National Institute of Information and Communications Technology

1
New Research Development Testbed Network JGN
II (draft)

• 2004.7.3
• National Institute of Information and
  Communications Technology

2
National Institute of Information and
Communications Technology
Communications Research Laboratory
Telecommunications Advancement
Organization of Japan
1952 Radio Research Laboratory
National Research Laboratory
1979 Communications and Broadcast Satellite
Organization
Authorized Corporation
1988 Communications Research Laboratory
1992 Telecommunications Advancement Organization
of Japan
2001 Communications Research Laboratory
Incorporated Administrative Agency
Collaborative RD, Funding and Promotion
Core RD, Regular services
1 April, 2004
3
Outline of NICT

• Main Mission
• ? Core RD
• Information and Network Systems Department
• Wireless Communications Department
• Applied Research and Standards Department
• Basic and Advanced Research Department
• ? Collaborative RD
• Research and Development Management Department
• Collaborative Research Management Department
• ? Funding and Promotion
• Key Technology Research Promotion Department
• Information and Communications Promotion
  Department
• Employment Information
• Establishment Date April 1, 2004
• Budget 60 billion yen in 2004 fiscal year
• Permanent Staffs 480

4
Background of starting up JGN
?e-Japan IT strategy II --- ?Research Result of
JGN ?1999.42004.3 ?233 projects, and 669
total research institutes ?Research by MPHPT of
Japan ?2003.27 Research on Next Generation
Research and Development Network for Ubiquitous
Networking Era Basic Functions, Research
Subjects, Strategies etc.
5
Products of JGN
JGN Japan Gigabit Network
Contribution for IT society Accelerating to
realize IT society by Broad Band Network
Technologies and IPv6 Technologies
Academic Contribution Paper contributions /
Report
Industry Practical Use / Industrialization /
Standardization
PR effects News Papers
Research Results IPv6 technologies Broad
Band Network Technologies
Human Resource Development Academic
Degrees Qualifications, Licenses
Local Community Development
Products of JGN
Equipment of Research Infrastructure
Research Activation
Direct Investment National direct expenses /
Induced Research Investment
Direct Effects
Second Effects
Economic Ripple Effects
Third Effects
Market Production Effects
6
Outline of New Research and Development Testbed
Network JGN II

1. Purpose Pushing forward the following
policies in alliance with Industry, Academy,
Government, Local Community etc. - Promotion
of wide variety of ICT RDs from basic and
fundamental RDs to proof experiments -
Activation of not only domestic and but also
international local communities - Human
resource development through practical research
activities - Survey and practice of an aspect of
future ICT society
2. Feature - Open testbed network for research
and development - IP based network (L2 and L3)
- Maximum transmission speed of main
links20Gbps - 63 domestic access points and
a Japan-US international link with
APAN-Tokyo-IX and Los Angels Abiline-NOC and
Chicago StarLIGHT (Starting from August 1,
2004) - Optical testbed environment with
advanced optical switches for a variety of
high speed network experiments
3. How to use - Refer http//www.jgn.nict.go.jp
- Submit JGN II Research Project Proposal to
jgn2center_at_nict.go.jp - Also ask to
sec_at_allocation.apan.net for international
experiments
4.Operation time period April 2004 to March
2008
7
Services provided by JGN II at all access points
? Ethernet connection services (Layer 2 services)
for domestic network (1) Access point
connection service Connection with 2 access
points by VLAN (2) Multi-access points
connection service (Available after Oct. 2004)
Connection with multi-access points by same
VLAN ? IP connection services (Layer 3
services) for all networks including
international networks IPv4/v6 dual stack
services among JGN II users, or JGN II users and
users through other research networks such as
APAN
- Connection port in domestic access points-
10/100/1000Base-TX(RJ45) Optical connections
such as 1000BASE-SX/LX will be required to
negotiate in each project.
8
Services provided by JGN II at specific access
points
? OXC Connection Service (Tokyo Otemachi
NTT-C and KDDI, Osaka Dojima, Keihanna, Fukuoka,
Kanazawa) - Connection services by Optical wave
between OXC sites - Interfaces 1Gbps and
10Gbps ? 10G Connection Service (16
access points including Tokyo Otemachi KDDI,
Osaka Dojima, Fukuoka, Tsukuba,
Kanazawa, Keihanna, Okayama and Kita-kyushu) -
10Gbps connection services among sites by
10Gbps-Ether - Connection to other access points
which do not support this service is also
available with some condition such as limited
bandwidth ? Optical Network Testbed Services
(Tokyo Otemachi NTT-C Tsukuba RC, Tokyo
Otemachi NTT-C and KDDI NICT Koganei HQ,
NICT Keihanna Osaka Dojima) - Optical
transmission experiment services among specific
access points
9
Structure of JGN II Core Network
NW-A Research on NW Operation Management
Technology
Kanazawa
NTT-C Otemchi
Fukuoka
Sapporo
Dojima
10G (1G8)
GMPLS Inter-Connection
Kita-kyushu
Kanazawa
NICT Kashima
Dojima
Fukuoka
Okayama
Tsukuba
10Gbps2
1G
NICT Keihanna
KDDI Otemachi
NW-B Testbed for Realization of Terabit class
Network
Sendai
Kita-Kyusyu
Kanazawa
1G
Fukuoka
10G
Nagano
NICT Kashima
10G (1G8)
NICT Kobe
1G
10G (1G8)
10G
10G (1G8)
10G
1G
10G
10G
10G
NICT Koganei HQ
Dojima
NICT Tsukuba
Okayama
Otemachi
Optical
1G
Optical
10G
10G2
1G
Dojima
Kochi
Nagoya
NICT Tsukuba
1G
KDDI Otemachi APAN Tokyo - IX
NICT Keihanna
NICT Keihanna
Okinawa
10Gbps2 Los Angeles and Chicago
Optical NW testbed
10
JGN II Japan-US Link (10Gbps2)
KDDI Otemechi APAN Tokyo - IX
StarLight( Chicago )
Japan-US Cable
Abilene ( Los Angels )
11
Outline of JGN II network
Explanatory notes
20Gbps 10Gbps 1Gbps Optical testbed
lt10Ggt Ishikawa High Tech Exchange Center
(Ishikawa Tatsunokuti
Town) lt100Mgt Toyama Pref. Sogo-jyoho Center
(Toyama City) Fukui Pref. Info-SuperHighway AP

(Fukui City)
lt100Mgt Hokkaido Regional Network AP
(Sapporo City)
Access points in local sites
Core network sites
lt10Ggt Kyoto Univ. (Kyoto
City) Osaka Univ. (Osaka Ibaraki
City) lt1Ggt NICT Kansai Advanced RC (Kobe
City) lt100Mgt Lake Biwa Info-Highway AP (Otsu
City) Nara Technical RC (Nara
City) Wakayama Univ. (Wakayama
City) Hyogo Pref. Nishi-Harima Branch
(Kamigori Town)
lt1Ggt Tohoku Univ. (Sendai City) NICT
Iwate IT Open Lab. (Iwate Pref. Takisawa
Village) lt100Mgt Hachinohe Institute of
technology (Hatinohe
City) Akita Reginal IX (Akita City)
Keio Univ. Tsuruoka Campus (Ymagata
Tsuruoka City) Aizu Univ. (Aizuwakamatsu
City)
Sapporo
lt1Ggt Teleport Okayama (Okayama City)
Hiroshima Univ.(Higashi Hiroshima City) lt100Mgt
Tottori Env. Univ. (Tottori City)
Techno-Arc Shimane (Matsue City) New Media
Plaza Yamaguchi
(Yamaguchi City)
lt100Mgt Niigata Univ. (Niigata City) Matsumoto
Jyohosozokan (Matsumoto City)
lt10Ggt Kyushu Univ. (Fukuoka City) lt100Mgt
NetCom Saga (Saga City) Nagasaki City
(Nagasaki City) Kumamoto Pref. HQ
(Kumamoto City) Toyonokuni HyperNetwork
AP (Oita City)
Miyazaki Univ. (Miyazaki City) Kagoshima
Univ. (Kagoshima City)
Sendai
lt10Ggt Tokyo Univ. (Tokyo Bunkyo
Ward) NICT Kashima Space Com. RC
(Ibaraki Pref. Kashima City) lt1Ggt
Yokosuka Telecom. Research Park
(Yokosuka City) lt100Mgt Utsunomiya
Univ. (Utsunomiya City) Gunma
Sangyo-Gijyutsu Center
(Maebashi City) Reitaku Univ.
(Chiba Pref. Kashiwa City) NICT Honjyo ICT Open
Lab. (Honjyo City) Yamanishi pref. Open RD
Center (Yamanashi pref. Tamaho
Towan)
Kanazawa
NICT Kita-kyushu IT Open Lab.
Nagano
NICT Koganei-HQ
Osaka
Fukuoka
Okayama
NICT Tsukuba RC
Nagoya
IXInternet eXchange APAccess Point
NICT Keihanna Info-Com. RC
Tokyo Otemachi -KDDI building for US and APAN
Kochi
Okinawa
lt100Mgt Kazawa Pref. Shinki-sangyo-soshitsu-shien
Center (Takamatsu City) Tokushima Univ.
(Tokushima City) Ehime Univ. (Matsuyama
City) Kochi Institute of Technology
(Kochi Pref. Tosayamada Town)
lt100Mgt Nagoya Univ. (Nagoya City)
Shizuoka Prefecture Univ.
(Shizuoka City) Softpia Japan
(Ogaki City) Mie prefecture Nursing Univ.
(Tsu City)
Los Angels and Chicago
12
AUP of JGNII
1 User organization must exchange a joint
research agreement with NICT at first time before
using JGN II. 2 When user proposes new projects
after the first experiment project, user will
only be required new project proposal. Exchange a
joint research agreement with NICT will no longer
required. New project partners must exchange a
joint research agreement with NICT each. 3
Following actions are prohibited ?Experiments
without a joint research agreement with NICT
?Experiments with no relation to users research
?Profitable network use ? Use by outsider
without a joint research agreement with NICT
?Interference with network operation and
management ?Violation against public order and
standards of decency ?Improper actions which
NICT(a manager of JGN II) recognizes 4 A TransPAC
user using a Chicago link will be automatically a
JGN II user, and be required to exchange a joint
research agreement with NICT after Aug. 1, 2004.
(Draft Idea) ? NICT does not guarantee quality of
JGN II. ? NICT may collect information necessary
for network operation and management.
13
JGN II RD Sites of NICT
JGN II Research Centers (7 sites in Japan)
NICT Koganei, Keihanna (Information and
Network System Department)
?Kyoto? NICT Keihanna Advanced and Fundamental
Technologies
?Tokyo? NICT Koganei Advanced and Fundamental
Technologies
?Miyagi Sendai? Tohoku JGN II RC Application
Oriented Operation Platform Techniques
?Okayama? Okayama JGN II RC Interconnectivity
test for Next Generation Internet
?Ibaraki Tsukuba? Tsukuba JGN II RC Adaptive
Service Control using High HCI
techniques Operation and Management Techniques
for GMPLS network
?Fukuoka Kita-Kyusyu? Kita-Kyusyu JGN II
RC Adaptive Routing Control Technique based on
network measurement Seamless Resource Allocation
Control Techniques under consideration of
QoS E2E Communication Control Techniques
suitable for Diversity and Variability
?Tokyo? Otemachi JGN II RC Development of
Supporting Tools for Network Construction Connec
tivity Provision Techniques for Wide-Area
High-Reliable Network Test and Evaluation
Techniques, and those Tools for IPv6 Equipments
?Osaka? Osaka JGN II RC Secure Resource Sharing
Techniques for Closer Cooperation with
RCs Large-scale Data Processing Coordination
Techniques for Wide-Area Network
?Kochi? Kochi JGN II RC Surrounding Computing
Techniques
14
Conclusion
?2004.4.1 CRL and TAO merged to NICT ?2004.4
Under operation of RD Testbed NetworkJGN
II ?7 Research Centers for RD ?2004.8.1
Japan-US 10Gbps Link (Former Japan Route of
TransPAC)
15
Contacts
Domestic jgn2center_at_nict.go.jp International
sec_at_allocation.apan.net
