WRC-12 Citel Preparation

1

CITEL Preparation World Radiocommunication
Conference (WRC-12)
Fortaleza Brazil August, 2010
2
WRC-12 Agenda Items of interest to Aviation
to consider and take appropriate action on
requests from administrations to delete their
country footnotes or to have their country name
deleted from footnotes, if no longer required,
taking into accordance Resolution 26 (Rev.WRC-07)

• AI 1.1 to consider and take appropriate action on
  requests from administrations to delete their
  country footnotes or to have their country name
  deleted from footnotes, if no longer required,
  taking into accordance Resolution 26 (Rev.WRC-07)
• PV Administrations share concern with proposals
  to add country footnotes.
• AI 1.2 Taking into account the ITU-R studies
  carried out in accordance with Resolution 951
  (Rev.WRC-07), to take appropriate action with a
  view to enhancing the international regulatory
  framework.
• PV Are of the view that the international
  spectrum regulatory framework could be improved
  and are examining the options to address this
  with a view to minimizing potential impact on
  existing services while providing flexible,
  timely and efficient access to spectrum for new
  technologies. (Brazil, Canada, Mexico and
  Guatemala)

3
WRC-12 Agenda Items of interest to Aviation

• AI 1.3 To consider spectrum requirements and
  possible regulatory actions, including
  allocations, in order to support the safe
  operation of unmanned aircraft systems (UAS),
  based on the results of ITU-R studies, in
  accordance with Resolution 421 (WRC-07)
• PP To provide an AM(R)S allocation in the
  5030-5091 Mhz band to support line-of-sight
  control links for unmanned aircraft. (US only)
• AI 1.4 To consider, based on the results of
  ITU-R studies, any further regulatory measures to
  facilitate introduction of new aeronautical
  mobile (R) service (AM(R)S) systems in the bands
  112-117.975 MHz, 960-1 164 MHz and
  5 000-5 030 MHz in accordance with
  Resolutions 413 (Rev.WRC-07), 417 (WRC-07) and
  420 (WRC-07)
• PV If the spectrum requirements for surface
  applications at airports cannot be fully
  accommodated within the 5 091-5 150 MHz band, and
  if compatibility studies identified in Resolution
  420 (WRC-07) ensure protection of RNSS and RAS
  from AM(R)S surface applications, supports a new
  allocation to the AM(R)S in the band 5 000-5 030
  MHz.

4
WRC-12 Agenda Items of interest to Aviation

• AI 1.5 to consider worldwide/regional
  harmonization of spectrum for electronic news
  gathering (ENG), taking into account the results
  of ITU-R studies, in accordance with Resolution
  954 (WRC-07)
• PV Support reviewing the requirements developed
  in WP 6A to determine if harmonization is
  feasible on a regional/global basis for ENG
  systems. (Brazi, Canada, USA)
• AI 1.7 to consider the results of ITU-R
  studies in accordance with Resolution 222
  (Rev.WRC-07) in order to ensure long-term
  spectrum availability and access to spectrum
  necessary to meet requirements for the
  aeronautical mobile-satellite (R) service, and to
  take appropriate action on this subject, while
  retaining unchanged the generic allocation to the
  mobile-satellite service in the bands
  1 525-1 559 MHz and 1 626.5-1 660.5 MHz
• PP Support for NOC Article 5 9, consequential
  modification to 5.357A, NOC 5.362A. Canada/USA
  support Method D, Brazil Method B, Mexico Method
  C.

5
WRC-12 Agenda Items of interest to Aviation
to revise frequencies and channelling
arrangements of Appendix 17 to the Radio
Regulations, in accordance with Resolution 351
(Rev.WRC-07), in order to implement new digital
technologies for the maritime mobile service
to revise frequencies and channelling
arrangements of Appendix 17 to the Radio
Regulations, in accordance with Resolution 351
(Rev.WRC-07), in order to implement new digital
technologies for the maritime mobile service
AI 1.9 to revise frequencies and
channelling arrangements of Appendix 17 to the
Radio Regulations, in accordance with Resolution
351 (Rev.WRC-07), in order to implement new
digital technologies for the maritime mobile
service PV Support the revision of RR
Appendix 17 in order to implement the use of new
digital technologies for the maritime mobile
service, taking into account that (Brazil,
Canada, USA) AI 1.12 to protect the
primary services in the band 37-38 GHz from
interference resulting from aeronautical mobile
service operations, taking into account the
results of ITU-R studies, in accordance with
Resolution 754 (WRC-07) PV Support for
sharing studies in the band 37-38 GHz to
determine appropriate compatibility criteria for
the AMS. The establishment of sharing criteria
that both protects the other primary services in
the band 37-38 GHz, as well as allows for
compatible AMS applications, if the studies show
that this sharing is feasible with particular AMS
applications.The suppression of the AMS from the
37-38 GHz band, only if the studies show that
sharing is not feasible.
6
WRC-12 Agenda Items of interest to Aviation

• AI 1.14 to consider requirements for new
  applications in the radiolocation service and
  review allocations or regulatory provisions for
  implementation of the radiolocation service in
  the range 30-300 MHz, in accordance with
  Resolution 611
• PV To adopt new allocations that would support
  radiolocation operations within 30-300 MHz ITU-R
  studies must demonstrate that radiolocation
  systems are compatible and do not cause
  interference to existing services, including
  mobile-satellite, mobile (including aeronautical
  mobile), land mobile, fixed, radio astronomy,
  amateur, and amateur-satellite. Some regulatory
  text in the form of one or more applicable
  footnotes may be necessary to ensure incumbent
  services are protected if the radiolocation
  service is allocated in the 30-300 MHz band.
• AI 1.15 to consider possible allocations in the
  range 3-50 MHz to the radiolocation service for
  oceanographic radar applications, taking into
  account the results of ITU-R studies, in
  accordance with Resolution 612 (WRC-07)
• PV The United States and Canada support studies
  of the sub-bands near 4.5 MHz, 13 MHz, 27 MHz,
  and 45MHz. If a radiolocation allocation is made
  in these sub-bands then appropriate regulatory
  provisions may be necessary to ensure that
  incumbent services are protected.

7
WRC-12 Agenda Items of interest to Aviation

• AI 1.19 to consider regulatory measures and
  their relevance, in order to enable the
  introduction of software-defined radio and
  cognitive radio systems, based on the results of
  ITU-R studies in accordance with Resolution 956
  (WRC-07)
• PP No regulatory actions by WRC-12 are required
  in order to permit the implementation of either
  SDR or CRS technologies in the context of any
  system of any radiocommunication service.
  Therefore, no changes to the Radio Regulations
  are needed to address SDR and CRS as they are
  technologies, each with its own attributes, and
  not radiocommunication services. With respect to
  the definitions, description, or characterization
  of SDR or CRS, there is no need to include a
  definition of SDR or CRS in Article 1 of the
  Radio Regulations.
• AI 1.21 to consider a primary allocation to the
  radiolocation service in the band 15.4 15.7
  GHz, taking into account the results of ITU-R
  Studies, in accordance with Resolution 614
  (WRC-07)
• PV If the studies identified in Resolution 614
  (WRC-07) demonstrate that the incumbent services
  and systems can be protected from the potential
  use of the 15.4-15.7 GHz band by radiolocation
  systems, the United States supports a new primary
  allocation to the radiolocation service in the
  band 15.4-15.7 GHz

8
WRC-12 Agenda Items of interest to Aviation

• AI 1.22 to examine the effect of emissions from
  short range devices on radiocommunication
  services in accordance with Resolution 953
  (WRC-07)
• PV Brazil, Canada, US and Uruguay are of the
  view that no emission limits or emissions masks
  for SRDs are needed in the Radio Regulations.
  Further, much of the work required to advance
  harmonization can be done through ITU-R
  Recommendations and Reports.
• AI 1.23 to consider an allocation of about 15
  kHz in parts of the band 415-526.5 kHz to the
  amateur service on a secondary basis, taking into
  account the need to protect existing services
• PV Support the allocation of about 15 kHz to the
  amateur service on a secondary basis in the band
  415-526.5 kHz provided that appropriate ITU-R
  sharing studies demonstrate compatibility of this
  allocation with the existing services, including
  the maritime mobile service.(Canada, Dominican
  Republic, US) In addition Canada supports an
  allocation to the amateur service on a secondary
  basis in the range 493-510 kHz, noting that
  protection of incumbent services could be further
  addressed in a similar manner to the provisions
  provided in No. 5.82B.
•

9
WRC-12 Agenda Items of interest to Aviation

• AI 1.25 to consider possible additional
  allocations to the mobile-satellite service, in
  accordance with Resolution 231 (WRC-07)
• PV Administrations support studies within the
  scope of the agenda item, ie not below 4 GHz or
  above 16 GHz , any bands considered must
  demonstrate compatibility with incumbent and
  future deployments. Support for exclusion of
  specific bands, 5030-5091 MHz 5 091-5 250 MHz, 7
  025-7 075 MHz, 3 625-4 200 MHz, 5 850-6 425 MHz,
  10.95-11.2 GHz, 11.45-12.2 GHz and 13.75-14.5 GHz


10
WRC-12 Agenda Items of interest to Aviation

• END
