Mathematical Arguments and Triangle Geometry

1
Mathematical Arguments and Triangle Geometry

• Chapter 2

2
Deductive Reasoning

• A process
• Demonstrates that if certain statements are true

• Then other statements shown to follow logically
• Statements assumed true
• The hypothesis
• Conclusion
• Arrived at by a chain of implications

3
Deductive Reasoning

• Statements of an argument
• Deductive sentence
• Closed statement
• can be either true or false
• Open statement
• contains a variable truth value determined once
  variable specified

4
Deductive Reasoning

• Statements open? closed? true? false?
• All cars are blue.
• The car is red.
• Yesterday was Sunday.
• Rectangles have four interior angles.
• Construct the perpendicular bisector.

5
Deductive Reasoning

• Nonstatement cannot take on a truth value
• Construct an angle bisector.
• May be interrogative sentence
• Is ?ABC a right triangle?
• May be oxymoron

The statement inthis box is false
6
Rules of Logic

• Use logical operators
• and, or
• Evaluate truth of logical combinations
• P and Q

7
Rules of Logic

• Combining with or
• P or Q

8
Rules of Logic

• Negating a statement
• not P

9
Conditional Statements

• Implication P implies Q if P
  then Q

10
Conditional Statements

• Vivianis TheoremIF a point P is interior toan
  equilateral triangle THEN the sum of the lengths
  of the perpendiculars from P to the sides of the
  triangle is equal to the altitude.

11
Conditional Statements

• What would make the hypothesis false?
• With false hypothesis, it still might be possible
  for the lengths to equal the altitude

12
Conditional Statements

• Consider a false conditional statement
• IF two segments are diagonals of a trapezoidTHEN
  the diagonals bisect each other
• How can we rewrite this as a true statement

13
Conditional Statements

• Where is this on the truth table?
• We want the opposite
• IF two segments are diagonals of a trapezoidTHEN
  the diagonals do not bisect each other

TRUE statement
14
Conditional Statements

• Given P ? Q
• The converse statement is Q ? P
• Hypothesis and conclusion interchanged
• Consider truth tables
• Reversed

15
Conditional Statements

• Given P ? Q
• The contrapositive statement is ?Q ? ?P
• Note they have the same truth table result
• This can be useful in proofs

16
Conditional Statements

• Cevas theorem
• If lines CZ, BY, and XA are concurrentThen
• State the converse, the contrapositive

17
Conditional Statements

• Cevas theorem a biconditional statement
• Both statement and converse are true
• Note two separate proofs are required
• Lines CZ, BY, and XA are concurrent IFF

18
Mathematical Arguments

• Developing a robust proof
• Write a clear statement of your conjecture
• It must be a conditional statement
• Proof must demonstrate that your conclusions
  follow from specified conditions
• Draw diagrams to demonstrate role of your
  hypotheses

19
Mathematical Arguments

• Goal of a robust proof
• develop a valid argument
• use rules of logic correctly
• each step must follow logically from previous
• Once conjecture proven then it is a theorem

20
Mathematical Arguments

• Rules of logic give strategy for proofs
• Modus ponens P ? Q
• Syllogism P ? Q, Q ? R, R ? Sthen P ? S
• Modus tollens P ? Q and ? Qthen ? P -- this
  is an indirect proof

21
Universal Existential Quantifiers

• Open statement has a variable
• Two ways to close the statement
• substitution
• quantification
• Substitution
• specify a value for the variablex 5 9
• value specified for x makes statement either true
  or false

22
Universal Existential Quantifiers

• Quantification
• View the statement as a predicate or function
• Parameter of function is a value for the variable
• Function returns True or False

23
Universal Existential Quantifiers

• Quantified statement
• All squares are rectangles
• Quantifier All
• Universe squares
• Must show every element of universe has the
  property of being a square
• Some rectangles are not squares
• Quantifier there exists
• Universe rectangles

24
Universal Existential Quantifiers

• Venn diagrams useful in quantified statements
• Consider the definitionof a trapezoid
• A quadrilateral with a pair of parallel sides
• Could a parallelogram be a trapezoid according to
  this diagram?
• Write quantified statements based on this diagram

25
Negating a Quantified Statement

• Useful in proofs
• Prove the contrapositive
• Prove a statement false
• Negation patterns for quantified statements

26
Try It Out

• Negate these statements
• Every rectangle is a square
• Triangle XYZ is isosceles, or a pentagon is a
  five-sided plane figure
• For every shape A, there is a circle D such that
  D surrounds A
• Playfairs Postulate Given any line l, there is
  exactly one line m through P that is parallel to
  l (see page 41)

27
Congruence Criteria for Triangles

• SAS If two sides and the included angle of one
  triangle are congruent to two sides and the
  included angle of another triangle, then the two
  triangles are congruent.
• We will accept this axiom without proof

28
Angle-Side-Angle Congruence

• State the Angle-Side-Angle criterion for triangle
  congruence (dont look in the book)
• ASA If two angles and the included side of one
  triangle are congruent respectively to two angles
  and the included angle of another triangle, then
  the two triangles are congruent

29
Angle-Side-Angle Congruence

• Proof
• Use negation
• Justify the steps in the proof on next slide

30
ASA

• Assume AB? ?DE

31
Orthocenter

• Recall Activity 1
• Theorem 2.4 The altitudes of a triangleare
  concurrent

32
Centroid

• A median the line segment from the vertex to
  the midpoint of the opposite side
• Recall Activity 2

33
Centroid

• Theorem 2.5 The three medians of a triangle are
  concurrent
• Proof
• Given ABC, medians ADand BE intersect at G
• Now consider midpointof AB, point F

34
Centroid

• Draw lines EX and FY parallel to AD
• List the pairs ofsimilar triangles
• List congruent segments on side CB
• Why is G two-thirds of the way along median BE?

35
Centroid

• Now draw medianCF, intersectingBE at G
• Draw parallels asbefore
• Note similar triangles and the fact that G is
  two-thirds the way along BE
• Thus G G and all three medians concurrent

36
Incenter

• Consider the angle bisectors
• Recall Activity 3
• Theorem 2.6The angle bisectors of a triangle are
  concurrent

37
Incenter

• Proof
• Consider angle bisectors for angles A and B with
  intersection point I
• Constructperpendicularsto W, X, Y
• What congruenttriangles do you see?
• How are the perpendiculars related?

38
Incenter

• Now draw CI
• Why must it bisect angle C?
• Thus point I is concurrent to all three
  anglebisectors

39
Incenter

• Point of concurrency called incenter
• Length of all three perpendiculars is equal
• Circle center at I, radius equal to perpendicular
  is incircle

40
Circumcenter

• Recall Activity 4
• Theorem 2.7The three perpendicular bisectors of
  the sides of a triangle are concurrent.
• Point of concurrency called circumcenter
• Proof left as an exercise!

41
Euler Line

• What conclusion did you draw from Activity 9?

42
Euler Line

• Proof
• Find line through two of the points
• Show third point also on the line

43
Euler Line

• Given OG throughcircumcenter, Oand centroid, G
• Consider X onOG with G between O and X
• Recall G is 2/3 of dist from A to D
• What similar triangles now exist?
• Parallel lines?
• Now G is 2/3 dist from X to O

44
Euler Line

• X is on altitudefrom A
• Repeat argumentfor altitudes fromC and B
• So X the same point on those altitudes
• Distinct non parallel lines intersect at a unique
  point

45
Preview of Coming Attractions

• Circle Geometry
• How many points to determine a circle?
• Given two points how many circles can be drawn
  through those two points

46
Preview of Coming Attractions

• Given 3 noncolinear points how many distinct
  circles can be drawn through these points?
• How is the construction done?
• This circle is the circumcircle of triangle ABC

47
Preview of Coming Attractions

• What about four points?
• What does it take to guarantee a circle that
  contains all four points?

48
Nine-Point Circle (First Look)

• Recall the orthocenter, where altitudes meet
• Note feet of the altitudes
• Vertices for the pedaltriangle
• Circumcircle of pedal triangle
• Passes through feet of altitudes
• Passes through midpoints of sides of ABC
• Also some other interesting points try it

49
Nine-Point Circle (First Look)

• Identify the different lines and points
• Check lengths of diameters

50
Cevas Theorem

• A Cevian is a line segment fromthe vertex of a
  triangle to a pointon the opposite side
• Name examples of Cevians
• Cevas theorem for triangle ABC
• Given Cevians AX, BY, and CZ concurrent
• Then

51
Cevas Theorem

• Proof
• Name similartriangles
• Specify resultingratios
• Now manipulate algebraically to arrive at product
  equal to 1

52
Converse of Cevas Theorem

• State the converse of the theorem
• If
• Then the Cevians are concurrent
• Proving uses the contrapositive of the converse
• If the Cevians are not concurrent
• Then

53
Menelaus Theorem

• Recall Activity 10

54
Menelaus Theorem

• Consider that the ration AZ/ZB is negative
• are in opposite
  directions
• Theorem 2.8In triangle ABC with X online BC, Z
  on line AB, X, Y, Z collinear
• Then

55
Mathematical Arguments and Triangle Geometry

• Chapter 2
