Numerical Linear Algebra

1
Numerical Linear Algebra

• Chris Rambicure
• Guojin Chen
• Christopher Cprek

2
WHY USE LINEAR ALGEBRA?

• 1) Because it is applicable in many problems.
• 2)And its usually easier than calculus

3
TRUE
Linear algebra has become as basic and as
applicable as calculus,and fortunately it is
easier.
-Gilbert Strang
Calculus
4
HERE COME THE BASICS
5
SCALARS

• What youre used to dealing with
• Have magnitude, but no direction

6
VECTORS

• Represent both a magnitude and a direction
• Can add or subtract, multiply by scalars, or do
  dot or cross products

7
THE MATRIX

• Its an mxn array
• Holds a set of numerical values
• Especially useful in solving certain types of
  equations
• Operations Transpose, Scalar Multiply, Matrix
  Add, Matrix Multiply

8
EIGENVALUES

• You can choose a matrix A, a vector x, and a
  scalar x so that Ax sx, meaning the matrix just
  scales the vector
• X in this case is called an eigenvector, and s is
  its eigenvalue

9
CHARACTERISTIC EQUATION

• det(M-tI) 0
• M the matrix
• I the identity
• t eigenvalues

10
CAYLEY-HAMILTON THEOREM

• IF
• AND
• THEN p(A) 0, meaning A satisfies its
  characteristic equation

11
A Couple Names, A Couple Algorithms
12
IN THE BEGINNING(Grassmanns Linear Algebra)

• Grassmann is considered to be the father of
  linear algebra
• Developed the idea of a linear algebra in which
  the symbols representing geometric objects can be
  manipulated
• Several of his operations the interior product,
  the exterior product, and the multiproduct

13
Whats a Multiproduct Equation Look Like?

• d1Äd2 d1Äd2 0
• The multiproduct has many uses, including
  scientific, mathematic, and industrial
• Got updated by William Clifford

14
CLIFFORDS MODIFICATION TO GRASSMANS EQUATION

• d1Äd2 d1Äd2 2kij
• The 2kij is whats referred to as Kroneckers
  Symbol
• Both of these equations are used for Quantum
  Theory Math

15
VECTOR SPACE

• Another idea which is kind of tied with Grassman
• Vector Space refers to some set of vectors that
  contains the origin
• It is usually infinite
• Subspace is a subset of vector space. It, of
  course, is also vector space

16
Cholesky Decomposition

• Algorithm developed by Arthur Cayley
• Takes a matrix and factors it into a triangular
  matrix times its transpose
• ARR
• Useful for matrix applications
• Becomes even more worthwhile in parallel

17
HOW TO USE LINEAR ALGEBRA FOR PDES

• You can use matrices and vectors to solve partial
  differential equations
• For equations with lots of variables, youll wind
  up with really sparse matrices
• Hence, the project weve been working on all year

18
BIBLIOGRAPHY

• Hermann Grassmann. Online. http//members.fortun
  ecity.com/johnhays/grassmann.htm
• Abstract Linear Spaces. Online.
  http//www-groups.dcs.stand.ac.uk/history/HistTop
  ics/Abstract_linear_spaces.html
• Liberman, M. Linear Algebra Review. Online.
  http//www.ling.upenn.edu/courses/ling525/linear_a
  lgebra_review.html
• Cholesky Factorization. Online.
  http//www.netlib.org/utk/papers/factor/node9.html

19
Numerical Linear Algebra

• Guojin Chen
• Christopher Cprek
• Chris Rambicure

20
Johann Carl Friedrich Gauss
Born April 30, 1777 (Germany) Died Feb 23, 1855
(Germany)
21
Gaussian Elimination

• LU Factorization
• Operation Count
• Instability of Gaussian Elimination without
  Pivoting
• Gaussian Elimination with Partial Pivoting

22
Linear systems A linear system of equations (n
equations with n unknowns) can be written
a11 x1 a12 x2 ... a1n xn b1

a21 x1 a22 x2 ... a2n xn
b2

...



an1 x1 an2 x2 ...
ann xn bn

Using matrices, the above system of
linear equations can be written
23
Gauss Elimination and Back Substitution
Convert this to triangular form
Then solve the system by Back Substitution.
24
(No Transcript)
25
LU Factorization

• Gaussian elimination transforms a full linear
  system into an upper-triangular one by applying
  simple linear transformations on the left.
• Let A be a square matrix. The idea is to
  transform A into upper-triangular matrix U by
  introducing zeros below the diagonal.

26
LU Factorization

• This elimination process is equivalent to
  multiplying by a sequence of lower-triangular
  matrices Lk on the left
• Lm-1 L2L1A U

27
(No Transcript)
28
LU Factorization

• Setting L (Lm-1 )-1 (L2)-1(L1)-1
• We obtain an LU factorization of A
• A LU

29
In order to find a general solution of a system
of equations, it is helpful to simplify the
system as much as possible. Gauss elimination is
a standard method (which has the advantage of
being easy to implement on a computer) for doing
this. Gauss elimination uses elementary
operations. We can interchange any two
equations multiply an equation by a
(nonzero) constant add a multiple of one
equation to any other one and aim to reduce the
system to triangular form. The system obtained
after each operation is equivalent to the
original one, meaning that they have the same
solutions.
30
Algorithm of Gaussian Elimination without
Pivoting U A, L I For k 1 to m-1 for j
k 1 to m ljk ujk/ukk uj,km uj,km
ljkuk,km
31
Operation Count

• There are 3 loops in the previous algorithm
• There are 2 flops per entry
• For each value of k, the inner loop is repeated
  for rows k1, , m.
• Work for Gaussian elimination is
• m3 flops

32
(No Transcript)
33
Instability of Gaussian Elimination without
Pivoting

• Consider the following matrices
• A1
• A2

34
(No Transcript)
35
Pivoting

• Pivots
• Partial Pivoting
• Example
• Complete Pivoting

36
Pivot
37
Partial Pivoting
38
Example

• A

P1
39
L1

40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
Reference http//www.maths.soton.ac.uk/teaching/u
nits/ma273/node8.html http//www.maths.soton.ac.uk
/teaching/units/ma273/node9.html Numerical Linear
Algebra by Lloyd Trefethen and David Bau,
III http//www.sosmath.com/matrix/system1/system1.
html
44
Numerical Linear AlgebraThe Computer Age

• Christopher Cprek
• Chris Rambicure
• Guojin Chen

45
What Ill Be Covering

• How Computers made Numerical Linear Algebra
  relevant.
• LAPACK
• Solving Dense Matrices on Parallel Computers.

46
Why All the Sudden Interest?

• Gregory Moore regards the axiomatization of
  abstract vector spaces to have been completed in
  the 1920s.
• Linear Algebra wasnt offered as a separate
  mathematics course at major universities until
  the 1950s and 60s.
• Interest in linear algebra skyrocketed.

47
Computers Made it Practical

• Before computers, solving a system of 100
  equations with 100 unknowns was unheard of.
• The brute mathematical force of computers made
  linear algebra systems incredibly useful for all
  kinds of applications involving linear algebra.

48
Computers and Linear Algebra

• The computer software Matlab provides a good
  example it is among the most popular in
  engineering applications and at its core it
  treats every problem as a linear algebra problem.

• A need for more advanced large matrix operations
  resulted in LAPACK.

49
What is LAPACK?

• Linear Algebra PACKage
• Software package designed specifically for linear
  algebra applications.
• The original goal of the LAPACK project was to
  make the widely used EISPACK and LINPACK
  libraries run efficiently on shared-memory vector
  and parallel processors.

50
LAPACK continued

• LAPACK is written in Fortran77 and provides
  routines for solving systems of simultaneous
  linear equations, least-squares solutions of
  linear systems of equations, eigenvalue problems,
  and singular value problems.
• Dense and banded matrices are handled, but not
  general sparse matrices. In all areas, similar
  functionality is provided for real and complex
  matrices, in both single and double precision.

51
Parallel Dense Matrix Partitioning

• Parallel computers are well suited for processing
  large matrices.
• In order to process a matrix in parallel, it is
  necessary to partition the matrix so that the
  different partitions can be mapped to different
  processors.

52
Partitioning Dense Matrices

• Striped Partitioning
• Block-Striped
• Cyclic-Striped
• Block-Cyclic-Striped
• Checkerboard Partitioning
• Block-Checkerboard
• Cyclic-Checkerboard
• Block-Cyclic-Checkerboard

53
Striped Partitioning

• Matrix is divided into groups of complete rows or
  columns, and each processor is assigned one such
  group.

54
Striped Partitioning cont

• Block-striped Partitioning is when contiguous
  rows or columns are assigned to each processor
  together.
• Cyclic-striped Partitioning is when rows or
  columns are sequentially assigned to processors
  in a wraparound manner.
• Block-Cyclic-Striped is a combination of the two.

55
Striped Partitioning cont

• In a column-wise block striping of an nn matrix
  on p processors (labeled P(0), P(1), , P(P-1)
• P(I) contains columns with indices (n/p)I, (n/p)I
  1, , (n/p)(I1) 1.
• In row-wise striping
• P(I) contains rows with indices I, Ip, I2p, ,
  In-p.

56
Checkerboard Partitioning

• The matrix is divided into smaller square or
  rectangular blocks or submatrices that are
  distributed among processors.

57
Checkerboard Partitioning cont

• Much like striped-partitioning, checkerboard
  partitioning may use block, cyclic, or a
  combination.
• A checkerboard-partitioned square matrix maps
  naturally onto a two-dimensional square mesh of
  processors. An nn matrix onto a p processor mesh
  divides the blocks into size (n/?p)(n/?p).

58
Matrix Transposition on a Mesh

• Assume that an nn matrix is stored in an nn
  mesh of processors, so each processor holds a
  single element.
• A diagonal runs down the mesh.
• An element above the diagonal moves down to the
  diagonal and then to the left to its destination
  processor.
• An element below the diagonal moves up to the
  diagonal and then to the right to its destination
  processor.

59
Matrix Transposition cont
60
Matrix Tranposition cont

• An element at initial p8 moves to p4, p0, p1, and
  finally to p2.
• If pltnn, then the tranpose can be computed in
  two phases.
• Square matrix blocks are treated as indivisible
  units, and whole blocks are communicated instead
  of individual elements.
• Then do a local rearrangement within the blocks.

61
Matrix Transposition cont

• Communication and the Local Rearrangement

62
Matrix Transposition cont

• The total parallel run-time of the procedure for
  transposition of matrix on a parallel computer

63
Parallelization of Linear Algebra

• Transposition is just an example of how numerical
  linear algebra can be easily and effectively
  parallelized.
• The same techniques and principles can be applied
  to operations like multiplication, addition,
  solving, etc.
• This explains their current popularity.

64
Conclusion

• Linear algebra is flourishing in an age of
  computers, where there are limitless
  applications.
• LAPACK exists as an efficient code library for
  processing large systems of equations on parallel
  processing computers.
• Parallel Computers are very well suited to these
  kinds of problems.

65
Useful Links

• http//www.crpc.rice.edu/CRPC/brochure/res_la.html

• http//citeseer.nj.nec.com/26050.html
• http//www.maa.org/features/cowen.html
• http//www.nersc.gov/dhbailey/cs267/Lectures/Lect
  _10_2000.pdf
• http//www.cacr.caltech.edu/ASAP/news/specialevent
  s/tutorialnla.htm
• http//www.netlib.org/scalapack/
• http//citeseer.nj.nec.com/125513.html
• http//discolab.rutgers.edu/classes/cs528/lectures
  /lecture7/
• http//www.cse.uiuc.edu/cse302/lec20/lec-matrix/le
  c-matrix.html
