Lighting Safety

1
Lighting Safety
2
Agenda

• Accident
• Why lighting is important
• Temporary Lighting
• Foot Candles
• Emergency Lighting

3
Accident

• An employee of Majestic Marble was laying tile on
  the fifth floor when he walked in to a nearby
  room he fell between 35 and 40 ft down landing on
  metal ducting. He sustained a broken toe, a
  puncture wound to his left shin, he cut open his
  forehead and multiple abrasions

4
What was the Cause

• The room was improperly lit
• The worker did not have the required head lamp or
  flash light

5
Why is it Important?

• Increases Productivity
• Enhances Comfort
• Most importantly improves safety

6
Common Misconception

• People often think lighting is only a problem if
  it is too dark but lights that are too bright can
  also be dangerous
• Having to work in awkward positions because light
  is in your eyes can cause eyestrain and headaches
  making anything you are working on more dangerous

7
Temporary Lighting

• Extension Cords/ String Lighting
• Head Lamps/ Flash lights

8
Extension Cord/ String Lighting

• Extension cord with light bulbs attached at set
  intervals
• Each bulb must be covered with a plastic cage to
  protect bulbs from breaking
• Very important to be strung properly

9
Flash Lights/ Head Lamp

• This method is best when working in confined
  spaces
• Head lamps are better because leaves hands free

10
The Unit of Measurement

• Lighting is measured in foot candles
• One foot candle is the amount of light given off
  by one candle one foot away
• A Light meter is used to measure the number of
  foot candles

11
Common Foot Candle Applications

• Application
• General construction
• Underground/ Indoors
• Storage/ Loading Areas
• First aid Stations/ Offices
• Shops/ Plants

• Min. Foot Candles
• 5
• 5
• 30
• 10
• 10

12
Example

• This is an example of a living room that read 10
  foot candles.

13
Example 2

• This kitchen read about 25 foot candles

14
Example 3

• This grocery store read about 150 foot candles

15
Emergency Lighting

• Emergency illumination must be provided for a
  minimum of 1.5 hours in the event of failure of
  normal lighting.
• Must provide initial illumination of on average
  at least one foot-candle and a minimum at any
  point of 0.1 foot-candle measured along the path
  of egress at floor level.
• The maximum illumination at any one point can be
  no more than 40 times the minimum illumination at
  any one point to prevent excessively bright and
  dark spots

16
Emergency Light
17

• Lighting is often a neglected part of jobsite
  safety and is the cause of many fall incidents
• Safety accidents can be reduced simply by
  following the lighting safety regulations

18
Thank You!
