Halliburton Real Time

1
Halliburton Real Time

• Uses of WITSML
• David Johnson
• Drilling and Completions

2
Halliburton real time offerings -

• Real time operations centers
• RTOC services
• Persistent data store
• Real Time Data Hub
• Point to Point communications
• OpenWire

3
Real Time Operations Centers

• Improve
• Quality of drilling
• Speed of decision-making
• Accuracy of well planning placement
• Connect
• Resources
• Experts
• Reduce
• Dead time
• Lost time
• Increase
• Personnel utilization
• Knowledge capture
• Best practice communication

4
Persistent Data Storage

• Real Time Data Hub
• WITSML data aggregation store

• Data preservation
• Collected in real time
• Vendor neutral
• Always available
• Online in WITSML server
• Data Management
• Store multiple versions
• Historical use

5
Point to Point data loading

• OpenWire
• WITSML data loading

• Automatic data loading
• on demand
• multiple sources
• multiple destinations
• Simple management
• run by end user
• data loading centers

6
(Landmark) Real Time enabled software solutions

• EDM-based Engineering solutions
• RTV viewing utility cross-referencing OpenWells
  reports and real time logs
• Compass real time analysis of trajectories
• OpenWells real time data input from Fluids, BHA
  Run, Cement and other report and informational
  objects
• WellPlan analysis of RT drilling parameters
• Interpretation solutions
• DecisionSpace AssetView review, compare and
  contrast well parameters in the GG
  interpretation
• DecisionSpace Well Planning real time wellbore
  placement with trajectory object

7
Automatic data loading intoAssetView
8
Automatic data loading intoEDM
9
Real Time Data Hub OpenWire

• Centralized data loading
• Web-based interface
• Manage data loading from anywhere
• Expanded coverage
• Improved data through-put

10
Real Time Data Hub

• WITSML streaming in from Service Providers
• Stored in system

11
Real Time Data Hub

• WITSML streaming in from rig-site
• Stored in system
• WITSML server broadcasting changes

12
(WITSML) Real Time Software Solutions

• Real Time Data Hub
• Persistent data storage
• Neutral formats
• Industry standards

• OpenWire
• Automatic WITSML data loading
• Tested with service companies
• Loss-less data transfer

13
Questions -
