Chapter 18FORENSIC SCIENCE ON THE INTERNET
2
Introduction

• The Internet, often referred to as the
  information superhighway, has opened a medium
  for people to communicate and to access millions
  of pieces of information from computers located
  anywhere on the globe.
• No subject or profession remains untouched by the
  Internet, and this is also true for forensic
  science.
• A major impact of the Internet will be to bring
  together forensic scientists from all parts of
  the world, linking them into one common
  electronic community.

THE INTERNET
3
A Network of Networks

• The Internet can be defined as a network of
  networks.
• A single network consists of two or more
  computers that are connected to share
  information.
• The Internet connects thousands of these networks
  so all of the information can be exchanged
  worldwide.
• Connections can be made through a modem, a device
  that allows computers to exchange and transmit
  information through telephone lines.
• Higher speed broadband connections are available
  through cable lines or through DSL telephone
  lines.

THE INTERNET
4
A Network of Networks

• Computers can be linked or networked through wire
  or wireless (WI-Fi) connections.
• Computers that participate in the Internet have a
  unique numerical Internet Provider (IP) address
  and usually a name.

THE INTERNET
5
The World Wide Web

• The most popular area of the Internet is the
  World Wide Web.
• It is considered a collection of pages stored in
  the computers connected to the Internet
  throughout the world.
• Web browsers allow the user to explore
  information stored on the Web and to retrieve Web
  pages the viewer wishes to read.

THE INTERNET
6
The World Wide Web

• Several directories and indexes on the Internet,
  known as search engines, are available to assist
  the user in locating a particular topic from the
  hundreds of thousands of web sites located on the
  Internet.
• Commercial Internet service providers connect
  computers to the Internet while offering the user
  an array of options.
• A keyword or phrase entered into a search engine
  will locate sites on the Internet that are
  relevant to that subject.

THE INTERNET
7
Electronic Mail (e-Mail)

• The service that is most commonly used in
  conjunction with the Internet is electronic mail
  (e-mail).
• This communication system can transport messages
  across the world in a matter of seconds.
• Extensive information relating to forensic
  science is available on the Internet.
• The types of Web pages range from simple
  explanations of the different fields of forensics
  to intricate details of forensic science
  specialties.

THE INTERNET
8
Forensic Analysis of the Internet

• It is important from the investigative standpoint
  to be familiar with the evidence left behind from
  a users Internet activity.
• A forensic examination of a computer system will
  reveal quite a bit of data about a users
  Internet activity.
• The data described on the next few slides would
  be accessed and examined utilizing the forensic
  techniques outlined in Chapter 17.

THE INTERNET
9
Internet Cache

• Evidence of Internet web browsing typically
  exists in abundance on the users computer.
• Most web browsers (Internet Explorer, Netscape,
  and Firefox) utilize a system of caching to
  expedite web browsing and make it more efficient.

• This web browsing Internet cache is a potential
  source of evidence for the computer investigator.

• Portions of, and in some cases, entire visited
  web pages can be reconstructed.
• Even if deleted, these cached files can often be
  recovered.

THE INTERNET
10
Internet Cookies

• To appreciate the value of the cookie you must
  first understand how they get onto the computer
  and their intended purpose.
• Cookies are placed on the local hard disk drive
  by the web site the user has visited.
• This is, of course, if the particular web browser
  being used is set to allow this to happen.
• A cookie is used by the web site to track certain
  information about its visitors.
• This information can be anything from history of
  visits or purchasing habits, to passwords and
  personal information used to recognize the user
  for later visits.

THE INTERNET
11
Internet History

• Most web browsers track the history of web page
  visits for the computer user.
• This is probably done merely for a matter of
  convenience.
• Like the recent calls list on a cell phone, the
  Internet history provides an accounting of sites
  most recently visited, with some storing weeks
  worth of visits.
• Users have the availability to go back and access
  sites they most recently visited, just by
  accessing them through the browsers history.
• The history file can be located and read with
  most popular computer forensic software packages.

THE INTERNET
12
Bookmarks and Favorite Places

• Another way users can access websites quickly is
  to store them in their bookmarks or favorite
  places.
• Like a pre-set radio station, Internet browsers
  allow a user to bookmark websites for future
  visits.
• A lot can be learned from the bookmarked sites of
  a person. Perhaps you might learn what online
  news a person is interested in or what type of
  hobbies he/she has.
• You may also see that persons favorite child
  pornography or computer hacking sites bookmarked.


THE INTERNET
13
Internet Communications

• Computer investigations often begin or are
  centered around Internet communication.
• It may be
• A chat conversation amongst many people
• An instant message conversation between just two
  individuals
• Or the back and forth of an e-mail exchange
• Human communication has long been a source of
  evidentiary material.
• Regardless of the type, investigators are
  typically interested in communication.

THE INTERNET
14
Value of the IP address

• In our earlier discussion, it was stated that in
  order to communicate on the Internet a device
  needs to be assigned an Internet Protocol (IP)
  address.
• The IP address is provided by the Internet
  Service provider from which the device accesses
  the Internet.
• Thus it is the IP address that might lead to the
  identity of a real person.
• If an IP address is the link to the identity of a
  real person, then it would quite obviously be
  very valuable for identifying someone on the
  Internet.

THE INTERNET
15
IP Address Locations

• IP addresses are located in different places for
  different mediums of communications.
• E-Mail will have the IP address in the header
  portion of the mail.
• This may not be readily apparent and may require
  a bit of configuration to reveal.
• Each e-mail client is different and needs to be
  evaluated on a case-by-case basis.
• In the case of an Instant Message or Chat
  session, the particular provider (the one
  providing the mechanism of chatAOL, Yahoo, etc.)
  would be contacted to provide the users IP
  address.

THE INTERNET
16
Difficulty with IP Addresses

• Finding IP addresses may be difficult.
• E-mail can be read through a number of clients or
  software programs.
• Most accounts offer the ability to access e-mail
  through a web-based interface as well.
• Often the majority of chat and instant message
  conversations are not saved by the parties
  involved.
• Each application needs to be researched and the
  computer forensic examination guided by an
  understanding of how it functions.

THE INTERNET
17
Hacking

• Unauthorized computer intrusion, more commonly
  referred to as hacking, is the concern of every
  computer administrator.
• Hackers penetrate computer systems for a number
  of reasons.
• Sometimes the motive is corporate espionage and
  other times it is merely for bragging rights
  within the hacker community.
• Most commonly though, it is a rogue or
  disgruntled employee, with some knowledge of the
  computer network, who is looking to cause damage.

• Despite the motivation, corporate America is
  frequently turning to law enforcement to
  investigate and prosecute these cases.

THE INTERNET
18
Locations of Concentration

• Generally speaking, when investigating an
  unauthorized computer intrusion, investigators
  will concentrate their efforts in three
  locations
• Log files
• Volatile memory
• Network traffic

THE INTERNET
19
Logs

• Logs will typically document the IP address of
  the computer that made the connection.
• Logs can be located in several locations on
  computer network.
• Most servers that exist on the Internet track
  connections made to them through the use of logs.

• Additionally the router, ( the device responsible
  for directing data) might possibly contain logs
  files detailing connections.
• Similarly, devices known as firewalls might
  contain log files which list computers that were
  allowed access to the network or an individual
  system.

THE INTERNET
20
Use of Volatile Data

• Many times, in cases of unlawful access to a
  computer network, some technique is used by the
  perpetrator to cover the tracks of his IP
  address.
• Advanced investigative techniques might be
  necessary to discover the true identity.
• Where an intrusion is in progress the
  investigator might have to capture volatile data
  (data in RAM).
• The data existing in RAM at the time of an
  intrusion may provide valuable clues into the
  identity of the intruder, or at the very least
  the method of attack.
• Like the case of the instant message or chat
  conversation the data that exists in RAM, needs
  to be acquired.

THE INTERNET
21
An Additional Standard Tactic

• Another standard tactic for investigating
  intrusion cases is documenting all programs
  installed and running on a system.
• By doing this the investigator might discover
  malicious software installed by the perpetrator
  to facilitate entry.
• This is accomplished utilizing specialized
  software designed to document running processes,
  registry entries, and any installed files.

THE INTERNET
22
Live Network Traffic

• The investigator may want to capture live network
  traffic as part of the evidence collection and
  investigation process.
• Traffic that travels the network does so in the
  form of data packets.
• In addition to containing data these packets also
  contain source and destination IP addresses.
• If the attack requires two-way communication, as
  in the case of a hacker stealing data, then it
  needs to be transmitted back to the hackers
  computer.

THE INTERNET
23
The Destination IP Address

• To get there, the destination IP address is
  needed.
• Once this is learned, the investigation can focus
  on that system.
• Moreover, the type of data that is being
  transmitted on the network may be a clue as to
  what type of attack is being launched, if any
  important data is being stolen, or types of
  malicious software, if any, that are involved in
  the attack.

THE INTERNET
