Erhan Erdin

1

Computer Architecture Support for Database
Applications

• Erhan Erdinç Pehlivan

2
Outline

• Introduction
• Methodology of the Experiment
• Analysis of OLTP workloads
• Analysis of DSS workloads
• Conclusion

3
Introduction

• Today Database workloads alone motivate the sale
  of vast quantities of symmetric multiprocessor
  (SMP) machines,

4
Introduction

• Unfortunately, due to some challenges,
  commercial applications are often ignored in
  preference to technical benchmarks, such as
  SPEC(Standard Performance Evaluation Corporation)
• Reasons
• Complex standardized benchmarks.
• Large hardware requirements for full scale.
• Numerous configuration parameters.
• Lack of useful proprietary information.

5
What is SMP

• method of work management that treats all
  processors equally
• threads that can run concurrently on any
  available processor
• improves the total throughput of the system
• requires applications that can take advantage of
  multi-threaded parallelism

6
SMP ARCHITECTURE
7
SMP(Continued)

• Advantages of SMP
• High performance
• Simplicity to program
• Easier load balancing
• Disadvantages of SMP
• Low availability
• Low scalability

8
Database Workloads

• OLTP(Online transaction processing)
• Ex Airline reservation systems
• DSS(Decision Support Systems)
• Ex Datawarehouse systems

9
Characteristics of OLTP and DSS

• OLTP
• uses short, moderately complex queries that read
  and/or modify a relatively small portion of the
  overall database.
• have a high degree of multiprogramming,
• DSS
• typically long-running, moderately to very
  complex queries, that scan large portions of the
  database in a read-mostly fashion.
• The multiprogramming level in DSS systems is
  typically
• much lower than that of OLTP systems.

10
Motivation

• Since SPEC evaluations dont hold for DBMS,
  architectural behavior of two standard database
  workloads will be investigated in terms of
• cycles per instruction (CPI) decomposition,
• cache miss rates,
• branch behavior.
• superscalarness,
• out-of-order execution

11
Methodology Experimental Platform

• a commodity four-processor Intel-based SMP
  server running Windows NT is chosen.

12
(No Transcript)
13
IO System Configurations(OLTP)
14
IO System Configurations(DSS)
15
Software Architecture(OLTP)

• Transaction Processing Councils TPC-C benchmark

16
Software Architecture(OLTP)
17
Software Architecture(DSS)

• Transaction Processing Councils TPC-D benchmark
• the activity of a wholesale supplier in doing
  complex business analysis.
• analysis pricing and promotions, market share
  study,shipping management, supply and Demand
  management, profit and revenue management and
  customer satisfaction study.
• 17 read-only queries and 2 update queries,

18
Software Architecture(DSS)
19
Pentium Pro Processor Architecture
20
Potential sources of stalls

• misses to the L1 instruction cache
• a branch misprediction
• the instruction mix of the workload
• the out-of-order execution engine

21
Measurement Methodology

• NT performance monitor
• Pentium Pro hardware counters.
• Intel tool called emon

22
Analysis of OLTP Workloads

• OLTP does short, moderately complex transactions
• small, random I/O operations
• large number of concurrent users, a high degree
  of multiprogramming.
• database implements locking,logging
• The combination of these tasks
• Large instruction working set
• Larger data footprint

23
Experimental Results CPI
24
Experimental Results Memory System Behavior

• How do OLTP cache miss rates vary with L2 cache
  size?

25
Experimental Results Memory System

• What effects do larger caches have on OLTP
  throughput and stall cycles?

26

Experimental Results Processor Issues
How useful is superscalar issue and retire for
OLTP?
27
Experimental Results Processor Issues

• How effective is branch prediction for OLTP?

28
Experimental Results Processor Issues

• Is out-of-order execution successful at hiding
  stalls for OLTP?

29
Experimental Results Multiprocessor Scaling
Issues

• How well does OLTP performance scale as the
  number of processors increases?

30
Experimental Results Multiprocessor Scaling
Issues

• How do OLTP CPI components change as the number
  of processors is scaled?

31
Experimental Results Multiprocessor Scaling
Issues

• How prevalent are cache misses to dirty data in
  other processors caches for OLTP?

32
Experimental Results Multiprocessor Scaling
Issues

• Is the four-state (MESI) invalidation-based cache
  coherence protocol worthwhile for OLTP?

33
Experimental Results Multiprocessor Scaling
Issues

• How does OLTP memory system performance scale
  with increasing cachesizes and increasing
  processor count?

34
Analysis of Decision SupportWorkloads

• DSS queries are typically long-running,
  moderately to very complex queries,
• Scan large portions of the database in a
  read-mostly fashion.
• Large sequential disk I/O read operations.
• The multiprogramming level in DSS systems is
  typically lower than that of OLTP systems.

35
Dss Workload
36

Experimental ResultsMemory System Behaviour

• How do DSS cache miss rates vary with L2 cache
  size?

37
Experimental ResultsMemory System Behaviour

• What impact do larger L2 caches have on DSS
  database performance and stall cycles?

38
Experimental ResultsMemory System Behaviour

• How prevalent are cache misses to dirty data in
  other processors caches in DSS?

39
Experimental ResultsMemory System Behaviour

• Is the four-state (MESI) invalidation-based cache
  coherence protocol worthwhile for DSS?

40
Experimental ResultsMemory System Behaviour

• How does DSS memory system performance scale with
  increasing cache sizes?

41
Experimental Results Processor Issues

• How useful is superscalar issue and retire for
  DSS?

BEHAVES LIKE OLTP
42
Experimental Results Processor Issues

• How effective is branch prediction for DSS?

43
Experimental Results Processor Issues

• Is out-of-order execution successful at hiding
  stalls for DSS?

44
Conclusions for OLTP

• out-of-order execution is only somewhat effective
  for this database workload.
• increased superscalar width for the out-of-order
  engine may be helpful.
• Innovation needed in branch prediction algorithms
  and hardware structures to better support
  database workloads.
• caches are effective at reducing the processor
  traffic to memory
• Three-state (MSI) cache coherence protocol would
  be better
• the amount of time when the memory system is
  unavailable decreases with larger caches,
  increases with of processors

45
Conclusions for DSS

• out-of-order execution provides potentially more
  benefit for DSS than OLTP
• DSS performance is less sensitive to L2 cache
  size than OLTP performance.
• Existing branch prediction schemes are more
  effective for this workload.
• Increasing the micro-operation retire width in
  the Pentium Pros out-of-order RISC core may
  provide performance improvements
• Dirty misses are less prevalent for DSS than
  OLTP.
