Face Recognition and Its applications

1
Face Recognition and Its applications
PART 1
Based on works of Jinshan Tang Ariel P from
Hebrew University Mircea Focsa, UMFT Xiaozhen
Niu, Department of Computing Science, University
of Alberta Christine Podilchuk,
chrisp1_at_caip.rutgers.edu, http//www.caip.rutgers.
edu/wiselab
2
Contents

• Introduction
• Face detection using color information
• Face matching
• Face Segmentation/Detection
• Facial Feature extraction
• Face Recognition
• Video-based Face Recognition
• Comparison
• Conclusion
• Reference

3
Face Segmentation/Detection

• During the past ten years, considerable progress
  has been made in multi-face recognition area,
• This includes
• Example-based learning approach by Sung and
  Poggio (1994).
• The neural network approach by Rowley et al.
  (1998).
• Support vector machine (SVM) by Osuna et al.
  (1997).

4
Introduction
5
(No Transcript)
6
Basic steps for face recognition
Input face image
Face detection
Face recognition
Face feature extraction
Face database
Feature Matching
Decision maker
Output result
7
Face detection

• Geometric information based face detection
• Color information based face detection
• Combining them together

(a) Geometric information based face detection
(b) Color information based face detection
8
Color information based face detection
Face color is different from background
Choice of color spaces is very important

• Color Spaces
• R,G,B
• YCbCr
• YUV
• r,g
• ..

Skin color
Background color
Figure 4. Skin color distribution in a
complex background
9
A face detection algorithm Using Color and
Geometric information
10
Ideas (1) compensate for lightning, (2) separate
by transforming to new (sub) space.
11
Ideas (1) compensate for lightning, (2) separate
by transforming to new (sub) space. (3)
clustering.
12
Feature-based face detection
Color can be used in segmentation and grouping of
image subareas.
13
Location and shape parameters of eyes are the
most important features to be detected through
segmentation and morphological operations
(dilation and erosion).
14
(No Transcript)
15

• Ideas
• Eyes
• Mouth
• Boundary (edge detection)
• Boundary approximated to ellipse or something
  (Hough)

16
The concept of eye glasses
The concept of half-profiles
17
Face Matching

• Feature based face matching
• Template matching

Features versus templates
18

• Feature based face matching

You can extract various features
Face image From face detection
Normalization
Feature extraction
Feature vector
classifier
Decision maker
Output results
You can use various decision makers
You can use various classifiers
19
Normalization
Eye location
Normalization rotation normalization, scale
normalization
Averaged for objects
Cross Correlation
object
template
20
Feature extraction

• Eyebrow thickness and vertical position at the
  eye center position
• A coarse description of the left eyebrows arches

• Nose vertical position and width
• Mouth vertical position, width, height upper and
  lower lips
• eleven radii describing the chin shape
• Bigonial breadth (face width at nose position)
• Zygomatic breadth (face width halfway between
  nose tip and eyes).

3.5-D feature vector
21
Example of some geometrical features
22
Classifier
This is just one example of classifier, others
are Decision Trees, expressions, decomposed
structures, NNs.
Bayes classifier
Rank the distance values
Output the results
Feature vector
Computer
(j2,3,N)
23
ANN Classifier
Feature vector
Class 1
Class 2
ANN one-class-in-one network multi-class-in-one
network
MAXNET
Classification results
Fig.2. one-class-in-one network
24
Template matching
Templates database
You have to create the data base of templates for
all people you want to recognize
Produce a template
Face image From face detection
Normalization
matching
Decision maker
Output results
25
There are different templates used in various
regions of the normalized face. Various methods
can be used to compress information for each
template.
26
Example-based learning approach (EBL)

• Three parts
• The image is divided into many possible-overlappin
  g windows,
• each window pattern gets classified as either a
  face or not a face based on a set of local
  image measurements.
• For each new pattern to be classified, the system
  computes a set of different measurements between
  the new pattern and the canonical face model.
• A trained classifier identifies the new pattern
  as a face or not a face.

27
Example of a system using EBL
28
Neural network (NN)

• Kanade et al. first proposed an NN-based approach
  in 1996.
• Although NN have received significant attention
  in many research areas, few applications were
  successful in face recognition.
• Why?

29
Neural network (NN)

• Its easy to train a neural network with samples
  which contain faces, but it is much harder to
  train a neural network with samples which do not.
• The number of non-face samples are just too
  large.

30
Neural network (NN)

• Neural network-based filter.
• A small filter window is used to scan through all
  portions of the image,
• and to detect whether a face exists in each
  window.
• Merging overlapping detections and arbitration.
  By setting a small threshold, many false
  detections can be eliminated.

31
An example of using NN
32
Test results of using NN
33
SVM (Support Vector Machine)

• SVM was first proposed in 1997, it can be viewed
  as a way to train polynomial neural network or
  radial basic function classifiers.
• Can improve the accuracy and reduce the
  computation.

34
Comparison with Example Based Learning (EBL)

• Test results reported in 1997.
• Using two test sets (155 faces).
• SVM achieved better detection rate and fewer
  false alarms.

35
Recent approaches

• Face segmentation/detection research area still
  remain active, for example
• An integrated SVM approach to multi-face
  detection and recognition was proposed in 2000.
• A technique of background learning was proposed
  in August 2002.
• Still lots of potential!

36
Static face recognition

• Numerous face recognition methods/algorithms
  have been proposed in last 20 years,
• several representative approaches are
• Eigenface
• LDA/FDA (Linear DA, Fisher DA) Discriminant
  analysis (algorithm)
• Neural network (NN)
• PCA Principal Component Analysis
• Discrete Hidden Markov Models (DHMM)
• Continuous Density HMM (CDHMM).

37
Eigenface

• The basic steps are
• Registration. A face in an input image first must
  be located and registered in a standard-size
  frame.
• Eigenpresentation.
• Every face in the database can be represented as
  a vector of weights,
• the principal component analysis (PCA) is used
  to encode face images and capture face features.
• Identification. This part is done by locating the
  images in the database whose weights are the
  closest (in Euclidean distance) to the weights of
  the test images.

38
LDA/FDA

• Face recognition method using LDA/FDA is called
  the fishface method.
• Eigenface use linear PCA. It is not optimal to
  discrimination for one face class from others.
• Fishface method seeks to find a linear
  transformation to maximize the between-class
  scatter and minimize the within-class scatter.
• Test results demonstrated LDA/FDA is better than
  eigenface using linear PCA (1997).

39
Test results of LDA

• Test results of a subspace LDA-based face
  recognition method in 1999.

40
Video-based Face Recognition

• Three challenges
• Low quality
• Small images
• Characteristics of face/human objects.
• Three advantages
• Allows much more information.
• Tracking of face image.
• Provides continuity,
• this allows reuse of classification information
  from high-quality images in processing
  low-quality images from a video sequence.

41
Basic steps for video-based face recognition

• Object segmentation/detection.
• Motion structure.
• The goal of this step is to estimate the 3D
  depths of points from the image sequence.
• 3D models for faces.
• Using a 3D model to match frontal views of the
  face.
• Non-rigid motion analysis.

42
Recent approaches

• Most video-based face recognition system has
  three modules for
• detection,
• tracking
• and recognition.
• An access control system using Radial Basis
  Function (RBS) network was proposed in 1997.
• A generic approach based on posterior estimation
  using sequential Monte Carlo methods was proposed
  in 2000.
• A scheme based on streaming face recognition
  (SFR) was propose in August 2002.

43
The Streaming Face Recognition (SFR) scheme

• Combine several decision rules together, such as
• Discrete Hidden Markov Models (DHMM) and
• Continuous Density HMM (CDHMM).
• The test result achieved a 99 correct
  recognition rate in the intelligent room.

44
Comparison

• Two most representative and important protocols
  for face recognition evaluations
• The FERET protocol (1994).
• Consists of 14,126 images of 1199 individuals.
• Three evaluation tests had been administered in
  1994, 1996, and 1997.
• The XM2VTS protocol (1999).
• Expansion of previous M2VTS program (5 shots of
  each of 37 subjects).
• Now consists 295 subjects.
• The results of M2VTS/XM2VTS can be used in wide
  range of applications.

45
1996/1997 FERET Evaluations

• Compared ten algorithms.

46
Conclusion

• Face recognition has many potential
  applications.
• For many years not very successful,
• we need to improve the accuracy of face
  recognition
• Combining face recognition and other biometric
  recognition technologies,
• Such as
• fingerprint recognition technology,
• voice recognition technologies
• and so on

For our applications accuracy is much more
important than speed.
47
Conclusion

• Significant achievements have been made recently.

• LDA-based methods and NN-based methods are very
  successful.
• FERET and XM2VTS have had a significant impact to
  the developing of face recognition algorithms.
• Challenges still exist, such as pose changing and
  illumination changing.
• Face recognition area will remain active for a
  long time.

48
Reference

• 1 W. Zhao, R. Chellappa, A. Rosenfeld, and
  P.J. Phillips, Face Recognition A Literature
  Survey, UMD CFAR Technical Report CAR-TR-948,
  2000.
• 2 K. Sung and T. Poggio, Example-based
  Learning for View-based Human Face Detection,
  A.I. Memo 1521, MIT A.I. Laboratory, 1994.
• 3 H.A. Rowley, S. Baluja, and T. Kanade,
  Neural Network Based Face Detection, IEEE Trans.
  On Pattern Analysis and Machine Intelligence,
  Vol. 20, 1998.
• 4 E. Osuna, R. Freund, and F. Girosi, Training
  Support Vector Machines An Application to Face
  Recognition, in IEEE Conference on Computer
  Vision and Pattern Recognition, pp. 130-136,
  1997.
• 5 M. Turk and A. Pentland, Eigenfaces for
  Recognition, Journal of Cognitive Neuroscience,
  Vol.3, pp. 72-86, 1991.
• 6 W. Zhao, Robust Image Based 3D Face
  Recognition, PhD thesis, University of Maryland,
  1999.
• 7 K.S. Huang and M.M. Trivedi, Streaming Face
  Recognition using Multicamera Video Arrays, 16th
  International Conference on Pattern Recognition
  (ICPR). August 11-15, 2002.
• 8 P.J. Phillips, P. Rauss, and S. Der, FERET
  (Face Recognition Technology) Recognition
  Algorithm Development and Test Report, Technical
  Report ARL-TR 995, U.S. Army Research Laboratory.
• 9 K. Messer, J. Matas, J. Kittler, J. Luettin,
  and G. Maitre, XM2VTSDB The Extended M2VTS
  Database, in Proceedings, International
  Conference on Audio and Video-based Person
  Authentication, pp. 72-77, 1999.
