Steam Enhanced Remediation

1
Steam Enhanced Remediation In Fractured
Rock (and a little about the other sites) Gorm
Heron, Scientist/Engineer Hank Sowers, CEO/Chief
Operator Dacre Bush, Geologist/Program
Manager Gregg Crisp, Site manager SteamTech
Environmental Services Bakersfield, CA
2
Visalia Pole Yard
160,000 gallons removed from subsurface In-situ
destruction significant UC Berkeley LLNL - SCE
Creosote DNAPL to 140 ft depth Alluvial sands
and gravels with clays Both LNAPL and
DNAPL Approaching MCLs in 2002 Craig Eaker, SCE
3
Alameda Point
Alameda Point (Berkeley Environmental Restoration
Center)
4
Edwards AFB Site 61
5
Beale AFB
5
6
Loring Fractured limestone
7
Florida site

• Full-scale clean-up with performance guarantee
• Steam enhanced remediation and electrical
  heating
• Tight pneumatic and hydraulic control
• Stimulated oxidation reactions for reduction of
  TPH concentrations in oily areas
• Detailed subsurface monitoring (temperature and
  electrical resistance tomography)

8
Well types
Perimeter steam injection wells (SI)
Extraction well with Hawthorn electrode (EE)
Area A steam injection well with Hawthorn
electrode (SE)
Deep electrode (DE)
Steam
Electrode
Sand
Clay
Electrode
9
Preliminary results, Edwards AFB

• Acknowledgments to
• Stephen Watts, Edwards AFB project manager
• Dave Leeson, AFCEE
• Scott Palmer, Earth Tech project manager
• Gregg Crisp, site manager and operator
• Layi Oyelowo, Edwards AFB
• Results are preliminary, conclusions have not
  been published or confirmed by the above persons

10
Fractured granite (quartz monzonite)
11
Objectives/questions

• Will SER be effective for removal of VOCs from
  fractured rock at Edwards AFB?
• How is the DNAPL mobilized and extracted?
• What are the ultimate VOC cleanup levels that can
  be expected at Edwards AFB using SER?
• How rapidly will the steam heat Site 61 at
  Edwards AFB?
• How should steam injection and extraction
  well-fields be designed for optimum performance
  at Edwards AFB?
• What is the optimal steam injection and
  extraction strategy for DNAPL in fractured rock
  at Edwards AFB?
• How long will the site stay hot after completion
  of the steaming?

12
Hydrogeology
Weathered zone
30 ft
Fractured granite
13
TCE distribution
?
?
?
14
Vertical distribution of contaminants before
operations PID readings on cores
15
Extraction and steam injection wells
16
Injection well design
17
17
18
18
19
Strategy
Vacuum test Vapor capture radius 80 ft
Initially steam injection deep only, extraction
shallow Air co-injection Extract 25 to 50 more
than injected Monitor carefully and adjust
strategy
20
Subsurface monitoring network
VEA-2
VEA-4
EW-3
TMA-D
EW-4
TMA-C
IW-1
VEA-5
TMA-B
EW-1
EW-2
TMA-A
VEA-3
VEA-1
21
ERT data planes
ERT data planes
VEA-2
VEA-4
VEA-5
VEA-3
VEA-1
22
Example ERT data plane
6/23
6/27
6/10
7/6
7/10
23
Thermocouple data
Depth below grade (ft)
24
Depth below grade (ft)
25
Depth below grade (ft)
26
Water balance
27
Energy balance
28
Vapor flow rate and PID readings
29
Headspace PID data
30
Recovery of NAPL
31
Results

• Successful treatability study - great data
• Steam heated site partially, and accelerated
  mass removal
• More than 700 lbs of VOCs removed
• NAPL recovered where no NAPL was expected
• Air injection promising for opening fractures to
  steam flow, and potentially for reducing risk of
  NAPL condensation
• ERT apparently valuable at Edwards Heated
  zones showed large changes in electrical
  resistivity
• Very uneven steam distribution Increased focus
  on temperature monitoring, also in extraction
  wells
