CNC Press Brake India

1
(No Transcript)
2
About us

• Machinery Spares is the pioneer company of The
  I.S. Chawla Group which is a group of Engineering
  Companies catering to the needs of Capital
  Equipment for a large number of industries which
  include
• Automobile Ancillaries
• Pre-fabricated Structure Builders
• Sheet Metal Fabricators
• Pumps Valves Manufacturers
• White Body Goods Manufacturers
• Ship Builders
• Pipe Line Projects
• Lighting Pole Manufacturers

3
Turnover INR 600 million
Year of Establishment 1954
Number of Employees 300
Plants Rajkot
KEY FACTS of the I.S. CHAWLA GROUP OF COMPANIES
4
Our Products
Workshop Machinery
Sheet Metal Machinery
5
SEW Cross Shaft, Gap Frame ( C Frame) - SNX-2
Series
Sheet Metal Machinery

•  Applicable for single and progressive die
  application in blanking, piercing, bending,
  forming,
•  Interlink with transfer unit
•  Rigid frame with less deflection
•   Wide bolster and side area
•   These presses are most suitable for automobile
  components white good industry

6
YSD Press Brake with NC Option - PPTK Series
HPBK Series
Sheet Metal Machinery
A simple, effcient and accurate system by means
of a torsion bar ensures the parallelism between
beams is used for the synchroism.
7
YSD Hydraulic Shearing Machine with NC Option -
HGO, HGN, HGS Series
Sheet Metal Machinery
YSD  - HYDRAULIC VARIABLE RAKE ANGLE GUILLOTINE
SHEARING MACHINES. Three pairs of Rollers
Priovide guiding of blade beam, the two lower
roller guides
8
TEE 3 Roll Pyramid Type Mechanical Plate Bending
Machine
Sheet Metal Machinery
'Tee' Electro Mechanical Pyramid Type Plate
Bending Machines Are The Most Popular Plate
Bending Machines Working In India With Over A
Thousand Machines In Use. They Are Designed For
Production Of Cylindrial Shells Used For Pipes,
Storage Tanks, Chimneys, Pressure Vessels, Etc.
9
PANTHER Precision All Geared Lathes - 1350 1650
Series
Workshop Machinery
PANTHER 1350 1650 SERIES ALL GEARED PRECISION
LATHE MACHINE CONFIRMING TO STANDARD OF GRADE 1
ACCURACY
10
SAMSON Heavy Duty All Geared Radial Drilling
Machine RD Series
Workshop Machinery
SAMSON Heavy Duty All Geared Radial Drilling
Machine - RD Series
Salient Features For Drilling, Reaming And
Tapping.
11
Samson Universal Milling Machines - UFM Series
Workshop Machinery
UFM-1H GEARED HORIZONAL MILLING HAVING X Y
AXIS AUTOMIC FEEDS.HARDENED AND GROUND TABLE AND
GUIDEWAYS.
12
KENT Hydraulic Surface Grinders upto 800 x 400 mm
Workshop Machinery
Kent Precision Hydraulic Surface Grinding
Machines
13
SAMSON Single Column VTL (Vertical Turning Lathe)
Workshop Machinery
'Samson' Single Column Vertical Turret Lathes Are
Versitile Machine Which Are Suitable For
Machining Parts For Almost Every Type Of
Industry. Boring, Tapering, Surfaceing As Well As
Grooving Cutting Off Jobs Can Be Carried Out,
On These Machine.
14
Machine
Workshop Machinery
Tapping Machine
Shaping Machine
Drilling Machine
Slotting Machine
15
Contact us
MUMBAI 201, Karmastambh, LBS Marg, Vikhroli
(W), Mumbai 400 083. Tel [phone] Fax
91-22-25798809 Email info_at_machineryandspares.com

Chennai 234, AngappaNaicken Street,Chennai-600
001,Tele Fax [phone] Email
mands_at_md4.vsnl.net.in
RAJKOT NH8 B, Opp Field Marshal School, Shapar,
Dist Rajkot. Tel [phone] Email
rajkot_at_machineryandspares.com
Faridabad 53, 1st Floor, Neelam Flyover
market, Faridabad-121 001, Tel [phone] Fax
0129-2420150 Email fbd_at_machineryandspares.com
BENGALURU 603-A, Mittal Tower M. G.
Road, Bengaluru-560 001. Tel [phone] Fax
080-25594143 Email blr_at_machineryandspares.com
Navi-Mumbai Address R 495/1, Near Shankar
Hotel, Rabale MIDC, Navi Mumbai Tel [phone]
