Heather Swan

1
Measuring Fast Spectral Variability of
GRB Early Afterglows with the
AEOS Burst Camera
Image of M8, taken by the AEOS Burst Camera

• Heather Swan
• Physics Department
• University of Michigan
• Carl Akerlof, Timothy McKay, Eli Rykoff, Donald
  Smith, U of Michigan
• Mark Skinner, Andrew Alday, Kevin Moore, Boeing
  LTS

1
2
Outline

• Why?
• What is the AEOS and ABC?
• GRB response
• Data and simulations

3
GRB 030418 was dimmer than expected at early times
Circum-burst absorbs optical light if we could
see the spectrum, we would expect to see red -gt
blue
Optical lightcurve
First image 76s after g-rays
4
GRB 990123 was brighter than expected at early
times
Relativistic fireball example of a reverse
shock if we could see the spectrum, we would
expect to see blue -gt red
Optical lightcurve
g-rays were still emitting for first few images
5
Swifts BAT error box is the perfect size for the
ABC
90 will be localized to a 3 arc minute
radius (Can see them with the ABC)
50 will be localized within 12 seconds (Can see
them promptly) (From Fenimore, et al)
6
The AEOS telescope is a large optical telescope
used by the Air Force

• Advanced Electro-Optical Systems Telescope (AEOS)
• Largest ground based AF optical telescope
  (3.67m)
• Designed to track satellites, can quickly (20
  sec) slew to coordinates
• Located in Haleakala, Hawaii, at 10,000 ft

ABC
6
7
The AEOS Burst Camera (ABC) is attached to the
AEOS

• Optics designed by Carl Akerlof
• Package designed by Alan Schier
• Camera built by Astronomical Research Cameras
• Field of view 6' x 6'
• Focal length of 15.5m
• 9 ToO observations / year

Limiting Mag 22nd for 10 sec exposure
8
The ABC will try to observe GRBs within minutes
after they are localized
9
No prompt response yet

• GRB needs to be lt 1 hour old and visible in Maui
• The few that have been attempted
• Bad weather
• Bad pointing
• Several test bursts have been sent
• Responses between 1 and 10 minutes
• One was caught during testing (030329)
• Images taken several days after the event

GRB 030329
10
A diffraction grating was recently installed on
the ABC

• Low resolving power (8)
• Installed Jan 05

A light bulb viewed through the grating, and a
star.
11
Simulations of the grating are similar to what is
seen
Blackbody, suns temp
1st
0th
2nd
higher orders
Image from ABC of a star
The blaze angle was chosen so most of the light
would be in the 1st order
12
We can differentiate between blue and red stars
Cooler temps
Hotter temps
Simulations of different temperature blackbodies
13
We can differentiate between different types of
objects
Quasar
Star
Symbiotic binary
14
In summary, the ABC is up and running, were just
waiting for a GRB

• The ABC can quickly and deeply observe GRBs
• First image within minutes of GRB detection
• Small 6 x 6 field of view
• Deep (22nd mag) images with 10s exposures
• The ABC has a diffraction grating
• Will get early spectral information for GRBs

Questions?
