Textbook reading

1
Textbook reading

• Thyroid imaging
• function studies
• Radioiodine therapy
• ??? ??? ???

2
Thyroid imaging and function studies

• Evaluation for clinical palpable nodules
• Thyroid scintigraphy and radiotracer uptake
  studies
• U.S. and F.N.A
• Laboratory data

3
Thyroid scintigraphy

• Determining the functional status of the thyroid
  nodules.
• Detection of the extra-thyroid metastasis form
  thyroid carcinoma.
• The thyroid tissue origins from mediastinal
  masses.
• Correcting the physical finding with
  abnormalities in the image.

4
Radiopharmaceuticals

• Iodine-131
• Iodine-123
• Technetium-99m

5
Radiopharmaceuticals

• Iodine
• a precursor of thyroid hormone .
• concentration (1001 than plasma)
• Organification.
• Bound to thyroglobulin.

• Pertechnetate ion (TcO4-)
• concentration

6
Physics and dosimetryiodine-131
7
Iodine-131

• not good choice for routine thyroid scintigraphy
• The presence of beta particle emissions
• The relative high energy of the principal gamma
  ray emissions for gamma camera.
• The long half-life

8
Physics and dosimetryiodine-123
9
Iodine-123

• Better for thyroid image
• Electron capture
• Gamma energy is ideally suited for gamma
  camera(159 keV)
• Half-life is suitable (13.2hr)

10
Iodine-123

• Disadvantage
• Prepared from I-124 and I-125
• Higher radiation precursors
• Short half-life
• Commercial limited
• Higher cost

11
Physics and dosimetryTechnetium-99m
12
Technetium-99m

• Better for thyroid scintigraphy
• Reliably available from molybdenum-99 /Tc99m
  generator system
• Ideal half-life (6hr)
• Suitable energy (only gamma ray 140KeV)

13
Pharmacokineticsradioiodine

• GI absorbs ion by Oral administration
• Into circulation
• Rapid uptake and Organification of iodine
• Detectable within minutes.
• Reached the follicular lumen within 20-30 minutes
• Normal range for uptake is 10-30 of the
  administered dose at 24 hr

14
Pharmacokineticsradioiodine

• I-123
• Detection after several hours delay

• I-131
• Detection after 1 day delay

15
PharmacokineticsTechnetium-99m

• Iv administration
• Rapid uptake by thyroid but not organification
• Optimal uptake for imaging is 20-30 min with the
  0.5-3.75 of the reagent

16
Technetium-99m radioiodine

• Concordant localization and identical
  scintigraphy
• Dis-concordant in a small percentage of thyroid
  nodules for the loss of the organification

17
Precautions

• Breast feeding
• Pregnancy
• Interference of stable iodine contained in foods
  and medications

18
Breast feeding

• I-123
• Resumed after several days if the amount used if
  no more than 30 uCi used
• Usual imaging dosage is 100-400 uCi
• I-131
• Should be terminated for several weeks
• Tc99m pertechnetate
• Resumed in 24 hr

19
radioiodine precaution for pregnancy

• Radioiodine can cross placenta
• Fetal thyroid can concentrate iodine after 10th
  -12th gestation weeks.
• Resulting in hypothyroidism and cretinism.

20
Interference for radioiodine uptake

• Several non-iodine drug can affect that.
• 1 mg of stable iodine can cause significant
  reduction of the 24 hr radioiodine uptake
• 10 mg can effectively block the gland, with 98
  reduction uptake.

21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
Normal thyroid scintigraphy

• In the euthyroid adult the thyroid gland weights
  15-20 g.
• Butterfly shape with lateral lobe extending along
  each side of the thyroid cartilage of the larynx
• The lateral lobes are connected by an isthmus
  that crosses the trachea anteriorly below the
  level of the cricoid cartilage.

28

• The right lobe is often larger than the left.
• The lateral lobes typically measure 4-5 cm from
  superior to inferior poles and 1.5-2 cm wide.
• The pyramidal lobe is a paramedian structure that
  arises from the isthmus, either to the right or
  left lobe of the middle, and represents
  functioning thyroid tissue in the thyroglossal
  duct tract.

29
Normal thyroid scintigraphy

• Homogeneous
• Uniform distribution
• Variation
• Middle or medial of the lateral lobes owing to
  the thickness
• Activity of the Isthmus varies greatly among
  patients, with little or no activity and
  prominent activity

30
(No Transcript)
31
TC-99m pertechnetate

• Thyroid tissue
• Salivary gland
• Esophagus activity seen to the left of middle and
  can confirm by having patient swallow, hollowed
  by a repeat image.

32
Clinical applications

• indication for thyroid scintigraphy
• Further evaluation of findings on physical
  examination
• Detection of metastases with thyroid carcinoma
• Follow-up of radioiodine therapy for
  differentiated thyroid cancer
• Determination of functional status of thyroid
  nodules
• Differential diagnosis of mediastinal masses
• Detection of extra thyroidal tissue (lingual
  thyroid)
• Screening after dead and neck irradiation.

33
(No Transcript)
34
Clinical applicationsGoiter

• Refers to an enlargement of the thyroid gland
• Endemic goiters
• Iodine deficiency-induced hyperplasia
• Colloid nodular goiters
• Nontoxic goiters
• Graves disease
• Toxic goiter
• Thyroid carcinoma
• Other neoplasm-lymphoma
• Active phase of thyroiditis

35
(No Transcript)
36
Scintigraphy of Goitermultinodular colloid
goiters

• Inhomogeneous uptake of tracer
• Cold areas of various sites
• Carcinoma changes rate is low (1-5)
• Highly suspicion out of proportion in size to
  other cold areas or enlarging suddenly.

37
Scintigraphy of GoiterGraves disease

• Uniform with intensely increased uptake
• The pyramidal lobe is frequently seen
• Not generally considered an indication for
  obtaining a thyroid scinitigram (?)

38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
Clinical applicationsthyroid nodules

• Extremely common
• The incidence increases with age
• More common in women
• Likehood of malignancy
• Multiple nodule (multiple nodular goiters, less
  than 5)
• Solitary cold nodule (5-40)

43
Scintigraphy for thyroid nodules

• Cold nodules-nonfunctioning
• The majority of the thyroid nodules
• As small as 3 cm can be detected by pinhole
  collimator
• Hot nodules-functioning
• Function equal to the surrounding normal thyroid
• Indeterminate
• Need to close to correct between physical
  examination and scintigraphy findings.
• Oblique view with a pinhole collimator
• The management is the same as the cold nodules.

44
(No Transcript)
45
Cold nodules

• Risk factors of malignancy
• prior history of radiation to the head and neck
  or mediastinum
• gt1000-1500 rads
• Solitary cold nodules in young female
• Multiple nodular goiters in elderly

46
(No Transcript)
47
Hot nodules

• Hyper functioning
• Autonomous
• Out of negative feedback control

48
Hot nodules

• Autonomous nodules
• Thyroid gland produces much hormone
• Greater than 3-4 cm
• suppress pituitary TSH
• Extra-nodular thyroid tissue is not visualable
• Small nodules
• Extra-nodular thyroid tissue is visualable
• Spontaneous involution
• Cystic degeneration

49
Hot nodules

• Hot nodules with hyperthyroidism
• Large(3-4 cm), multiple nodules
• Autonomous hot nodule with Thyrotoxicosis
• Plummers disease

50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
Discordant nodules

• Possibility of discordant between radioiodine and
  Tc-99m pertechnetate
• Radioiodine-cold
• Tc-99m pertechnetate-hot
• 2-3 in Tc-99m pertechnetate hot nodules

55
Substernal thyroid

• D.D mediastinal masses
• Goitrous enlargement with downward extension
• Abnormal migration during develop

56
Substernal thyroid

• I-131 is better than Tc99m
• Delayed performed (48-72 hr)
• Function and tracer uptake in sternal thyroid is
  poor
• Blood clearance of the background activity
• Cervical thyroid should also be noted

57
(No Transcript)
58
(No Transcript)
59
Clinical applicationsother ectopic thyroid tissue

• The thyroglossal duct runs from the foramen cecum
  at the base of the tongue to the thyroid
• Lingual thyroid complete failure to migrate
• Absence of tracer uptake in the expected cervical
  area
• Thyroid tissue may be found along the tract of
  the thyroglossal duct.

60
Clinical applicationsthyroiditis

• Acute thyroiditis
• Suppurative bacterial infection
• Focal abscess
• subacute thyroiditis
• Granulomatous thyroiditis
• De Quervains disease
• Non-suppurative
• Etiology unproved-virus infection (URI, neck
  tenderness)
• Initial phase would be a Thyrotoxicosis
• Chronic thyroiditis
• Hashimotos thyroiditis
• Lymphocytic infiltration
• More common in women with goiter or
  hypothyroidism
• Rarely with hyperthyroidism-hashitoxicosis

61
Scintigraphy for acute subacute thyroiditis

• Acute thyroiditis
• Cold nodule for the focal abscess
• Subacute thyroiditis
• Decrease or absent uptake of radioiodine in the
  affected part of the gland
• Gallium-67 imaging inflammatory process

62
Scintigraphy for chronic thyroiditis

• Highly variable and depend on the stage in the
  natural history
• Normal in the early stage
• Later, diffuse enlargement
• Eventually, hypothyroidism, inhomogeneous with
  hot and cold areas

63
Clinical applicationsthyroid cancer metastasis

• Follicular carcinoma
• Mixed papillary-follicular carcinoma
• Papillary carcinoma
• Medullary carcinoma
• Ana plastic carcinoma

64
Thyroid cancer metastasis

• The most common sites of metastasis are locally
  in the lymph nodes of the neck, lung ,and bone.
• nodal activity is focal ,intense, starburst
  pattern on parallel-hole collimators

65
Thyroid cancer metastasis

• Imaging is performed 48-72 hr after radioiodine
  administration.
• More lesion are demonstrated in this time than at
  24 hr.

66
I-131 follow-up imaging

• The preparations and dosage are controversial.
• Thyroid hormone replacement is withdraw for 4-6
  weeks to stimulate TSH secretion.
• Use bovine TSH before imaging.
• Not satisfactory for increasing I-131 uptake
• allergy

67
Scanning dosages for follow-up imaging

• Controversial
• More metastasis deposits are seen with higher
  doses
• 5-10 mCi of I-131 for detecting metastasis
• As little as 5 mCi with less satisfactory uptake
  of sequent therapeutic dose
• Diagnostic dose should be limited 1-2 mCi

68
(No Transcript)
69
(No Transcript)
70
Tumor imaging

• Thalium-201 chloride
• Tc-99m sestamibi
• For location metastasis in patients with
  increased thyroglobulin and negative radioiodine
  whole body scintigraphy

71
Iodine -131 MIBG for Medullary carcinoma

• meta-iodo-benzyl-guanidine
• Neurosecretory storage vesicles of chromaffin
  cells
• Sensitivity is low (30)
• Soft tissue metastasis is more visualized than
  bone metastasis.

72
Medullary carcinoma of thyroid

• Indium -111 somatostatin receptor scintigraphy
  for Medullary carcinoma
• Iodine -131 MIBG
• FDG-PET

73
Thyroid function studies

• Thyroid percent uptake
• Suppression test
• Stimulation test
• Per chlorate discharge test

74
(No Transcript)
75
Thyroid percent uptake

• The earliest applications radiotracer in
  medicine.
• The degree of radioiodine uptake parallels the
  functional activities of the thyroid hormone
  produced
• Normal uptake range 10-30
• Sensitivity and specific test of serum T3 T4

76
Thyroid percent uptake

• DD hyperthyroidism
• Increase uptake
• Graves disease
• Plummers disease
• Decrease uptake
• Subacute thyroiditis
• Thyrotoxicosis factitia

77
Suppression test

• Not used in current routine practice.
• Autonomous functioning glands
• TSH level is a sensitivity test now

78
Suppression test

• Receiving 25 mg T3 qid for 8 day
• 24hr uptake is repeated beginning at 7th day.
• It is fall in the percentage of uptake to less
  50 of the baseline and less the 10 overall.

79
Stimulation test

• Infrequent use now.
• D.D primary and secondary (pituitary)
  hypothyroidism
• Primary-failure to response to exogenous TSH
• Secondary-increasing radioactivity after TSH
  administration

80
Stimulation test

• Receiving 10 units of TSH iv
• The radiotracer repeats beginning the next day.
• Primary-no response
• Secondary-radiotracer doubling

81
Per chlorate discharge test

• to detect defects in
• Intra-thyroidal iodide organification

82
Per chlorate discharge test

• Dissociation of the trapping and organification
  function
• Congenital enzyme deficiency associated with
  deafness (Pendred's syndrome),
• Some chronic thyroiditis
• During the treatment of PTU

83
Per chlorate discharge test

• I is "trapped" by the thyroid gland through an
  energy-requiring active transport mechanism
• Once in the gland, it is rapidly bound to
  thyroglobulin

84
Per chlorate discharge test

• inhibit active iodide transport
• cause the release of the intrathyroidal iodide
  not bound to thyroid protein

• thiocyanate (SCN-)
• perchlorate (ClO4-)

85
Per chlorate discharge test

• administration of radioiodine orally
• counts are obtained at frequent intervals (every
  10 or 15 minutes).
• Two hours later, 1g of KClO4 orally
• repeated epithyroid counts continue to be
  obtained for an additional 2 hours

86
In normal individuals

• little loss of the thyroidal radioactivity
  accumulated prior to induction of the "trapping"
  block
• radioiodine accumulation in the thyroid gland
  ceases after the administration of the iodide
  transport inhibitor

87
Per chlorate discharge test

• Less than 10 discharge of radioiodine
• Normal
• Hyperthyroidism on inadequate antithyroid drug
  therapy
• Greater than 10 washout
• Organification defect

88
Radioiodine treatment

• Hyperthyroidism
• Thyroid cancer

89
Hyperthyroidismindications for iodine-131 therapy

• Graves disease (diffuse toxic goiter)
• Plummers disease (toxic nodular goiter)
• Functioning thyroid cancer (metastasis)

90
Hyperthyroidism Contraindication for iodine-131
therapy

• Thyrotoxicosis factitia
• Subacute thyroiditis
• Silent thyroiditis (atypical ,subacute,
  lymphocytic, transient, postpartum)
• Struma ovarii
• Thyroid hormone resistance
• Secondary hyperthyroidism
• Thyrotoxicosis associated with Hashimotos
  disease (hashitoxicosis)
• Jod-Basedow phenomenon (iodine-induced
  hyperthyroidism)

91
Radioiodine treatment

• Goal
• Euthyroid in a reasonable length of time with a
  single radioiodine dose
• Gravesdiseas-80-120 uCi/g
• Standard dose5-10mCi
• Higher for Graves opthalmopathy
• More than 90 patients are cured with a single
  dose
• Hypothyroidism-hormone replacement

92
Radioiodine treatment

• Plummers disease
• Hyperthyroidism caused by toxic nodules
• More radio-resistant
• Inhomogenity, rapidly radioiodine turnover ,low
  retain dose
• Increase dose to 15-29 mCi

93
Radioiodine treatment

• Metastases from differentiated thyroid cancer
• Controversial with small , early stage lesions
• Residual, recurrence differentiated thyroid
  cancer - improved survival rate with I-131

94
Radioiodine treatment

• Metastasis more common at neck, lung and bone
• Bone metastasis is more difficult eradicated than
  lung metastasis
• Initial dose 150-200mCi
• Repeated doses up to 1Ci

95
Radioiodine treatment

• Follow-up imaging is performed yearly until the
  metastatic lesions are elimination
• Serum thyroglobulin tumor marker
• If the level is increase in a post-op patient. it
  may be a recurrence
• Then performed imaging to localize the lesion

96
(No Transcript)
97
Radioiodine treatment

• Not statistically significances of leading the
  secondary cancer by radioiodine Tx
• Not reduce fertility
• Congenital defects are not increased in the child
  of treated patients

98
attention
Thanks for your attention
