Vehicle-to-Vehicle Wireless Communication Protocol for Collision Warning

1
Vehicle-to-Vehicle Wireless Communication
Protocol for Collision Warning

• Arunkumar Anand
• No 2, S7 ECE

Seminar Presentation 2006 Dept. of Electronics
Communiactions. Govt. Engg. College, Wayanad.
http//arunkumaranand.bizhat.com/seminar
28th September 2006
2
Contents

• Motivation
• Application Levels
• Overview of Vehicular Communications
• Needs and Assumptions
• Protocol for Vehicular Comm.
• Application Challenges
• State Transition
• Future Works
• Conclusion
• References

3
Motivation
Accidents have been taking thousands of lives
each year

• Study shows - About 60 roadway collisions could
  be avoided if the operator of the vehicle was
  provided warning at least one-half second prior
  to a collision
• (- US. Patent No. 5,613,039)
• Constraints of human drivers perception
• Line-of-sight limitation of brake light
• Large processing/forwarding delay for emergency
  events.

4
1. Line of Sight Limitation
Constraints of human drivers perception
On foggy days
Whats in front of that bus ?
Whats behind the bend ?
On rainy days
Fig.1
5
Constraints of human drivers perception
2. Large forwarding delay for emergency events.
Three Cars, namely
Reaction time ranges from 0.7sec to 1.5sec
Car A
Car B
Car C
Animation. 1
6
Overview of Different Vehicular Communications
Data Base
Scope of this Paper
Communication
Hot Spots (DSRC)
Petrol Pump, Workshop etc..
Satellite to
Vehicle
(GPS)
-
( V2V )
Vehicle
-
Vehicle
to
-
to
-
Roadside
Vehicle
(DSRC)
( DSRC)
( V2R )
Fig.2
7
Application Levels

• Traffic Safety can be improved if drivers have
  the ability to see further down the road.
• If traffic information was provided to Drivers,
  Police and other Authorities roads would be safe
  and traveling on them would be more efficient
• Vehicle-to-Vehicle(V2V) and Vehicle-to-Roadside(V2
  R) Communication can bring out the following
  achievements.

• Presence of obstacles on road.
• Emergency Braking of a preceding vehicle.
• Information about Blind Crossing, School
  proximity, Railway crossing etc
• Entries to Highways.
• High Speed Internet Access.
• Electronic Toll Collection.
• Parking Space locater in Cities.
• Nearest Petrol Pump, Workshop etc..

8
for a vehicle participating in V2V communication
Needs and Assumptions
Interested on Direction, Speed, Position etc

• Is able to obtain its own geographical location
  and determine the relative positions on the
  road.(Digital Maps, GPS)
• Is equipped with at least one wireless transceiver

9
Protocol for Vehicular Comm.
10
Animation. 2
Analyze a practical situation

• DSRC for cooperative vehicle information

11
Animation. 2
Not For me!
Who affects the most ?
position speed intent

• DSRC for cooperative vehicle information

For me!
12
Terms

• Abnormal Vehicle (AV)
• A vehicle acts abnormally, e.g. deceleration
  exceeding a certain threshold, dramatic change of
  moving direction, major mechanical failure, etc.
• Emergency Warning Messages (EWM)
• Messages generated by an AV to warn other
  surrounding vehicles, which include the
  geographical location, speed, acceleration and
  moving direction of the AV.

13
Application Challenges lt1gt

• Requiring to support multiple co-existing AVs
  over a longer period of time
• Co-existing AVs AVs whose existences overlap in
  time and whose transmissions may interfere with
  each other
• An AV can exist for an extended period of time
• Chain effects of emergency road situation

Fig.3
14
Application Challenges lt2gt

• Differentiation of emergency events and
  elimination of redundant EWMs
• Unnecessary EWMs should be avoided so that the
  channel bandwidth can be better utilized for
  useful EWMs

Fig.4
15
State transitions of AVs
Eliminate redundant EWMs

• Each AV may be in one of three states

• Initial AV When an emergency event occurs to a
  vehicle, the vehicle becomes an AV and enters the
  initial AV state, transmitting EWMs following the
  rate decreasing algorithm.

• Non-flagger AV nonparticipating in sending EWMs
  to the group on some conditions to
  eliminate redundant EWMs

• Flagger AV resuming EWM transmissions at the
  minimum required rate.

16
State transitions of AVs (condition.)

• Transitions from Initial AV state to Non-flagger
  AV state
• At least Talert duration has elapsed since the
  time when the vehicle became an initial AV.
• EWMs from one of the followers of the initial
  AV are being overheard

• Transitions from Non-flagger AV to flagger AV
• sets a timer for a Flagger Timeout ( FT)
  duration. If it does not receive any EWMs from
  its followers when the FT timer expires, the
  non-flagger AV changes its state to flagger AV.

17
Examples of state transitions
18
Examples of state transitions (cont.)
Fig. 5d
19
Future Works
USDOT Intelligent Transportation Systems (ITS)
Program

• Vehicle manufacturers would install the
  technology in all new vehicles,
• beginning at a particular model year
• Full-scale deployment in both the vehicles and
  the roadside infrastructure will be made
  by 2008/9

Car2Car Communication Consortium (
www.car-to-car.org )

• Non-profit organization initiated by European
  vehicle manufacturers.
• To create and establish an open European
  industry standard for

• Car2Car communication systems based on wireless
  LAN components and to guarantee
  European-wide inter-vehicle operability

20
Conclusion

• An Overview of Vehicular Comm. is given.
• Protocol of Vehicular Comm. Is discussed.
• Protocol Challenges are also analysed.

Hi Buddy
A new era is arriving where vehicles
will communicate with each other, the devices
within them, and also with the world making the
next generation of vehicles into communication
hubs.
21
References

• 1 S. Biswas, "Vehicle-to-Vehicle Wireless
  Communication Protocols for Enhancing Highway
  Traffic Safety," Communications Magazine, IEEE
  Publication Date Jan. 2006 Volume 44, Issue 1
  page(s)74- 82
• 2 X. Yang et al., " A Vehicle-to-Vehicle
  Communication Protocol for Cooperative Collision
  Warning,"Proc. 1st Annual Intl. Conf. Mobile and
  Ubiquitous Syst Networking and Services, 2004
• 3 G.S Bickel, "Inter/Intra-Vehicle Wireless
  Communication" at http//userfs.cec.wustl.edu/gsb
  1/index.html
• 4 Q. Xu, R. Sengupta, and D. Jiang, "Design and
  Analysis of Highway Safety Communication Protocol
  in 5.9 GHz Dedicated Short-Range Communication
  Spectrum," Proc. IEEE VTC, vol. 57, no. 4, 2003,
  pp. 245155
• 5 C.Bettstetter  "Toward Internet-Based Car
  Communications On Some System Architecture And
  Protocol Aspects" TUM, Germany
• 6 J. Zhu and S. Roy, "MAC for Dedicated Short
  Range Communications in Intelligent Transport
  Systems,"IEEE Commun. Mag., vol. 41, no. 12, 2003
• 7 http//www.car-to-car.org/

22
Questions ?
For online Documentation Support
http//arunkumaranand.bizhat.com/seminar
