Brownian Dynamics

1
MD-PNP simulations of Alpha-Hemolysin open
channel ion currents
Ioana Cozmuta, J. T. OKeeffe, D. Bose and
V. Stolc NASA Ames Research Center, Eloret
Corp.
2
The alpha hemolysin ion channel
3
Natural function

• Alpha hemolysin is a toxin produced by
  Staphylococcus aureus bacteria
• It spontaneously self-assembles into a water
  soluble ionic channel with a molecular weight of
  33.2 k-Dalton and a length of 10nm
• The channel contains 2051 AA residues organized
  in 7 sequence-identical chains (symmetry group
  C121)
• The channel is strongly surface active and it
  inserts into pre-formed lipid membranes, damaging
  the membrane properties
• Extra cellular Ca2 or other divalent cations
  prevent cell damage by closing the channel

Menestrina, G, The Journal of Membrane Biology,
90, 177-190, 1986
4
Conductance

• measured in voltage-clamp experiments
• Asymmetric I-V characteristic over linear
  increase in the first quadrant and sub linear in
  the third.
• Linear relationship between the channel
  conductance and the conductivity (molarity) of
  the electrolyte solution at a constant clamp
  voltage.
• The channel is slightly anion- selective at pH 7.0

Biophysical Journal, 79, 4, 1967-1975, 2001
5
A bio-engineering application

• Alpha hemolysin channel in 1.0 M KCl solution
  with an external applied voltage of 125 mV leads
  to an ionic current of 120 pA (channel
  conductance 1nS)
• ss-DNA or RNA molecules driven by an electric
  field through the ion channel generate a
  transient decrease of ionic current

6
An atomistic view of the channel
7
Atomistic model

• pdb file from the protein data bank
  http//www.rcsb.org/pdb/
• Structure resolved via X-ray diffraction 1.6 Å
  at 287K and a pH of 6
• Ramachandran plot backbone phi, F psi, Y
  angles (-180 to 180 deg)
• Topology file generated in Amber using the parm94
  force field

Song, L., Hobaugh, M. R., Shustak, C., Cheley,
S., Bayley, H., Gouaux, J. E., Structure of
staphylococcal alpha-hemolysin, a heptameric
transmembrane pore, Science 274 pp. 1859
(1996) Force field Cornell et al, 1995 AMBER,
http//www.scripps.edu/
8
Geometry
C1 GLU(111) z-11Å, R7.4 Å acid turn
LYS(147) z-11Å, R6.1 Å basic
MET(113) z-19Å, R6.4 Å hydrophobic turn
THR(145) z-19Å, R8.2 Å hydrophilic C2 LEU(135)
z-47Å, R6.3 Å hydrophobic
C2
C1
9
Amino Acids sequence
10
Charged residues on the inner pore
11
(No Transcript)
12
The MD-PNP model
13
Multi-scale modeling
Goddard group, http//wag.caltech.edu/
14
MD-PNP hybrid model
15
MD simulations
16
Benchmarking for NAMD
http//www.ks.uiuc.edu/Research/namd/
Solvated protein 175,364 atoms, cutoff 20Å,
UC130Å, Dt2fs 3.52days/ns 128 CPU
Benchmark system 92,000 atoms, cutoff 12Å,
UC109Å, Dt 1fs 1.61days/ns 128 CPU
Actual system 120,000 atoms, cutoff 20Å, Dt2fs
(MTS) 1.29 days/ns for 200 CPU
17
SPC/E water model

• SPC/E model q(O)-0.8476e, q(H)0.4238e

18
Ionic solution, 1MKCl

• crystal structure arrangement of atoms (NaCl)
• selected number to correspond to 1M solution
  (1KCl pair for 55 water molecules)
• box with 400 KCl pairs

• K Van der Waals parameters (Aquist)
• R 2.658Å e 0.000328
• DG -80.9kcal/mol

• Cl- Van der Waals parameters (SmithDang)
• R 2.47Å e0.01
• D(mutual) 2.910-9m2/s
• D(? dilution) 1.810-9m2/s

19
MD procedure

• minimization for 5000 steps
• heating to 300K in steps of 50K
• NPT equilibration of solution for 400ps (time
  step 2fs)
• dynamics for 1ns using MTS-NVE
• Pure diffusion
• External applied electric field

20
Checking the energy and density
21
Diffusion coefficients
22
KCl solution inside the pore
V125 mV Lz 100 Å 1 e-1.610-19 C 1Å
10-10 m E 0.0288 kcal/mol/Å /e-
23
(No Transcript)
24
1K at z 60Å (center)
DIFFUSION
EEL 40 kcal/mol VdW -0.03 kcal/mol
EEL 15 kcal/mol VdW -0.02 kcal/mol
EEL -2 kcal/mol VdW -0.01 kcal/mol
25
K diffusion coefficients
26
Cl- diffusion coefficients
27
Pore volume
CONNOLY CALCULATIONS PORE Rp1Å V1 97199.9
1186.3 Å3 Rp 1.4Å V1.4 98508.6 738.7 Å3 Rp
25Å V25 212437.4 2466.8 Å3 Vpore 114583
2835 Å3 n69 ions 1M N moles solute/1L
solution NA molecules/1027 Å3 6.023E-4 molec/
Å3
28
Binding energies
29
Binding energies in the pore
30
PNP simulations
31
2-D Poisson Nerst Plank (PNP)
Schematic representation of a-hemolysin channel.
In the PNP model a 2D grid (represented as
concentric rings) corresponding to a cylindrical
polar coordinate system (radial and axial) is
applied over the pore stem.
32
Electrostatic potential maps
Pore constrictions and transmembrane voltage (no
fixed charges)
Pore constrictions, transmembrane voltage and
fixed charges
33
Study at 120mV
34
Channel selectivity
Anion selective
Experimental values 1M KCl, 120mV? G1nS 0.5M
t(K)/t(Cl-) 1.5
Menestrina, G, The Journal of Membrane Biology,
90, 177-190, 1986
35
Open Channel Ion Current
MD-PNP calculations
Menestrina, G, The Journal of Membrane Biology,
90, 177-190, 1986
36
CONCLUSIONS

• The MD calculations show that both K and Cl-
  ions are transported through the a-hemolysin
  channel
• The ions diffusion coefficient inside the pore is
  reduced by a factor of 5 for K and 6 for Cl-
  compared to pure solution.
• Overall (in solution and in the pore) D(K) gt
  D(Cl-) while in the pore-cap D(K) lt D(Cl-)
• Binding sites for K occur at the two ends of the
  pore (cis and trans) while for Cl- the best
  binding sites are located at the stem-cap
  connecting region
• There is a greater binding potential and also
  more binding sites for K than Cl-
• 2D-PNP model prediction show that
• I-V behavior is consistent with observed
  experimental profiles over-linear for positive
  voltages and sub-linear for negative voltages
• A smooth cylinder would have a larger conductance
  that is reduced by the presence of the two
  constrictions
• The polar walls of the pore increase the current
• Channel is slightly anion (Cl-) selective

37
ACKNOWLEDGEMENTS

• MD simulations with NAMD (http//www.ks.uiuc.edu/R
  esearch/namd)
• Movies and analysis generated with VMD
  (http//www.ks.uiuc.edu/Research/vmd)
• Amber, VMD, NAMD lists, GRID (Molecular Inc)
• NAS support group (http//www.nas.nasa.gov)
• System administrators of the Nanotechnology
  Division Aldo Foot, Marcy Shull

VMD/NAMD - developed by the Theoretical and
Computational Biophysics Group in the Beckman
Institute for Advanced Science and Technology at
the University of Illinois at Urbana-Champaign.
38
The temperature factor(B- or Debye-Waller factor)

• the molecular motions in the simulation (thermal
  vibrations) can be related to crystallographic Bi
  factors (calculated from X-ray scattering)
• Bi is the temperature factor of atom i
• Ui is the mean square displacement of atom i
• The pore stem and the pore inside are the
  dynamically active parts

B(eq) 8pi21/3U(1,1) U(2,2) U(3,3)
39
Hydrophobicity map

• Alternating layers with high (blue) and
  respectively low (red) hydrophobicity
• Hydrophobicity influences the ongoing dynamics
  hydrophylic residues will form more HB with water
  thus the local friction coefficient will be
  larger

40
Ingredients for the MD modeling
The a-hemolysin pore
1M KCl
Force field Cornell et al, 1995 AMBER,
http//www.scripps.edu/ Multi-CPU scalable MD
software NAMD, http//www.ks.uiuc.edu/
41
1K at z35Å (trans)
DIFFUSION
Interaction energy K-protein Electrostatic 15
kcal/mol VdWaals -0.02 kcal/mol
42
1K at z90Å (cis)
DIFFUSION
Interaction energy K-protein Electrostatic -2
kcal/mol VdWaals -0.01 kcal/mol
43
1K along channel axis
Diffusion
