Diastolic Dysfunction: Nuts, bolts & who cares ?

1

• Diastolic Dysfunction Nuts, bolts who cares ?
• Kunjan Bhatt MD
• Austin Heart

2
Background

• For patients gt 65 years old, CHF is the most
  common diagnosis at discharge.
• The population is aging
• In the early 1900s, 4 population was gt 65.
• By 2010, 1/3 population will be gt 65.

3
Background

• Among the elderly, cardiovascular disease is the
  MOST common cause of mortality and morbidity.
• In the US, 5 million people have CHF. ½ these
  cases are from CHF with preserved LV function.

4
Background

• Classically, weve sought out causes of CHF as a
  result of systolic dysfunction.
• Now we are discovering that ½ cases of CHF is
  being caused by diastolic dysfunction, where LV
  systolic function is preserved.

5

• Lets Clarify some misconceptions

6
Misconception 1

• Diastolic dysfunction is uncommon as is Diastolic
  congestive heart failure.
• Fact 1
• Everyone and their mother over the age of 40-50
  has E/A reversal, during resting 2D echo. The
  actual incidence is 25-30 in individuals gt 45
  years.
• Over the past 10 years, incidence of Diastolic
  CHF has increased.
• 70 y.o pts incidence of CHF SHF DHF
• 80 y.o pts incidence of CHF DHF gt SHF

7
Misconception 2

• Discussions of Diastolic dysfunction cause people
  to vasovagal, fall asleep, and bore them ½ to
  death. Diastolic dysfunction is simple, SEE?
• E/A normal ? great! Normal Diastolic function!
  Stop pestering me!
• E/A reversed ? whoop-dee-do. Abnormal diastolic
  dysfunction. Can we stop talking about this now?

8
FACT 2

• This is actually ½ true this subject is great
  to put most people to sleep.
• HOWEVER, Diastolic dysfunction classification
  should not be normal or abnormal. Its
  patronizing to patients who have rip-roaring CHF
  with preserved LV function.
• Spectrum of disease. LOAD DEPENDENT!!
• This is why Im giving the talk!

9
Misconception 3

• Diastolic dysfunction Diastolic CHF
• Not quite!
• Fact 3
• Diastolic dysfunction characterizes abnormal
  relaxation of the LV, and for the purposes of
  this talk, an echo finding.
• Diastolic CHF describes a clinical syndrome of
  CHF in patient with preserved LV function.

10
Causes of Diastolic dysfunction ? Heart Failure

• Hypertension
• Hypertension
• Hypertension
• Hypertension
• Hypertension
• Hypertension
• Hypertension

11
Other Causes of abnormal Diastolic filling

• Cardiomyopathy
• Hypertrophic
• Restrictive
• Infiltrative
• CAD
• Valvular heart disease
• Diabetes
• Obesity
• Sleep Apnea
• Constrictive Pericarditis

12
Determinants of Diastolic filling
Quinones ASE Review 2007
13
Topics for Discussion

• Brief Review of Diastolic physiology
• MV inflow patterns
• IVRT Isovolumic Relaxation time
• DT Deceleration time
• Velocity of propagation
• Tissue Doppler of the MV annulus
• E/E
• Atrial Fib and Sinus Tachycardia
• Diseases of the Pericardium
• The who cares factor

14
Normal Diastolic function

• Occupies about 2/3 of the cardiac cycle. Takes
  longer than systole
• Active process, requires energy
• Abnormalities of diastolic function ALWAYS
  precede those of systolic function.
• Ex Acute MI

15
Normal Diastolic filling

• 1. Isovolumic Relaxation
• 2. Early rapid diastolic filling phase
• 3. Diastasis
• 4. Late diastolic filling due to atrial
  contraction

Quinones, ASE Review 2007
16
Normal Diastolic function

• When LV pressure becomes less than LA pressure,
  MV opens
• Rapid early diastolic filling begins.
• Driving force is predominantly elastic recoil and
  normal relaxation.
• 80 LV filling during this phase

17
Normal Diastolic function

• As a result of rapid filling, LV pressure rapidly
  equilibrates with and may exceed LA pressure.
• Results in deceleration of MV inflow.
• Late diastolic filling is from atrial
  contraction. Its 20 LV filling.

18

• MV Inflow Patterns

19
MV inflow Patterns

• 5 stages Normal and Stages I IV diastolic
  dysfunction
• Stage I Impaired relaxation
• Stage II Pseudo-normal
• Stage III Restrictive Filling, reversible
• Stage IV Restrictive Filling, irreversible

20
MV PW inflow patterns
21
MV inflow pattern limitations
Advantages Disadvantages
22

• DT and IVRT

23
IVRT Isovolumic relaxation time

• Time interval between aortic valve closure and
  mitral valve opening. Usually obtained from
  Apical view with Doppler sample between AV and MV

• It will lengthen with impaired LV relaxation and
  decrease with with increase in LV filling
  pressures.
• Normal 70 90 ms.

24
DT and IVRT

• DT - Peak of the E wave time interval for the E
  wave velocity to reach 0.
• PHT 0.29 DT
• IVRT time interval of AV closure to MV opening.

25
Deceleration time

• Nl 160 220 ms
• Deceleration time increases, if there is abnormal
  relaxation. It decreases in elevated LV filling
  pressures
• The LV can also relax vigorously from tremendous
  elastic recoil such as young healthy people
  (short DT but normal)
• Conversely, if there is a decrease in LV
  compliance or a significant increase in LA
  pressure ? DT decreases (pathologic suggests
  elevated filling pressures)

26
IVRT DT Strengths and Weaknesses
Strengths Weaknesses
Lester et al, JACC 2008 51 679 - 689
27

• Velocity of Propogation
• (color M-mode of MV inflow)

28
Velocity of propagation of mitral inflow

• Normally, there is a intraventricular pressure
  gradient.
• Apical lt Base
• This gradient decreases with a decrease in
  myocardial relaxation
• Color M mode displays color coded mean velocities
  from the annulus to the apex over time.

29
Velocity of propagation of mitral inflow

• Color flow baseline needs to be shifted to lower
  the nyquist limit.
• The central highest velocity jet should be blue.
• Trace the slope of the first aliasing line.
• gt 50 cm/s normal
• lt 50cm/s abnormal
• Load dependent.
• Hard to do accurately

30
Velocity of propagation of mitral inflow

• Vp has been used to estimate filling pressures
  (PCWP)
• 1. E/Vp gt 1.5 ? PCWP gt 15 mmHg
• 2. PCWP 4.5 1000/(2 x IVRT) Vp 9
• 3. PCWP (5.27 x E/Vp) 4.6
• Falsely high in restrictive Cardiomyopathy and
  HOCM.

31
MV inflow propagation velocity Strengths and
Weaknesses
Strengths Weaknesses
Lester et al, JACC 2008 51 679 - 689
32

• LA Volume

33
LA Volume Index

• EASY TO DO!!
• The new echo GOLD STANDARD for LA size.
• LA 2D dimension extrapolates that LA enlarges in
  an AP diameter. Erroneous assumption.
• Correlates much better with the true gold
  standard which is MRI.

• Has been called the HbAIC of cardiac disease.
  Robust marker of clinical outcomes
• WHAT DO YOU NEED
• BSA (remember, its an index)
• A4C and A2C traced LAs
• Shortest length

34
LA volume

• Divide the LA volume by BSA!!
• A-L method is used most commonly (we dont like
  calculus)
• 22 /- 6 ml / m2 (normal)
• 28-34 - mild
• 34-40 - moderate
• gt40 - severe

35
LA volume Strengths and Weaknesses
Strengths Weaknesses
Lester et al, JACC 2008 51 679 - 689
36

• Pulmonary Vein Profile

37
Pulmonary venous flow

• Normally 4 different waves seen S1/S2/D/A
• Normal S dominance.
• Young people can have a D dom normally

38
Pulmonary Vein Profile

• PVs1 early in systole and relates to atrial
  relaxation. A decrease in LA pressure promotes
  forward flow.
• PVs2 mid systole. Represents the increase in
  pulmonary venous pressure.
• Normally the S2gtS1
• Distinction only identifiable in about 30
  people, normally.

39
Pulmonary Vein Profile

• PVd occurs after opening of the MV and in
  conjunction with decrease in LA pressure
• Pva increase with atrial contraction. May
  result in a flow reversal into the PV. Depends
  upon
• LV diastolic pressure
• LA compliance
• HR

40
Pulmonary Vein Profile

• Think of PVd and Pva as extensions of MV inflow E
  and A.
• The peak velocity and DT correlate well with
  those of mitral E velocity because the LA acts as
  a passive conduit for flow during early diastole.
• DT becomes shorter as PCWP increases.
• Both Pva velocity and duration increase with
  higher LVEDP.

41
PV profiles in diastolic dysfunction.
42
Pulmonary Vein flow Strengths and Weaknesses
Strengths Weaknesses
Lester et al, JACC 2008 51 679 - 689
43

• Tissue Doppler
• (heres where it gets ugly)

44
Tissue doppler

• Measuring tissue velocity and NOT blood flow
• Speed of tissue is 1/10 of arterial blood.
• Arterial blood velocity 150 cm/s
• Venous Blood velocity 10 cm/s
• Myocardial Tissue velocity 1 20 cm/s
• Speed usually expressed in cm/s

45
Tissue Doppler What we change on echo Machines

• Doppler instruments are altered to reject the
  high velocity of blood
• Requires a high frame rate
• DECREASE GAIN!
• Lower aliasing velocities

46
QUESTION

• WHAT ARE THE 3 profiles seen on Tissue Doppler?

47
Tissue doppler

• 3 velocity profiles are seen systolic (S),
  Early Diastolic (E) and late diastolic (A)
• S systolic velocity of the MV annulus.
• Normally should be gt 6 cm/s
• Can perform segmental or regional functional
  assessment
• E Early Diastolic velocity
• 2 sites are typically measured medial and
  lateral Normal Range
• Em gt 10 cm/s
• El gt 15 cm/s
• A - Late diastolic velocity.
• Atrial contraction
• Correlates with LA function
• Increases in early diastolic dysfunction
• decreases with LA dysfunction (later diastolic
  dysfunction)

48
TDI - applications

• Beyond E and E/E, mostly in research
• Evaluation of Thick Walls
• LVH, HCM, Infiltrative CM, Restrictive CM,
  Athlete's Heart
• Normal TDI and strain vs abnormal TDI and strain
• Assessment of viability (akinetic vs scar).
• Relates to Tissue velocity gradients

49
Tissue Doppler Normal Profiles
Lateral gt 15 cm/s
Medial gt 10 cm/s
50
Tissue Doppler

• E velocity is essential for classifying the
  diastolic filling pattern and estimating filling
  pressures.
• Helpful to differentiate myocardial disease from
  pericardial disease
• Normally E increases with an increase in the
  transmitral gradient (exertion or increase
  preload)
• In Diastolic Dysfunction its low doesnt
  increase as much with exertion or inc. preload

51
Tissue Doppler

• E decreases with aging (precedes even E/A
  reversal)
• Load independent! Reproducible
• One of the earliest markers for diastolic
  dysfunction
• Correlates with filling pressures, especially
  when used as a ratio
• E/E

52
Tissue Doppler

• STRENGTHS
• 1. Can be obtained in most patients
• 2. Early marker of diastolic dysfunction
• 3. Not influenced by changes in heart rate
• 4. Primarily load independent in disease states

• WEAKNESSES
• 1. Influenced by local changes in wall motion
  (infarction)
• 2. Not accurate in significant MV disease
• - MAC
• - MVR

53
Who cares about Tissue Doppler? (beyond the Echo
Nerd Herd)

• E/E can guesstimate PCWP
• gt15 ? wedge gt 20
• lt 8 normal
• 8 - 15 ??
• E/E has been validated in clinical studies as a
  marker of elevated PCWP (gt 15).

• Elevated E/E is predictive of poor outcomes in
  MI
• Significantly decreased E associated with higher
  mortality.

54
E/E is a robust clinical marker

• What the ratio means?
• gt 15 ? elevated filling pressures
• lt 8 ? Nl
• 8 15 ? ???

Nagueh et al, JACC 1997 30 1527 - 1533
55
Assessment of Diastolic filling in A-fib and
Sinus Tachycardia

• A fib
• No A wave from Mv inflow and blunted PVs wave
• DT time measurement is tricky, variable
• Can use E/E
• Can use DT of the PVd wave
• Sinus Tachycardia
• E and A waves may fuse.
• Use E/E

56
Lets Review
57
Normal MV inflow

• E/A 0.9-1.5
• DT 160-240 ms
• IVRT 70-90 ms
• Vp gt 50 cm/s
• S dominant PV pattern

58
Stage I

• DT gt 240 ms
• E/A lt 0.9
• IVRT - gt 90 ms
• LAVIgt28 ml/m2
• Elt10
• Vp lt 50 cm/s
• S dominant PV pattern

59
Stage II

• Looks the same like normal hence the name
  pseudonormal
• Many of the parameters are the same as Normal LV
  inflow.
• PV S blunting or D dominant PV

60
How do I differentiate between Stage II and
normal?

• Valsalva shouldnt change normal but
  pseudonormal should look like Stage I. Also Stage
  III should look like stage I
• E (Tissue Doppler) Normal is normal. Lower
  velocities with diastolic dysfunction (Em lt10,
  El lt 15).
• Left atrial volume With elevated filling
  pressures, the left atrium will remodel and
  enlarge (LA Volume Index gt 28 ml / m2)
• Velocity of propagation - gt 50 cm/s (normal) or lt
  50 cm/s (abnormal)
• D dominant pulmonary veins

61
Stage II

• Valsalva
• ???

62
The 4 Phased Valsalva Maneuver

• PHASES
• I - AO pressure increases (increase in IT pres.)
• II AO and PP decrease because dec. in preload.
  Reflex tachycardia.
• III AO pressure decreases more in response to
  release of IT pressure
• IV recovery period. Preload, AO, PP increase.

Nishimura et al. Mayo clinic proceedings.
200479 577-578.
63
Stage III Restrictive,reversible

• DT lt 160 ms
• IVRT lt 70 ms
• E/A gt 21
• E lt 5cm/s
• Vp lt 50 cm/s
• LAVI gt 35 ml / m2
• DgtgtS (PV Pattern)

64
Stage III Restrictive, reversible

• Valsalva
• ???

65
Stage IV restrictive irreversible

• DT lt 130ms
• E/A gt 2.5
• E lt 5 cm/s
• Vp lt 50 cm/s
• IVRT lt 70ms
• LAVI gt 40
• No valsalva change
• DgtgtS (PV pattern)

66
What about other causes of CHF with preserved LV
function

• TEE 5C view

67
Causes of pericardial constriction

• Prior Cardiac surgery
• Idiopathic
• Pericarditis
• Prior Radiation
• Collagen Vascular
• Infection (TB)

68
Constrictive Pericarditis

• Everything weve spoken about for diastolic
  dysfunction DOES NOT APPLY HERE.
• Not uncommon
• Escapes clinical and echo detection
• Pericardial Thickness may be normal in 1/5th of
  cases
• Calcification of the pericardium may only occur
  in 20 pts on CXR

69
Constrictive Pericarditis some Echo findings

• Thickened pericardium ( 80)
• Abnormal ventricular septal motion
• Flattening of the posterior wall during diastole
• Respirophasic variation of Ventricular cavity
  size
• Dilated IVC

70
Echo criteria to diagnose Pericardial Constriction

• 1)Disassociation between intrathoracic and
  intra-pericardial pressures. (normally theyre
  related)
• 2)Exaggerated ventricular interdependence (i.e.
  the filling of one, significantly impacts the
  filling of the other)

71
Doppler Findings in Constrictive Pericarditis

• Respiratory variation of gt25 in mitral E
  velocity

72
Doppler Findings in Constrictive Pericarditis

• OH Figure 17-29

• Increased DFR with expiration in the hepatic vein.

73
Other features of constriction

• Tissue doppler that is gt 7 cm/s (annulus
  paradoxus)
• Unless the myocardium is involved, myocardial
  relaxation is intact.
• Septal annular velocities are normal or even
  increased (not close to the pericardium like the
  lateral annulus)
• PW MV inflow that looks like restrictive filling
  pattern ?
• E/A gt 1.5 and DT lt 160 ms.
• E/E is inversely proportional to the PCWP (as
  opposed to myocardial diseases).

74

• WHO CARES?

75
Who cares about diastolic dysfunction?

• Steady rise in prevalence of CHF with preserved
  LV function.
• By the 7th decade, incidence of diastolic CHF
  systolic CHF
• By the 8th decade, incidence of diastolic CHF gt
  systolic CHF
• The survival of patients with the clinical
  syndrome of heart failure is similar in those
  with persevered versus those with a reduced LV
  ejection fraction

76
Summary

• Diastolic Dysfunction is a real, dynamic process.

• Much information can be gained on LV filling
  pressures without a drop of blood (no cath)
• Prognostic information and therapeutic options
  stem from the results (myocardial, pericardial).
• You are in the front line to look for this stuff.
  Keep a sharp look out, youll favorably alter
  patient care. Thats the bottom line.

77

• Thank you !
• (for not falling asleep)
