Sustainable Design Energy Sciences Building

1
Sustainable DesignEnergy Sciences Building
2

• Sustainability Regulations
• DOE final rule 10 CFR part 433 (30 better than
  ASHRAE)
• DOE Order 430.2b Departmental Energy, Renewable
  Energy and Transportation Management
• EPAct 2005 Energy Policy Act of 2005
• EO 13423 Executive Order 13423, Strengthening
  Federal Environmental, Energy, and Transportation
  Management of 2007
• Memorandum of Understanding, Federal Leadership
  in High Performance and Sustainable Buildings
• EISA 2007 Energy Independence and Security Act
  of 2007

3
LEED v2.2 Predicted Results

• Certification Level Gold
• 44 points (39 required)
• Sites 11
• Water Efficiency 5
• Energy Atmosphere 7
• Materials Resources 6
• Indoor Environmental Quality 11
• Innovation 5

4
Sustainable Sites - Features

• Proximity to 200 area main parking Lot

• Site selected to optimize functionality (energy
  quad)

• East West orientation

• Reserved parking for LEV/FEV and EV charging
  stations

N

• Proximity to Pace bus route

5
Sustainable Sites - Features

• Reduction of heat island effect by using
  reflective surfaces for hardscapes and roofs

• Restore original habitat to the majority of the
  site and maximize open space

• Storm water management and storm water quality
  (detention and rain gardens)

• Light pollution reduction by efficient exterior
  lighting design

N
6
Daylight and Transparency
7
Water Efficiency- Features

• High Efficiency Toilets 1.28 GPF
• High Efficiency Urinals ½ GPF urinals
• Low-Flow Lavatories (metering) 0.25 gallons per
  use
• Low-Flow Shower 1.5 GPM
• Low-Flow Kitchen Sink 1.5 GPM

8
Water Savings
9
Energy and Atmosphere- Features

• Optimize energy performance
• Enhanced Commissioning
• Measurement and Verification Enhanced Metering
• Energy efficient lighting design Fluorescent
  and LED

10
Energy and Atmosphere- Features

• High insulation R value walls, roofs, below-grade
  walls, slab
• Low U factor and SHGC windows and skylights

• High Efficiency Lighting with Daylighting
  Controls in certain areas
• Occupancy sensors

• Reduce exhaust and makeup airflow during
  unoccupied periods for laboratory spaces
• Chilled water and hot water loop pressure reset

• 38 better than ASHRAE

11
Energy and Atmosphere- Features

• Fan wall unit air handling units
• Building Automation system
• Minimize static pressure

• Heat recovery loop on fan exhaust

• Low flow variable volume fume hoods with auto
  closing sashes

• Flash steam heat recovery

• Leadership in Energy Efficient Lab/Office Design

12
Rainscreen Facade
13
High Performance Lighting
MOTION SENSORS DIMMERS
LEDs
GREEN LIGHTING
FLUORESCENT
DAYLIGHTING
14
Material Selection
Reclaimed Wood Paneling
Recycled Glass Countertops
Rapidly Renewable Recyclable Ceiling Tile
No Voc Paint
Recycled Glass Tile
Recycled Rubber Flooring
Linoleum
Recycled Wood Furniture
Concrete
