Title: Electrical Wiring Residential


1
Electrical Wiring Residential
  • Unit 5
  • Switch Control
  • Receptacle Bonding
  • Conductor Identification

2
Conductor Identification
  • For alternating-current circuits, The NEC
    requires that the grounded (identified) conductor
    have an outer finish that is either continuous
    white or gray.
  • The grounded conductor is also called the neutral
    conductor.
  • An ungrounded (hot) conductor must have an outer
    finish that is a color other than green, white,
    natural gray, or gray with three continuous white
    stripes.

3
Grounded (Neutral) Conductor
  • For residential wiring, the 120/240 volt
    electrical system is grounded by the electric
    utility at their transformer, and again by the
    electrician at the main service.

4
Grounded (Neutral) Conductor
  • By definition a neutral conductor is
  • The conductor that carries only the unbalanced
    current from the other conductors, as in the case
    of a multi-wire circuit of three or more
    conductors.
  • The conductor where the voltage from every other
    conductor to it is equal under normal operating
    conditions.
  • By these definitions, the white conductor in a
    two-wire branch circuit is not truly a neutral
    conductor

5
Color Coding (Cable Wiring)
  • The conductors in nonmetallic-sheathed cable
    (Romex) are color coded as follows.
  • Two-wire
  • One black (hot Phase conductor)
  • One white (grounded identified conductor)
  • One bare (equipment grounding conductor)

6
Color Coding (Cable Wiring)
  • Three-wire
  • One black (hot Phase conductor)
  • One white (grounded identified conductor)
  • One red (hot Phase conductor)
  • One bare (equipment grounding conductor)

7
Color Coding (Cable Wiring)
8
Changing Colors When Conductors Are in a Raceway
  • For cable wiring such as nonmetallic-sheathed
    cable or armored cable, 200.7(C)(1) and (2)
    permits the white conductor to be used for
    single-pole, three-way, or four-way switch loops.
  • These code sections require that when used for a
    switch loop, the conductor that is white is to be
    used for the supply to the switch, and not as the
    return conductor from the switch, to the switched
    outlet.

9
Typical Colors for Residential Wiring
10
Push-in Terminations
  • Screwless push-in terminals on receptacles are
    listed by Underwriters Laboratories (UL) for
    use only with solid 14 AWG copper conductors.

11
Push-in Terminations
  • They are not to be used with
  • Aluminum or copper-clad aluminum conductors.
  • Stranded conductors
  • 12 AWG conductors By design, the holes are large
    enough to take only a 14 AWG solid conductor.
  • Push-in terminals for 12 AWG solid copper
    conductors are still permitted on snap switches.

12
Exploded Receptacle Diagram
13
Always pigtail for more than 2 conductors
14
Receptacle Configurations
15A 250V
15A 125V
20A 125V
20A 250V
15
Conductor Color Coding For Switch Connections
  • Always connect a white wire to the white (silver)
    terminal or to the white wire of a lampholder or
    receptacle.
  • Always connect the black switch-leg conductor
    (red in some cases) to the black wire (or dark
    brassy terminal) of a lampholder or receptacle.

16
Conductor Color Coding For Switch Connections
  • In cables, always re-identify white conductors
    when they are used as ungrounded (hot)
    conductors.
  • This re-identification must be done wherever the
    conductors are visible and accessible.
  • Never use a green colored insulation for a
    grounded or ungrounded conductor. Green is
    reserved for equipment grounding conductors

17
Connecting Switches, Receptacles, and Lighting
Outlets.
  • A conductor carrying an alternating current
    produces a magnetic field (flux) around the
    conductor.
  • The greater the current, the stronger the
    magnetic field.

18
Connecting Switches, Receptacles, and Lighting
Outlets.
  • In alternating current _at_ 60Hz., the current and
    magnetic field reverses direction 120 times each
    second.
  • If the conductor is run through a steel raceway,
    steel jacketed cable, or a knockout in a steel
    box, the alternating magnetic field will induce
    heat into the steel.

19
Connecting Switches, Receptacles, and Lighting
Outlets.
  • When all the conductors of the same circuit are
    run through the same raceway, the magnetic fields
    around the conductors are equal and opposite,
    thereby canceling one another out.
  • The NEC 300.3(B) requires that all conductors
    of the same circuit and, where used, the grounded
    conductor, all equipment grounding conductors and
    bonding conductors shall be contained within the
    same raceway, trench, cable, or cord, unless
    otherwise permitted

20
Connecting Switches, Receptacles, and Lighting
Outlets.
  • NEC 404.2(A) requires that three-way and
    four-way switches shall be so wired that all
    switching is done only in the ungrounded circuit
    conductor.
  • Switch loops do not require a grounded conductor.

21
Proper Use of Conductors in Romex Cabling
22
Conductors in
Trenches
23
Grounded Conductors at Switch Locations
  • Are grounded (neutral) conductors needed at
    switching locations?
  • In most cases, the answer is no.
  • However, a grounded conductor is required when a
    true pilot light is connected at the switch
    location.
  • In the event that electronic dimming and/or
    switching devices are to be used, a neutral may
    be required at one or more of the switch
    locations.

24
Grounded Conductors at Switch Locations
25
Using a
2-Wire as a Switch Loop
26
Using a 3-Wire To Send a Feed Through a Light
27
3-Way Switch Line Diagram and Graphic
28
3-Way Fed at Light, Dead Ended at Both Ends
29
4-Way Switch Line Diagram Drawing
30
Bonding and Grounding at Receptacles and Switches
  • A metal box is considered to be adequately
    grounded when the wiring method is armored cable,
    non-metallic sheathed cable with ground, or a
    metal raceway such as EMT.
  • Grounding and bonding of the equipment grounding
    conductor to a metal box, switch, or receptacle
    is important.
  • Most metal boxes have a No. 10-32 tapped hole for
    securing a green hexagon shaped equipment
    grounding screw.

31
Bonding and Grounding at Receptacles and Switches
  • To ensure the continuity of the equipment
    grounding conductor path, 250.148 requires that
    where more than one equipment grounding conductor
    enters a box, they shall be spliced with devices
    suitable for the use.
  • Splices shall not depend on solder!
  • In existing locations where there is no equipment
    grounding conductor in a switch box, and where
    within reach of a conductive floor (i.e.
    concrete, tile, etc), use non-metallic faceplates.

32
Bonding and Grounding at Receptacles and Switches
33
Bonding and Grounding at Receptacles and Switches
34
Various Listed Means of Grounding and Bonding
35
A G-Clip is a Great Way to Attach a Ground To
an Existing Metal Box
36
Timers
  • Timers a unique on that they provide automatic
    control of electrical loads.
  • Timers are used where a load is to be controlled
    for specific ON/OFF times of the day or night.
  • Timers come in a wide variety of styles. Some
    fit in switch-boxes, some have weatherproof
    cases.
  • Timers can also be used with photocells to
    provide even more flexibility for exterior
    lighting.

37
Intermatic Timer
38
Photocells
39
This Concludes Unit 5
