Title: Universal Design, Accessible Design, & Adaptable Design


1
Universal Design, Accessible Design, Adaptable
Design Definitions and Examples
2
  • Goal Define
  • Universal design
  • Accessible design
  • Adaptable design
  • Specify their relationship to the broader notion
    of design in general

3
Scope of the Discussion
  • universal design and "accessible design" are
    often used interchangeably
  • Both terms focus on designing products and
    services so that as many people, with as broad a
    spectrum of abilities as possible, can use them.
  • Yet "accessible design" and "accessibility" have
    taken on legal meanings that force a distinction
    to be drawn between universal and accessible
    design.
  • In essence, accessible design is mandated by law
    while universal design is not.

4

Scope of the Discussion
  • Additional design categories have been proposed,
    in particular adaptable and transgenerational
    design (Story, 1998).
  • Of these only adaptable design will be discussed
    because it is closely related to accessible
    design.
  • Adaptable design is mentioned in the laws
    mandating accessibility of telecommunication
    products and services as well as electronic and
    information technology products and services.

5
Scope of the Discussion
  • The discussion will start with a definition of
    design
  • and move to the narrower definitions of
  • Accessible design
  • Universal design
  • Adaptable design

6
Defining Design
  • Design can be a noun or a verb
  • As a noun, design refers to an object or entity
  • As a verb, design refers to a process
  • For this discussion, design will be used as a
    verb, that is, design is a process.

7
Defining Design
"Design is the thought process comprising the
creation of an entity" (Miller, 1996).
More simply, the designer needs to see the
connection between problem and possibility"
(Miller, 1996).
8
Universal Design
9
Universal Design
Universal design - the design of entities that
can be used and experienced by people of all
abilities, to the greatest extent possible,
without adaptations.
Buildings, work places, products, services, and
educational activities/materials can all be
universally designed.
10
Universal Design
Curb cuts are the prototypical example of
universal design. People in wheelchairs use curb
cuts, but so do bike riders, skate boarders, and
people pushing baby strollers.
11
Accessible Design
12
Accessible Design
Accessible design - the design of entities that
satisfy specific legal mandates, guidelines, or
code requirements with the intent of providing
accessibility to the entities for individuals
with disabilities.
This definition focuses on the legal implications
of the term.
13
Accessible Design
  • Accessible design derives its legal meaning from
  • Americans with Disabilities Act (ADA)
  • Section 255 of the Telecommunications Act of
    1996
  • Section 508 amendments to the Workforce
    Investment Act of 1998


14
Accessible Design
  • These laws also state that either
  • products need to be compatible with assistive
    technology devices used by people with
    disabilities
  • or
  • products are able to be modified so as to be
    rendered accessible

15
Accessible Design
Note systems may be designed so that they are
not accessible, but with specific modifications
be made accessible to individuals with specific
disabilities.
Such modifications are termed accommodations and
characterize the process of adaptable design.
16
Adaptable Design
17
Adaptable Design
Adaptable design - features are modifications
made to the standard design for the purpose of
making the design usable for an individual, as
needed.
This definition focuses on modifications made to
existing entities which make the entity
accessible to people with disabilities.
18
Adaptable Design
  • Van conversion provides wheelchair accessibility
    for occupants.
  • Vans are a standard, non- wheelchair accessible,
    design. After modifications, vans are wheelchair
    accessible.
  • Van accommodation is not required or mandated by
    any law, code or guidelines hence, it is not
    considered accessible design, but adaptable
    design.

19
Adaptable Design
  • How adaptable design differs from accessible
    design
  • adaptable design is not mandated by laws
  • adaptable design focuses on modifying an existing
    standard design

20
Adaptable Design
  • How adaptable design differs from universal
    design
  • universal design creates products and services
    that are accessible and usable without
    adaptations
  • adaptable design focuses on modifying an existing
    standard design
  • universal design occurs at the beginning of the
    design process
  • adaptable design occurs after the design process
    is complete and the product has been produced

21
Relationship Between General Design,Universal
Design,and Accessible Design
22
Relationship Between General Design, Universal
Design, and Accessible Design
23
Relationship Between General Design, Universal
Design, and Accessible Design
  • The rectangle labeled Entities that are
    accessible is explicitly used to emphasize the
    fact that accessibility can be achieved by design
    strategies from all design categories.
  • If accessibility is achieved because it is
    mandated, then it results from accessible design
    strategies.
  • If accessibility is achieved as a result of an
    accommodation, it is an adaptable design
    strategy.
  • Accessibility can also result from applying
    universal design principles.

24
Examples of Entities from Each Design Category
25
Example from
26
Examples of Entities from Each Design Category
Universal Design
  •
  • Universal Design
  • ADJUSTABLE SEATS, STEERING WHEEL, AND FLOOR
    PEDALS ON CARS AND TRUCKS The collection of
    adjustable features enable people with very
    different body sizes to use the car or truck.
    These adjustability features are not required or
    mandated by laws or regulations.
  • AUTOMATIC DOOR OPENERS The automatic door
    openers at malls, shopping centers, and other
    public places are examples of universal design if
    they are not mandated by laws or codes.

27
Examples from Universal Accessible Design
28
Examples of Entities from Each Design Category
Accessible Universal Design
  • Accessible Design and Universal Design
  • CURB CUTS Curb cuts were designed to allow
    wheelchair users to navigate and thereby have
    access to city streets and sidewalks, and the
    amenities they afford such as access to public
    places, buildings, shops, and restaurants. Curb
    cuts are mandated by ADA (Access Board, 1999) and
    as such an example of accessible design.
    However, curb cuts are used by people on
    roller-blades, skateboards, bicycles, tricycles,
    people pulling shopping carts and people pushing
    strollers, and therefore provide an example of
    universal design.

29
Examples from Accessible Design
30
Examples of Entities from Each Design Category
Accessible Design
  •
  • Accessible Design
  • THE ADA ACCESSIBILITY GUIDELINES FOR BUILDINGS
    AND FACILITIES (ADAAG) - covers the construction
    and alteration of facilities in the private
    sector (places of public accommodation and
    commercial facilities) and the public sector
    (state and local government facilities). For
    example, section 4.9 deals with stairs. Section
    4.9.2 deals specifically with Treads and Risers.
    It says that On any given flight of stairs, all
    steps shall have uniform riser heights and
    uniform tread widths. Stair treads shall be no
    less than 11 in (280 mm) wide, measured from
    riser to riser. Open risers are not permitted.
  •

31
Examples from Adaptable Accessible Design
32
Examples of Entities from Each Design Category
Adaptable Accessible Design
  • Adaptable Design and Accessible Design
  • VOLUME CONTROLS FOR ATTACHING TO TELEPHONES A
    volume control that attaches to a telephone is an
    example of an adaptable design that is also
    accessible design. It is a modification made to
    a standard design for the purpose of making it
    accessible to persons who are hard-of-hearing
    (Story, 1998). This design is accessible in that
    the Telecommunication Act of 1996, Section 255,
    requires telephones that do not contain volume
    controls to be compatible with technologies like
    the attachable volume control unit so as to be
    accessible for individuals with hearing
    difficulties (Access Board, 1998).
  • BASE CABINETS THAT ARE REMOVABLE FROM UNDER
    BATHROOM SINKS (Story, 1998) Base cabinets that
    are removable from under bathroom sinks not only
    allow wheelchair users access but also allows
    dwarfs or short people to remove the base cabinet
    and use a chair. The ability to remove the base
    units is not mandated or required by guidelines
    or code as required by the definition of
    accessible design.

33
Examples from Adaptable, Accessible Universal
Design
34
Examples of Entities from Each Design Category
Adaptable, Accessible, Universal Design
  • Adaptable, Accessible, and Universal Design
  • RAMPS TO AN EXISTING PUBLIC BUILDING WHEN
    RENOVATED When an existing public building
    undergoes major renovation it may come under ADA
    accessibility requirements. One such adaptation
    is the addition of a wheelchair ramp. Ramps not
    only improve accessibility for people in
    wheelchairs, they also improve accessibility for
    people pushing strollers, or pulling suitcases,
    or people with walkers. The ramps are like
    curb-cuts in that they improve accessibility for
    all users and hence exemplify universal design.
    Ramps provided under the conditions described
    above are accessible designs because they are
    mandated. They are adaptable designs because
    they are added to a standard design.

35
Examples from Adaptable Design
36
Examples of Entities from Each Design Category
Adaptable Design
  • Adaptable Design
  • DAMPERS FOR VIBRATION REDUCTION ON TENNIS
    RACQUETS One may purchase a variety of devices
    that fit around the strings of a tennis racquet
    near the frame. These devices change the
    vibration patterns of the racquet. If the
    undamped racquet produces a vibration pattern
    that cause undue stress on a player's elbow it
    can result in tennis elbow, which is a painful
    condition. The string damping device changes the
    racquets vibration pattern so that it no longer
    places undue stress on the player's elbow and
    thereby avoids injury. The device is an
    adaptation in that it is a modification to a
    standard product that makes the racquet usable to
    an individual. For any given racquet, the
    adaptation only works for people with certain arm
    characteristics and not others hence, it is not
    universal design. The device is not mandated nor
    does it provide accessibility to individuals with
    disabilities hence, it is not accessible design.
  • VAN CONVERSIONS FOR WHEELCHAIR ACCESSIBILITY
    There is an active after-market business centered
    on modifying vans to be wheelchair accessible for
    both drives and passengers. Two examples of
    companies providing van conversions are Kino
    Mobility, Inc. and New England Wheels, Inc.
    (Inc., 2002 New England Wheels, 2003). This is
    adaptable design because a standard product is
    being modified so as to be accessible to
    individuals using a wheelchair. This is not an
    example of an entity in the intersection of
    adaptable and accessible design because the van
    conversions are not mandated by any law,
    regulations, or code.
  •

37
Conclusions
38
Conclusions
Design is the thought process comprising the
creation of an entity.
  • When conceptualizing the problem and
    possibilities from a UNIVERSAL DESIGN
    perspective, THE POSSIBILITIES INCLUDE AN ENTITY
    THAT CAN BE USED AND EXPERIENCED BY PEOPLE OF ALL
    ABILITIES, TO THE GREATEST EXTENT POSSIBLE
    WITHOUT ADAPTATIONS.
  • When approaching the same problem from an
    ACCESSIBLE DESIGN perspective, THE POSSIBILITIES
    WILL FOCUS ON HOW TO SATISFY LEGAL MANDATES,
    GUIDELINES, OR CODES TO ENSURE ACCESSIBILITY.
  • From an ADAPTABLE DESIGN perspective, THE
    POSSIBILITIES INVOLVE MODIFYING OR ACCOMMODATING
    A STANDARD DESIGN FOR THE PURPOSE OF MAKING IT
    USABLE FOR AN INDIVIDUAL WITH A DISABILITY.

39
Conclusions
Forces Driving Universal, Accessible, Adaptable
Design
  • highly competitive global markets
  • evolving accessibility legislation
  • require corporations to maximize their products
    market potential and services while addressing
    the needs of individuals with disabilities

40
Conclusions
Forces Driving Universal, Accessible, Adaptable
Design
  • these dual forces require that designers
    understand and utilize different design
    perspectives
  • during the design thought process, designers
    should include a deliberate discussion and
    analysis of which design approach will be used to
    address the specified problem

41
Conclusions
Forces Driving Universal, Accessible, Adaptable
Design
  • forgoing such deliberations could be very costly
    to a corporation in terms of
  • lost market share
  • possible litigation for failing to comply with
    mandated accessibility requirements
Write a Comment
User Comments (0)
About PowerShow.com
