THE TISSUES & INTEGUMENTARY SYSTEM

1
THE TISSUES INTEGUMENTARY SYSTEM

• HUMAN ANATOMY PHYSIOLOGY (LABORATORY MANUAL)
  BY ROMER, PINO, POPE, CHAPTER 2
• FUNDAMENTALS OF ANATOMY PHYSIOLOGY BY MARTINI,
  7TH EDITION, CHAPTERS 4 5

2
PRESENTATION CREATED BYALFONSO A. PINO, MD.
3
THE MICROSCOPE
4
THE COMPOUND MICROSCOPE
5
BASE

• It contains
• Off on switch
• Voltage regulator
• illuminator

6
STAGE

• It supports the microscope slides and contains
  slide clips and mechanical stage

7
MECHANICAL STAGE

• It has 2 knobs for movement of the slides from
  left to right and front to back

8
SUBSTANCE CONDENSOR

• It has 3 parts
• blue filter
• iris diaphragm
• condenser lens

9

• Blue filter
• the short wavelength of the blue light
  provides maximum resolution
• Iris diaphragm
• controls the amount of light passing from the
  slide source
• Condenser lens
• collets and focuses the light from the
  illuminator onto the slide

10
LENSES

• They magnify the image
• Objectives they have 3 or 4 objectives
• 4X scanner
• 10X low power
• 40X high dry
• 100 X oil emersion lens
• Ocular lens or eyepiece
• it is 10X and it can have a scale

11
ADJUSTMENT KNOBS

• They are for focusing
• Coarse adjustment knob
• for locating and focusing objects (DO NOT
  USE for high magnification)
• Fine adjustment knob (small)
• for focusing on higher powers

knobs
12
ARM

• Supports the objective lens

13
CARES OF THE MICROSCOPE

• When moving the microscope, carry it with 2 hands
  (one hand to grip the arm and the other under
  the base
• Lenses have to be clean with lens paper (to keep
  them free of oil and dust).
• Do not use the coarse adjustment when focusing
  with the higher power objectives

14
PROCEDURES

• 1- Turn on the illuminator using the on/off
  switch
• 2- Turn the nosepiece to bring the 4X objective
  (scanner) into position
• 3- Raise the stage into its highest position
• 4- Place a slide of the letter e in the slide
  clamp on the stage
• 5- Turn the coarse adjustment knob to bring the
  e into focus
• 6- Measure the field (the brightly lighted circle
  that you see when you look through the ocular
  lens)
• 7- Center the e in your field of view and then
  rotate the nosepiece to 10X
• 8- Use the fine adjustment knob to focus until
  the image is sharp. Draw the image. Do not use
  the coarse adjustment
• 10- Rotate the nosepiece until the 40X. Draw the

15
CUBOIDAL CELLS

• Simple cuboidal kidney

16
SQUAMOUS CELLS

• Simple squamous peritoneum

17
COLUMNAR CELLS

• Simple columnar small intestine

18
TISSUE

• CONCEPT- IT IS A COLLECTION OF SPECIALIZED CELLS

• CELLS PRODUCTS THAT ARE
  ORGANIZED
•
  TO PERFORM FUNCTIONS
• 4 TYPES
• EPITHELIAL TISSUE
• CONNECTIVE TISSUE
• MUSCLE TISSUE
• NEURAL TISSUE

19

• EPITHELIAL TISSUE- IT COVERS EXPOSED SURFACES
  (SKIN),
• LINES
  INTERNAL PASSAGES CHAMBERS
• (DIGESTIVE,
  RESPIRATORY, REPRODUCTIVE AND ,
•
  URINARY SYSTEMS )
• IT FORMS
  GLANDS
• CONNECTIVE TISSUE- IT FILLS INTERNAL SPACES,
• PROVIDES
  STRUCTURE SUPPORT ,
•
  TRANSPORTS MATERIAL WITHIN THE BODY
• STORES
  ENERGY
• MUSCLE TISSUE- IT CONTRACTS TO PERFORM MOVEMENT.


• IT GENERATES HEAT
  THAT WARMS THE BODY
• NEURAL TISSUE- IT CARRIES INFORMATION FROM ONE
  PART OF
• THE BODY TO
  ANOTHER BY ELECTRICAL IMPULSES

20
FUNCTIONS OF THE EPITHELIA

• PHYSICAL PROTECTION- FROM ABRASION,
• DEHYDRATION, CHEMICAL OR BIOLOGICAL
  AGENTS
• CONTROL PERMEABILITY- REGULATED BY
• HORMONES, TRANSPORT IONS NUTRIENTS
• PROVIDES SENSATIONS- TOUCH RECEPTORS,
• NEUROEPITHELIUM CONTEINS SENSORY CELLS
• THATPRODUCE SENSATIONS OF SMELL, TASTE,

• SIGTH, EQUILLIBRIUM OR HEARING
• PROVIDES SECRETIONS- GLANDS CELLS PRODECE
• SECRETIONS FOR PHYSICAL PROTECTION,
  CHEMICAL
• MENSSAGERS IN
  INTERSTITIAL FLUID BLOOD

21
CLASSIFICATION OF THE EPITHELIA

• SHAPE- SQUAMOUS- THIN FLAT
• CUBOIDAL- LIKE LITTLE HEXAGONAL
  BOXES
• COLUMNAR- TALLER MORE SLENDER
• NUMBER OF CELLS
• SIMPLE- SINGLE LAYER OF CELLS
• STRATIFIED- SEVERAL LAYERS OF
  CELLS
• COMBINATIONS OF SHAPE NUMBER

22
Martini pg 111
23
TYPES OF EPITHELIA TISSUES WITH EXAMPLES

• SIMPLE SQUAMOUS- Lung, serous membranes, lining
  heart
• STRATIFIED SQUAMOUS- epidermis, mouth, throat,
  vagina
• SIMPLE CUBOIDAL- glands, ducts, kidney tubules
• STRATIFIED CUBOIDAL- linings some ducts
• TRANSITIONAL- urinary bladder, ureters
• SIMPLE COLUMNAR- stomach, gallbladder, uterine
  tubes
• PSEUDOSTRATIFIED CILIATED COLUMNAR EPITHELIUM-
•
  respiratory tract

• STRATIFIED COLUMNAR EPITHELIUM- salivary glands
  ducts

24
Martini pg112
25
Martini pg 112
26
Martini pg 113
27
Transitional epithelium (Martini pg 113)
28
Simple columnar epithelium (Martini pg 115)
29
Stratified columnar epithelium (Martini pg 115)
30
Pseudostratified ciliated columnar
epithelium (Martini pg 115)
31
FUNCTIONS OF THE CONNECTIVE TISSUE

• IT FORMS AN STRUCTURAL FRAMEWORK
• IT TRANSPORTS FLUID MATERIALS
• IT PROTECTS DELICATES ORGANS
• IT SUPPORTS, SURROUNDS INTERCONNECTS


•
  TISSUES
• IT STORAGES ENERGY
• IT CONTAINS CELLS THAT DEFEND THE BODY FROM
  MICROORGANISMS

32
CHARACTERISTICS OF THE CONNECTIVE TISSUE

• COLLAGEN FIBERS
• THEY ARE LONG, STRAIGTH UNBRANCHED
• THEY ARE A BUNDLE OF FIBROUS PROTEIN SUBUNITS
•
  WOUND TOGETHER
• THEY HAVE LITTLE STRETCH, BUT GREAT TENSILE
  STRENGH
• THEY FORM TENDONS AND LIGAMENTS
• RETICULAR FIBERS
• THEY HAVE SAME SUBUNITS THAN COLLAGEN FIBERS
• BUT WITH A DIFFERENT PHYSICAL ARRNGEMENTARRANGEMME
  NT
•

• THEY FORM A NETWORK THAT RESISTS FORCES APPLY
• FROM MANY DIRECTIONS AND
• THEY STABILIZE RELATIVE POSITION OF CELLS,
  ORGANS, BLOOD
• VESSELS, NERVES
  OTHER STRUCTURES

33

• ELASTIC FIBERS
• THEY CONTEIN PROTEIN ELASTIN
• THEY ARE BRANCHED WAVY
• AFTER STRECHING, THEY CAN RETURN TO THEIR
  ORIGINAL LENGTH
• THEY LACK THE TENSILE STRENGTH OF COLLAGEN
• THEY DOMINATE IN ELASTIC LIGAMENTS


34
TYPES OF CONNECTIVE TISSUES

• AREOLAR
• ADIPOSE
• RETICULAR
• DENSE REGULAR
• DENSE IRREGULAR
• ELASTIC
• CARTILAGE
• BONE
• BLOOD
• LYMPH

35
Areolar tissue(Martini pg 119)
36
Adipose tissue(Martini pg 122)
37
Reticular tissue(Martini pg 122)
38
Dense regular connective tissue(Martini pg 124)
39
Dense irregular connective tissue(Martini pg 124)
40
Elastic tissue(Martini pg 124)
41
Hyaline cartilage(Martini pg 127)
42
Bone tissue(Martini pg128)
43
Blood(Martini pg125)
44
INTEGUMENTARY SYSTEM
45
INTEGUMENTARY SYSTEM(Martini, chapter 5 pg 154)

• LAYERS OF THE SKIN
• FROM EXTERNAL TO INTERNAL
• 1- EPIDERMIS
• 2- DERMIS
• 3- HYPODERMIS

46
Martini pg 154
47
EPIDERMIS

• Function- protection from chemical, physical
  biological agents
• 5 strata (from external to internal)
• Stratum corneum
• Stratum lucidum
• Stratum granulosum
• Stratum spinosum
• Stratum germinativum (basale)

48

• Stratum corneum- 15-30 layers of keratinized
  cells. Water
•
  resistant


• F- allows insensible perspiration
• More or less 500 ml of water
  every day
• Stratum lucidum- clear layer only in thick skin
  (palms soles).

• F-contains flattered packed
  cells filled with the protein


•
  keratin
• Stratum granulosum- grainy layer
• F- to produce protein keratin
  keratohyalin basic
•
  structural component of hair nails


• Stratum spinosum (8 to 10 layers)
• F- it contains Langerhands cells
  for Immune response
• against
  microorganisms Cancer cells
• Stratum germinativum or basale(The innermost)

• F- cells divide to replace
  superficial cells


• it contains Melanocytes to
  produce melanin
• For protection
  against uv radiation

49
Epidermis (5 strata) (Martini pg 156)
50
DERMIS

• Function- thermoregulation protection
• 2 mayor components-
  papillary reticular layers
• Papillary l- contains capillary lymphatic
•
  vessels sensory neurons
• function- support nourishment of
  the
• overlaying
  epidermis
• Reticular l- deep to papillary layer
• function- to resist tension in the
  skin

51
HYPODERMIS

• FUNCTION- ENERGY STORE
• CUSHIONING
• INSULATION

52
ACCESSORY STRUCTURES

• Meissners corpuscles (white in models)
• F- light touch tactile receptors
• Pacinian corpuscles (olive in models)
• F- deep pressure vibration
  receptors
• Sebaceous glands- discharges waxy sebum into the
  hair
•
  follicle

• F- lubrication
• Hair for protection, insulation, and tactile
  reception.
• It is divided into
• Shaft exposed hair and first part
  under skin
• Root- surrounded by hair follicle.
  Contains hair
• papilla- at the base
• Hair bulb- surrounds the papilla
• Arrector pili- smooth muscle that erects the hair
• Sweat glands- Apocrine
• Merocrine

53

• Apocrine sweat gland
• Secrets its products into the hair
  follicle
• Begins its function at puberty
• Bacteria can intensify its odor
• Present only under armpits, around
  the nipples and groin
• Merocrine sweat gland- Discharge its contends
  directly on the
•
  skin surface


• Sensible perspiration and
  thermoregulation by cooling
• surface of skin to
  reduce body temperature.
• It also acts to excrete water and
  electrolytes and reduces
• growth of
  microorganisms.
•


54
Hair follicle (Martini pg165)
55
Hair follicle (Martini pg165)
56
REMEMBER, GO TO THE TUTORING ROOM AND PRACTICE
WITH MODELS!

• ROOM 3326
