Pulmonary Function Tests (PFT

1
Pulmonary Function Tests (PFTs)

• Scott Stevens D.O.
• Gannon University
• College of Health Sciences
• Graduate Program Department of Nursing

2
Pulmonary Function Tests (PFTs)

• A nonspecific term used most often to describe
  only spirometry
• Pulmonary tests include chest x-ray (CXR),
  arterial blood gas (ABG), Spirometry with
  FEV1sec, FVC, FEV1/FVC, FEF 25-75, Flow-volume
  loops, Ventilation-perfusion (V/Q) scan, Pulse
  oximetry (SpO2), SaO2 from ABG, Mixed venous
  oxygen (PvO2) and saturation from pulmonary
  artery catheter

3
PFT Indications

• Possible pneumonectomy or lobectomy
• Surgery of upper abdomen
• History of pulmonary disease COPD, bronchitis,
  emphysema, pulmonary fibrosis, significant
  smoking history
• Severe obesity, obstructive sleep apnea (OSA),
  pickwickian syndrome (obesity, decreased
  pulmonary function, polycythemia)
• Evidence of pulmonary dysfunction during history
  and physical exam
• Dyspnea shortness of breath, SOB
• DOE dyspnea on exertion

4
Patients at risk for post-op pulmonary
complications

• Significant history of pulmonary disease
• Thoracic or abdominal (esp. upper) surgery
• Obesity
• Long-term smokers
• Elderly patients (gt70 yrs)

5
High risk PFT results

• FEV1 lt 2L
• FEV1/FVC lt 0.5
• VC lt 15cc/Kg in adult lt 10cc/Kg in child
• VC lt 40 to 50 than predicted

6
Why get PFTs preoperatively?

• By estimating pulmonary reserve one can better
  plan and predict pre-, intra- and post-operative
  pulmonary care requirements

7
Preoperatively

• Goal is to treat any reversible conditions,
  optimize pt
• Bronchodilators testing will show any
  improvement with treatment, adjust doses
• Most important in patients with a gt15
  improvement in FEV1 after treatment
• Bronchitis optimize patient
• respiratory therapy, bronchodilators for
  bronchospasm
• antibiotics to treat infection, sputum for
  culture and sensitivity (CS)
• Optimize CHF

8
Intraoperatively

• Ventilator adjustments
• Severe emphysema requires longer expiratory times
  (normal IE is 12, so in COPD ? 13)
• Closely monitor peak inspiratory pressures (PIP)
  to avoid rupturing an emphysematous bleb
• CO2 retainers EtCO2 should be keep near the
  pts baseline, a rapid correction will lead to
  metabolic alkalosis
• Bronchospasm avoid histamine releasing drugs
• Pentothal (STP), Morphine (MSO4), Atracurium,
  Mivacurium, Neostigmine
• Tx with nebulized albuterol

9
Postoperatively

• Extubation
• If FEV1 is gt50 predicted than extubation
  probably will not be effected
• If FEV1 is between 25 50, with some hypoxemia
  and hypercarbia prolonged intubation probable
• If FEV1 is lt25 predicted only life saving
  procedures should be done, regional anesthesia if
  possible, long term ventilatory support, possible
  inability to wean from ventilator, tracheostomy
  probable
• Extubation criteria
• VSS, awake alert, resp. rate lt 30
• ABG on FiO2 of 40 ? PaO2 gt70 and PaCO2 lt55
• MIF is more negative than -20cm H2O
• Vital capacity (VC) gt 15cc/Kg

10
Acute respiratory failure

• Intubation criteria
• Mechanics RRgt35, VC lt15cc/Kg in adult or
  lt10cc/Kg in child, MIF more neg. than -20cmH2O
• Oxygenation PaO2 lt 70mmHg on FiO2 of 40, A-a
  gradient gt 350mmHg on 100 O2
• Ventilation PaCO2 gt 55 (except in chronic
  hypercarbia), Vd/Vt gt 0.6 (remember normal dead
  space is 30)
• Clinical airway burn, chemical burn,
  epiglottis, mental status change, rapidly
  deteriorating pulmonary status, fatigue

11
Normal CXR
12
Expiratory CXR
13
Inspiratory CXR (same pt)
14
Expiratory CXR for pneumothorax (PTX)
15
Tension Pneumothorax
16
CHF or excessive IV fluids
17
RUL consolidation ? aspiration
18
ABG

• Results pH / PCO2 / PO2 / bicarbonate / base
  excess
• Usually obtained from radial, brachial, femoral,
  axillary, or dorsalis pedis artery
• Drawn in heparinized syringe
• Must be measured within 15 minutes or glycolysis
  will occur with lactic acid production, decreased
  pH, and increased PCO2
• Sample can be stored on ice for 1 to 2 hours
• Heparin may significantly lower PCO2 by dilution,
  esp. in children when small samples taken

19
ABG normal values

• pH 7.35 7.45
• PCO2 35 45 mmHg
• PO2 75 105 mmHg
• Bicarbonate 20 26 mmoles/L
• Base excess -3 to 3 mmoles/L

20
pH

• Acidemia blood pH lt 7.35
• Alkalemia blood pH gt 7.45
• Acidosis a process which causes acid to
  accumulate
• Alkalosis a process which causes alkali
  accumulation
• Altered pH ? next determine if respiratory (CO2)
  or metabolic (HCO3-)
• Buffers substance that can absorb or donate H
• Bicarb(HCO3-), Hb, serum proteins,
  phosphate(HPO4-)

21
PaCO2

• Hypercapnia increased CO2
• Hypocapnia decreased CO2
• Rule an increase of PCO2 by 10 mmHg causes a
  decrease in pH by 0.08, likewise, a decrease of
  PCO2 by 10 mmHg will increase pH by 0.08
• So an acute increase in CO2 to 60 should cause a
  drop in pH to 7.24

22
PaO2

• Hypoxemia decreased PO2 in blood, lt 75
• Hypoxia a low O2 state
• A-a gradient a measure of efficiency of lung
• PAO2 (PB-PH2O)(FiO2) (PaCO2/0.8)
• PAO2 (760-47)(0.21) (40/0.8) 100
• PAO2 (760-47)(0.5) (40/0.8) 306
• PAO2 (760-47)(1) (40/0.8) 663
• Normal A-a approximately (Age / 3)
• A-a gradient is widened during anesthesia and
  with intrinsic lung Dz PTX, PE, shunt, V/Q
  mismatch, diffusion problems
• A-a gradient is normal with hypoventilation or
  low FiO2
• Tx is supplemental O2, adjust ventilation, tx
  atelectasis, add PEEP, tx underlying cause

23
Bicarbonate

• A calculated value from
• H 24 (PaCO2/HCO3-)
• Values alter due to acidosis/alkalosis
• Base excess is calculated directly using PaCO2,
  pH, and bicarbonate values
• Rule a decrease in bicarb. by 10 mmoles
  decreases the pH by 0.15, likewise, an increase
  in bicarb. By 10 mmoles increases pH by 0.15
• A bicarb. of 13 would result in a pH of 7.25
• Total body bicarb. deficit (base deficit wt
  in Kg 0.4), in mEq/L, usually replace ½ of
  deficit

24
Respiratory Acidosis

• Low pH High PaCO2
• Acute and chronic causes
• Hypoventilation with hypercarbia
• CNS depression trauma, drugs
• Decreased FRC obesity
• Upper or lower airway obstruction
• COPD, asthma, pulmonary fibrosis
• After 1-2 days renal compensation occurs
• H excreted by kidney and HCO3- reabsorbed into
  blood to partially correct pH

25
Respiratory Alkalosis

• High pH Low PaCO2
• Hyperventilation with hypocarbia
• Causes hypoxic respiration, CNS Dz,
  encephalitis, anxiety, narcotic withdrawl,
  pregnancy, early septic shock, hypermetabolic
  states, artificial ventilation
• Renal compensation will occur causing increased
  excretion of HCO3- and decreased secretion of H
  which partially corrects pH

26
Metabolic Acidosis

• Low pH Low HCO3-
• Causes lactic acidosis from hypoperfusion, DKA,
  renal Dz with bicarb loss (anion gap and K),
  HCO3- loss in diarrhea, ASA ingestion, high
  protein intake
• Respiratory compensation (central chemoreceptors)
  with hypocarbia, more rapid than renal
  compensation, partial correction
• Kidneys may increase H excretion

27
Metabolic Alkalosis

• High pH High HCO3-
• Causes bicarb. infusion, metabolism of lactate
  or citrate, loss of H from vomiting or excessive
  NGT suctioning
• Respiratory compensation by limited
  hypoventilation due to eventual hypoxic drive,
  partial correction
• Kidneys may increase bicarb. excretion in urine

28
(No Transcript)
29
(No Transcript)
30
Spirometry
31
FEV-1 second

• After maximal inspiration, the volume of air that
  can be forcefully expelled in one second
• Effort dependent
• Normally between 3 5 L
• Also reported as percent predicted
• Also reported as a percent of FVC
• FEV1 / FVC ? normally gt 75
• Most important clinical tool in assessing the
  severity of airway obstructive disease

32
FEV1
33
Degree of risk in obstructive lung disease

• RISK FEV1 / FVC
• Normal gt 75
• Mild 60-75
• Moderate 45-60
• Severe 35-45
• Extreme lt 35

34
Flow-Volume loop
35
Flow-volume loops

• Helps distinguish between upper airway
  obstruction (extrathoracic) and generalized
  pulmonary disease (intrathoracic)
• An extrathoracic obstruction decreases
  inspiratory flow
• An intrathoracic obstruction decreases expiratory
  flow

36
(No Transcript)
37
FEF 25-75

• Forced expiratory flow at 25 to 75 of FVC
• Effort independent
• Reflects collapse of small airways, peripheral
  airways
• Sensitive indicator of early airway obstruction

38
MVV or MBC

• Maximal voluntary ventilation
• Maximal breathing capacity
• will to live test
• The maximal amount of air a pt can exhale in one
  minute at maximal effort (hyperventilation)
• Extremely effort dependent, nonspecific
• Tests motivation, mechanics, strength, and
  endurance
• A decrease has been shown to predict increased
  morbidity and mortality in pts undergoing
  thoracic surgery

39
Thats All For Today
