishing rules determine what incoming
  requests for HTTP objects will be accepted by ISA
  Server and how ISA Server will respond to those
  requests.

7
How to Configure Web Listeners

• Web listeners are used by Web and secure Web
  publishing rules.
• A Web listener is an ISA Server configuration
  object that defines how the ISA Server computer
  listens for HTTP requests and SSL requests.
• The Web listener defines the network, IP address,
  and the port number on which ISA Server listens
  for client connections.

8
How to Configure Web Listeners

• If the ISA Server computer receives a HTTP or
  HTTPS on a network adapter and no Web listener is
  configured for the IP address associated with the
  network adapter, ISA Server will discard all the
  requests before applying Web server publishing
  rules.

9
How to Configure Web Listeners

• NetworkThis option specifies the network on
  which ISA Server will listen for incoming Web
  requests
• Port numbersThis option specifies the port
  number on which the Web listener will listen for
  incoming Web requests
• Client authentication methodsThis option
  specifies the supported authentication methods if
  you are going to require authentication on the
  Web listener
• Client Connection SettingsThis option specifies
  the number of concurrent client connections and
  connection timeout values for the Web listener.

10
How to Configure Web Listeners
11
If you have multiple network adapters or multiple
IP addresses
12

• On the Port Specification page, select the
  protocol and port number used by the Web listener

13

• modify the Web listener settings by
  doubleclicking the Web Listener object in the
  Toolbox

14

• To configure the client connection options, click
  Advanced on the Preferences tab to get to the
  Advanced Settings dialog box

15
How to Configure Path Mapping

• Path mapping is an ISA Server feature that
  enables ISA Server to redirect user requests to
  an alternate path on internal Web servers.
• When a user connects to a Web site published on
  ISA Server, the user types a specific URL.
• Before forwarding a request to the published Web
  server, ISA Server checks the URL specified in
  the request
• If a path mapping is configured for that URL, ISA
  Server will replace the path specified in the
  request with an internal path name and forward it
  to the appropriate Web server

16
How Path Mapping Works

• Path mapping can be used in several different
  scenarios
• For example
• An organization may have a Web sitehttp//www.coh
  ovineyard.com.
• If the entire Web site is located on a single Web
  server you can use path mapping to redirect
  client requests to different virtual directories
  on that server.
• The URL http//www.cohovineyard.com/catalog can
  be redirected to a virtual directory named
  CurrentCatalog on the Web server
• the URL http//www.cohovineyard.com/sales is
  redirected to the SalesData virtual directory

17

• You can also use path mapping to redirect client
  requests to multiple internal Web servers.
• For example
• when users request the URL http//www.cohovineyard
  .com/sales,they can be directed to the Sales
  virtual directory on one Web server.
• When users request the URL http//www.cohovineyard
  .com/catalog, they are redirected to a Catalog
  virtual directory on another Web server

18
How to Configure Path Mapping

• ISA Server Management -gtFirewall Policy-gtWeb
  publishing rule-gtTasks-gtEdit Selected Rule.

19
(No Transcript)
20
How to Configure Link Translation

• Path mapping allows you to redirect client
  requests from the ISA Server computer to
  different locations on one or more Web servers.
• By using path mapping you can mask a complex
  internal Web server configuration and present a
  simple Web site view to the Internet.
• Link translation can provide the same end result,
  but is used in different situations.
• Link translation is used when the Web pages
  published on ISA Server contain links to other
  Web servers on the protected network, and those
  Web servers are not accessible from the Internet

21

• Link translation is an ISA Server configuration
  object that enables ISA Server to replace
  internal server names on Web pages with server
  names that are accessible from the Internet
• Some published Web sites may include references
  to internal names of computers other than the
  server listed in the Web publishing rule

22
Link Translation Levels

• Header link translation
• Translation of links in the body of a returned
  Web page
• EXWeb page on a server named Web1 is accessed
  through the URL www.cohovineyard.com may include
  a reference to an image using http//Web1.cohovine
  yard.com/images/image1.jpg
• Translation of links to other internal Web pages

23
How to Configure Link Translation

• ISA Server Management-gtFirewall Policy-gtWeb
  publishing rule-gtLink Translation

24
(No Transcript)
25
How to Configure Web Publishing Rules

• ISA Server Management-gtTasks-gtPublish A Web Server

26
Configuring Secure Web Publishing Rules

• Secure Web publishing provides an additional
  layer of security when publishing an internal Web
  site by enabling the option to use SSL to encrypt
  all network traffic to and from the Web site.
• Secure Web publishing is critical when securing
  Web sites that contain confidential information,
  or when the Web site asks clients to submit
  confidential information such as credit-card
  numbers

27
Components of a Secure Web Publishing Rule
Configuration

• What Is Secure Sockets Layer?
• Secure Sockets Layer (SSL) is used to validate
  the identities of two computers involved in a
  connection across a public network, and to ensure
  that the data sent between the two computers is
  encrypted.
• To do this, SSL uses digital certificates and
  public and private keys.

28
What Is Secure Sockets Layer

• SSL enables the following features
• Server authentication
• Client authentication
• Encrypted SSL connections

29
SSL Configuration Options

• SSL tunneling
• the SSL connection is set up directly between the
  client computer and the Web server
• the ISA Server computer does not encrypt or
  decrypt the network packets but merely forwards
  encrypted packets between the client and the Web
  server.
• ISA Server cannot inspect the content of the
  packets because the contents are encrypted as
  they pass through theISA Server computer.

30

• SSL bridging
• the ISA Server computer acts as the end point for
  one or more SSL connections
• The network packets can still be encrypted from
  the Web client to the Web server.
• however, in an SSL bridging scenario, the ISA
  Server computer will decrypt network traffic from
  the client computer and then re-encrypt it before
  sending it to the Web server

31
Enabling SSL on ISA Server

• If you plan to use SSL in an SSL tunneling
  configuration, you must install a digital
  certificate only on the Web server. The Web
  server and the client will use this certificate
  and the associated keys to create the SSL
  connection.
• If you plan to use SSL in a SSL bridging
  configuration, you must install a digital
  certificate on the ISA Server computer, and
  possibly, on the Web server.To create an SSL
  connection with the client, the ISA Server
  computer must have a certificate installed.
• If you require client certificates, you also need
  install digital certificates on each client
  computer.

32
How to Install Digital Certificates on ISA Server

• How to Configure a New Secure Web Publishing Rule

33
Configuring Server Publishing Rules

• Web publishing rules are used on ISA Server to
  enable access to HTTP and HTTPS content on
  internal Web servers.
• Server publishing rules are used to enable access
  to internal applications that use other
  protocols.
• Server publishing is a secure and flexible way to
  publish the content or services provided by
  internal servers to the Internet

34
Components of a Server Publishing Rule
Configuration

• Server publishing rules are used on ISA Server to
  map a port number on an external interface of the
  ISA Server computer to the IP address of an
  internal server providing a specific service.
• When ISA Server receives a request on the
  external IP address for a specific port, it
  passes the request to the internal server defined
  on the server publishing rule

35

• ISA Server performs the following steps
• 1.A client computer on the Internet needs to
  access an application server on a network
  protected by the ISA Server computer. the client
  computer will perform a DNS lookup to locate the
  IP address for the server that is providing the
  service
• 2. ISA Server checks the destination port number
  and then uses the server publishing rule to map
  the request to an IP address of an internal
  server.
• 3. The internal server returns the object to the
  ISA Server computer, which passes it on to the
  requesting client

36
How to Configure a Server Publishing Rule
