MANAGEMENT of

1
MANAGEMENT of INFORMATION SECURITY Second Edition
2
Learning Objectives

• Upon completion of this chapter, you should be
  able to
• Select from the dominant information security
  management models, including U.S. government
  sanctioned models, and customize them for your
  organizations needs
• Implement the fundamental elements of key
  information security management practices
• Follow emerging trends in the certification and
  accreditation of U. S. Federal IT systems

3
Introduction

• To create or maintain a secure environment, one
  must design a working security plan and then
  implement a management model to execute and
  maintain the plan
• This may begin with the creation or validation of
  a security framework, followed by an information
  security blueprint that describes existing
  controls and identifies other necessary security
  controls
• A framework is the outline of the more thorough
  blueprint, which is the basis for the design,
  selection, and implementation of all subsequent
  security controls
• Most organizations draw from established security
  models and practices to develop a blueprint or
  methodology

4
ISO/IEC 177992005

• One of the most widely referenced and often
  discussed security models is Information
  Technology Code of Practice for Information
  Security Management, which was originally
  published as British Standard BS 7799
• The purpose is to establish guidelines and
  general principles for initiating, implementing,
  maintaining, and improving information security
  management in an organization

5
ISO/IEC 177992005 (continued)

• ISO/IEC 177992005 is intended as a common basis
  and practical guideline for developing
  organizational security standards and effective
  security management practices, and to help build
  confidence in inter-organizational activities
• ISO/IEC 177992005 replaced BS77991

6
ISO/IEC 177992005 (continued)

• ISO/IEC 177992005 has 133 possible controls, not
  all of which must be used part of the process is
  to identify which are relevant
• Each section includes four categories of
  information
• One or more objectives
• Controls relevant to the achievement of the
  objectives
• Implementation guidance
• Other information

7
ISO/IEC 177992005 (continued)

• Many countries, including the U.S., Germany, and
  Japan, have not adopted the model, claiming it is
  fundamentally flawed
• The global InfoSec community has not defined any
  justification for the code of practice identified
• The model lacks the necessary measurement
  precision of a technical standard
• There is no reason to believe the model is more
  useful than any other approach
• It is not as complete as other frameworks
• It is perceived as being hurriedly prepared,
  given the tremendous impact that its adoption
  could have on industry information security
  controls

8
Figure 6-1 177992005 Usability
9
SANS SCORE and ISO/IEC 17799

• One way to determine how closely an organization
  is complying with ISO 17799 is to use the SANS
  SCORE Audit Checklist
• The checklist provides insight into eleven
  sections of ISO/IEC 17799

10
The Eleven Sections Of ISO/IEC 17799

• Security Policy focusing mainly on InfoSec
  policy
• Organization of InfoSec for both the internal
  organization and external parties
• Asset Management including responsibility for
  assets and information classification
• Human Resources Security ranging from controls
  prior to employment, during employment, to
  termination or change of employment
• Physical and Environmental Security including
  secure areas and equipment security

11
The Eleven Sections Of ISO/IEC 17799 (continued)

• 6. Communications and Operations Management
• Incorporating operational procedures and
  responsibilities
• Third-party service delivery management
• System planning and acceptance
• Protection against malicious and mobile code
• Backup
• Network security management
• Media handling
• Exchange of information
• Electronic commerce services and monitoring

12
The Eleven Sections Of ISO/IEC 17799 (continued)

• 7. Access Control
• Business requirement for access control
• User access management
• User responsibilities
• Network access control
• Operating system access control
• Application and information access control
• Mobile computing and teleworking

13
The Eleven Sections Of ISO/IEC 17799 (continued)

• 8. Information Systems Acquisition, Development,
  and Maintenance
• Security requirements of information systems
• Correct processing in applications
• Cryptographic controls
• Security of system files
• Security in development and support processes and
  technical vulnerability management

14
The Eleven Sections Of ISO/IEC 17799 (continued)

• 9. Information Security Incident Management
  addressing reporting InfoSec events and
  weaknesses and management of InfoSec incidents
  and improvements
• Business Continuity Management InfoSec aspects
  of BCM
• Compliance
• With legal standards
• With security policies and standards
• Technical compliance with information systems
  audit considerations

15
ISO/IEC 270012005 The InfoSec Management System

• BS77992 is the companion to BS77991, and
  provides implementation details using a
  Plan-Do-Check-Act cycle

16
Figure 6-3BS77992 Plan-Do-Check-Act
17
ISO/IEC 270012005 The InfoSec Management
System (continued)

• Plan
• Define the scope of the ISMS
• Define an ISMS policy
• Define the approach to risk assessment
• Identify the risks
• Assess the risks
• Identify and evaluate options for the treatment
  of risk
• Select control objectives and controls
• Prepare a Statement of Applicability(SOA)

18
ISO/IEC 270012005 The InfoSec Management
System (continued)

• Do
• Formulate a Risk Treatment Plan
• Implement the Risk Treatment Plan
• Implement controls
• Implement training and awareness programs
• Manage operations
• Manage resources
• Implement procedures to detect and respond to
  security incidents

19
ISO/IEC 270012005 The InfoSec Management
System (continued)

• Check
• Execute monitoring procedures
• Undertake regular reviews of ISMS effectiveness
• Review the level of residual and acceptable risk
• Conduct internal ISMS audits
• Undertake regular management review of the ISMS
• Record actions and events that impact an ISMS

20
ISO/IEC 270012005 The InfoSec Management
System (continued)

• Act
• Implement identified improvements
• Take corrective or preventive action
• Apply lessons learned
• Communicate results to interested parties
• Ensure improvements achieve objectives

21
ISO/IEC 270012005 The InfoSec Management
System (continued)

• In 2005, BS 77992 was updated and codified as
  ISO/IEC 270012005, and is the foundation for
  third-party certification
• Its major sections include
• Introduction
• Scope
• Terms and definitions
• ISMS
• Management responsibility
• Management review
• ISMS improvement

22
ISO/IEC 270012005 The InfoSec Management
System (continued)

• Proposed use of 270012005
• Use within organizations to formulate security
  requirements and objectives
• Use within organizations as a way to ensure that
  security risks are cost-effectively managed
• Use within organizations to ensure compliance
  with laws and regulations
• Use within organizations as a process framework
  for the implementation and management of controls
  to ensure that the specific security objectives
  of an organization are met

23
ISO/IEC 270012005 The InfoSec Management
System (continued)

• Proposed use of 270012005 (continued)
• Definition of new InfoSec management processes
• Identification and clarification of existing
  InfoSec management processes
• Used by the management of organizations to
  determine the status of InfoSec management
  activities
• Used by the internal and external auditors of
  organizations to determine the degree of
  compliance with the policies, directives, and
  standards adopted by an organization

24
ISO/IEC 270012005 The InfoSec Management
System (continued)

• Proposed use of 270012005 (continued)
• Used by organizations to provide relevant
  information about InfoSec policies, directives,
  standards, and procedures to trading partners and
  other organizations with whom they interact for
  operational or commercial reasons
• Implementation of business-enabling InfoSec
• Used by organizations to provide relevant
  information about InfoSec to customers

25
NIST Security Models

• NIST documents have two notable advantages
• They are publicly available at no charge
• They have been available for some time and thus
  have been broadly reviewed by government and
  industry professionals
• SP 800-12, Computer Security Handbook
• SP 800-14, Generally Accepted Security Principles
  Practices
• SP 800-18, Guide for Developing Security Plans
• SP 800-26, Security Self-Assessment Guide-IT
  Systems
• SP 800-30, Risk Management for Information
  Technology Systems

26
NIST SP 800-12 The Computer Security Handbook

• Excellent reference and guide for the routine
  management of information security
• Little provided on design and implementation of
  new security systems use as supplement to gain a
  deeper understanding of background and terminology

27
NIST SP 800-12 The Computer Security Handbook
(continued)

• Lays out the NIST philosophy on security
  management by identifying 17 controls organized
  into three categories
• The Management Controls section addresses
  security topics that can be characterized as
  managerial
• The Operational Controls section addresses
  security controls that focus on controls that
  are, broadly speaking, implemented and executed
  by people (as opposed to systems)
• The Technical Controls section focuses on
  security controls that the computer system
  executes

28
NIST Special Publication 800-14Generally
Accepted Principles and Practices for Securing
Information Technology Systems

• Describes best practices useful in the
  development of a security blueprint
• Describes principles that should be integrated
  into information security processes
• Documents 8 points and 33 principles

29
NIST Special Publication 800-14Key Points

• The more significant points made in NIST SP
  800-14 are
• Security supports the mission of the organization
• Security is an integral element of sound
  management
• Security should be cost-effective
• Systems owners have security responsibilities
  outside their own organizations
• Security responsibilities and accountability
  should be made explicit
• Security requires a comprehensive and integrated
  approach
• Security should be periodically reassessed
• Security is constrained by societal factors

30
NIST Special Publication 800-14Principles

• Principle 1. Establish a sound security policy as
  the foundation for design
• Principle 2. Treat security as an integral part
  of the overall system design
• Principle 3. Clearly delineate the physical and
  logical security boundaries governed by
  associated security policies
• Principle 4. Reduce risk to an acceptable level
• Principle 5. Assume that external systems are
  insecure

31
NIST Special Publication 800-14Principles
(continued)

• Principle 6. Identify potential trade-offs
  between reducing risk and increased costs and
  decreases in other aspects of operational
  effectiveness
• Principle 7. Implement layered security (Ensure
  no single point of vulnerability)
• Principle 8. Implement tailored system security
  measures to meet organizational security goals
• Principle 9. Strive for simplicity

32
NIST Special Publication 800-14Principles
(continued)

• Principle 10. Design and operate an IT system to
  limit vulnerability and to be resilient in
  response
• Principle 11. Minimize the system elements to be
  trusted
• Principle 12. Implement security through a
  combination of measures distributed physically
  and logically
• Principle 13. Provide assurance that the system
  is, and continues to be, resilient in the face of
  expected threats
• Principle 14. Limit or contain vulnerabilities

33
NIST Special Publication 800-14Principles
(continued)

• Principle 15. Formulate security measures to
  address multiple overlapping information domains
• Principle 16. Isolate public access systems from
  mission critical resources
• Principle 17. Use boundary mechanisms to separate
  computing systems and network infrastructures
• Principle 18. Where possible, base security on
  open standards for portability and
  interoperability
• Principle 19. Use common language in developing
  security requirements

34
NIST Special Publication 800-14Principles
(continued)

• Principle 20. Design and implement audit
  mechanisms to detect unauthorized use and to
  support incident investigations
• Principle 21. Design security to allow for
  regular adoption of new technology, including a
  secure and logical technology upgrade process
• Principle 22. Authenticate users and processes to
  ensure appropriate access control decisions both
  within and across domains

35
NIST Special Publication 800-14Principles
(continued)

• Principle 23. Use unique identities to ensure
  accountability
• Principle 24. Implement least privilege
• Principle 25. Do not implement unnecessary
  security mechanisms
• Principle 26. Protect information while being
  processed, in transit, and in storage
• Principle 27. Strive for operational ease of use
• Principle 28. Develop and exercise contingency or
  disaster recovery procedures to ensure
  appropriate availability

36
NIST Special Publication 800-14Principles
(continued)

• Principle 29. Consider custom products to achieve
  adequate security
• Principle 30. Ensure proper security in the
  shutdown or disposal of a system
• Principle 31. Protect against all likely classes
  of attacks
• Principle 32. Identify and prevent common errors
  and vulnerabilities
• Principle 33. Ensure that developers are trained
  in how to develop secure software

37
NIST Special Publication 800-18A Guide for
Developing Security Plans for Information
Technology Systems

• Provides detailed methods for assessing,
  designing, and implementing controls and plans
  for various-sized applications
• Serves as a guide for the activities described in
  this chapter, and for the overall information
  security planning process
• It includes templates for major application
  security plans

38
NIST Special Publication 800-2617 Areas Defining
the core of the NIST Security Management
Structure

• Management Controls
• Risk Management
• Review of Security Controls
• Life Cycle Maintenance
• Authorization of Processing (Certification and
  Accreditation)
• System Security Plan
• Operational Controls
• Personnel Security
• Physical Security
• Production, Input/Output Controls
• Contingency Planning
• Hardware and Systems Software
• Data Integrity
• Documentation
• Security Awareness, Training, and Education
• Incident Response Capability

• Technical Controls
• Identification and Authentication
• Logical Access Controls
• Audit Trails

39
NIST Special Publication 800-30Risk Management
Guide for Information Technology Systems

• Provides a foundation for the development of an
  effective risk management program
• Contains both the definitions and the practical
  guidance necessary for assessing and mitigating
  risks identified within IT systems
• Strives to enable organizations to better manage
  IT-related risks

40
RFC 2196 Site Security Handbook

• The Security Area Working Group within the IETF
  has created RFC 2196, the Site Security Handbook
  that provides a functional discussion of
  important security issues along with development
  and implementation details
• Covers security policies, security technical
  architecture, security services, and security
  incident handling
• Also includes discussion of the importance of
  security policies, and expands into an
  examination of services, access controls, and
  other relevant areas

41
Control Objectives for Information and related
Technology (COBIT)

• Control Objectives for Information and related
  Technology (COBIT) also provides advice about the
  implementation of sound controls and control
  objectives for InfoSec
• COBIT was created by the Information Systems
  Audit and Control Association (ISACA) and the IT
  Governance Institute (ITGI) in 1992

42
Control Objectives for Information and related
Technology (COBIT) (continued)

• COBIT presents 34 high-level objectives that
  cover 215 control objectives these objectives
  are categorized into four domains
• Plan and organize
• Acquire and implement
• Deliver and support
• Monitor and evaluate

43
Control Objectives for Information and related
Technology (COBIT) (continued)

• Plan and organize
• Makes recommendations for achieving
  organizational goals and objectives through the
  use of IT
• Ten controlling objectives (PO1 PO10)
• Acquire and implement
• Focuses on specification of requirements
• Acquisition of needed components
• Integration of these components into the
  organizations systems
• Examines ongoing maintenance and change
  requirements
• Seven controlling objectives (AI1 AI7)

44
Control Objectives for Information and related
Technology (COBIT) (continued)

• Delivery and support
• Focuses on the functionality of the system and
  its use to the end user
• Examines systems applications, including input,
  processing, and output components
• Examines processes for efficiency and
  effectiveness of operations
• 13 high-level controlling objectives (DS1 DS13)

45
Control Objectives for Information and related
Technology (COBIT) (continued)

• Monitor and evaluate
• Seeks to examine the alignment between IT systems
  usage and organizational strategy
• Identifies the regulatory requirements for which
  controls are needed
• Monitors the effectiveness and efficiency of IT
  systems against the organizational control
  processes in the delivery and support domain
• Four high-level controlling objectives (ME1 ME4)

46
Committee of Sponsoring Organizations of the
Treadway Commission (COSO)

• COSO is a U.S. private-sector initiative formed
  in 1985
• Its major objective is to identify the factors
  that cause fraudulent financial reporting and to
  make recommendations to reduce its incidence
• COSO has established a common definition of
  internal controls, standards and criteria, and
  helps organizations comply with critical
  regulations like Sarbanes-Oxley

47
Committee of Sponsoring Organizations of the
Treadway Commission (COSO) (continued)

• COSO is built on five interrelated components
• Control environment
• Risk assessment
• Control activities
• Information and communication
• Monitoring

48
Security Management Practices

• In information security, two categories of
  benchmarks are used
• Standards of due care/due diligence
• Best practices
• Best practices include a subcategory of
  practicescalled the gold standardthat are
  general regarded as the best of the best

49
Standards of Due Care/Due Diligence

• When organizations adopt minimum levels of
  security for a legal defense, they may need to
  show that they have done what any prudent
  organization would do in similar circumstances
  this is known as a standard of due care
• Implementing controls at this minimum standard,
  and maintaining them, demonstrates that an
  organization has performed due diligence

50
Standards of Due Care/Due Diligence (continued)

• Due diligence requires that an organization
  ensure that the implemented standards continue to
  provide the required level of protection
• Failure to support a standard of due care or due
  diligence can expose an organization to legal
  liability, provided it can be shown that the
  organization was negligent in its application or
  lack of application of information protection

51
Best Security Practices

• Security efforts that seek to provide a superior
  level of performance in the protection of
  information are referred to as best business
  practices or simply best practices
• Some organizations refer to these as recommended
  practices
• Security efforts that are among the best in the
  industry are referred to as best security
  practices

52
Best Security Practices (continued)

• These practices balance the need for information
  access with the need for adequate protection
  best practices seek to provide as much security
  as possible for information and information
  systems, while demonstrating fiscal
  responsibility and ensuring information access
• Companies with best practices may not be the best
  in every area they may only have established an
  extremely high quality or successful security
  effort in one area

53
The Gold Standard

• Best business practices are not sufficient for
  organizations that prefer to set the standard by
  implementing the most protective, supportive, and
  yet fiscally responsible standards they can
• They strive toward the gold standard, a model
  level of performance that demonstrates industrial
  leadership, quality, and concern for the
  protection of information
• The implementation of gold standard security
  requires a great deal of support, both in
  financial and personnel resources

54
Selecting Best Practices

• Choosing which recommended practices to implement
  can pose a challenge for some organizations
• In industries that are regulated by governmental
  agencies, government guidelines are often
  requirements
• For other organizations, government guidelines
  are excellent sources of information and can
  inform their selection of best practices

55
Selecting Best Practices (continued)

• When considering best practices for your
  organization, consider the following
• Does your organization resemble the identified
  target organization of the best practice?
• Are you in a similar industry as the target?
• Do you face similar challenges as the target?
• Is your organizational structure similar to the
  target?
• Are the resources you can expend similar to those
  called for by the best practice?
• Are you in a similar threat environment as the
  one assumed by the best practice?

56
Best Practices

• Microsoft has published a set of best practices
  in security at its Web site
• Use antivirus software
• Use strong passwords
• Verify your software security settings
• Update product security
• Build personal firewalls
• Back up early and often
• Protect against power surges and loss

57
Benchmarking and Best Practices Limitations

• The biggest problem with benchmarking in
  information security is that organizations dont
  talk to each other a successful attack is viewed
  as an organizational failure, and is kept secret,
  insofar as possible
• However, more and more security administrators
  are joining professional associations and
  societies like ISSA and sharing their stories and
  lessons learned
• An alternative to this direct dialogue is the
  publication of lessons learned

58
Baselining

• A baseline is a value or profile of a
  performance metric against which changes in the
  performance metric can be usefully compared
• Baselining is the process of measuring against
  established standards
• In InfoSec, baselining is the comparison of
  security activities and events against the
  organizations future performance
• Baselining can provide the foundation for
  internal benchmarking, as information gathered
  for an organizations first risk assessment
  becomes the baseline for future comparisons

59
Baselining Example

• The Gartner group offers twelve questions as a
  self assessment for best security practices
• People
• Do you perform background checks on all employees
  with access to sensitive data, areas, or access
  points?
• Would the average employee recognize a security
  issue?
• Would they choose to report it?
• Would they know how to report it to the right
  people?

60
Baselining Example (continued)

• Processes
• Are enterprise security policies updated on at
  least an annual basis, employees educated on
  changes, and policies consistently enforced?
• Does your enterprise follow a patch/update
  management and evaluation process to prioritize
  and mediate new security vulnerabilities?
• Are the user accounts of former employees
  immediately removed on termination?
• Are security group representatives involved in
  all stages of the project life cycle for new
  projects?

61
Baselining Example (continued)

• Technology
• Is every possible route to the Internet protected
  by a properly configured firewall?
• Is sensitive data on laptops and remote systems
  encrypted?
• Do you regularly scan your systems and networks,
  using a vulnerability analysis tool, for security
  exposures?
• Are malicious software scanning tools deployed on
  all workstations and servers?

62
Metrics in InfoSec Management

• When an organization applies statistical and
  quantitative approaches of mathematical analysis
  to the process of measuring the activities and
  outcomes of the InfoSec program, it is using
  InfoSec metrics
• InfoSec metrics enable organizations to measure
  the level of effort required to meet the stated
  objectives of the InfoSec program

63
Metrics in InfoSec Management (continued)

• Specifying InfoSec metrics requires the
  assessment and quantification of what will be
  measured
• Collecting InfoSec metrics is daunting to some
  organizations, and requires thoughtful
  consideration of the intent of the metric, along
  with a thorough knowledge of how production
  services are delivered

64
Metrics in InfoSec Management (continued)

• Interpreting InfoSec metrics requires both raw
  data as well as the context
• Decisions also need to be made regarding
  presentation of correlated metrics, as well as
  color use to denote specific results
• Disseminating InfoSec metrics requires the CISO
  to consider who gets them, as well as method of
  delivery

65
Emerging Trends In Certification and
Accreditation

• In security management, accreditation is the
  authorization of an IT system to process, store,
  or transmit information
• It is issued by a management official and serves
  as a means of assuring that systems are of
  adequate quality
• It also challenges managers and technical staff
  to find the best methods to assure security,
  given technical constraints, operational
  constraints, and mission requirements

66
Emerging Trends In Certification and
Accreditation (continued)

• Certification is the comprehensive evaluation of
  the technical and nontechnical security controls
  of an IT system to support the accreditation
  process that establishes the extent to which a
  particular design and implementation meets a set
  of specified security requirements
• Organizations pursue accreditation or
  certification to gain a competitive advantage, or
  to provide assurance or confidence to customers

67
SP 800-37 Guidelines for Security C A of
Federal IT Systems

• Develops standard guidelines and procedures for
  certifying and accrediting federal IT systems
  including the critical infrastructure of the
  United States
• Defines essential minimum security controls for
  federal IT systems
• Promotes the development of public and private
  sector assessment organizations and certification
  of individuals capable of providing cost
  effective, high-quality security certifications
  based on standard guidelines and procedures

68
SP 800-37 Guidelines for Security C A of
Federal IT Systems (continued)

• The specific benefits of the security
  certification and accreditation (CA) initiative
  include
• More consistent, comparable, and repeatable
  certifications of IT systems
• More complete, reliable, information for
  authorizing officialsleading to better
  understanding of complex IT systems and
  associated risks and vulnerabilitiesand
  therefore, more informed decisions by management
  officials
• Greater availability of competent security
  evaluation and assessment services
• More secure IT systems within the federal
  government

69
Figure 6-4SpecialPublicationsSupportingSP
800-37
70
SP 800-37 Guidelines for Security C A of
Federal IT Systems (continued)

• 800-37 focuses on a three-step security controls
  selection process
• Step 1 Characterize the system
• Step 2 Select the appropriate minimum security
  controls for the system
• Step 3 Adjust security controls based on system
  exposure and risk decision

71
Planned Federal System Certifications

• Systems are to be certified to one of three
  levels
• Security Certification Level 1 - The entry-level
  certification appropriate for low priority
  (concern) systems
• Security Certification Level 2 - The mid-level
  certification appropriate for moderate priority
  (concern) systems
• Security Certification Level 3 - The top-level
  certification appropriate for high priority
  (concern) systems

72
SP 800-53 Minimum Security Controls for Federal
IT Systems

• SP 800-53 is part two of the Certification and
  Accreditation project
• Its purpose is to establish a set of
  standardized, minimum security controls for IT
  systems addressing low, moderate, and high levels
  of concern for confidentiality, integrity, and
  availability
• Controls are broken into the three familiar
  general classes of security controls management,
  operational, and technical

73
SP 800-53 Minimum Security Controls for Federal
IT Systems (continued)

• Critical elements represent important
  security-related focus areas for the system, with
  each critical element addressed by one or more
  security controls
• As technology evolves, so will the set of
  security controls, requiring additional control
  mechanisms

74
Figure 6-5Participants in the CA Process
75
Summary

• Introduction
• Security Management Models
• Security Management Practices
• Emerging Trends in Certification and
  Accreditation
