Know You System Fire Extinguisher & Suppression Activation Training

1
Know You SystemFire Extinguisher Suppression
Activation Training
2
Fire ExtinguishersFire Suppression Systems

• Inspection
• Maintenance
• Activation Procedure
• First-Aid Measures
• Personal Protection
• Fire Prevention

3
Daily Inspection

• Inspection is a quick check to verify that the
  Fire Ext. is in the proper place in good
  working order.
• On Cartridge Operated Exts- check that the red
  stem on top of the cap is in the down position.
• Check to see if the plunger has been activated
  seal is intact.
• Check exterior housing and hoses for defects.
• Check for proper current certification
  stickers.
• Check the mounting bracket for defects.

4
Inspection Cont.

• On Stored Pressure Exts- check that the
  indicator on the gauge is in the green area. If
  it is in overcharged or undercharged range
  replace unit.
• Inspect activation pin, seals,
• Inspect hose, nozzle, housing, mounting bracket.
• Check for proper certifications sticker.

5
Inspection Cont.

• On Mobile Equipment fire suppression systems-
  check that the pull pin red actuator knob is in
  place at all activation points.
• Check all hoses, connection, nozzles, unit
  housing and mounting for defects.
• Check for proper certifications stickers.
• If any of these components are defective, get the
  unit checked or serviced. Before operation.

6
Steps of a Physical Inspection of a Fire
Suppression Systems

• Inspect all activation points.
• Check unit for pin, handle, safety clips

7
Steps of a Physical Inspection of a Fire
Suppression Systems Cont.

• Inspect hose spray nozzles for damage, kinks,
  or missing parts, etc.
• If integrity of the system has been compromised
  shut it down, get it fixed.

8
Steps of a Physical Inspection of a Fire
Suppression Systems Cont.

• Visually inspect the gas cartridges for damage.
• Inspect extinguisher unit for damage.
• Report repair any substandard units.
• Make sure unit has a State Fire Marshall Sticker.

9
Maintenance

• Maintenance is a through check of fire exts
  and fire suppression systems.
• Maintenance is performed by qualified technicians
  at a minimum of once a year.
• When you perform your routine inspections, check
  the maintenance date on the sticker.

10
Proper Step to Activate a Fire Suppressions
System.

• Stop Rib all moving equipment.
• Lower all raised attachments.
• Shut down engine.
• If possible turn masters switch off.
• Activate the fire suppression system.

11
Proper Steps to Activate Fire Suppression Cont.

• Exit the vehicle once the fire is out or knocked
  down safely so you can leave unharmed.
• If safe to do so secure the hand held ext. in
  case a flair up of the fire reoccurs.
• If the suppression can not put out the fire, this
  unit can be used to help you escape.
• Call Dispatch or Hoistman as soon as possible,
  notifying the type of emergency.
• Put on self rescuer, exit to refuge or out of the
  mine per company procedures.

12
First Aid Measures

• Eye contact wash with water for a minimum of 15
  minutes.
• Skin contact Wash area with soap and water.
• Inhalation Remove from exposure.
• Ingestion Give large amounts of water and
  induce vomiting.

13
Fire Prevention, Removing the Potential for
Fire Occurrences. An Ounce of Prevention Is Worth
a Pound of Cure.

• Good Housekeeping is a must. Check for and
  remove all rags, paper, or combustible products
  from engine, or power train compartments daily.
• Keeping machine in good operating conditions
  inspect unit for leaks, drips, chaffed hoses in
  areas where heat can be generated.
• Wash off any accumulated hydraulic oil, fuels,
  or grease, if hydraulic hose fails in the area,
  wash off area before beginning, dont burn it off
  with radiate heat from engines, this can cause a
  fire.

14
Dont Try This at Home
15
Any Questions?Preventing Conditions That
Contribute to Possible Mine Fires is Everyones
Responsibility.Got Safety?

• Created By Pat Gazewood
