RADIATION ONCOLOGY

1
RADIATION ONCOLOGY

• An Introduction
• by W.G. McMillan

2
Radiation

• What is it?
• How does it work?
• Why do it?
• How do we measure it?
• How do we deliver it?
• How is it different from getting an X-ray?

3
Physical Considerations

• Excitation
• an electron in an atom or molecule is raised to a
  higher energy level without being ejected
• Ionization
• an electron in an atom or molecule is given
  enough energy to be ejected.
• in living material, this releases enough energy
  locally to break biological bonds.
• CC requires 4.9 eV and 1 ionization event
  provides 33 eV.

4
Ionizing Radiation

• Electromagnetic
• waves of wavelength ?, frequency v, velocity c
• where ? v c and c 3 x 1010 cm/sec
• ?-rays radioactive decay of unstable nucleus
• x-rays produced by electrical device
• photons packets of energy
• where E hv where h Plancks constant
• using both equations
• if ? is long, then v is small and E is small

5
(No Transcript)
6
Electromagnetic Spectrum
7
Ionizing Radiation

• Particulate
• electrons small negatively charged particles can
  be accelerated to almost the speed of light.
• protons positively charged particles , mass
  2000 times greater than electron
• ? particle nucleus of helium atom 2 protons
  2 neutrons ( ie decay of radium-226 to radon-222)
• heavy charged ions nuclei of elements C, Ne,
  Argon, etc.

8
Photon Interaction With Matter Photoelectric
Effect ? Z
9
First Radiograph 1896
10
Photon Interaction With Matter Compton Effect
Independent of Z
11
Portal Image
12
Biological Considerations

• Radiation Interaction with biological materials
• Cell Survival Curves
• Repair of Radiation Damage
• Effect of oxygenation on radiation damage
• Cell cycle considerations
• Pharmacological modification of radiation effects

13
Radiation Interaction With DNA

• Indirect Interaction
• fast electron hits H2O ? H2O e- H2O H2O ?
  H3O OH-
• reactive species interact with DNA
• Direct Interaction
• photons (rarely) or particles (always) directly
  interact with DNA

14
Direct vs Indirect Action of Radiation on DNA
15
Human Chromosomes With and Without Radiation
16
Surviving Fraction of Cells Post Radiation
17
HeLa Cell Survival Curve Post Radiation
18
2 Phases of Cell Survival Curve Post Radiation
19
(No Transcript)
20
Radiation Damage

• 3 types
• Lethal leads irrevocably to cell death
• Potentially lethal radiation damage which can be
  modified by artificial post radiation conditions
  (ie balanced salt solution) to allow repair.
• Sublethal in normal conditions, can be repaired
  in a few hours. Its repair is shown by increased
  survival when a dose of radiation is split into 2
  fractions separated by a time interval.

21
Radiation Damage Repair

• Sublethal Damage Repair (SLD)
• mechanism is thought to be based on repair of
  multiple hit, not single hit damage.
• for multiple hit damage, if there is a time
  interval between radiation doses, then repair of
  the first hit can occur before the second hit
  occurs.
• size of the shoulder on the survival curve
  correlates with amount of sublethal damage
  repair.
• very little SLD repair when irradiated with large
  particles (no shoulder on curve)

22
(No Transcript)
23
(No Transcript)
24
4 Rs of Radiobiology (Reoxygenation not shown)
25
Oxygen Effect on Radiation Damage

• OER (Oxygenation Enhancement Ratio)
• the ratio of the doses of radiation needed to
  achieve the same biological effect under hypoxic
  vs aerated conditions.
• thought to act at the level of free radicals (ie
  indirect effect on DNA).
• ?-rays at low doses, OER 2. At high doses,
  3.5.
• densely ionizing particles (ie ? particles), OER
  1.
• intermediate ionizing particles (ie neutrons),
  OER 1.6

26
OER and Different Radiation Types
27
Cell Cycle Considerations
28
Pharmacologic Modification of Radiation Effect

• Radiosensitizers
• many substances will sensitize cancer cells to
  radiation, but most also sensitize normal cells
  to the same degree. 2 types of substances show
  differential effect between tumours and normal
  tissues
• Halogenated Pyrimidines (BUdR, IUdR)
• substituted for thymidine in DNA, weakening it
  and making it more sensitive to x-rays and UV
  light.
• quickly cycling cells take up more than normal
  cells.
• Hypoxic Cell Sensitizers
• misonidazole, etanidazole

29
Pharmalogical Modification of Radiation Damage

• Radioprotectors
• effective vs sparsely ionizing radiation ( x and
  ?-rays). Work by scavenging free radicals.
• amifostine (WR2721) is carried by astronauts
• d-Con (WR1607) is more potent, but cardiotoxic.
• cystaphos (WR638) is carried by Russian infantry.
• Clinical trials
• amifostine RC trial in China in rectal cancer
  showed protection to skin, mucous membrane,
  bladder and pelvic structures.

30
Normal Tissue Radiation Biology

• Casarets Classification of tissue
  radiosensitivity
• based on parenchymal cells

31
(No Transcript)
32
(No Transcript)
33
Normal Tissue Adverse Effects

• Normal tissues do not all respond in the same way
  to radiation
• early responding tissues (skin, mucosa,
  intestinal epithelium.
• late responding tissues (spinal cord)
• How do we influence normal tissue reaction?
• early responding tissue fraction size, total
  dose and treatment time all affect early
  responding tissue.
• fraction size and total dose affect late
  responding tissue.

34
Fractionation

• Spares normal tissue by
• repair of sublethal damage.
• repopulation of cells if overall time is long
  enough. May also spare tumour cells.
• Increases tumour damage by
• reoxygenation
• reassortment of cells into radiosensitive phases
  of cell cycle.

35
(No Transcript)
36
Hyperfractionation

• Aims to further separate early and late effects
• overall time is about the same, but number of
  fractions is doubled, dose per fraction is
  decreased and total dose is increased.
• Intent is to reduce late effects while getting
  the same or better tumour control with the same
  or slightly increased early effects
• time interval between fractions must be long
  enough to ensure that repair of sublethal damage
  is complete before the 2nd dose is given. Usually
  gt 6 hours between fractions.

37
Accelerated Fractionation

• same total dose, same number of fractions, but
  given twice daily. Therefore, overall time is
  half.
• intent is to reduce repopulation in rapidly
  proliferating tumours, with little or no late
  effects since number of fractions and dose per
  fraction dont change.
• in practice, not achievable since early effects
  become limiting. (remember, early effects depend
  on fraction size and overall time).

38
Chemotherapy

• Most anticancer drugs work by affecting DNA
  synthesis or function.
• Most chemotherapy agents are in 3 main groups
• alkylating agents substitute alkyl groups for H
• antibiotics inhibit DNA and RNA synthesis
• antimetabolites analogues of normal cell
  metabolites
• kill by 1st order kinetics (ie a given dose of
  drug kills a constant fraction of cells, so best
  chance of cancer control is when tumour is small)

39
Radiation and Chemotherapy

• Oxygen effect more complex than for radiation.
• some drugs more toxic to hypoxic cells, some to
  aerated cells and some show no difference.
• drug resistance is a huge problem
• decreased drug accumulation (molecular pumps)
• elevated levels of glutathione.
• increase in DNA repair
• radiation resistance and chemotherapy resistance
  may develop together, but are rarely caused by
  one another.

40
Radiation and Chemotherapy

• often used together.
• idea of spatial cooperation
• radiation is likely to be effective against a
  localized primary tumour, but it is ineffective
  against disseminated disease. Chemotherapy can
  cope with micrometastases, but not a large
  primary tumour (ie rectal cancer).
• Chemotherapy may be the primary treatment
  modality, and radiation is used to treat
  sanctuary sites ( ie small cell lung cancer).
• combination of toxicities can be limiting

41
Radiation and Surgery

• radiation often used as adjuvant to surgery
• breast
• colorectal
• lung
• radiation is frequently used in the neoadjuvant
  setting, to make an unresectable tumour
  resectable
• colorectal
• head and neck
• both can be used in the palliative setting
• bone mets
• brain mets

42
(No Transcript)
43
Radiation and Surgery

• Multiple issues when combining two modalities
• timing (ie colorectal cancer)
• fibrosis (ie breast cancer)
• functional result (ie anal canal cancer)
• cosmesis (ie breast or head and neck cancer)
• wound healing (any)
• pathology (ie colorectal cancer)
• radiation dose limitation (ie bone mets)
• delay in radiation treatment or surgery

44
(No Transcript)
45
How is radiation delivered?

• external beam radiotherapy (teletherapy).
• linear accelerators or radioactive isotope.
• brachytherapy
• intracavitary or interstitial implants.

46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
Immobilization
50
Simulation
51
Beam Shaping
52
Linear Accelerator
53
Cobalt Machine
54
How do we measure it?

• before high energy, used SED (skin erythema
  dose).
• 1928, unit of radiation exposure used was the
  Roentgen (R).
• now we use absorbed dose d?/dm where d? is mean
  energy imparted to a material of mass dm. Unit is
  Gy (1 Gy 1 Joule / kg).

55
Case 1 59 yr old female, postmenopausal

• Presented with lump in left breast, found in
  shower.
• Mammogram showed stellate lesion
• lumpectomy and AND
• pathology 2.5 cm Grade 2 infiltrating duct
  carcinoma, 1 margin positive, 0/10 nodes
  positive, no lymphovascular invasion, ER/PR
  positive
• referred back for re-resection no residual
  disease

56
Case 1 continued...

• referred to medical oncologist and put on TAM
• referred to radiation oncologist and offered
  radical radiation to breast
• risk of local recurrence without it is gt 30
• radiation decreases local recurrence to 6-7 .
• Lumpectomy radiation mastectomy.
• 4250 cGy / 16 fractions / 3 weeks 1 day
• can start 8-12 weeks after surgery
• radiation planning session
• daily in the building for 1 hr.

57
(No Transcript)
58
CT Planning
Xxxxxxxxxxxxx
xxxxxxxxxx
xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
xxxxxxxxxxxxxxxxx
xxxxxxxxxxxx
59
(No Transcript)
60
Case 1 continued...

• Acute toxicity
• fatigue
• skin changes erythema, moist and dry
  desquamation
• Chronic toxicity
• skin hyperpigmentation, telangiectasia, sun
  sensitivity
• breast parenchyma firm texture, radiation
  breast (erythema, swelling, tenderness ? rare
  mastectomy)
• rib brittleness
• pulmonary fibrosis
• cardiac events

61
Case 2 68 yr old male

• Presented with 6 months of rectal bleeding and 2
  months of diminished calibre stool. DRE showed
  barely palpable lesion, fixed.
• Colonoscopy showed lesion at 11 cm. Bx adenoca
• CXR -, CT abd/pelvis -, CEA ? at 12.
• Referred for neoadjuvant chemoradiation
• to make it resectable!!!
• 5FU for 1 cycle, then combined with radiation
• 4500 cGy / 25 fractions / 5 weeks to pelvis.

62
(No Transcript)
63
(No Transcript)
64
CT Plan
xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
xxxxxxxxxxxxxxxxxxxxxxxxxxx
65
(No Transcript)
66
(No Transcript)
67
Case 2 continued...

• 4 weeks after completing neoadjuvant therapy,
  lesion was decreased and mobile.
• CT showed smaller lesion.
• LAR at 7 weeks
• pathology 3 cm moderately differentiated
  adenocarcinoma, margins -, 0/10 lymph nodes , no
  lymphovascular invasion

68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
71
References

• Slides 5, 27, 42, 44, 48-53, from Radiation
  Oncology, Kasey Etreni MRT(T), Radiation
  Therapist, Northwestern Ontario Regional Cancer
  Centre, http//rope.nworcc.on.ca/What.pdf
• slides 6, 8-10, 14-19, 22-24, 26, 31, 32, 35,
  from Radiobiology for the Radiologist, Fourth
  Edition, Eric J. Hall, 1994
• slides 11, 57-59, 62-66, from Chris deFrancesco,
  Radiation Therapist, Juravinski Cancer Centre
