Finite element modelling and simulation of knee motion

1
Finite element modelling and simulation of knee
motion
Derek Bickerstaff Thornbury Hospital, Sheffield,
UK

• ACL STUDY GROUP MEETING
• MAY 29 JUNE 4, 2004, SARDINA

2
AIMS

• Develop validate a high-quality 3-D finite
  element (FE) knee model
• To serve as a template for constructing
  patient-specific FE meshes
• Develop method to morph template model into
  patient-specific FE knee models
• To enable the investigation of kinematic motion
  of pathologic knees using finite element
  simulations

3
Creating a Morphable Template
Acquire high resolution magnetic resonance (MR)
volume of knee
Identify label (segment) tissue structures
DONE ONCE
Template set of 3-D segments
Use segments to construct 3-D template finite
element knee mesh
20mins
3-D Register template segments to patient MR
images
RE-USED MANY TIMES
3-D Mapping function results
Apply mapping to template mesh to generate
patient FE mesh
lt 1 min
4
3-D MRI Sequence

• High-resolution MRI volume acquisition
• Developed for Simbio EU Project
• 0.35mm x 0.35mm x 2mm
• T2 TR47ms, TE15ms, Flip angle30º, gradient
  echo sequence
• Optimised for cartilage imaging
• Ensure accurate segmentation to generate smooth
  articulating surfaces

5
Segmenting Template MRI Volume
Bones soft tissue structures segmented
manually from MR images
6
Generating Template FE Mesh

• 3-D segments meshed using ANSYS and Matlab
  software
• Some optimisation of anatomy necessary to ensure
  good quality mesh
• Very low volume elements lead to numerical
  instability
• Thin / tapering anatomies truncated (e.g.
  meniscal horns)

7
Final Template FE mesh

• Final template 3-D FE mesh consisted of
• 3,464 8-node solid elements (cartilages
  menisci
• 13,120 shell elements (mostly for rigid bones)
• 232 bar/beam elements (ligaments)

8
Template to Patient-Specific FE knees
Template Red Patient Green
Registered yellow

• 3-D register template MR segment images to
  patient MR volume (set of images)
• using a non-linear algorithm (vreglocal3d)
  developed in-house
• Mapping function results

9
Morphing the Template Mesh

• Mapping function from registration process used
  to morph the template mesh
• Inherent smoothness of template ? smooth patient
  mesh
• Necessary for FE simulations of articulating
  surfaces

10
Sample Patient FE Meshes

• 11 patients scanned in total
• 5 meshes generated

11
Meniscal FE meshes
MN07 partial medial meniscal injury MN02
partial medial meniscal injury MN03 partial
medial meniscal injury AC03 postero-lateral
corner injury
AC03
12
Simulation of Template Knee

• FE simulation of flexing knee boundary
  conditions imposed by exercise rig
• Posterior view of ? knee cartilages menisci
• Performed using PAM-SAFE FE solver (ESI, Rungis,
  France)

13
Method to Validate Motion

• Patient flexed knee under light load in custom
  designed MR compliant rig
• Quasi-dynamic cine MRI images acquired
• T1 cine sequence TR10ms, TE2.0ms, flip
  angle90?
• Interpolated 512 x 512 acquisition matrix
• 0.82 x 0.82 mm in-plane resolution
• 7 sagittal images for each flexion position
  total 42 (6 positions)

Pre-op motion partial lateral meniscal tear
14
Dynamic Images Segmentation

• Bones segmented manually from dynamic MR images
• Drawbacks of acquired dynamic data
• Sparse images
• Often some degree of out-of-plane motion during
  flexion

Sample femoral slices shown for 1 flexion
position
15
Dynamic Registration

• Rigid registration method
• Maps a fully segmented binary volume (3-D) onto
  the sparse dynamic binary slices (2-D)

16
Euler Angles

• Resultant transformations can be resolved for
  Euler angles for rotation throughout motion
• 6 flexion positions
• Generate affine matrix for each flexion position
• Decompose matrices into Euler angles (order Z, X,
  Y) of femur w.r.t. static tibia
• Order of resolution is important for
  interpretation. We used
• Flexion/Extension (Z)
• Internal/External Rotation (Y)
• Varus/Valgus (X)
• A sensitivity analysis of simulated data
  demonstrated registration method to be stable
  reliable to accuracies of lt1 degree
• Quoted angles that follow are with respect to the
  static knee scanned at 15 º flexion hence
  starting angles of -15º at full extension
• Can apply the calculated angles back to the
  static volumes.

17
Template Knee Motion
Both tibia and femur moving
Fixed tibia all motion shown at femur
18
Patient Motion Results
flexion internal varus

• 45º flexion ROM
• External femoral rotation
• of 8º in 1st 15º of knee
• flexion (pre-op)
• External femoral rotation
• of 15º in 1st 23º of knee
• flexion (pre-op)

Postero-lateral corner injury pre/post op
19
Patient Motion Results
flexion internal varus

• 40º flexion ROM
• External femoral rotation
• of 15º in 1st 25º of knee
• flexion

Partial lateral meniscal tear pre/post op
20
Conclusions

• Mesh morphing method works well for generating
  patient-specific finite element knee meshes
• Ensures a smooth mesh sufficient for kinematic
  simulations
• Produces better automated segmentation for knee
  than intensity-based methods
• Further development required to account for major
  pathologies
• Examination of vector fields produced by
  registration process implementation of decision
  tree based on their properties
• Additional work required to model complex nature
  of cruciate collateral ligaments
• Current advances may permit solid modelling of
  the ligaments.
• Further work required to measure muscle forces
  pretension in ligaments ? improve in vivo type
  simulations
• Basis of work to develop pre-operative planning
  system to produce bespoke image of patients knee
  to reproduce
• anatomical attachments of ligaments (e.g. ACL) to
  plan surgery
• material properties of ligament to reproduce more
  accurately normal kinematics of knee

21
Acknowledgements

• Dept. of Medical Physics, University of
  Sheffield, UK
• Dr. Rod Hose, Dr. Jill Van der Meulen, Mr David
  Chan
• Medical Physics, Sheffield Teaching Hospitals
  Trust, UK
• Prof. David Barber, Dr. Avril McCarthy, Dr.
  Steven Wood
• Academic Radiology, University of Sheffield, UK
• Dr. Iain Wilkinson, Mrs Gail Darwent
• Simbio EU Project for Funding
• Simbio A Generic Environment for Bio-numerical
  Simulation
• IST EU Programme, Project No. 10378
• www.simbio.de

22
References

• McCarthy A.D., Hose D.R., Barber D.C., Wood S.,
  Darwent G., Chan D., Bickerstaff D.R. and
  Wilkinson I.D. A registration-based MR method
  for calculating in-vivo 3-D knee joint motion
  Validating finite element simulations.
  Proceedings of the International Society for
  Magnetic Resonance in Medicine, Toronto, July
  10-16, 2003
• S. Wood, D.C. Barber, A.D. McCarthy, D. Chan ,
  I.D. Wilkinson, G. Darwent and D.R. Hose, A
  novel image registration application for the
  in-vivo quantification of joint kinematics.",
  Proceedings of MIUA 2002 Conference, 22-23 July,
  Portsmouth, UK, 2002
• U. Hartmann, G. Lonsdale, G. Berti, J. Fingberg,
  A. Basermann, R. Grebe, P. Aimedieu, D. R. Hose,
  A. McCarthy, F. Kruggel, M. Tittgemeyer, C.
  Wolters, T. Hierl, Bio-numerical simulations
  with SimBio Selected Results, Proceedings of
  International Workshop on Deformable Modelling
  and Soft Tissue Simulation, Bonn, Germany, Nov.
  14-15, 2001

23

• Extra slides to demo meshing limitations follow

24
AC03 Cartilage meshes

• AC03
• Femoral cartilage
• Anterior
• Posterior
• Tibial cartilages

25
Template Meshing limitations

• Registration process can crush elements
• may need minimal thickness flag
• could cause holes in mesh
• can warp elements by crushing

26
Meshing limitations

• Registration process can warp elements by
  stretching
