Automatic Number Plate Recognition

1
AUTOMATIC NUMBER PLATE RECOGNITION SYSTEM

• BY
• SUHAIL KHAN
• ROLL NO31

2
INTRODUCTION

• Automatic Number Plate Recognition (or 'number
  plate recognition') is a special form of optical
  character recognition (OCR).
• It enables computer systems to read automatically
  the registration number (license number) of
  vehicles from digital pictures.
• Reading automatically the registration number
  means transforming the pixels of the digital
  image into the ASCII text of the number plate.
• OCR technology scans paper documents and turn
  them into electronic, editable files.
• Capturing of fast moving vehicles needs special
  technique to avoid motion blur . To ensure the
  right image quality short shutter time is used
  with high-power illumination.

3

• The best illumination is the IR, because the
  retro-reflective plates reflect this kind of
  light and it is undetectable for the human eye.
• This combination works fine during day and night
  and provides constant good image quality.
• Only dedicated ANPR cameras meet these
  requirements, which provide flexible shutter
  control with built-in IR flash and able to catch
  the vehicles up to 250km/h which is suitable for
  all kind of license plate reading applications.

4
HOW TO BULIT ANPR SYSTEMS ?

• ANPR has two technological issues
• The quality of license plate recognition software
   with its applied recognition algorithms, and
• The quality of image acquisition technology, the
  camera and the illumination.
• The very key factor is the number plate
  recognition software.
• A sophistication recognition software should
  have following features
• the highest recognition accuracy
• the fastest processing speed
• the most type of number plates it can handle,
• the widest range of picture quality it can
  handle,
• the most tolerant against distortions of input
  data .

5

• The key technological parts of an APNR system
• high accuracy Optical Character Recognition (OCR)
  is an essential requirement
• technology image acquisition technology -
  determines the average image quality the number
  plate recognition algorithm has to work on.

6
ANPR SOFTWARE

• Different CARMEN software versions are used for
  different ANPR application areas
• There are basically 3 versions
• CARMEN Free Flow general-purpose license plate
  recognition engine , used for processing images
  of fast moving vehicles
• CARMEN Parking Lane developed for parking
  management applications where automatic
  identification of vehicles is needed.
• CARMEN Parking cost-effective solution, which is
  ideal for parking, vehicle entry and access
  control systems. It is capable of the automatic
  detection, identification and recognition of the
  registration number of any vehicle.

7
CARMEN FREE FLOW SOFTWARE

• It is highly accurate, fail safe and stable, fast
  and intelligent.
• it provides the highest technological performance

• It can be integrated into practically any ANPR
  system
• Features
• offers general-purpose license plate reading from
  digital pictures of any type of sources.
• provide high quality car plate recognition for
  very different type of images and plates with
  default settings.
• 98.5 recognition rate (correct reading/total
  number of input)

8

• Applications
• Intelligent Transportation Systems (ITS),
• security systems
• motorway toll collection (highway toll
  collection),
• traffic analysis,
• police law enforcement,
• state border control,
• enforcement of traffic regulations,
• vehicle theft prevention,
• automation and simplification of airport,
• harbor and warehouse logistics,
• security monitoring of roads and checkpoints
• vehicle surveillance

9
CARMEN PARKING SOFTWARE

• specially designed for parking systems, security
  systems and access control systems.
• It has a unique integration level of license
  plate recognition technology, the video
  acquisition technology and the processing of
  multiple images of video streams.
• It comes with an industrial quality native driver
  for image acquisition and video streaming,
  providing a plug-and-play core number plate
  recognition module (software and capture card)
  for car park and vehicle access control systems.

10

• Features
• offers flexible,
• low maintenance,
• effective and intelligent technology for car park
  operation.
• reduces costs as well as increasing efficiency
  and security.
• the Carmen Parking ANPR package contains the
  following elements
• Automatic number plate recognition engine
• FXVD4mc_s grabber card
• Functions library (ANSI C/C, MSVC/C, MSVB and
  Delphi, ActiveX, OCX)
• Demo and test applications
• Tutorial and sample programs both in executable
  and source code.
• High Resolution Camera equipped with a special
  and synchronized IR flash.(optional)

11

• A parking lot equipped with Carmen Parking can
  provide
• Flexible and automatic vehicle entry to and exit
  from a car park
• Management information about car park usage
• Improved security for both car park operators and
  car park users
• Improved traffic flow during peak periods
• Vehicle recognition through date and time
  stamping as well as exact location
• Comprehensive database of traffic movement can
  be managed
• Applications
• car park management,
• car parking automation,
• occupation management,
• automation of access control,
• security access control,
• flotilla management (car pool management),
• automation of vehicle entry to and exit from car
  parks,
• inventory management,
• state border control

12
CARMEN PARKING LANE SOFTWARE

• used for one or two lanes of access control
  systems.
• With integration CARMEN Parking Lane into parking
  management systems, it is possible to automate
  vehicle entry to and exit from a car park or a
  secure zone and to use the recognized
  registration number for inventory management.
• specially developed for parking management
  applications where automatic identification of
  vehicles is needed.
• provides accurate and quick identification of
  vehicles without human assistance.

13
ANPR HARWARES

• ANPR consists of following hardware products
• Image capturing -FXCAM LPR/ANPR camera series
  to provide good quality images
• ARH Car PC for Mobile ANPR applications is a
  mobile PC with unique features like GPS receiver
  and GPS antenna.
• Video signal digitizing -FXVD4 frame grabber card
  the primary function of this card is digitizing
  the video signal. FXVD4mc_s is a high quality
  4-channel frame grabber card

14
FXCAM DIGITAL ANPR CAMERA

• The smart shutter technology enables you to make
  an adaptive image capturing system, controlled
  automatically by software.
• Effective range is up to 20 meters (65 ft) but it
  may vary depending on the specific environmental
  conditions.
• Ideal for both moving traffic and access control
  (parking management) applications.
• Image quality
• Resolution 752X480 pixels, ROI support
• Image processing speed 60 frames/sec at full
  image size
• Continuous, or triggered buffering for 60 full
  size images
• Lossless RAW image format
• Adjustable gain and shutter time 1/100 to 1/30000
  sec
• No extra illumination required

15

• Lens
• High quality motorized zoom and iris (effective
  range 3-20m)
• IR pass filter included
• High speed and ultra sensible image sensor
• CMOS monochrome WideVGA (pixel size 6lm x 6lm)
• Global Shutter TrueSNAP
• Dynamic range up to 100dB
• High performing illumination
• High power IR LEDs - ideal for ANPR day night
• Strong sunlight / shadow correction
•    Power consumption
• Isolated 24-28V AC or 30-36V DC input (50-60Hz)
• Optional 12V DC (FXCAM202)
• Less than 15W (26V AC) depending on heating
  ON/OFF
• Reverse polarity protection

16
(No Transcript)
17
FRAME GRABBER CARDS

• FXVD4mc_s is a high quality 4-channel frame
  grabber card
• function of this card is digitizing the video
  signal by an Bt878 video capture chip.
• To improve the reliability and stability of a
  stand-alone system the FXVD4mc_s has a secondary
  function the watchdog.
• This function helps to reboot the computer when a
  system crashes
• On the card there is a RISC co-processor which
  serve the hardware protection of the software

18

• Interface PCI 2.1 AD
• conversation Bt87
• Input 4 x BNC video, 75 Ohm
• Watchdog Programmable with 1-250 sec. delays
• Supported Operating System
• Windows Vista 32bit, XP, 2003, 2000
• Linux
• Programming Languages
• Visual C/C
• Visual Basic
• Borland Delphi
• Visual Basic.NET
• C
• Java
• GCC and Java under Linux

19

• Additional Tools
• SDK for easy integration
• DLLs and ActiveX components
• Video Formats PAL or NTSC (75 W, 1 Vp-p)
• Video Framing Full, Field, Half _at_ any / odd /
  even
• Image Output Memory, file
• File Types BMP, JPEG
• File Formats Grayscale, RGB15, RGB16, RGB24,
  RGB32, YUV422
• Documentation Reference Manual in electronic
  format
• System Requirements Free PCI slot with Bust
  Mastering support
• Power consumption approx. 450mA
• Size 97 mm x 120 mm

20
(No Transcript)
21
ARH CAR PC

• PC-based system which is specially designed for
  mobile installation
• The anti-vibration protection and the anti-shock
  protection makes its usage reliable in vehicles.
• it has unique features like
• Intelligent (programmable) UPS
• GPS receiver
• GPS antenna
• Advantages
• Maintenance free operation
• No moving parts
• Configurable

22

• Processor Intel Core Duo 1.2 GHz
• RAM 1 GB DDR2
• Graphics Integrated Intel graphics controller
• HDD Automotive 40GB (Flashdrive optional)
• Network Gigabit LAN controller
• Input/output
• 2 x RJ45 LAN
• 2x serial
• 3x USB2.0
• DVI VGA out
• PS2 for keyboard
• Mic line in, line out
• Composite S-video TV out
• Power Input voltage 9-30 VDC (5.4A _at_ 9DC)
• Power consumption max. 50W (typical 15-20W)
• Power Module with UPS
• Smart Battery, Li-Polymer, 3000mAH
• GPS receiver and antenna included
• Windows XP Professional included

23
(No Transcript)
24
DEVELOPING POWERFUL APPLICATIONS
25
APPLICATIONS

• Parking
• Access Control
• Motorway Road Tolling
• Border Control
• Journey Time Measurement
• Law Enforcement

26
REFERENCES

• www.anpr.net
• en.wikipedia.org/wiki/Automatic_number_plate_recog
  nition
