Diversity and MIMO System for Fading Channels

1
Diversity and MIMO System for Fading Channels
Dr. Essam Sourour Alexandria University, Faculty
of Engineering, Dept. Of Electrical Engineering
2
Overview

• Diversity and its types
• MIMO systems

3
Why Diversity?

• BER in fading channel is calculated by averaging
  the AWGN BER over the fading pdf
• In Rayleigh fading channel the pdf of the SNR, g
  is given by the exponential function
• This pdf causes large performance loss
• If we get a better pdf of the SNR, performance
  will increase
• This is done by diversity techniques

4
What is Diversity ?

• Diversity is achieved by creating several
  independent paths between the transmitter and
  receiver
• Each path fades independently, hence, there is a
  low chance they fade together
• Receiver combines the received signal for the
  several paths using some method
• Diversity is used in all mobile communication
  systems

5
Types of Diversity

• Space diversity multiple transmit and multiple
  receive antennas
• Multiple Tx split power over several Tx
  antennas. More antennas more power split
• Multiple Rx collect signal by several Rx
  antennas. More antennas more collected power
• Antennas separation about l/2 is required
• If directional antennas (typically) larger
  separation is required

6
Types of Diversity

• Polarization diversity
• Transmit and/or receive with both vertical and
  horizontal polarization
• Scattering is independent for each polarization,
  giving independent paths
• Limited to 2 transmit and 2 receive diversity
• Tx polarization diversity half power for each
  polarization

7
Types of Diversity

• Frequency diversity
• Transmit same signal with several frequencies
• Frequencies separated by gt coherence bandwidth
• Also wideband signals achieve frequency
  diversity, like OFDM techniques over wideband
  (WLAN, WiMax, LTE)
• Multipath diversity
• In Direct-Sequence-Spread-Spectrum signals we can
  receive from multipath separately using Rake
  receiver
• Used in all CDMA systems (IS-95, CDMA2000, WCDMA)

8
Types of Diversity

• Time diversity
• Signal is re-transmitted (repeated) after gt
  coherence time
• Also achieved using coding and interleaving
• Reduces overall transmission data rates
• Coding and interleaving used in all mobile
  communication systems
• Also combined with repeat-diversity in what is
  called Hybrid Automatic Repeat Request (H-ARQ)

9
Types of Diversity

• Beam-forming
• Transmit with antenna array
• Each antenna is fed with different phase
• Forms a directional beam towards the receiver, or
  group of receivers
• Antenna beam tracks the intended receiver
• Requires knowledge of the fading channel at Tx
• Optional is 4G mobile communication systems
  (WiMax and LTE)

10
Types of Diversity

• In all types of diversity we achieve several
  independent paths between Tx and Rx
• If not independent there is some performance
  degradation
• If correlation coefficient lt 0.5 degradation is
  not noticeable
• Space diversity will be studied, but approach
  applies to all methods

11
Diversity Order

• In many cases the average probability of error
  looks like
• M is the diversity order
• If the number of paths between Tx and Rx is N,
  then diversity order ? N
• For example if Nt is the number of Tx antennas
  and Nr is the number of Rx antennas
• Number of branches N Nt Nr
• Diversity order M ? N
• Full diversity order if M number of branches

12
Receiver Diversity

• Signal from multiple receiver antennas are
  linearly combined
• Weighted sum of each branch
• Each branch weight is complex
• The phase of each received path are aligned
• Signals from each branch are coherently combined

• Receiver must estimate the phase (and some times
  gain) of each branch
• Estimation through pilot signals

13
Receiver Diversity

• Receiver diversity achieves two types of gain
  Array gain and Diversity gain
• Array gain due to coherent combining of multiple
  branches
• Defined average combined SNR /average branch SNR

• Achieved even if there is no fading
• Diversity gain due to the better (than
  exponential) pdf p(g) of the combined SNR
• Better BER results of the integration

14
Receiver Diversity

• Several methods to combine the receiver branches
• Selection combining
• Threshold combining
• Maximal ratio combining
• Equal gain combining
• Mix of the above
• Tradeoff between performance and complexity

15
Selection Combining

• Fading channel path gain to each branch is
• Noise PSD at each branch is Ni
• Receiver selects the branch with largest
  instantaneous SNR
• If the noise PSD No is the same for all branches,
  this is equivalent to selecting largest
• Easier to implement
• Combiner output SNR best branch SNR

16
Selection Combining

• For M branch diversity, the CDF of the combined
  SNR is given by
• Probability of best SNR lt g Probability all SNR
  lt g
• In Rayleigh fading each SNR is exponential
• CDF of M branches is given by
• If the target SNR is go, outage is given by
• If the average SNR per branch are equal

17
Selection Combining

• Most benefit from M1 (no diversity) to M2
• Benefit reduces as M increases

18
Selection Combining

• From basic probability, the PDF is the
  differential of CDF
• If the average SNR per branch are equal the CDF
  is given by
• The PDF of the combined SNR is given by
  differentiating w.r.t g
• The average SNR after combining is
• Increases with M, but not linear

19
Selection Combining

• Probability of error is calculated by averaging
  the AWGN formula over the PDF of the SNR
• Now we use
• For BPSK there is no closed form, needs numerical
  integration (or simulation)
• For DPSK we get

20
Selection Combining

• Similarly, more gain when moving from M1 to M2
• Gains reduces as M increases

21
Selection Combining

• Same observation for D-BPSK (equation 7.11)
• Gains reduces as M increases

22
Threshold Combining

• A simpler approach is to stay with a branch till
  its SNR falls below a threshold
• If the SNR falls below threshold, switch to
  another branch according to
• Random selection, or
• Best branch
• Example 2 branches

Bad switch
23
Threshold Combining

• Assume M2 and switching happens when the SNR on
  one antenna falls below gT (even if to lower
  SNR)
• The CDF of selected SNR is the probability that
  SNR lt g
• Two possibilities for overall SNR, SNR lt gT , or
  gt gT
• If SNR lt gT
• Prob(SNRltg)Prob(SNR1ltgT) x Prob(SNR2ltg)
• If SNR gt gT
• Prob(SNRltg)Prob(gT ltSNR1ltg)
• Prob(SNR1ltgT) x Prob(SNR2ltg)
• For Rayleigh fading and equal average SNR

24
Threshold Combining

• Hence, the CDF is given by
• The outage probability is given by
• If the threshold gT ?o, the outage probability
  is similar to selection diversity with M2

25
Threshold Combining

• The PDF is found by differentiating the CDF
• Again, for BPSK there is no closed form for BER.
  Requires numerical integration or simulation
• For DPSK the BER is given by

26
Threshold Combining

• M2
• DBPSK with threshold combining
• Slightly worse than selection combining

27
Maximal Ratio Combining

• Instead of selecting one branch, all branches are
  added with weight ai exp(-j?i)
• If a transmitted symbol is s with unity power
  s21
• The received symbol at branch i is s ri
  exp(j?i) ni
• The combined symbol is
• Assume all ni have equal variance No, the SNR is
• We need to select ai to maximize SNR

28
Maximal Ratio Combining

• Using Swartz inequality we find the optimum
  weights
• The resulting SNR is
• Combined SNR is the sum of all branches SNR
• Each gi is exponential with mean
• Assuming all branch SNR have equal mean, g? is
  chi-square with 2M degrees of freedom (see
  Proakis, chapter 2) and mean
• The PDF is given by

29
Maximal Ratio Combining

• The outage probability is found from PDF
• The average BER is calculated by averaging the
  AWGN BER over the random SNR
• For BPSK

30
Maximal Ratio Combining

• BER performance for BPSK
• Best diversity method

31
Comparison
BPSK with Maximal Ratio Combining
BPSK with Selection Combining
Maximal Ratio Combining provides better
performance (lower BER)
32
Equal Gain Combining

• MRC required knowledge of the SNR on each branch
• Simpler approach is equal weight for all branches
  (all ai1)
• The combined SNR is
• There is no closed form solution for the CDF or
  PDF except for M2

33
Equal Gain Combining

• From the CDF we find the outage probability
• Also the BER for BPSK is

34
Equal Gain Combining

• BER for BPSK

BPSK with Maximal Ratio Combining
BPSK with Equal Gain Combining
35
MIMO

• Traditional diversity is based on multiple
  receiver antennas
• Multiple-In Multiple-Out (MIMO) is based on both
  transmit and receive diversity
• Also known as Space Time Coding (STC)
• With Mt transmission antennas and Mr receiver
  antennas we have Mt Mr branches
• Tx and Rx processing is performed over space
  (antennas) and time (successive symbols)

36
MIMO or STC

• In Mobile communication systems it may be
  difficult to put many antennas in the mobile unit
• Diversity in the downlink (from base station to
  mobile station) can be achieved by Multiple-In
  Single-Out (MISO) (i.e., Mr1)
• In the uplink (from mobile station to base
  station) diversity is achieved my conventional
  diversity (SIMO)
• Hence, all diversity cost is moved to the base
  station
• All 3G and 4G mobile communication system employ
  MIMO in their standard

37
Type of MIMO

• Two major types of space time coding
• Space time block coding (STBC)
• Space time trellis coding (STTC)
• STBC is simpler by STTC can provide better
  performance
• STBC is used in mobile communications. STTC is
  not used in any systems yet
• We will talk only about STBC

38
Space Time Block Codes

• There are few major types
• Transmit diversity main goal is diversity gain
• Spatial multiplexing main goal is increase data
  rate
• Eigen steering main goal is both. Requires
  knowledge of the channel at the transmitter side
• Mix of the above Lots of research
• Transmit diversity, spatial multiplexing and
  simplified version of Eigen steering are used in
  3G and 4G standards
• While in 3G standards MIMO was an enhancement, in
  4G MIMO is a main part

39
Transmit Diversity

• Take Mt2 and Mr1
• Two symbols so and s1 are transmitted over two
  transmission periods
• No change in data rate (denoted as rate 1 STBC)
• Channel is known at receiver only

40
Transmit Diversity

• Transmission matrix
• Transmission matrix columns are orthogonal to
  guarantee simple linear processing at the
  receiver
• Other transmission matrices are defined in
  literature
• Received signal is
• Performance is same as MRC with M2
• However, if Tx Power is the same, then transmit
  diversity (2x1) is 3 dB worse than (1x2)

41
Transmit Diversity

• Take Mt2 and Mr2
• Performance is the same as MRC with M4
• However, if Tx Power is the same, then transmit
  diversity (2x2) is 3 dB worse than (1x4)

42
Performance

• MRRCMaximal Ratio Receiver Combining
• Note 3 dB difference in favor of Rx MRC diversity
• Reference S. Alamouti, a simple transmit
  diversity technique for wireless communications,
• IEEE JSAC, October 98

No diversity
Order 2
Order 4
43
Spatial Multiplexing

• Purpose is to increase data rate (2x2 gives twice
  data rate)
• The 4 gains must be known at receiver
• Simplest way zero forcing algorithm

44
Spatial Multiplexing

• Optimum method Maximum Likelihood
• Try all combinations of s1 and s2
• Find the combination that minimizes the squared
  error
• Complexity increases with high order modulation

45
Performance

• Equal rate comparison
• Reference David Gesbert, Mansoor Shafi, Da-shan
  Shiu, Peter J. Smith, and Ayman Naguib, From
  theory to practice an overview of MIMO
  spacetime coded wireless systems, IEEE JSAC,
  April 2003

Zero forcing
ML
Alamouti
46
Eigenvalue Steering

• Assume a MIMO system

47
Eigenvalue Steering

• Example with Mt 2 and Mr4
• Any matrix H can be represented using Singular
  Value Decomposition as
• U is Mr by Mr and V is Mt by Mt unitary matrices
• ? is Mr by Mt diagonal matrix, elements si

48
Eigenvalue Steering

• Using transmit pre-coding and receiver shaping

49
Eigenvalue Steering

• This way we created r paths between the Tx and
  specific Rx without any cross interference
• The channel (i.e., Channel State Information)
  must be known to both transmitter and receiver
• The value of r rank of matrix H, r ?min(Mt,
  Mr)
• Not all r paths have good SNR
• Data rate can increase by factor r
• See Appendix C for Singular Value Decomposition
• See Matlab function U,S,V svd(X)

50
Example

• Reference Sanjiv Nanda, Rod Walton, John
  Ketchum, Mark Wallace, and Steven Howard, A
  high-performance MIMO OFDM wireless LAN, IEEE
  Communication Magazine, February 2005

51
SVD Matlab Example

• X is 4 by 2 matrix
• X1 2 3 4 5 6 7 8
• U,S,V svd(X)
• U
• -0.1525 -0.8226 -0.3945 -0.3800
• -0.3499 -0.4214 0.2428 0.8007
• -0.5474 -0.0201 0.6979 -0.4614
• -0.7448 0.3812 -0.5462 0.0407

• V
• -0.6414 0.7672
• -0.7672 -0.6414
• S
• 14.2691 0
• 0 0.6268
• 0 0
• 0 0
• Then s1 14.2691 and s2 0.6268
