EEL 4242 POWER ELECTRONICS

1
EEL 4242 POWER ELECTRONICS

• THYRISTORS

2
Thyristor Symbol
Figure 7.1
3
Cross Sections of Thyristors
Figure 7.2
4
Characteristics of Thyristors
Figure 7.3
5
Two Transistor Model of Thyristors
Figure 7.4
6
Current Gain with Emitter Current
Figure 7.5
7
Two Transistor Model
Figure 7.6
8
Gate Turn-On of Thyristors
Figure 7.7
9
Gate Turn-On Characteristics
Figure 7.8
10
Line Commutated Thyristor Circuit
Figure 7.9
11
Line Commutated Thyristor Circuit
Figure 7.9
12
GTOs
Figure 7.15
13
GTO Turn-on and Turn-off Pulses
Figure 7.16
14
di/dt Protection
Figure 7.32
15
dv/dt Equivalent
Figure 7.33
16
SPICE Model
Figure 7.34
17
Summary

• A thyristor is a latching device and it can be
  turned on with a small gate pulse, typically 100
  µs .

• Thyristors are generally off by line commutation
  due to the natural behavior of the input line
  supply.

• During the turn-off process, thyristors must be
  subjected to a reverse voltage for a certain
  minimum time known the turn-off.

• What was the major idea?

• What was the muddiest idea?
