ACG-AltiLED LED High-Bay Industrial Lighting Fixture

1
ACG-AltiLEDLED High-Bay Industrial Lighting
Fixture

• ACG Elektronik Ltd.
• www.acgelectronics.com

2
CONTENTS
3
ADVANTAGES OF LED LIGHTING

• High efficiency (low power consumption)
• During the production of AltiLED7 100
  lumens/watt, Philips Lumileds Luxeon Rebel LEDs
  are used. Efficiency of various light sources are
  shown in the below table

4
ADVANTAGES OF LED LIGHTING

• Long lifespan (gt50.000 hours)
• Estimated lifespan of AltiLED is over 50.000
  hours. According to the test report of Philips
  Lumileds, light output will decrease 7.3 at the
  end of 10.000 hours and 30 at the end of 54.000
  hours.

5
ADVANTAGES OF LED LIGHTING

• High light usage (80)
• For some light sources that are used in
  industrial lighting the bulb efficiency is quite
  high. But for conventional systems reflectors are
  used to direct the light to the illuminated
  surface. Most of the light is unused and
  scattered around in those systems. For LED
  lighting this is not the case, around 80 of
  light is directed to the illuminated surface.

6
ADVANTAGES OF LED LIGHTING

• Superior light quality (CRI gt70)
• AltiLED provide a high quality cool white
  (6500K) light. So that the colors are observed as
  they are under sunlight. The flickering of light
  in gas discharge and fluorescent bulbs is totally
  prevented.

7
ADVANTAGES OF LED LIGHTING

• High lumen maintenance
• Lumen output of high intensity discharge lamps
  are decreasing rapidly after a few thousands of
  hours of use. After 10.000 hours of operation the
  lumen output of most metal halide lamps decrease
  30, while for high quality LEDs it is only 7.

8
ADVANTAGES OF LED LIGHTING

• Even light distribution
• Conventional lighting fixtures cause
  higher/lower than required illuminated areas. The
  patented design of AltiLED provides an even light
  distribution.

Conventional lighting fixtures
AltiLED
9
ADVANTAGES OF LED LIGHTING

• Green product

Sodyum Sodium lamps, mercury lamps, fluorescent
lamps and metal halide lamps all contain excess
amounts of mercury, which causes pollution of
water and soil. Being a green product, AltiLED
contains none of the restricted substances (lead,
mercury, cadmium etc.) according to RoHS
(Restriction of Hazardous Substances).
Using AltiLED will provide less energy use,
less polution caused by power plants and less
CO2(carbon dioxide) emission to the atmosphere.
Each AltiLED7 prevents emission of 8.7 tons of
CO2, at the end of 50.000 hours of usage.
10
HOW MUCH WILL I SAVE?

• SAVINGS CALCULATION
• AltiLED7 will provide significant energy and
  maintenance savings. You can calculate total
  savings and payback time from the following link

• http//www.acgelectronics.com/index.php?pagealtil
  ed

300 days/year, 24 hours/day.
11
A RELIABLE EFFICIENT LED LIGHTING FIXTURE

• ELECTRONIC DESIGN
• LED properties are changing during the
  operation of the LED lighting system. To deal
  with those dynamic properties, LED manufacturers
  strongly recommend constant current drivers.
  Otherwise the system will not be reliable.
• Low-quality LEDs not only diminishes the
  efficiency of the system, but also affect the
  light quality and system reliability. In AltiLED,
  Philips Lumileds highest bin LEDs are used.

It is also important that the electronic
components used in the constant current driver
are high efficiency and durable. In AltiLED there
is a specially developed circuit with an
efficiency of 93. AltiLED is CE tested and
certified.
12
A RELIABLE EFFICIENT LED LIGHTING FIXTURE

• THERMAL DESIGN
• Efficiency and lifespan of LED lighting
  fixtures are adversely affected by heat. It must
  be assured that certain limits of LEDs are not
  reached. To provide that, significant attention
  must be payed for thermal design.
• For AltiLED a computer aided thermal simulation
  is done, and design is verified to have an 50.000
  hours of lifespan.

13
A RELIABLE EFFICIENT LED LIGHTING FIXTURE

• OPTICAL DESIGN
• One of the most important advantages of LED
  lighting fixtures is the high light usage
  capability. Instead of reflectors used in
  conventional lighting systems, high efficiency
  lenses are used in LED lighting systems. Each
  module of AltiLED has a high efficiency lens
  (90) to direct the light to the illuminated
  area. Despite the long distance between the
  fixture and the ground, light usage is as high as
  80.

14
HOW MANY FIXTURES SHOULD I USE?

• Recommended lighting levels
• According to IESNA recommended lighting levels
  are as follows

15
HOW MANY FIXTURES SHOULD I USE?

• How much of the light should be supplied by
  general lighting?
• Up to 200 lux is provided by general lighting,
  over 200 lux is provided by task lighting.

General lighting
Task lighting
16
HOW MANY FIXTURES SHOULD I USE?

• How many fixtures should be used?
• The illumination levels depending on the total
  number of fixtures is given in the table below.
  It must also be taken into account that at the
  end of 50.000 hours of usage, there will be a 30
  decrease in the light output. For that reason
• instead of 150 lux, 200 lux
• instead of 200 lux, 260 lux
• can be selected.

17
ASSEMBLY

• Power supply
• AltiLED works with 24V DC voltage input. A
  reliable, high efficiency power supply must be
  used and the product shouldnt be connected to
  220/380V AC directly.

18
ASSEMBLY

• Power supply connection diagrams
• According to the dimensions of the indoor
  place, 2, 3 or 4 pcs. fixtures can be powered
  with a single power supply. The connection
  diagrams section of the datasheet (in
  www.acgelectronics.com) must be read carefully
  before designing the electrical system.

19
ASSEMBLY

• Mechanical mounting
• Product is designed to be mounted by a chain or
  metal rope. Cable length is 1.0 meter. The net
  weight of AltiLED7 is 5.1kgs.

20
MORE INFORMATION CONTACT US

• To get more information about AltiLED Series
  Industrial Lighting Fixtures you can use the
  following links
• Product datasheet (all the information about the
  product)
• http//www.acgelectronics.com/datasheets/acg_altil
  ed_datasheet_1_03_en.pdf
• Assembly guide http//www.acgelectronics.com/data
  sheets/acg_assembly_guide_en.pdf
• Technical Information
• http//www.acgelectronics.com/datasheets/acg_altil
  ed_technical_information_en.pdf
• To request for quotation or any other
  information
• Inquiry form
• http//www.acgelectronics.com/index.php?pagetekli
  f

21
ABOUT US

• About Us
• ACG Electronics is a provider of innovative LED
  Lighting products and services for the private,
  municipal and governmental sectors. The company
  established in 2005 at Ankara, Turkey. In 2009,
  with its well established expertise in the field
  of manufacturing, ACG Electronics chose to
  diversify in the field of Industrial Wide Area
  Lighting.
• We recognize high implementation cost is a major
  resistance the industry faces, adapted a business
  model based on our team strength, that utilize
  the excellent talents and lower manufacturing
  costs in Turkey to produce high quality, low cost
  innovative products and pass the savings onto our
  customers, to bring financially viable solutions
  to our customers.
• ACG Electronics exports its products to 34
  countries (Germany, Austria, United Kingdom, The
  Netherlands, USA, France, Italy, Finland, Spain,
  Portugal, Sweden, Denmark, Norway, Belgium,
  Luxemburg, Canada, Japan, Russia, Switzerland,
  Greece, Bulgaria, Romania, Hungary, Lithuania,
  Estonia, Iran, Poland, Brazil, Argentina, Mexico,
  Hong Kong, China, United Arap Emirates and
  Senegal).
• We are a privately held corporation based in the
  Ankara, Turkey with manufacturing. For further
  information about our company please contact
  sales_at_acgelectronics.com
