Allot Network Intelligence

1
Allot Network Intelligence

A mind for networks

• Tomás Gómez de Acuña
• tgomez_at_allot.com

2
Company Overview

• Global company
• Founded 1997
• Sales support offices throughout the world
• USA (MN-HQ, CA, NY, TX, AZ)
• Europe (France-HQ, UK, Germany, Italy, Spain,
  Scandinavia)
• Asia Pacific (SingaporeHQ, Japan, Australia)
• Latin America (Brazil)
• Worldwide 24/7 support
• 230 employees (85 engineers)
• A traffic management pioneer
• Shipping since 1999 with rapid growth
• Over 1,500 customers and 10,000 systems in
  operation
• Markets and selected customers
• Service Providers
• Verizon, NTL, FastWeb, Megacable, Telia, Equant,
  Sprint, Waku-Waku, Telecom Malaysia, Prima,
  Northland, Wilhelm.tel, Optus, France Telecom,
  Eutelsat, Cabovisao
• Enterprise
• Dixons, INS, Samsung, Symantec, Schneider
  Electric, Hitachi, Areva, EDF, Teva, BBVA,
  Kroger, Ecco, Universities, BES

3
Enterprise network challenge
RED LAN / CORE
4
Internet Access

• Do we really know the traffic that goes through
  Internet?
• Is it possible to block and control unwanted
  traffic?
• Do we know which kind of information access the
  users to internet?
• Do we have the capability to control not working
  applications like P2P, music, streaming, Chat,
  etc
• Number of connections we opened outside the
  network
• Number of connection per user and/or application
• Detailed reports of all this information?
• Really we know how, when, and which way we spend
  bandwidth in Internet?

5
Access to the data center

• How many users can access to the data center?
• Do we have a way to control number of
  connections in the data center?
• It is possible to priories VIP users?
• It is possible to avoid DoS attacks and worm
  attacks?
• Do we know bandwidth, connections, etc
  consumption per user?.
• Number of connections per applications, user?
• Do we assure security and availability of the
  data center?

6
WAN Network

• which applications use the wan links?
• Are all the applications business oriented?
• Why WAN is so slow?
• Do we know how may connections we have opened in
  the WAN?
• Can we assure mission critical applications over
  the WAN?.
• Are we ready to implement new services in my
  company like Citrix, VoIP, Videoconferencing,
  etc?
• Do we control what our users are doing over the
  WAN?

7
Conclusion

• We have networks of thousands of euros
• We invest a lot of money to increase bandwidth
  and to upgrade links
• We spend a lot of money supporting all this
  investment
• But.
• Do we really are able to have a detailed
  knowledge about our network that allow us to
  invest the money in a better way?

8
The solution Allot Network Intelligence
RED LAN / CORE
9
Service Provider Solution
Core

• Control del tráfico hacia y desde el Data Center
• Prioriza el tráfico de los clientes críticos
• Evita ataques de DoS y DDoS al Data Center
• Evita que se caigan los servidores
• Evita que se propaguen gusanos (WORMS)
• Proyecto de varios equipos
• Referencia Comunitel (100 K Euros)

• Control del tráfico P2P
• Ahorro de ancho de banda (ahorro de coste en el
  operador)
• Quality of Experince (los usuarios perciben que
  la red va mejor)
• Equidad entre los usuarios y las conexiones por
  usuario
• Evita que pocos usuarios no deseados consuman
  todo el ancho de banda
• Proyectos de entre 1 y 10 equipos
• Referencia FastWeb (2 Millones de Euros)

• Definición de servicios de pago para el operador
  (el operador genera más dinero)
• Video Club online
• Turbo button
• Triple play
• Etc
• Uno o varios equipos de Allot por POP
• Proyecto de decenas o cientos de equipos
• Referencia NTL (8 Millones de Euros)

10
Allot Solutions Save Money

• Reduce peering internet expenses
  OPEX
• Prevent malicious traffic,
• reducing customer support calls
  OPEX
• Increase over-subscription avoiding
• more network devices investment
  CAPEX
• Identify network issues to avoid
• downtime
  OPEX
• Add new equipment and upgrades
• only when necessary CAPEX

11
Allot features

• Network visibility Network Intelligence
• Network troubleshouting
• Application firewall
• Connection/DoS control
• QoS Control
• P2P control
• Application control
• Subscriber control
• Service Creation
• Accounting/billing

12
Allot features

• Layer 7 classification and monitoring
• Signature base
• DPI (Deep Packet Inspection)
• Application control and blocking
• HTTP, chat, FTP, SMTP filtering
• Connection control
• Connection control per user/application/service
• DoS and worm contention
• Data Center protection
• Bandwidth limitation per connection/flow
• P2P and other applications control
• QoS policing
• Priority
• Guaranty
• Limitation
• IP service, Accounting and Billing

13
Allot product

• NetEnforcer
• NetXplorer
• Subscriber Management Platform

14
Allot Netenforcer product range
2,5G
1G
AC-1010, AC-1020, AC-1040
AC-802 AC-804 AC-808
310M
100M
AC-402 AC-404
2M
15
NetEnforcer - Enterprise / Medium SP Platform
Model Bandwidth Pipes VCs Managed Links
AC40X Monitoring Only 100 Mbps 1 024 4,096 1 - 2
AC40X/2M 2 Mbps 1 024 4,096 1 - 2
AC40X/10M 10 Mbps 1 024 4,096 1 - 2
AC40X/45M 45 Mbps 1 024 4,096 1 - 2
AC40X/100M 100 Mbps 1 024 4,096 1 - 2
AC80X Monitoring Only 310 Mbps 4,096 28,672 1 - 2 - 4
AC80X-CF 45 Mbps 4,096 28,672 1 - 2 - 4
AC80X-CF 100 Mbps 4,096 28,672 1 - 2 - 4
AC80X-CF 155 Mbps 4,096 28,672 1 - 2 - 4
AC80X-CF 310 Mbps 4,096 28,672 1 - 2 - 4
16
NetEnforcer - SP Carrier Platform
Model BandwidthFull Duplex BandwidthFull Duplex Pipes VCs Managed Links
AC-10X0-Monitoring Only AC-10X0-Monitoring Only 1000 Mbps 10,000 80,000 1-2
AC-10X0-155M AC-10X0-155M 155 Mbps 10,000 80,000 1-2
AC-10X0-310M AC-10X0-310M 310 Mbps 10,000 80,000 1-2
AC-10X0-620M AC-10X0-620M 620 Mbps 10,000 80,000 1-2
AC-10X0-1000M AC-10X0-1000M 1000 Mbps 10,000 80,000 1-2
AC-25X0- Monitoring Only AC-25X0- Monitoring Only 2500 Mbps 40,000 80,000 1-2-4
AC-25X0-310M AC-25X0-310M 310 Mbps 40,000 80,000 1-2-4
AC-25X0-620M AC-25X0-620M 620 Mbps 40,000 80,000 1-2-4
AC-25X0-1000M AC-25X0-1000M 1000 Mbps 40,000 80,000 1-2-4
AC-25X0-2500M AC-25X0-2500M 2500 Mbps 40,000 80,000 1-2-4
17
Allot multilinks topologies (1)
Redundant configurations
Managing two different links
One link
NE 404/804/1020/2520
NE 402/802/1010
NE 404/804/1020/2520
18
Allot multilinks topologies (2)
Managing four links
Redundant configuration fully mesh
NE 808/2540
NE 808/2540
19
High-Availability Topologies
20
NetXplorer Architecture
GUI Client
GUI Client
NetXplorer Server
Mediation / Billing
NetXplorer DataCollector
NetXplorer DataCollector
21
Subscriber Management Architecture
22
