Dr. William R. Law

1
PHYB 301Human Physiology
Basic cell physiology, membranes, and the
membrane potential
Dr. William R. Law Room 203A, CMW 6-7622 wrlaw_at_uic
.edu
http//www.uic.edu
/wrlaw
Office hours 630-830 AM 1230-130 PM
Office hours 630-830 AM 1230-130 PM
2
Why study pathophysiology?
3
(No Transcript)
4
Homeostasis the foundation of Physiology

• When things go right a balance of interactive
  and varied
• functions at all levels of organization

• The body is considered from the perspective of
  the interactions of different organ systems
• Organs are considered from the vantage of the
  interactions of different cell types.
• Cells are viewed from the perspective of the
  interactions of different structures and
  organelles.
• Structures/organelles from the perspective of
  interactions of different molecules

5
Homeostasis the foundation of Physiology
When things go wrong the balance has been
disrupted, or a new, deleterious balance has been
instituted. PATHOPHYSIOLOGY

• Teleological approach molecules, organelles,
  celles, organs, etc, fulfill a bodily need.
• Mechanistic approach molecules, organelles,
  cells, organs, etc, just do.

6
Homeostasis the foundation of Physiology
Homeostasis occurs through key regulatory
paradigms to achieve steady-state conditions

• Feedback the effect influences the cause
• thermostat
• Hierarchical communication there is a command
  structure controlling an outcome.
• Hypothalamus-pituitary-adrenal axis
• Adaptation the steady-state is changed to
  accommodate a new situation
• Altitude

7
Why cellular physiology?The cell is the smallest
unit capable of carrying out the processes
associated with life.

• Classical Properties of Living Organisms
• Reproduction
• Nutrition
• Respiration
• Excretion
• Irritability/respond
• Movement
• Growth

• How cells fulfill these criteria of Living
  Organisms
• Cell replication
• Nutrition
• Respiration
• Excretion
• Respond to environment
• Movement within and externally
• Grow in number and size

8
Organization of the cell

• Membranes
• Plasma membrane encompasses the functional cell
  unit
• Membranes segregate most other individual
  components of the cell
• Nucleus
• Organelles
• Cytoplasm - suspension of fluid with various
  cellular elements

9
Double membrane
Cristae
10
Double membrane
Cristae
Matrix
11
Mitochondria Cellular Power Plant

• Unique Characteristics
• Contains its own DNA (maternal lineage only)
• Double membrane
• The inner memrane is heavily folded into
  "cristae"
• The gel-like fluid "matrix" contains enzymes for
  production of adenosine triphosphate (ATP)
• Energy conversion
• C-H bonds of substrate (food) is converted to
  high energy phosphate bonds through the citric
  acid cycle (also called the Kreb or tricarboxylic
  acid cycle).
• Hydrogen atoms carried by nicotinamide adenine
  dinucleotide (NAD) and flavine adenine
  dinucleotide (FAD)
• importance of niacin and riboflavin
• Electrons carried through a very ordered series
  of reactions to incoporate energy into usable
  form (ATP)

12
GDP
13
Mitochondria Cellular Power Plant

• Unique Characteristics
• Contains its own DNA (maternal lineage only)
• Double membrane
• The inner memrane is heavily folded into
  "cristae"
• The gel-like fluid "matrix" contains enzymes for
  production of adenosine triphosphate (ATP)
• Energy conversion
• C-H bonds of substrate (food) is converted to
  high energy phosphate bonds through the citric
  acid cycle (also called the Kreb or tricarboxylic
  acid cycle).
• Hydrogen atoms carried by nicotinamide adeninje
  dinucleotide (NAD) and flavine adenine
  dinucleotide (FAD)
• importance of niacin and riboflavin
• Electrons carried through a very oerdered series
  of reactions to incoporate energy into usable
  form (ATP)

• Oxygen is the final electron acceptor combines
  with H to form water
• Carbon combines with oxygen to form CO2

14
Organization of the cell

• Membranes Structurally define cells, nucleus,
  and organelles.
• Phospholipids

15
(No Transcript)
16
(No Transcript)
17
Phsopholipids are amphipathic

• Phospholipids are polar, having hydrophobic
  "tails" made of lipids, and hydrophilc "head"
  groups
• Phosphatidylcholine head is choline (lecithins)

18
(No Transcript)
19
Phospholipids are amphipathic

• Phospholipids are polar, having hydrophobic
  "tails" made of lipids, and hydrophilc "head"
  groups
• Phosphatidylcholine head is choline (lecithins)

• Phosphatidylethanolamine head is ethanolamine
• Phosphatidylinositol wellyou get the idea
• The hydrophobic "tail" is composed of varying
  phospholipids, a fatty acid esterified to
  glycerol or (serine sphingomyelin)
• Because of this polar nature, phospholipids
  self-assemble in aqueous solutions to form
  bilayers.

20
micelle
21
Organization of the cell

• Membranes Structurally define cells, nucleus,
  and organelles.

• Phospholipids- primary building block of the
  membrane
• Fluid mobile
• Individual phospholipids remain in a singel
  monolayer
• Provide some substrate for cellular signalling
• Cholesterol
• stiffens membranes
• Can move in any dimension through membrane
• Glycolipids lipid/sugar moiety
• Proteins
• Glycoprotein protein/sugar moiety

22
(No Transcript)
23
DNA
RNA
Protein
24
RNA

• Messenger RNA (mRNA) - long, single nucleotide
  strands that resemble half of a DNA molecule and
  carry the "message" containing instructions for
  protein synthesis from the DNA in the nucleus to
  the ribosomes in the cytoplasm.
• Transfer RNA (tRNA) - small, between 70 and 80
  nucleotides, cloverleaf-shaped molecules that
  transfer amino acid molecules to the mRNA.

25
Protein synthesisinvolves two major phases

• Transcription - complementary mRNA is made at the
  DNA gene. Three-base sequences, or triplets, on
  the DNA specify a particular amino acid. The
  corresponding three-base sequences on mRNA are
  called codons. The form is different, but the
  information is the same.
• Translation The mRNA is "decoded" to assemble
  proteins in a ribosome using tRNA. The language
  of nucleic acids (base sequence) is "translated"
  into the language of proteins (amino acid
  sequence). There are four basic steps
• Messanger RNA from the nucleus attaches to a
  ribosome in the cytoplasm.
• Transfer RNA transports an amino acid to the mRNA
  strand and recognizes a mRNA codon calling for
  its amino acid by binding its anticodon to the
  codon.
• The ribosome moves the mRNA strand along as each
  codon is read sequentially.
• As each amino acid is bound to the next by a
  peptide bond, its tRNA is released. The
  polypeptide chain is released when the
  termination (stop) codon is read.

26
(No Transcript)
27
5
28
(No Transcript)
29
(No Transcript)
30
Endoplasmic Reticulum (ER)Cellular manufacturing
facilities

• Major site of protein synthesis
• ribosomes begin the polypeptide synthesis process
  with a segment that binds to a signal-recognition
  protein (SRP) in the cytoplasm.
• SRP associates with a transmembrane receptor, or
  docking protein, on the rough ER. NOTE the
  SRP inhibits peptide synthesis until it can
  dock.
• Synthesis and translocation of the polypeptide
  into the ER occur simultaneously.

31
(No Transcript)
32
Endoplasmic Reticulum (ER)Cellular manufacturing
facilities

• Major site of protein synthesis
• ribosomes begin the polypeptide synthesis process
  with a segment that binds to a signal-recognition
  protein (SRP) in the cytoplasm.
• SRP associates with a transmembrane receptor, or
  docking protein, on the rough ER. NOTE the
  SRP inhibits peptide synthesis until it can
  dock.
• Synthesis and translocation of the polypeptide
  into the ER occur simultaneously.

• Secretory proteins
• translocated freely into interior of the ER
• Move to "smooth" ER secrion for encapsulation
• Vesicle "pinched off" for secretion, or further
  processing at Golgi complex

33
(No Transcript)
34
Endoplasmic Reticulum (ER)Cellular manufacturing
facilities

• Major site of protein synthesis
• ribosomes begin the polypeptide synthesis process
  with a segment that binds to a signal-recognition
  protein (SRP) in the cytoplasm.
• SRP associates with a transmembrane receptor, or
  docking protein, on the rough ER. NOTE the
  SRP inhibits peptide synthesis until it can
  dock.
• Synthesis and translocation of the polypeptide
  into the ER occur simultaneously.
• Secretory proteins
• translocated freely into interior of the ER
• Move to "smooth" ER secrion for encapsulation
• Vesicle "pinched off" for secretion, or further
  processing at Golgi complex

• Transmembrane proteins
• Translated into the ER membrane
• Membrane and protein is later incorporated into
  plasma membrane or membrane of other organelles

35
(No Transcript)
36
Endoplasmic Reticulum (ER)Cellular manufacturing
facilities

• Major site of protein synthesis
• ribosomes begin the polypeptide synthesis process
  with a segment that binds to a signal-recognition
  protein (SRP) in the cytoplasm.
• SRP associates with a transmembrane receptor, or
  docking protein, on the rough ER. NOTE the
  SRP inhibits peptide synthesis until it can
  dock.
• Synthesis and translocation of the polypeptide
  into the ER occur simultaneously.

• Other functions "smooth" ER contains enzymes for
• Lipid synthesis lipid and steroidal hormone
  synthesis
• Detoxifying endogenous and exogenous toxic
  substances (esp. liver)
• Calcium storage (muscle sarcoplasmic reticulum)

37
Golgi Complex The devil is in the details
Transport vesicles from smooth ER
Fuse with golgi stack, and proteins undergo
refinement
38
Golgi ComplexCellular refining facilities

• Post-translational Modification
• Glycosylation (oligosaccharide )
• Disulfide bonds
• Folding
• Quaternary structure
• Sorting and directing

39
Vesicular TransportSorting and
Directing(Example proteins for secretion)

• Directed binding of proteins to specific markers
• Sorting signal on the protein to be secreted
• Recognition marker on golgi-binds the sorting
  signal

40
(No Transcript)
41
Vesicular TransportSorting and
Directing(Example proteins for secretion)

• Directed binding of proteins to specific markers
• Sorting signal on the protein to be secreted
• Recognition marker on golgi-binds the sorting
  signal

• Triskelions (clathrin) or adaptins in cytosol
  form a "coating" that also causes bulging to form
  the vesicle.
• Coating may (or not) shed, exposing the V-snare

42
V-snare docks at T-snare on target
membrane Protein released beyond the membrane
43
Triskelion (clathrin) self-assembly
44
(No Transcript)
45
LysosomesCellular cleanup crew

• Membrane-enclosed sacs of hydrolytic enzymes
• Remove cellular debris
• Destroy invading pathogens

46
(No Transcript)
47
Vaults Ribonucleoprotein complexes that contain
untranslated RNA. Function speculated storage,
transport, or removal? Elevated in multi-drug
resistance in cancers.
48
Cytosol(cytoplasm and friends)

• Ribosomal protein synthesis
• Intermediate metabolism and storage degradation,
  synthesis, or transformation of small organic
  molecules for fuel.
• Metabolism
• Glycolysis - breakdown of simple sugars (esp.
  glucose) for oxidative metabolism. Yields small
  amount of energy.
• Process fatty and amino acids for entry into TCA
  cycle
• Storage
• Fat droplets (esp adipose cells)
• Glycogen
• Ultrastructure - the cytoskeleton
• Microtubules at 22 nm, the largest of the
  cytoskeletal structures composed of tubulin
• Architecture needed to maintain asymetry (Ex.
  Axons) or act as scaffolding during development
• Motion
• Transport of materials (vesicles, etc.)
• Movement
• Mitosis

49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
Cytosol(cytoplasm and friends)

• Ribosomal protein synthesis
• Intermediate metabolism and storage degradation,
  synthesis, or transformation of small organic
  molecules for fuel.
• Metabolism
• Glycolysis - breakdown of simple sugars (esp.
  glucose) for oxidative metabolism. Yields small
  amount of energy.
• Process fatty and amino acids for entry into TCA
  cycle
• Storage
• Fat droplets (esp adipose cells)
• Glycogen
• Ultrastructure - the cytoskeleton
• Microtubules at 22 nm, the largest of the
  cytoskeletal structures composed of tubulin
• Architecture needed to maintain asymetry (Ex.
  Axons) or act as scaffolding during development
• Motion via dynein and kinesin

53
Cytosol(cytoplasm and friends)

• Ribosomal protein synthesis
• Intermediate metabolism and storage degradation,
  synthesis, or transformation of small organic
  molecules for fuel.
• Ultrastructure - the cytoskeleton
• Microtubules at 22 nm, the largest of the
  cytoskeletal structures composed of tubulin

• Microfilaments at 6 nm, the smallest visible
  with standard EM composed of actin (G-form),
  which forms twisted strands (F-form).
• Architechture cell section stiffeners
• Microvilli increased surface areas in repeating
  pattern
• Stress fibers interconnect membrane sections
  forming support
• Movement
• Commonly with myosin molecules
• Myofilaments
• Transport
• Amoeboid motion cyclic assembly/dissembly of
  actin from sol to gel state

54
(No Transcript)
55
Cytosol(cytoplasm and friends)

• Ribosomal protein synthesis
• Intermediate metabolism and storage degradation,
  synthesis, or transformation of small organic
  molecules for fuel.
• Ultrastructure - the cytoskeleton
• Microtubules at 22 nm, the largest of the
  cytoskeletal structures composed of tubulin
• Microfilaments at 6 nm, the smallest visible
  with standard EM composed of actin (G-form),
  which forms twisted strands (F-form).

• Intermediate filaments stable protein strands,
  7-10 nm Provide a stable framework within the
  cell.

56
"free" ribosomes
ER
Plasma membrane
mitochondrion
57
(No Transcript)
